The present work is a relevant advance in the validation of the incremental step loading technique (ASTM F1624 standard) when applied to Small Punch tests (SPT) for the threshold load determination of medium- and high-strength steels in aggressive environments, as a novel alternative to conventional time-consuming tests under constant load. It completes previous works by the authors on this topic, extending a methodology to estimate the threshold stress from SPT tests in aggressive environments, covering the whole range of hardness marked by ASTM F1624 as the main goal. This is achieved by calibrating a model of the material’s hardness by the use of a coefficient in function of it. For this purpose, four medium- and high-strength steels of 33, 35, 50 and 60 HRC (Hardness Rockwell C) are exposed to three different cathodic polarization hydrogen embrittlement environments of 1, 5 and 10 mA/cm² in 1N H₂SO₄ acid electrolyte connected to a platinum anode. Threshold stresses in these circumstances are obtained by uniaxial specimens following ASTM F1624 and compared to their homologous threshold loads obtained by Small Punch tests according to the authors’ original methodology proposal. Finally, the aforementioned model, consisting of a correlation based on composing an elastic and a plastic part, is calibrated for a hardness ranging 33–60 HRC, this being the main original contribution of this work; the elastic part is dependent just on the elastic-to-plastic transition SPT load, while the plastic part is ruled by a material hardness-dependent coefficient. This technique supposes an advance in engineering tools, due to its applicability in situations of material shortage, such as in-service components, welded joints, local areas, complex geometries, small thicknesses, etc., often present in aerospace, automotive or oil–gas, among others. Full article

The utilization of micro-sample testing has demonstrated its effectiveness in conducting quantitative research on mechanical properties, damage evolutions and fracture features. For in-service equipment, millimicron sampling allows for non-destructive testing and analysis of mechanical performance evolution during operation. This paper presents a comparative study of the miniature uniaxial tensile test (MUTT) and small punch test (SPT) by experimental and finite element methods. As a comparison, the standard conventional-size tensile tests were also carried out. Detailed analyses of the elastoplastic behaviors and damage evolutions of MUTT and SPT were presented, followed by an application case illustrating the characterization of hydrogen embrittlement sensitivity based on MUTT and SPT. An inverse finite element modeling method of load–displacement curve reproduction was used to calibrate the variations of damage parameters of hydrogen-charged MUTT and SPT specimens. Hydrogen embrittlement (HE) indexes were determined by using different calculation methods. The results reveal that the HE sensitivity estimated by MUTT is higher than that measured by SPT, which is related to the different deformation processes and strain rates of the two testing methods. Full article

This comprehensive review examines the phenomena of stress corrosion cracking (SCC) and chloride-induced stress corrosion cracking (Cl-SCC) in materials commonly used in the oil and gas industry, with a focus on austenitic stainless steels. The study reveals that SCC initiation can occur at temperatures as low as 20 °C, while Cl-SCC propagation rates significantly increase above 60 °C, reaching up to 0.1 mm/day in environments with high chloride concentrations. Experimental methods such as Slow Strain Rate Tests (SSRTs), Small Punch Tests (SPTs), and Constant-Load Tests (CLTs) were employed to quantify the impacts of temperature, chloride concentration, and pH on SCC susceptibility. The results highlight the critical role of these factors in determining the susceptibility of materials to SCC. The review emphasizes the importance of implementing various mitigation strategies to prevent SCC, including the use of corrosion-resistant alloys, protective coatings, cathodic protection, and corrosion inhibitors. Additionally, regular monitoring using advanced sensor technologies capable of detecting early signs of SCC is crucial for preventing the onset of SCC. The study concludes with practical recommendations for enhancing infrastructure resilience through meticulous material selection, comprehensive environmental monitoring, and proactive maintenance strategies, aimed at safeguarding operational integrity and ensuring environmental compliance. The review underscores the significance of considering the interplay between mechanical stresses and corrosive environments in the selection and application of materials in the oil and gas industry. Low pH levels and high temperatures facilitate the rapid progression of SCC, with experimental results indicating that stainless steel forms passive films with more defects under these conditions, reducing corrosion resistance. This interplay highlights the need for a comprehensive understanding of the complex interactions between materials, environments, and mechanical stresses to ensure the long-term integrity of critical infrastructure. Full article

