Using solid particulates as a heat transfer medium for concentrated solar power (CSP) systems has many advantages, positioning them as a superior option compared with conventional heat transfer media such as steam, oil, air, and molten salt. However, a critical imperative lies in the comprehensive evaluation of the properties of potential solid particulates intended for utilization under such extreme thermal conditions. This paper undertakes an exhaustive examination of both ambient and high-temperature thermophysical properties of four naturally occurring particulate materials, Riyadh white sand, Riyadh red sand, Saudi olivine sand, and US olivine sand, and one well-known engineered particulate material. The parameters under scrutiny encompass loose bulk density, tapped bulk density, real density, sintering temperature, and thermal conductivity. The results reveal that the theoretical density decreases with the increase in temperature. The bulk density of solid particulates depends strongly on the particulate size distribution, as well as on the compaction. The tapped bulk density was found to be larger than the loose density for all particulates, as expected. The sintering test proved that Riyadh white sand is sintered at the highest temperature and pressure, 1300 °C and 50 MPa, respectively. US olivine sand was solidified at 800 °C and melted at higher temperatures. This proves that US olivine sand is not suitable to be used as a thermal energy storage and heat transfer medium in high-temperature particle-based CSP systems. The experimental results of thermal diffusivity/conductivity reveal that, for all particulates, both properties decrease with the increase in temperature, and results up to 475.5 °C are reported. Full article

Advanced power cycles—such as the supercritical carbon dioxide (sCO₂) cycle—have the potential to reduce the levelized cost of energy (LCOE) of concentrated solar thermal power (CST) plants by significantly boosting their overall solar-to-electric efficiency. To successfully integrate these cycles into CST plants, the industry may need to transition away from liquid working fluids (e.g., synthetic oils and molten salts) to solid and/or gaseous heat transfer media, which are more stable at high temperatures. To address this challenge, this study investigates a novel rotating receiver–storage unit that could enable high-temperature CST plants. A validated numerical model is presented for the charging and discharging processes of the proposed design. It was found that with cast steel as the storage medium in the proposed design, it is possible to achieve >70% receiver efficiency for operation temperatures of 850–1000 K. The overall plant model shows this design is best for relatively small CST systems as modularized units of 10 m diameter (reaching an energy density around 80 kWh/m³), which can be used to drive a 5 MW_e sCO₂ CST plant. These findings suggest that such a design would have up to 9 h of storage and could be effectively employed as an efficient peaking plant. Full article

The hunt for a cleaner energy carrier leads us to consider a source that produces no toxic byproducts. One of the targeted alternatives in this approach is hydrogen energy, which, unfortunately, suffers from a lack of efficient storage media. Solid-state hydrogen absorption systems, such as lithium amide (LiNH₂) systems, may store up to 6.5 weight percent hydrogen. However, the temperature of hydrogenation and dehydrogenation is too high for practical use. Various molar ratios of LiNH₂ with sodium hydride (NaH) and potassium hydride (KH) have been explored in this paper. The temperature of hydrogenation for LiNH₂ combined with KH and NaH was found to be substantially lower than the temperature of individual LiNH₂. This lower temperature operation of both LiNH₂-NaH and LiNH₂-KH systems was investigated in depth, and the eutectic melting phenomenon was observed. Systematic thermal studies of this amide-hydride system in different compositions were carried out, which enabled the plotting of a pseudo-binary phase diagram. The occurrence of eutectic interaction increased atomic mobility, which resulted in the kinetic modification followed by an increase in the reactivity of two materials. For these eutectic compositions, i.e., 0.15LiNH₂-0.85NaH and 0.25LiNH₂-0.75KH, the lowest melting temperature was found to be 307 °C and 235 °C, respectively. Morphological studies were used to investigate and present the detailed mechanism linked with this phenomenon. Full article

