Infrared imaging has gained considerable attention across diverse fields, including security, surveillance, and environmental monitoring. The need to minimize size, weight, power, and cost (SWaP-C) poses challenges for conventional optical systems like refractive lenses. Metalenses with subwavelength surface patterns have emerged as promising solutions to address these limitations. This review provides a comprehensive analysis of all-dielectric metalenses for long-wavelength infrared (LWIR) imaging applications, a critical spectral region for human detection and analytical applications (such as gas analysis). We examine the limitations of conventional infrared (IR) lens materials and highlight the performance advantages of LWIR metalenses. Key design principles, including chromatic and achromatic lens configurations, are discussed alongside their imaging performance. Additionally, we review advanced functionalities such as polarization control, multifocal capabilities, zoom, and reconfigurability. Theoretical performance limits and trade-offs are analyzed to provide insights into design optimization. We identify future challenges related to advanced design methods and fabrication techniques. LWIR metalenses can be expected to overcome the shortcomings of conventional LWIR lenses owing to meta-optics technologies, to achieve SWaP-C and advanced functionalities that cannot be achieved by conventional LWIR lenses. This review will guide researchers in academia and industry to develop LWIR metalenses to advance IR imaging technologies. Full article

High-precision hyperspectral remote sensing reflectance measurement of water bodies serves as the fundamental technical basis for accurately retrieving spatiotemporal distribution characteristics of water quality parameters, providing critical data support for dynamic monitoring of aquatic ecosystems and pollution source tracing. To address the critical issue of water surface glint interference significantly affecting measurement accuracy in aquatic remote sensing, this study innovatively developed a novel sensor system based on multi-field-of-view Kohler-polarization technology. The system incorporates three Kohler illumination lenses with exceptional surface uniformity exceeding 98.2%, effectively eliminating measurement errors caused by water surface brightness inhomogeneity. By integrating three core technologies—multi-field polarization measurement, skylight blocking, and high-precision radiometric calibration—into a single spectral measurement unit, the system achieves radiation measurement accuracy better than 3%, overcoming the limitations of traditional single-method glint suppression approaches. A glint removal efficiency (GRE) calculation model was established based on a skylight-blocked approach (SBA) and dual-band power function fitting to systematically evaluate glint suppression performance. Experimental results show that the system achieves GRE values of 93.1%, 84.9%, and 78.1% at ±3°, ±7°, and ±12° field-of-view angles, respectively, demonstrating that the ±3° configuration provides a 9.2% performance improvement over the ±7° configuration. Comparative analysis with dual-band power-law fitting reveals a GRE difference of 2.1% (93.1% vs. 95.2%) at ±3° field-of-view, while maintaining excellent consistency (ΔGRE < 3.2%) and goodness-of-fit (R² > 0.96) across all configurations. Shipborne experiments verified the system’s advantages in glint suppression (9.2%~15% improvement) and data reliability. This research provides crucial technical support for developing an integrated water remote sensing reflectance monitoring system combining in situ measurements, UAV platforms, and satellite observations, significantly enhancing the accuracy and reliability of ocean color remote sensing data. Full article

Multispectral imaging plays a key role in crop monitoring. A major challenge, however, is spectral band misalignment, which can hinder accurate plant health assessment by distorting the calculation of vegetation indices. This study presents a novel approach for short-range calibration of a multispectral camera, utilizing stereo vision for precise geometric correction of acquired images. By using multispectral camera lenses as binocular pairs, the sensor acquisition distance was estimated, and an alignment model was developed for distances ranging from 500 mm to 1500 mm. The approach relied on selecting the red band image as a reference, while the remaining bands were treated as moving images. The stereo camera calibration algorithm estimated the target distance, enabling the correction of band misalignment through previously developed models. The alignment models were applied to assess the health status of baby leaf crops (Lactuca sativa cv. Maverik) by analyzing spectral indices correlated with chlorophyll content. The results showed that the stereo vision approach used for distance estimation achieved high accuracy, with average reprojection errors of approximately 0.013 pixels (4.485 × 10⁻⁵ mm). Additionally, the proposed linear model was able to explain reasonably the effect of distance on alignment offsets. The overall performance of the proposed experimental alignment models was satisfactory, with offset errors on the bands less than 3 pixels. Despite the results being not yet sufficiently robust for a fully predictive model of chlorophyll content in plants, the analysis of vegetation indices demonstrated a clear distinction between healthy and unhealthy plants. Full article

