A hydrogen under-expanded jet released from a high-pressure vessel or equipment into the atmosphere through a 0.53 mm diameter orifice results in a sustained lifted flame for pressures above 4 MPa and flame blow-out at pressures below 3 MPa. Knowledge of whether the leaked hydrogen creates a sustained flame or is extinguished is an important issue for safety engineering. This study aims to clarify, in detail, a mechanism of flame stabilisation and blow-out depending on the spouting pressure. The model of flame stabilisation is derived using measurements and observations at the flame base location by means of high-speed schlieren images, laser diagnostics, and electrostatic probe techniques. The sustained stable flame originating from the 0.53 mm orifice is characterised by the existence of the spherical flame structures with a diameter of about 5 to 7 mm that appear one after another at the flame base and outside the streamlines of the hydrogen jet. As the spouting pressure reduces to 3.5 MPa, the sustained lifted flame becomes quasi-steady with higher fluctuations in amplitude of the flame base (lift-off height). In addition to that, flame structures are moving further from the hydrogen jet outlet, with a further decrease of spouting pressure leading to blow-out. The existence of spherical flame formations plays an important role in flame stabilisation. Based on the measurements of OH radicals using the PLIF method and ion currents, multiple flame surfaces were found to be folded in the flame structures. The hydrogen jet generates the vortex-like flow near its outer edge, creating flamelets upon ignition, ultimately forming the observed in the experiments spherical flame structures. Full article

The effects of the coolant pulsation and the plasma aerodynamic actuation (PAA) on the film cooling are herein explored via large eddy simulations. The electrohydrodynamic force derived from the PAA was solved through the phenomenological plasma model. The Strouhal number of the sinusoidal coolant pulsation and the averaged pulsation blowing ratio were 0.25 and 1.0, respectively. Comprehensive analyses were carried out on the time-averaged flow fields, and the results reveal that the pulsed cooling jet might cause a deeper penetration into the crossflow, and this phenomenon could be remarkably mitigated by the downward force of the PAA. Comparing steady film cooling to pulsed film cooling revealed a modest 15.1% reduction in efficiency, while the application of the dielectric barrier discharge plasma actuator (DBDPA) substantially enhanced the pulsed film cooling efficiency by 42.1%. Moreover, the counter-rotating vortex pair (CRVP) was enlarged and lifted off from the wall more poorly due to the coolant pulsation, and the PAA weakened the detrimental lift-off effect and entrainment of the CRVP. Then, the spatial–temporal development of the coherent structures was figured out by the alterations in the centerline temperature, reflecting the formation of the intermittent coherent structures rather than hairpin vortices due to the coolant pulsation, and their size and upcast behaviors were reduced by the PAA; thus, the turbulent integration of the coolant with the crossflow was suppressed fundamentally. Finally, the three-dimensional streamlines confirmed that the coherent structure dynamic behaviors were significantly regulated by the PAA for alleviating the adverse influences of the coolant pulsation. In summary, the PAA can effectively improve the pulsed film cooling efficiency by controlling the spatial–temporal development of the dominant coherent structures. Full article

Aerodynamic drag reduction is required with new stringent constraints on pollutant emissions and fuel efficiency of ground vehicles. In this context, active flow control is a promising approach to achieve this target. This study focuses on applying different flow control strategies on the square-back Ahmed model to reduce aerodynamic drag. A steady blowing jet, a synthetic jet and an unsteady jet are located at the back edges of the model as flow control devices. A numerical study based on the 3D WMLES simulation was performed to evaluate the drag reduction capabilities of these devices at different operating conditions. The results showed that a maximum aerodynamic drag reduction of 26.51% was achieved when using a steady blowing jet, and 17.27% with an unsteady jet. In contrast, the effect of the synthetic jet on the aerodynamic drag of the model is solely at high control frequencies. Full article

