We tested a scanning electron microscope equipped with the newly developed Unity-BEX detector (SEM-BEX) system to study thirty-nine samples of the testate amoeba Difflugia. This produces fast single-scan backscattered (BSE) and combined elemental X-ray maps of selected areas, resulting in high-resolution data-rich composite colour X-ray and combined BSE maps. Using a suitably user-defined elemental X-ray colour palette, minerals such as orthoclase, albite, quartz and mica were highlighted in blue, purple, magenta and green, respectively. Imaging was faster than comparable standard energy dispersive X-ray (EDX) analysis, of high quality, and did not suffer from problems associated with the analysis of rough surfaces by EDX, such as shadowing effects or working distance versus X-ray yield artifacts. In addition, we utilised the AZtecMatch v.6.1 software package to test its utility in identifying the mineral phases present on the Difflugia tests. Significantly, it was able to identify many minerals present but would require some further development due to the small size/thinness of many of the minerals analysed. The latter would also be further improved by the development of a bespoke mineral library based on actual collected X-ray data rather than based simply on stoichiometry. The investigation illustrates that in the case of the current material, minerals are preferentially selected and arranged on the test based upon their mineralogy and size, and likely upon inherent properties such as structural strength/flexibility and specific gravity. As with previous studies, mineral usage is ultimately controlled by source availability and therefore may be of limited taxonomic significance, although of value in areas such as palaeoenvironmental reconstruction. Full article

Excluding rough areas with surface rocks and craters is critical for the safety of landing missions, such as China’s Chang’e-7 mission, in the permanently shadowed region (PSR) of the lunar south pole. Binned digital elevation model (DEM) data can describe the undulating surface, but the DEM data can hardly detect surface rocks because of median-averaging. High-resolution images from a synthetic aperture radar (SAR) can be used to map discrete rocks and small craters according to their strong backscattering. This study utilizes the You Only Look Once version 7 (YOLOv7) tool to detect varying-sized craters in SAR images. It also employs the Markov random field (MRF) algorithm to identify surface rocks, which are usually difficult to detect in DEM data. The results are validated by optical images and DEM data in non-PSR. With the assistance of the DEM data, regions with slopes larger than 10° are excluded. YOLOv7 and MRF are applied to detect craters and rocky surfaces and exclude regions with steep slopes in the PSRs of craters Shoemaker, Slater, and Shackleton, respectively. This study proves SAR images are feasible in the selection of landing sites in the PSRs for future missions. Full article

Object detection in remote sensing images (RSIs) has become crucial in recent years. However, researchers often prioritize detecting small objects, neglecting medium- to large-sized ones. Moreover, detecting objects hidden in shadows is challenging. Additionally, most detectors have extensive parameters, leading to higher hardware costs. To address these issues, this paper proposes a multi-scale and high-precision lightweight object detector named MHLDet. Firstly, we integrated the SimAM attention mechanism into the backbone and constructed a new feature-extraction module called validity-neat feature extract (VNFE). This module captures more feature information while simultaneously reducing the number of parameters. Secondly, we propose an improved spatial pyramid pooling model, named SPPE, to integrate multi-scale feature information better, enhancing the model to detect multi-scale objects. Finally, this paper introduces the convolution aggregation crosslayer (CACL) into the network. This module can reduce the size of the feature map and enhance the ability to fuse context information, thereby obtaining a feature map with more semantic information. We performed evaluation experiments on both the SIMD dataset and the UCAS-AOD dataset. Compared to other methods, our approach achieved the highest detection accuracy. Furthermore, it reduced the number of parameters by 12.7% compared to YOLOv7-Tiny. The experimental results illustrated that our proposed method is more lightweight and exhibits superior detection accuracy compared to other lightweight models. Full article

This article presents a system for recording 3D point clouds of riverbanks with a mobile lidar mounted on an uncrewed water vehicle. The focus is on the orientation of the platform and the lidar sensor. Rivers are areas where the conditions for highly accurate GNSS can be sub-optimal due to multipath effects from the water and shadowing effects by bridges, steep valleys, trees, or other objects at the riverbanks. Furthermore, a small measurement platform may have an effect on the accuracy of orientations measured by an IMU; for instance, caused by electromagnetic fields emitted by the boat rotors, the lidar, and other hardware decreasing IMU accuracy. As an alternative, we use exterior orientation parameters obtained by photogrammetric methods from the images of a camera on the boat capturing the riverbanks in time-lapse mode. Using control points and tie points on the riverbanks enables georeferenced position and orientation determination from the image data, which can then be used to transform the lidar data into a global coordinate system. The main influences on the accuracy of the camera orientations are the distance to the riverbanks, the size of the banks, and the amount of vegetation on them. Moreover, the quality of the camera orientation-based lidar point cloud also depends on the time synchronization of camera and lidar. The paper describes the data processing steps for the geometric lidar–camera integration and delivers a validation of the accuracy potential. For quality assessment of a point cloud acquired with the described method, a comparison with terrestrial laser scanning has been carried out. Full article