Background and Objectives: In previous studies, we reported that the assessment of the cumulative thermal dose in the crystalline lens, conducted through computational modeling utilizing a supercomputer and the biothermal transport equation, exhibited a significant association with the incidence of nuclear cataracts. In this study, we have investigated the types of proteins that expressed underlying 35.0 °C (normal-temp) and 37.5 °C (warming-temp) by using the shotgun liquid chromatography (LC) with tandem mass spectrometry (MS/MS)-based global proteomic approach. Materials and Methods: We have discussed the changes in protein expression in warmed iHLEC-NY2 cells using Gene Ontology analysis and a label-free semiquantitative method based on spectral counting. Results: In iHLEC-NY2, 615 proteins were detected, including 307 (49.9%) present in both lenses cultured at normal-temp and warming-temp, 130 (21.1%) unique to the lens cultured at normal-temp, and 178 (29.0%) unique to the lens cultured at warming-temp. Furthermore, LC–MS/MS analysis showed that warming decreased the expression of actin, alpha cardiac muscle 1, actin-related protein 2, putative tubulin-like protein alpha-4B, ubiquitin carboxyl-terminal hydrolase 17-like protein 1, ubiquitin-ribosomal protein eL40 fusion protein, ribosome biogenesis protein BMS1 homolog, histone H2B type 1-M, and histone H2A.J. in iHLEC-NY2. Conclusions: The decreases in the specific protein levels of actin, tubulin, ubiquitin, ribosomes, and histones may be related to cataract development under warming conditions. This investigation could provide a critical framework for understanding the correlation between temperature dynamics and the development of nuclear cataracts. Full article

This study aims to build an optimal drug delivery system by manufacturing and evaluating a hydrogel contact lens using Tretinoin (ATRA) and protein nanoparticles to improve the drug delivery system as an ophthalmic medical contact lens. To evaluate the optical and physical properties of the manufactured lens, the spectral transmittance, refractive index, water content, contact angle, AFM, tensile strength, drug delivery, and antibacterial properties were analyzed. The contact lens was manufactured to contain ATRA and bovine serum albumin (BSA) in different ways, and the results confirmed that A, B, and C each had different physical properties. In particular, for Sample A, using the soak and release method and using ATRA solution in the contact lens with BSA added, the wettability was 55.94°, the tensile strength was 0.1491 kgf/mm², and drug delivery released 130.35 μm over 336 h, which was found to be superior to samples B and C. Therefore, the three hydrogel contact lenses compared in this study according to the addition method of ATRA and BSA can be used in various ways to build an optimal drug delivery system that is very useful as an ophthalmic medical lens. Full article

Objectives: This laboratory study aims to assess the effects of misaligning different trifocal intraocular lenses (IOLs) under varying spectral and corneal spherical aberration (SA) conditions. Methods: With an IOL metrology device under monochromatic and polychromatic conditions, the following models were studied: AT ELANA 841P, AT LISA Tri 839MP, FineVision HP POD F, Acrysof IQ PanOptix, and Tecnis Synergy ZFR00V. The SA was simulated using an aberration-free and average-SA cornea. The modulation transfer function (MTF) was measured at different pupil sizes for the on- and off-axis lens positions. Results: The IOLs exhibited varying responses to decentration up to 1 mm, showing the lowest impact in polychromatic light. The least affected was AT ELANA, with an MTF loss of 15.7% to 28.4% at 50 lp/mm across the studied conditions. It was followed by PanOptix and FineVision, with the MTF loss ranging from 19.1% to 36.0% and from 21.2% to 46.6%. AT LISA showed a more substantial reduction, i.e., 41.2% to 64.8%, but it was still lower than that of Synergy (51.1% to 78.8%). When decentration was induced at a 4.5 mm distance, its effect was more evident in conditions that were closer to each IOL’s SA correction. A tilt of 5° had a lesser impact than 1 mm decentration, with the effect being more severe at 4.5 mm. Conclusions: The off-axis position affects the optical quality of trifocal IOLs. Low- rather than high-SA-correcting trifocals perform better under misalignment. In polychromatic light, the impact of misalignment is less evident, suggesting a potential mitigating effect of chromatic aberration. Full article