Utilizing solid particles as a heat-transfer medium in concentrated solar power applications has gained growing attention lately. Unlike molten salts, solid particles offer many benefits, which include: high operating temperatures (greater than 1000 °C), a lack of freezing issues and corrosivity, abundant availability, high thermal energy storage capacity, a low cost, and applicability in direct irradiation. Comprehensive knowledge of thermophysical and optical properties of solid particles is essential to ensure an effective harnessing of solar energy. The most important considerations when selecting solid particles include: thermophysical and optical properties, thermal resistance, crack resistance, satisfactory health and safety risks, availability, and low cost. It is also imperative to consider optical and thermophysical characteristics that might change from what they were “as received” after cyclic heating for a long period. Therefore, the knowledge of thermal performance of particulate materials becomes significant before using them as a heat-transfer medium. In this study, some particulate materials were chosen to study their feasibilities as heat-transfer and storage media for a particle-based central receiver tower system. These particulate materials included white sand, red sand, ilmenite, and Carbobead CP. The candidate particulate materials were heated at high temperatures for 6 h and then cooled to room temperature. After that, cyclic heating was performed on the particulate materials for 500 h at 1200 °C. The optical properties were represented by weighted solar absorptance, and the thermophysical properties of the particulates were measured “as received” and after cyclic heating (aging). EDX and XRD were conducted to quantify the chemical composition and interpret the changes in appearance associated with the particulate materials after cyclic heating. The results showed a considerable agglomeration in all particulates except for white sand in the 6 h heating test, and high agglomeration in the ilmenite. A slight decrease in the optical properties in the white sand and Carbobead CP was found after the aging test. The specific heat was decreased for red and white sand. The EDX and XRD results for white sand and Carbobead CP showed chemical stability, indicating high durability and reliability. Full article

Thermal energy storage systems open up high potentials for improvements in efficiency and flexibility for power plant and industrial applications. Transferring such technologies as basis for thermal management concepts in battery-electric vehicles allow alternative ways for heating the interior and avoid range limitations during cold seasons. The idea of such concepts is to generate heat electrically (power-to-heat) parallel of charging the battery, store it efficiently and discharge heat at a defined temperature level. The successful application of such concepts requires two central prerequisites: higher systemic storage densities compared to today’s battery-powered PTC heaters as well as high charging and discharging powers. A promising approach for both requirements is based on solids as thermal energy storage. These allow during discharging an efficient heat transfer to the gaseous heat transfer medium (air) due to a wide range of geometric configurations with high specific surfaces and during charging high storage densities due to use of ceramic materials suitable for high operating temperatures. However, for such concepts suitable heating systems with small dimensions are needed, allowing an efficient and homogeneous heat transfer to the solid with high charging powers and high heating temperatures. An appropriate technology for this purpose is based on resistance heating wires integrated inside the channel shaped solids. These promise high storage densities due to operating wire temperature of up to 1300 °C and an efficient heat transport via radiation. Such electrically heated storage systems have been known for a long time for stationary applications, e.g., domestic storage heaters, but are new for mobile applications. For evaluation such concepts with regard to systemic storage and power density as well as to identify preferred configurations extensive investigations are necessary. For this purpose, transient models for the relevant heat transport mechanisms and the whole storage system were created. In order to allow time-efficient simulations studies for such an electrical heated storage system, a novel correlation for the effective radiation coefficient based on the Fourier Number was derived. This coefficient includes radiation effects and thermal conduction resistances and enables through its dimensionless parameterization the investigation of the charging process for a wide range of geometrical configurations. Based on application-typical specifications and the derived Fourier based correlation, extensive variation studies regarding the storage system were performed and evaluated with respect to systemic storage densities, heating wire surface loads and dimensions. For a favored design option selected here, maximum systemic storage densities of 201 Wh/kg at maximum heating wire surface loads of 4.6 W/cm² are achieved showing significant benefits compared to today’s battery powered PTC heaters. Additionally, for proofing and confirming the storage concept, a test rig was erected focusing experimental investigations on the charging process. For a first experimental setup-up including all relevant components, mean temperature-related deviations between the simulative and the experimental results of 4.1% were detected and storage temperatures of up to 870 °C were reached. The systematically performed results confirm the feasibility, high efficiency, thermodynamic synergies with geometric requirements during thermal discharging and the potential of the technology to reach higher systemic storage densities compared to current solutions. Full article

The use of phase change materials (PCM) for thermal energy storage (TES) is of great relevance, especially for the exploitation, in various ways, of the major ecological resource offered by solar energy. Unfortunately, the transition to the liquid state of PCM requires complex systems and limits their application. The goal of producing shape-stabilized phase change materials (SSPCM) is mainly pursued with the use of media capable of containing PCM during solid/liquid cycles. In this work, four cheap shape stabilizers were considered: sepiolite, diatomite, palygorskite and zeolite and two molten salts as PCM, for medium (MT) and high temperature (HT). The SSPCM, produced with an energy saving method, showed good stability and thermal storage performances. Diatomite reaches up to 400% wt. of encapsulated PCM, with a shape stabilization coefficient (SS_c) of 97.7%. Zeolite exhibits a SS_c of 87.3% with 348% wt. of HT-PCM. Sepiolite contains 330% wt. of MT-PCM with an SS_c of 82.7. Therefore, these materials show characteristics such that they can be efficiently used in thermal energy storage systems, both individually and inserted in a suitable matrix (for example a cementitious matrix). Full article