Off-road navigation in forest environments is a challenging problem in field robotics. Rovers are required to infer their traversability over a priori unknown and dynamically changing forest terrain using noisy onboard navigation sensors. The problem is compounded for small-sized rovers, such as that of a swarm. Their size-proportional low-viewpoint affords them a restricted view for navigation, which may be partially occluded by forest vegetation. Hand-crafted features, typically employed for terrain traversability analysis, are often brittle and may fail to discriminate obstacles in varying lighting and weather conditions. We design a low-cost navigation system tailored for small-sized forest rovers using self-learned features. The MobileNet-V1 and MobileNet-V2 models, trained following an end-to-end learning approach, are deployed to steer a mobile platform, with a human-in-the-loop, towards traversable paths while avoiding obstacles. Receiving a 128 × 96 pixel RGB image from a monocular camera as input, the algorithm running on a Raspberry Pi 4, exhibited robustness to motion blur, low lighting, shadows and high-contrast lighting conditions. It was able to successfully navigate a total of over 3 km of real-world forest terrain comprising shrubs, dense bushes, tall grass, fallen branches, fallen tree trunks, and standing trees, in over five different weather conditions and four different times of day. Full article

Shadows are widely used in the tracking of moving targets by video synthetic aperture radar (video SAR). However, they always appear in groups in video SAR images. In such cases, track effects produced by existing single-target tracking methods are no longer satisfactory. To this end, an effective way to obtain the capability of multiple target tracking (MTT) is in urgent demand. Note that tracking by detection (TBD) for MTT in optical images has achieved great success. However, TBD cannot be utilized in video SAR MTT directly. The reasons for this is that shadows of moving target are quite different from in video SAR image than optical images as they are time-varying and their pixel sizes are small. The aforementioned characteristics make shadows in video SAR images hard to detect in the process of TBD and lead to numerous matching errors in the data association process, which greatly affects the final tracking performance. Aiming at the above two problems, in this paper, we propose a multiple target tracking method based on TBD and the Siamese network. Specifically, to improve the detection accuracy, the multi-scale Faster-RCNN is first proposed to detect the shadows of moving targets. Meanwhile, dimension clusters are used to accelerate the convergence speed of the model in the training process as well as to obtain better network weights. Then, SiamNet is proposed for data association to reduce matching errors. Finally, we apply a Kalman filter to update the tracking results. The experimental results on two real video SAR datasets demonstrate that the proposed method outperforms other state-of-art methods, and the ablation experiment verifies the effectiveness of multi-scale Faster-RCNN and SimaNet. Full article

Cloud recognition is a basic task in ground meteorological observation. It is of great significance to accurately identify cloud types from long-time-series satellite cloud images for improving the reliability and accuracy of weather forecasting. However, different from ground-based cloud images with a small observation range and easy operation, satellite cloud images have a wider cloud coverage area and contain more surface features. Hence, it is difficult to effectively extract the structural shape, area size, contour shape, hue, shadow and texture of clouds through traditional deep learning methods. In order to analyze the regional cloud type characteristics effectively, we construct a China region meteorological satellite cloud image dataset named CRMSCD, which consists of nine cloud types and the clear sky (cloudless). In this paper, we propose a novel neural network model, UATNet, which can realize the pixel-level classification of meteorological satellite cloud images. Our model efficiently integrates the spatial and multi-channel information of clouds. Specifically, several transformer blocks with modified self-attention computation (swin transformer blocks) and patch merging operations are used to build a hierarchical transformer, and spatial displacement is introduced to construct long-distance cross-window connections. In addition, we introduce a Channel Cross fusion with Transformer (CCT) to guide the multi-scale channel fusion, and design an Attention-based Squeeze and Excitation (ASE) to effectively connect the fused multi-scale channel information to the decoder features. The experimental results demonstrate that the proposed model achieved 82.33% PA, 67.79% MPA, 54.51% MIoU and 70.96% FWIoU on CRMSCD. Compared with the existing models, our method produces more precise segmentation performance, which demonstrates its superiority on meteorological satellite cloud recognition tasks. Full article

The droplet deformation in dispersing units of high-pressure homogenizers (HPH) is examined experimentally and numerically. Due to the small size of common homogenizer nozzles, the visual analysis of the transient droplet generation is usually not possible. Therefore, a scaled setup was used. The droplet deformation was determined quantitatively by using a shadow imaging technique. It is shown that the influence of transient stresses on the droplets caused by laminar extensional flow upstream the orifice is highly relevant for the droplet breakup behind the nozzle. Classical approaches based on an equilibrium assumption on the other side are not adequate to explain the observed droplet distributions. Based on the experimental results, a relationship from the literature with numerical simulations adopting different models are used to determine the transient droplet deformation during transition through orifices. It is shown that numerical and experimental results are in fairly good agreement at limited settings. It can be concluded that a scaled apparatus is well suited to estimate the transient droplet formation up to the outlet of the orifice. Full article