The combination of wrought materials and laser-based directed energy deposition (DED-LB) is being increasingly used for manufacturing new and repairing old or damaged components in several industries. Aerospace components made of Inconel 718 featuring small-thickness DED-LB buildups are a remarkable example of such a combination due to the high added value it brings. Despite that these are usually critical components, the miniature testing methods to assess the local mechanical properties in the buildup area are not fully developed. This work contributes to this miniature testing development with an improvement of the small punch testing (SPT) technique for measuring the mechanical properties of the weld line between the DED-LB and the wrought substrate. A new criterion for weld line positioning in the SPT specimens is proposed and applied on samples of hybrid wrought/DED-LB Inconel 718. The results of positioning the weld line at the necking site of the SPT specimen show that the proposed approach is valid for assessing the properties of the transition zone between the wrought and additive states. For the specific conditions tested and taking the wrought material as a reference, the strength of the Inconel 718 drops 10% in the weld line and 20% in the buildup. Full article

The effects of the secondary processes of Hot Isostatic Pressing (HIP) at 920 °C and Heat Treatment (HT) at 1000 °C of Electron Beam-Melted (EBM) Ti–6Al–4V alloy on the microstructure and hydrogen embrittlement (HE) after electrochemical hydrogen charging (EC) were investigated. Comprehensive characterization, including microstructural analysis, X-ray diffraction (XRD), thermal desorption analysis, and mechanical testing, was conducted. After HIP, the β-phase morphology changed from discontinuous Widmanstätten to a more continuous structure, 10 times and ~1.5 times larger in length and width, respectively. Following HT, the β-phase morphology changed to a continuous “web-like” structure, ~4.5 times larger in width. Despite similar mechanical behavior in their non-hydrogenated state, the post-treated alloys exhibit increased susceptibility to HE due to enhanced hydrogen penetration into the bulk. It is shown that hydrogen content in the samples’ bulk is inversely dependent on surface hydride content. It is therefore concluded that the formed hydride surface layer is crucial for inhibiting further hydrogen penetration and adsorption into the bulk and thus for reducing HE susceptibility. The lack of a hydride surface layer in the samples subject to HIP and HT highlights the importance of choosing secondary treatment process parameters that will not increase the continuous β-phase morphology of EBM Ti–6Al–4V alloys in applications that involve electrochemical hydrogen environments. Full article

Studying the effect of quench and tempering heat treatments on steel, more specifically screening the effect of the austenitizing, quenching, and tempering conditions on mechanical properties, can be extremely material- and time-consuming when standard tensile testing specimens are employed. Jominy bar end quench testing has been used as a standard method to reduce the resources that are required for this type of screening. Jominy bar testing by itself shows, though, the limitation of yielding only hardness and microstructure as a result. In the last few years, the small punch test (SPT) standard has been developed. This technique can obtain an estimation of tensile mechanical properties with miniaturized specimens, which can be dissected from Jominy bars. The paper proposes a new testing methodology for screening the outcome of heat treatment conditions by combining the Jominy bar testing and SPT. Quench and tempering of API 5L X65Q pipe steel is used as a case study to describe the proposed methodology. The ability of the Jominy with SPT to detect variations in the mechanical properties produced by heat treatments is shown. This methodology can be directly applied as a high-throughput testing approach in the optimization of heat treatments. Full article

The Small Punch Creep-Recovery Test (SPCRT) is a novel miniature test used to estimate the viscoelastic properties of polymers and biomaterials. The current investigation related to the SPCRT is limited to Finite Element Method (FEM) simulations and experimental tests on PVC. The aim of this investigation was focused on: (i) extending the experimental tests to other polymers with dissimilar viscoelastic properties; (ii) deepening the influence of non-linear viscoelastic properties in the estimation capabilities of the SPCRT; and (iii) developing a numerical methodology to estimate and take into account the viscoelastic recovery produced during the unloading step of compressive creep-recovery tests (CCRT) and SPCRTs. The experimental tests (CCRTs and SPCRTs) were done on polyethylene PE 500, polyoxymethylene POM C, nylon PA 6, and polytetrafluoroethylene (PTFE), with a range of creep loads, in the case of CCRTs, in the whole elastic regime and the surroundings of the yield strength of each material. The experimental results confirmed that the SPCRT was an accurate and reliable testing method for linear viscoelastic polymers. For a non-linear viscoelastic behavior, SPCRT estimated the viscoelastic properties obtained from CCRTs for creep loads near the yield strength of the polymer, which corresponded with large-amplitude viscoelastic properties in dynamic creep testing. In order to consider the viscoelastic recovery generated in the unloading step of CCRTs and SPCRTs, a Maxwell-Wiechert model with two branches was used, simulating the different steps of the experimental tests, and solving numerically the differential equation of the Maxwell-Wiechert model with the Runge-Kutta-Fehlberg (RKF) numerical method. The coefficients of the elements of the Maxwell-Wiechert model were estimated approaching the straining curve of the recovery step of the simulation with the same curve registered on each experimental test. Experimental CCRTs with different unloading times demonstrated that the use of this procedure derived in no influence of the unloading step time in the viscoelastic properties estimation. Full article