Magnesium hydride (MgH₂) has received significant attention due to its potential applications as solid-state hydrogen storage media for useful fuel cell applications. Even though MgH₂ possesses several attractive hydrogen storage properties, it cannot be utilized in fuel cell applications due to its high thermal stability and poor hydrogen uptake/release kinetics. High-energy ball milling, and mechanically-induced cold-rolling processes are the most common techniques to introduce severe plastic deformation and lattice imperfection in the Mg/MgH₂. Furthermore, using one or more catalytic agents is considered a practical solution to improve both the de-/rehydrogenation process of MgH₂.These treatments are usually dedicated to enhance its hydrogen storage properties and deduce its thermal stability. However, catalyzation of Mg/MgH₂ powders with a desired catalytic agent using ball milling process has shown some disadvantages due to the uncontrolled distribution of the agent particles in the MgH₂ powder matrix. The present study has been undertaken to employ a cold gas-dynamic spray process for catalyzing the fresh surfaces of mechanically-induced cold-rolled Mg ribbons with Ni powder particles. The starting Mg-rods were firstly heat treated and forged 200 times before cold rolling for 300 passes. The as-treated ribbons were then catalyzed by Ni particles, using cold gas-dynamic spray process. In this catalyzation approach, the Ni particles were carried by a stream of Ar gas via a high-velocity jet at a supersonic velocity. Accordingly, the pelted Ni particles penetrated the Mg-substrate ribbons, and hence created numerous micropores into the Mg, allowed the Ni particles to form a homogeneous network of catalytic active sites in Mg substrate. As the number of coating time increased to three times, the Ni concentration increased (5.28 wt.%), and this led to significant enhancement of the Mg-hydrogen storage capacity, as well as improving the de-/rehydrogenation kinetics. This is evidenced by the high value of hydrogen storage capacity (6.1 wt.% hydrogen) and the fast gas uptake kinetics (5.1 min) under moderate pressure (10 bar) and temperature (200 °C). The fabricated nanocomposite MgH₂/5.28 wt.% Ni strips have shown good dehydrogenation behavior, indicated by their capability to desorb 6.1 wt.% of hydrogen gas within 11 min at 200 °C under 200 mbar of hydrogen pressure. Moreover, this system possessed long cycle-life-time, which extended to 350 h with a minimal degradation in the storage and kinetics behavior. Full article

The depletion of fossil fuels and rising global warming challenges encourage to find safe and viable energy storage and delivery technologies. Hydrogen is a clean, efficient energy carrier in various mobile fuel-cell applications and owned no adverse effects on the environment and human health. However, hydrogen storage is considered a bottleneck problem for the progress of the hydrogen economy. Liquid-organic hydrogen carriers (LOHCs) are organic substances in liquid or semi-solid states that store hydrogen by catalytic hydrogenation and dehydrogenation processes over multiple cycles and may support a future hydrogen economy. Remarkably, hydrogen storage in LOHC systems has attracted dramatically more attention than conventional storage systems, such as high-pressure compression, liquefaction, and absorption/adsorption techniques. Potential LOHC media must provide fully reversible hydrogen storage via catalytic processes, thermal stability, low melting points, favorable hydrogenation thermodynamics and kinetics, large-scale availability, and compatibility with current fuel energy infrastructure to practically employ these molecules in various applications. In this review, we present various considerable aspects for the development of ideal LOHC systems. We highlight the recent progress of LOHC candidates and their catalytic approach, as well as briefly discuss the theoretical insights for understanding the reaction mechanism. Full article