The main flow could be unsteady in flow fields of film cooling for several reasons such as flow interactions between the rotor and the stator in the turbine. Understanding the characteristics of the film-cooling flow with an unsteady flow is important in the design of gas turbines. The effects of 36-Hz pulsations in the main flow on the streamwise velocity distributions, turbulence statistics, and temperature fluctuations in the film-cooling flow from a cylindrical hole with an orientation angle are investigated by numerical methods. Large-eddy simulation (LES) results match the experimental data with an acceptable accuracy, whereas the Reynolds-averaged Navier–Stokes simulation (RANS) results show large deviations with the experimental data and the LES results. Under 36-Hz pulsations, the URANS results predict a weaker streamwise velocity of the coolant jet that blocks the main flow compared with the LES. With 36-Hz pulsations at the time-averaged blowing ratio of 0.5, u_rms, the root mean squared fluctuating velocity in the streamwise direction around the coolant core increased due to intensive mixing, and v_rms, the root mean squared fluctuating velocity in the wall-normal direction, increased along the trajectory of the injected coolant. Moreover, w_rms, the root mean squared fluctuating velocity in the spanwise direction, increased around the wall compared to those at a steady state. The dimensionless temperature fluctuations increased in the region of the core of the coolant compared with those at a steady state. When the orientation angle was 30°, the distribution of the results moved in the z-direction; however, the overall trend was similar to that of a simple angle. Full article

The lift of an aircraft can be effectively enhanced by circulation control (CC) technology at subsonic speeds, but the efficiency at transonic speeds is greatly decreased. The underlying mechanism of this phenomenon is not fully understood. In this study, Reynolds averaged Navier—Stokes simulation with $k-\omega$ shear stress transport model was utilized to investigate the mechanism of lift enhancement by CC in transonic flow. For validation, the numerical CC results were compared with the NASA experimental data obtained for transonic CC airfoil. Thereafter, the RAE2822 airfoil was modified with a Coanda surface. The lift enhancement effects of CC via steady blowing with different momentum coefficients were tested at $Ma=0.3$ and 0.8 at $\alpha =3^{\circ }$, and various fluid mechanics phenomena were investigated. The results indicate that the flow structure of the CC jet is insensitive to the incoming flow conditions because of the similarity to the local static pressure field around the trailing edge of the airfoil. Owing to the appearance of shockwaves on the airfoil surface in the transonic regime, the performance of the CC jet is restricted to the trailing edge of the airfoil. Transonic CC achieved a slight improvement in aerodynamic performance owing to a favorable shift in the shockwave pattern and accelerated flow in the separation region on the airfoil surfaces. Revealing the mechanism of lift enhancement of CC in the transonic regime can facilitate the rational design of new fluidic actuators with high activity and expand the potential applications of CC technology. Full article

Cavity flows occur in a wide range of low-speed applications (Mach number $\le 0.3$), such as aircraft wheel wells, ground transportation, and pipelines. In the current study, a steady jet is forced from a cavity leading edge at different momentum fluxes (0.11 kg/ms${}^2$, 0.44 kg/m·s${}^2$, and 0.96 kg/m·s${}^2$). The investigation was performed for an open cavity with length to depth ratio of 4 at the Reynolds number based on a cavity depth of approximately 50,000. Particle image velocimetry, surface oil flow visualisation, constant temperature anemometry, and pressure measurements were performed in this investigation. The aim of the jet blowing is to separate the cavity separated shear layer from the recirculation zone to reduce the cavity return flow, and hence stabilise the cavity separated shear layer. It was found that increasing the jet momentum flux causes an increase in the cavity return flow due to the increase in the thickness of the cavity separated shear layer. The study also found that the jet populates the separated shear layer with a large number of small-scale disturbances. These disturbances increase the broad band level of the pressure power spectra and Reynolds shear stress in the cavity separated shear layer. On the other hand, the jet disturbances make the shedding of the large vortical structures more intermittent. Full article