Offshore drilling rigs are the foundation of oil and gas exploitation in water areas. Their spatial and temporal distribution, state attributes and other information directly reflect the exploitation level of regional oil and gas resources. Therefore, it is very important to build an automatic detecting method for offshore drilling rigs with good performance to accurately capture the temporal and spatial distribution and state of oil and gas exploitation activities. At present, there are two main groups of methods for offshore drilling rigs: invariant feature-based methods and nighttime firelight-based methods. Methods based on invariant location are more subjective in terms of their parameter settings and require intensive computation. Nighttime light-based methods are largely unable to identify offshore drilling rigs without associated waste gas ignition. Furthermore, multiple offshore drilling rigs in close proximity to one another cannot be effectively distinguished with low spatial resolution imagery. To address these shortcomings, we propose a new method for the automatic identification of offshore drilling rigs based on Landsat-7 ETM+ images from 2018 to 2019, taking the Caspian Sea as the research area. We build a nominal annual cloud and cloud shadow-free Normalized Difference Water Index (NDWI) composite by designing an optimal NDWI compositing method based of the influence of cloud and cloud shadow on the NDWI values of water, bare land (island) and offshore drilling rigs. The classification of these objects is simultaneously done during the compositing process, with the following rules: water body (Max_NDWI > 0.55), bare land (island) (Min_NDWI < −0.05) and offshore drilling rig (0 < Mean_NDWI < 0.4). A threshold segmentation and postprocessing were carried out to further refine the results. Using this method, 497 offshore platforms were automatically identified using a nominal annual cloud and cloud shadow-free NDWI composite image and Google Earth Engine. Validation using Sentinel-2 Multispectral Imager (MSI) and Google Earth images demonstrated that the correct rate of offshore drilling rig detection in the Caspian Sea is 90.2%, the missing judgment rate is 5.3% and the wrong judgment rate is 4.5%, proving the performance of the proposed method. This method can be used to identify offshore drilling rigs within a large water surface area relatively quickly, which is of great significance for exploring the exploitation status of offshore oil and gas resources. It can also be extended to finer spatial resolution optical remote sensing images; thus small-size drilling rigs can be effectively detected. Full article

The lensless on-chip microscope is an emerging technology in the recent decade that can realize the imaging and analysis of biological samples with a wide field-of-view without huge optical devices and any lenses. Because of its small size, low cost, and being easy to hold and operate, it can be used as an alternative tool for large microscopes in resource-poor or remote areas, which is of great significance for the diagnosis, treatment, and prevention of diseases. To improve the low-resolution characteristics of the existing lensless shadow imaging systems and to meet the high-resolution needs of point-of-care testing, here, we propose a high-precision on-chip microscope based on in-line holographic technology. We demonstrated the ability of the iterative phase recovery algorithm to recover sample information and evaluated it with image quality evaluation algorithms with or without reference. The results showed that the resolution of the holographic image after iterative phase recovery is 1.41 times that of traditional shadow imaging. Moreover, we used machine learning tools to identify and count the mixed samples of mouse ascites tumor cells and micro-particles that were iterative phase recovered. The results showed that the on-chip cell counter had high-precision counting characteristics as compared with manual counting of the microscope reference image. Therefore, the proposed high-precision lensless microscope on a chip based on in-line holographic imaging provides one promising solution for future point-of-care testing (POCT). Full article

The problem of secondary atomization of droplets is crucial for many applications. In high-speed flows, fine atomization usually takes place, and the breakup of small droplets determines the final products of atomization. An experimental study of deformation and breakup of 15–60 µm size droplets in an accelerated flow inside a converging–diverging nozzle is considered in the paper. Particle image velocimetry and shadow photography were employed in the experiments. Results of gas and liquid phase flow measurements and visualization are presented and analyzed, including gas and droplets’ velocity, shape and size distributions of droplets. Weber numbers for droplets’ breakup are reported. For those small droplets at low Weber numbers, the presence of well-known droplets’ breakup morphology is confirmed, and rare “pulling” breakup mode is detected and qualitatively described. For the “pulling” breakup mode, a consideration, explaining its development in smaller droplets through shear stress effect, is provided. Full article