Arbitrarily designed flat optics directly manipulate the light wavefront to reproduce complex optical functions, enabling more compact optical assemblies and microsystem integration. Phase-shifting micro-optical devices rely on locally tailoring the optical path length of the wavefront through binary or multilevel surface relief micro- and nanostructures. Considering the resolution and tolerances of the production processes and the optical properties of the substrate and coating materials is crucial for designing robust multilevel diffractive flat optics. In this work, we evaluate the impact of the grayscale laser lithography resolution and geometry constraints on the efficiency of surface-relief diffractive lenses, and we analyze the process parameter space that limit lens performance. We introduce a spectral bandwidth metric to help evaluate the broad-spectrum performance of different materials. We simulate and experimentally observe that the diffractive focusing is dominated by the periodic wavelength-dependent phase discontinuities arising in the profile transitions of multilevel diffractive lenses. Full article

Tungsten oxide (WO₃) electrochromic devices are obtaining increasing interest due to their color change and thermal regulation. However, most previous work focuses on the absorption or transmission spectra of materials, rather than the optical parameters evolution in full spectrum in the electrochromic processes. Herein, we developed a systematic protocol of ex situ methods to clarify the evolutions of subtle structure changes, Raman vibration modes, and optical parameters of WO₃ thin films in electrochromic processes as stimulated by dosage-dependent Li⁺ insertion. We obtained the below information by ex situ spectroscopic ellipsometry. (1) Layer-by-layer Li⁺ embedding mechanism demonstrated by individual film thickness analysis. (2) The details of its optical leap in the Brillouin zone in the full spectral. (3) The optical constants varied with the Li⁺ insertion in the ultraviolet, visible, and near-infrared bands, demonstrating the potential for applications in chip fabrication, deep-sea exploration, and optical measurements. (4) Simulated angular modulation laws of WO₃ films for full spectra in different Li⁺ insertion states. This ex situ method to study the optical properties of electrochromic devices are important for monitoring phase transition kinetics, the analysis of optical leaps, and the study of ion diffusion mechanisms and the stoichiometry-dependent changes in optical constants over the full spectral. This work shows that electrochromic films in Li⁺ surface permeation can be applied in the field of zoom lenses, optical phase modulators, and other precision optical components. Our work provides a new solution for the development of zoom lenses and a new application scenario for the application of electrochromic devices. Full article

Micro-electrocorticography (µECoG) electrodes have emerged to balance the trade-off between invasiveness and signal quality in brain recordings. However, its large-scale applicability is still hindered by a lack of comparative studies assessing the relationship between ECoG and traditional recording methods such as penetrating electrodes. This study aimed to compare somatosensory evoked potentials (SEPs) through the lenses of a µECoG and an intracortical microelectrode array (MEA). The electrodes were implanted in the pig’s primary somatosensory cortex, while SEPs were generated by applying electrical stimulation to the ulnar nerve. The SEP amplitude, signal-to-noise ratio (SNR), power spectral density (PSD), and correlation structure were analysed. Overall, SEPs resulting from MEA recordings had higher amplitudes and contained significantly more spectral power, especially at higher frequencies. However, the SNRs were similar between the interfaces. These results demonstrate the feasibility of using µECoG to decode SEPs with wide-range applications in physiology monitoring and brain–computer interfaces. Full article

The unique diffractive properties of gratings have made them essential in a wide range of applications, including spectral analysis, precision measurement, optical data storage, laser technology, and biomedical imaging. With advancements in micro- and nanotechnologies, the demand for more precise and efficient grating fabrication has increased. This review discusses the latest advancements in grating manufacturing techniques, particularly highlighting laser interference lithography, which excels in sub-beam generation through wavefront and amplitude division. Techniques such as Lloyd’s mirror configurations produce stable interference fringe fields for grating patterning in a single exposure. Orthogonal and non-orthogonal, two-axis Lloyd’s mirror interferometers have advanced the fabrication of two-dimensional gratings and large-area gratings, respectively, while laser interference combined with concave lenses enables the creation of concave gratings. Grating interferometry, utilizing optical interference principles, allows for highly precise measurements of minute displacements at the nanometer to sub-nanometer scale. This review also examines the application of grating interferometry in high-precision, absolute, and multi-degree-of-freedom measurement systems. Progress in grating fabrication has significantly advanced spectrometer technology, with integrated structures such as concave gratings, Fresnel gratings, and grating–microlens arrays driving the miniaturization of spectrometers and expanding their use in compact analytical instruments. Full article