The integration of thermal energy storage systems enables improvements in efficiency and flexibility for numerous applications in power plants and industrial processes. By transferring such technologies to the transport sector, existing potentials can be used for thermal management concepts and new ways of providing heat can be developed. For this purpose, technology developments for solid media high-temperature thermal energy storage systems are taking place for battery-electric vehicles as part of the DLR Next Generation Car (NGC) project. The idea of such concepts is to generate heat electrically, to store it efficiently and to discharge it through a bypass concept at a defined temperature level. The decisive criterion when using such solutions are high systemic storage densities which can be achieved by storing heat at a high temperature level. However, when storing high temperature heat increasing dimensions for thermal insulation are required, leading to limitations in the achievable systemic storage density. To overcome such limitations, an alternative thermal insulation concept is presented. Up to now, conventional thermal insulations are based on sheathing the storage containment with efficient thermal insulation materials, whereby the thickness results from safety restrictions with regard to the permitted maximum surface temperature. In contrast, the alternative concept enables through the integration of the external bypass into the thermal insulation systemic advantages during the charging and discharging period. During discharging, previously unused amounts of heat or heat losses within the thermal insulation can be integrated into the bypass path and the insulation thickness can be reduced during loading through active cooling. Using detailed models for both the reference and the alternative thermal insulation concept, systematic simulation studies were conducted on the relevant influencing variables and on the basis of defined specifications. The results confirm that the alternative thermal insulation concept achieves significant improvements in systemic storage densities compared to previous solutions and high potentials to overcome existing limitations. Full article

The construction and maintenance of building stock is responsible for approximately 36% of all CO₂ emissions in the European Union. One of the possibilities of how to achieve high energy-efficient and decarbonized building stock is the integration of renewable energy sources (RES) in building energy systems that contain efficient energy storage capacity. Phase Change Materials (PCMs) are latent heat storage media with a high potential of integration in building structures and technical systems. Their solid-liquid transition is specifically utilized for thermal energy storage in building applications. The typically quite old example is the use of ice that serves as long-term storage of cold. Large pieces of ice cut in winter were stored in heavily insulated spaces and prepared for cooling of food or beverages in summer. In the contemporary use of the principle, the PCMs for building applications and tested in this study must have a melting range close to the desired temperature in the occupied rooms. As the PCMs need to be encapsulated, several types of metal containers have been developed and tested for their thermal conductivity and resistance to mechanical damage, which enhances the performance of these so-called latent heat thermal energy storage (LHTES) systems. Long-term compatibility of metals with PCMs depends, i.e., on the elimination of an undesirable interaction between the metal and the specific PCM. Heat storage medium must be reliably sealed in a metal container, especially if the LHTES is integrated into systems where PCM leaks can negatively affect human health (e.g., domestic hot water tanks). The aim of this study is to evaluate the interactions between the selected commercially available organic (Linpar 17 and 1820) and inorganic (Rubitherm SP22 and SP25) PCMs and metals widely used for PCM encapsulation (aluminum, brass, carbon steel, and copper). The evaluation is based on the calculation of the corrosion rate (CR), and the gravimetric method is used for the determination of the weight variations of the metal samples. The results show good compatibility for all metals with organic PCMs, which is demonstrated by a mass loss as low as 2.1 mg in case of carbon steel immersed in Linpar 1820 for 12 weeks. The exposure of metals to organic PCMs also did not cause any visual changes on the surface except for darker stains, and tarnishing occurred on the copper samples. More pronounced changes were observed in metal samples immersed in inorganic PCMs. The highest CR values were calculated for carbon steel exposed to inorganic PCM Rubitherm SP25 (up to 13.897 mg·cm⁻²·year⁻¹). The conclusion of the study is that aluminum is the most suitable container material for the tested PCMs as it shows the lowest mass loss and minimal visual changes on the surface after prolonged exposure to the selected PCMs. Full article

Efficient systems for high performance buildings are required to improve the integration of renewable energy sources and to reduce primary energy consumption from fossil fuels. This paper is focused on sensible heat thermal energy storage (SHTES) systems using solid media and numerical simulation of their transient behavior using the finite element method (FEM). Unlike other papers in the literature, the numerical model and simulation approach has simultaneously taken into consideration various aspects: thermal properties at high temperature, the actual geometry of the repeated storage element and the actual storage cycle adopted. High-performance thermal storage materials from the literatures have been tested and used here as reference benchmarks. Other materials tested are lightweight concretes with recycled aggregates and a geopolymer concrete. Their thermal properties have been measured and used as inputs in the numerical model to preliminarily evaluate their application in thermal storage. The analysis carried out can also be used to optimize the storage system, in terms of thermal properties required to the storage material. The results showed a significant influence of the thermal properties on the performances of the storage elements. Simulation results have provided information for further scale-up from a single differential storage element to the entire module as a function of material thermal properties. Full article