The $(k,n)$-threshold Secret Image Sharing scheme (SISS) is a solution to image protection. However, the shadow images generated by traditional SISS are noise-like, easily arousing deep suspicions, so that it is significant to generate meaningful shadow images. One solution is to embed the shadow images into meaningful natural images and visual quality should be considered first. Limited by embedding rate, the existing schemes have made concessions in size and visual quality of shadow images, and few of them take the ability of anti-steganalysis into consideration. In this paper, a meaningful SISS that is based on Natural Steganography (MSISS-NS) is proposed. The secret image is firstly divided into n small-sized shadow images with Chinese Reminder Theorem, which are then embedded into RAW images to simulate the images with higher $ISO$ parameters with NS. In MSISS-NS, the visual quality of shadow images is improved significantly. Additionally, as the payload of cover images with NS is larger than the size of small-sized shadow images, the scheme performs well not only in visual camouflage, but also in other aspects, like lossless recovery, no pixel expansion, and resisting steganalysis. Full article

A secret image sharing (SIS) scheme inserts a secret message into shadow images in a way that if shadow images are combined in a specific way, the secret image can be recovered. A 2-out-of-2 sharing digital image scheme (SDIS) adopts a color palette to share a digital color secret image into two shadow images, and the secret image can be recovered from two shadow images, while any one shadow image has no information about the secret image. This 2-out-of-2 SDIS may keep the shadow size small because by using a color palette, and thus has advantage of reducing storage. However, the previous works on SDIS are just 2-out-of-2 scheme and have limited functions. In this paper, we take the lead to study a general n-out-of-n SDIS which can be applied on more than two shadow. The proposed SDIS is implemented on the basis of 2-out-of-2 SDIS. Our main contribution has the higher contrast of binary meaningful shadow and the larger region in color shadows revealing cover image when compared with previous 2-out-of-2 SDISs. Meanwhile, our SDIS is resistant to colluder attack. Full article

Cloud-free remote sensing images are required for many applications, such as land cover classification, land surface temperature retrieval and agricultural-drought monitoring. Cloud cover in remote sensing images can be pervasive, dynamic and often unavoidable. Current techniques of cloud removal for the VNIR (visible and near-infrared) bands still encounters the problem of pixel values estimated for the cloudy area incomparable and inconsistent with the cloud-free region in the target image. In this paper, we proposed an efficient approach to remove thick clouds and their shadows in VNIR bands using multi-temporal images with good maintenance of DN (digital number) value consistency. We constructed the spectral similarity between the target image and reference one for DN value estimation of the cloudy pixels. The information reconstruction was done with 10 neighboring cloud-free pair-pixels with the highest similarity over a small window centering the cloudy pixel between target and reference images. Four Landsat5 TM images around Nanjing city of Jiangsu Province in Eastern China were used to validate the approach over four representative surface patterns (mountain, plain, water and city) for diverse sizes of cloud cover. Comparison with the conventional approaches indicates high accuracy of the approach in cloud removal for the VNIR bands. The approach was applied to the Landsat8 OLI (Operational Land Imager) image on 29 April 2016 in Nanjing area using two reference images. Very good consistency was achieved in the resulted images, which confirms that the proposed approach could be served as an alternative for cloud removal in the VNIR bands using multi-temporal images. Full article

Thermokarst waterbodies caused by permafrost thawing and degradation are ubiquitous in many subarctic and Arctic regions. They are globally important components of the biogeochemical carbon cycle and have potential feedback effects on climate. These northern waters are mostly small lakes and ponds, and although they may be mapped using very high-resolution satellites or aerial photography, these approaches are generally not suitable for monitoring purposes, due to the cost and limited availability of such images. In this study we evaluated the potential use of widely available high-resolution imagery from Sentinel-2 (S2) for the characterization of the spectral reflectance of thermokarst lakes and ponds. Specifically, we aimed to define the minimum lake area that could be reliably imaged, and to identify challenges and solutions for remote sensing of such waters in the future. The study was conducted in subarctic Canada, in the vicinity of Whapmagoostui-Kuujjuarapik (Nunavik, Québec), an area in the sporadic permafrost zone with numerous thermokarst waterbodies that vary greatly in size. Ground truthing lake reflectance data were collected using an Unmanned Aerial System (UAS) fitted with a multispectral camera that collected images at 13 cm resolution. The results were compared with reflectance from Sentinel-2 images, and the effect of lake area on the reflectance response was assessed. Our results show that Sentinel-2 imagery was suitable for waterbodies larger than 350 m² once their boundaries were defined, which in the two test sites would allow monitoring from 11% to 30% of the waterbodies and 73% to 85% of the total lake area. Challenges for remote sensing of small lakes include the confounding effects of water reflection (both direct radiation and diffuse), wind and shadow. Given the small threshold area and frequent revisit time, Sentinel-2 provides a valuable approach towards the continuous monitoring of waterbodies, including ponds and small lakes such as those found in thermokarst landscapes. UASs provide a complementary approach for ground truthing and boundary definition. Full article