The present work investigates the impact of steady micro-jet blowing on the performance of a planar micro-nozzle designed for both liquid micro-thrusters and nitrogen cold-gas micro-resistojets. Two micro-injectors have been placed into the divergent region along the sidewalls, injecting a secondary flow of propellant perpendicularly to the wall where they have been located. The micro-jet actuator configuration is characterized by the dimensionless momentum coefficient c_μ. The best performance improvement is retrieved at the maximum c_μ for both water vapor ($\mathsf{\Delta }{\%}_{T,jet}$ = +22.6% and $\mathsf{\Delta }{\%}_{Isp,Tjet}$ = +2.9% at c_μ = 0.168) and nitrogen gaseous flows ($\mathsf{\Delta }{\%}_{T,jet}$ = +36.1% and $\mathsf{\Delta }{\%}_{Isp,Tjet}$ = +9.1% at c_μ = 0.297). The fields of the Mach number and the Schlieren computations, in combination with the streamline visualization, reveal the formation of two vortical structures in the proximity of secondary jets, which energize the core flow and enhance the expansion process downstream secondary jets. The compressible momentum thickness along the width-wise direction θ_xy in presence of secondary injection reduces as a function of c_μ. In particular, it becomes smaller than the one computed for the baseline configuration at c_μ > 0.1, decreasing up to about and -57% for the water vapor flow at c_μ = 0.168, and -64% for the nitrogen gaseous flow at c_μ = 0.297. Full article

In a triple-hole system comprising a primary hole and two sister holes, when the sister holes are positioned slightly downstream of the main hole under steady flow conditions, their jets generate an anti-counter-rotating vortex pair. Vortex interactions between the jets increase the effectiveness of adiabatic film cooling. In this study, a series of large-eddy simulations were conducted to understand how pulsations in the main flow affect film cooling in a triple hole. To understand the effects of pulsations on film cooling performance is important for better cooling design of the gas turbine engines. The numerical simulations were carried out on a flat plate geometry with a triple cylindrical hole system at 35° injection angle. The pulsations were approximately sinusoidal, and their effect on film cooling was investigated at several frequencies (2, 16, and 32 Hz) and Strouhal numbers (Sr = 0.1005, 0.8043, and 1.6085) at an average blowing ratio of 0.5. The results for the triple-hole system were compared with those for a single hole for the same amount of cooling air and the same cross-sectional area of the holes. Increasing the Strouhal number of the main flow decreased η in both systems. However, at each Strouhal number, η was higher in the triple hole. Furthermore, the triple-hole system was found to be better for film cooling than a single-hole system for higher values of the pulsation Strouhal number. Contours of time-averaged film cooling effectiveness and dimensionless temperature, instantaneous film cooling effectiveness contours on a test plate, mean velocity magnitude contours in the hole, and Q-contours for the triple holes under the application of pulsations to the flow were investigated. Full article

Flow separation control over a wall-mounted hump model was studied experimentally to assess the performance of fluidic oscillators (sweeping jet actuators). An array of fluidic oscillators was used to control flow separation. The results showed that the fluidic oscillators were able to achieve substantial control over the separated flow by increasing the upstream suction pressure and downstream pressure recovery. Using the data available in the literature, the performance of the fluidic oscillators was compared to other active flow control (AFC) methods such as steady blowing, steady suction, and zero-net-mass-flux (ZNMF) actuators. Several integral parameters, such as the inviscid flow comparison coefficient, pressure drag coefficient, and modified normal force coefficient, were used as quality metrics in the performance comparison of the AFC methods. These quality metrics indicated the superiority of the steady suction method, especially at lower excitation amplitudes that is followed by the fluidic oscillators, steady blowing, and the ZNMF actuators, respectively. An aerodynamic figure of merit (AFM) was also constructed using the integral parameters and AFC power usage. The AFM results revealed that, for this study, steady suction was the most efficient AFC method at lower excitation amplitudes. The steady suction loses its efficiency as the excitation amplitude increases, and the fluidic oscillators become the most efficient AFC method. Both the steady suction and the fluidic oscillators have an AFM > 1 for the range tested in this study, indicating that they provide a net benefit when the AFC power consumption is also considered. On the other hand, both the steady blowing and ZNMF actuators were found to be inefficient AFC methods (AFM < 1) for the current configuration. Although they improved the flow field by controlling flow separation, the power requirement was more than their benefit. Full article