In current biomedical and environmental detection, multi-modal optical imaging technology is playing an increasingly important role. By utilizing information from dimensions such as spectra and polarization, it reflects the detailed characteristics and material properties of the targets. However, as detection system performance becomes more complex, issues such as aberrations introduced by multilayered lenses, signal attenuation, decreased polarization sensitivity, and latency can no longer be ignored. These factors directly affect the assessment of image details, influencing subsequent analyses. In this paper, we propose a method for designing and optimizing spectrum-splitting filters that considers the wavefront aberration and transmittance of the multi-modal optical imaging system. The method of optimizing coating phases to minimize scalar phase aberrations while maximizing system transmission leads to substantially improved imaging performance. Simulation and experimental results demonstrate that the method can improve the imaging performance. The proposed approach has potential applications in fields such as biomedical field, multi-spectral, remote sensing and microscopy. Full article

Spectral confocal sensors are effective for measuring displacements. The core of the spectral confocal measurement system is a dispersive objective lens that uses optical dispersion to establish a one-to-one correspondence between the focusing position and wavelength, achieving high-resolution measurements in the longitudinal direction. Despite significant progress in dispersive objective lenses for spectral confocal sensor systems, challenges such as a limited dispersion range, high cost, and insufficient measurement accuracy persist. To expand the measurement range and improve the accuracy of the spectral confocal sensor, we designed a compact, long-axial dispersion objective lens. This lens has a simple structure that requires only six lens elements, two of which form cemented doublets. The system length is 58 mm, with a working distance of 46 ± 6 mm and a dispersion range of 12 mm within the wavelength range of 450–656 nm. The lens has an object-side numerical aperture (NA) of 0.22 and an image-side NA between 0.198 and 0.24, ensuring high light energy utilization. Finally, a spectral confocal measurement system was constructed based on the designed dispersive objective lens, and performance evaluation tests were conducted. The test results showed that the system achieved a resolution of 0.15 μm and a maximum linear error of ±0.7 μm, demonstrating high-precision measurement capabilities. The proposed lens design enables the development of more portable and cost-effective spectral confocal sensors. Full article

In the athermal and apochromatic design of optical systems, the distribution of lens’ optical powers and the selection of optical glass and structural materials are crucial. In this paper, an athermal and apochromatic design method is proposed for optical systems with a long focal length, large relative aperture, and wide spectrum. Firstly, a complex optical system composed of multiple lenses is equivalent to a two-component, single-lens system consisting of a replacement and an equivalent lens group. The optical glass for the replacement lens group is selected based on weight and the principle of material replacement in the 3D glass diagram, thus achieving an athermal and apochromatic design. Secondly, an athermal and apochromatic optical system with a focal length of 130 mm, an F-number of 2.0, a spectral range of 480 nm~800 nm, a field of view angle of 22°, and an operating temperature of −40 °C~+60 °C is designed. The modulation transfer function (MTF) at each field of view is greater than 0.6 at 50 lp/mm in the −40 °C~+60 °C temperature range, and the secondary spectrum aberration is 0.0056 mm, which is within the focal depth range of the optical system. Full article

Differences in field of view may occur during unmanned aerial remote sensing imaging applications with acousto-optic tunable filter (AOTF) spectral imagers using zoom lenses. These differences may stem from image size deformation caused by the zoom lens, image drift caused by AOTF wavelength switching, and drone platform jitter. However, they can be addressed using hyperspectral image registration. This article proposes a new coarse-to-fine remote sensing image registration framework based on feature and optical flow theory, comparing its performance with that of existing registration algorithms using the same dataset. The proposed method increases the structure similarity index by 5.2 times, reduces the root mean square error by 3.1 times, and increases the mutual information by 1.9 times. To meet the real-time processing requirements of the AOTF spectrometer in remote sensing, a development environment using VS2023+CUDA+OPENCV was established to improve the demons registration algorithm. The registration algorithm for the central processing unit+graphics processing unit (CPU+GPU) achieved an acceleration ratio of ~30 times compared to that of a CPU alone. Finally, the real-time registration effect of spectral data during flight was verified. The proposed method demonstrates that AOTF hyperspectral imagers can be used in real-time remote sensing applications on unmanned aerial vehicles. Full article

Time lenses can measure ultrafast signals but are based on single-mode fibers (SMFs). To develop multimode time lenses that are based on a four-wave mixing process, we must have full control of the nonlinear interaction between the modes. Specifically, we need to generate an idler from each mode without any cross-talk between the modes. Here, as a first step toward a multimode time lens, we study how stable a short pulse is traveling in a multimode fiber, and how pulses at different modes interact with each other. We utilize a single-mode-based time lens to measure the dynamics of these pulses in the time and spectral domains. We found that there is cross-talk between the modes and that the pulses are not stable and excite other modes, rather than staying in the same modal order. These findings indicate that developing a multimode time-lens may be more challenging than expected. Full article