The flow behavior of gas in compressible and incompressible systems was investigated at an ambient temperature in an air–water system and at an operating process temperature in the IronArc system, using computational fluid dynamics. The simulation results were verified by experiments in the air–water system and established empirical equations to enable reliable predictions of the penetration length. The simulations in the air–water system were found to replicate the experimental behavior using both the incompressible and compressible models, with only small deviations of 7–8%. A lower requirement for the modified Froude number of the gas blowing to produce a jetting behavior was also found. For gas blowing below the required modified Froude number, the results illustrate that the gas will form large pulsating bubbles instead of a steady jet, which causes the empirical equation calculations to severely underpredict the penetration length. The lower modified Froude number limit was also found to be system dependent and to have an approximate value of 300 for the studied IronArc system. For submerged blowing applications, it was found that it is important to ensure sufficiently high modified Froude numbers of the gas blowing. Then, the gas penetration length will remain stable as a jet and it will be possible to predict the values using empirical equations. Full article

Numerical study on flow separation control is conducted for a stalled airfoil with steady-blowing jet. Stall conditions relevant to a rotorcraft are of interest here. Both static and dynamic stalls are simulated with solving compressible Reynolds-averaged Navier-Stokes equations. It is expected that a jet flow, if it is applied properly, provides additional momentum in the boundary layer which is susceptible to flow separation at high angles of attack. The jet angle can influence on the augmentation of the flow momentum in the boundary layer which helps to delay or suppress the stall. Two distinct jet angles are selected to investigate the impact of the jet angle on the control authority. A tangential jet with a shallow jet angle to the surface is able to provide the additional momentum to the flow, whereas a chord-normal jet with a large jet angle simply averts the external flow. The tangential jet reduces the shape factor of the boundary layer, lowering the susceptibility to the flow separation and delaying both the static and dynamic stalls. Full article

The present paper reports the results of an experimental and computational investigation of flat plate film cooling jets discharged from three fan-shaped holes. Measurements have been carried out at near unity density ratio in a low-speed wind tunnel, at low inlet turbulence intensity, with blowing ratios (BR) of 1 and 2. Aerodynamic results have shown that the jet stays attached to the flat plate. Thermal measurements have revealed that film cooling effectiveness decreases downstream of the holes, and BR equal to 1 provides the best trade-off between cooling air consumption and thermal protection. Consequently, BR = 1 was selected for assessing the performance of different turbulence models, implemented in STAR-CCM+, according with the steady Reynolds-averaged Navier–Stokes (RANS) approach. Predictions from realizable k-ε (RKE), shear stress transport k-ω (SST KW) and Reynolds stress model (RSM) were compared against measurements of laterally averaged and centerline adiabatic effectiveness, as well as off-the-wall velocity maps and profiles of stress components. RSM provided the most accurate predictions. Full article

Active flow control of canonical laminar separation bubbles by steady and harmonic vortex generator jets (VGJs) was investigated using direct numerical simulations. Both control strategies were found to be effective in controlling the laminar boundary-layer separation. However, the present results indicate that using the same blowing amplitude, harmonic VGJs were more effective and efficient at reducing the separated region than the steady VGJs considering the fact that the harmonic VGJs use less momentum than the steady case. For steady VGJs, longitudinal structures forming immediately downstream of the injection location led to the formation of hairpin-type vortices, causing an earlier transition to turbulence. Symmetric hairpin vortices were shown to develop downstream of the forcing location for the harmonic VGJs, as well. However, the increased control effectiveness for harmonic VGJs’ flow control strategy is attributed to the fact that the shear-layer instability mechanism was exploited. As a result, disturbances introduced by VGJs were strongly amplified, leading to the development of large-scale coherent structures, which are very effective at increasing the momentum exchange, thus limiting the separated region. Full article