The small punch test (SPT) can be very convenient to obtain mechanical properties due to its unique advantages from small-volume samples, and has gained wide popularity and appreciation among researchers. In this paper, the SPT test and finite element (FE) simulations were performed for three alloys, and the yield stresses (σ_YS) and ultimate tensile strengths (σ_UTS) from the uniaxial tensile test (UTT) were correlated with the yield force (F_y) and maximum force (F_m) of the small punch test (SPT) before and after compliance calibration. Finally, the effect of specimen size on the SPT curves was discussed. The results showed that the deviation between SPT test and FE simulation was due to the loading system stiffness, which was confirmed by the loading system compliance calibration test. The SPT curves before and after calibration have less influence on the empirical correlation results for σ_UTS, while the correlation results for σ_YS depend on the method used to determine F_y in the SPT curve. Finally, the simulation results indicated that the effect of specimen size on the force–displacement curve in the SPT is slight. This work also provides a reference for subsequent researchers to conduct empirical correlation studies using different specimen sizes. Full article

Natural fibers (NFs) have recently been the center of attention among researchers due to their low cost, availability, ease of manufacture, and potential environmental friendliness as reinforcing agents in composites. The present work deals with the mechanical behavior of palm fiber-reinforced epoxy-based composites with different weight percentage (Wt.%) ratios, ranging from 6% to 31.6%. Glass and hybrid fiber-reinforced epoxy-based composites were also examined. The indirect tensile test, i.e., diametral tensile test (DTT) and the small punch test (SPT), were used in the present work to determine the mechanical properties of the epoxy reinforced with discontinuous random oriented short fibers. Furthermore, short glass fibers were used to compare with palm fiber-reinforced epoxy. In addition, morphology observations of epoxy residue clinging to the natural fibers were carried out using the optical microscope and Scanning Electron Microscopy (SEM). The results showed that the natural fiber has a better adhesion bonding between the palm fiber/epoxy than that of glass fiber/epoxy. Therefore, adding palm fibers improves epoxy’s mechanical properties compared with synthetic glass fibers. The composite with high Wt.% of NF showed the highest diametral tensile strength (DTS), 21.74 MPa, over other composites. The DTS of composites with medium and low Wt.% of NF was lower than that of the high Wt.% by 14% and 30%, respectively. Full article

This paper aims to assess experimentally the mechanical and tribological behavior of conventional and functionally graded (FG) polymeric matrix composites reinforced with continuous glass fibers. The small punch test (SPT) and a pin-on-disc device were used in the present work to examine the mechanical and wear behavior, respectively. The hand lay-up technique was used in the present investigation to manufacture the conventional and FG composites. Various wooden looms with different nailed spacing were employed to manufacture the FG composites. According to test type, the FG composite is composed of four and ten layers, with a different glass fiber volume of fraction (V_f%) for each layer. In addition, the finite element simulation based on Hashin’s failure criterion and cohesive zone modeling was used to show the progressive failure and give more explanation regarding the flexural behavior of such composites. The present results indicate that the wear rate of an FG composite could be affected by many factors, including the disk speed, applied load, the composite layers number, and average glass fiber volume fraction. On the other hand, the arrangement of layers in the composite materials by variation of V_f% for each layer can improve the wear rate and value of the ultimate load before the fracture of the composite material when subjected to SPT. The experimental and numerical results for all SPT specimens showed that the fracture of the SPT specimens began beneath the punch tip and grew along the fiber direction. The ultimate flexural capacity of FG composites increased by 30% compared with the conventional composites. Full article

Thermal spray is one of the most widely used coating techniques to improve wear, surface fatigue or corrosion properties. In the atmospheric plasma spray (APS) process, a powdered material is melted by hydrogen and argon combustion and is propelled at high speed onto the target substrate. The high impact energy of the particles produces a dense and resistant coating layer. Mechanical and surface properties of the obtained coating depend on various spraying parameters, such as gas flow, traverse speed and spraying distance, among others. In this research, the influence of these manufacturing parameters on the thickness, hardness and resistance of the coating obtained from a Ni-Al alloy sprayed onto an aluminum alloy substrate was studied. In order to analyze the effect of these parameters on the coating properties, an extensive experimental program was carried out. A metallographic analysis, hardness and strength measurements were carried out using the small punch test to locally study the mechanical properties of the coating surface. The design of experiments and the response surface methodology facilitate the assessment of the optimal set of spraying parameters. Full article

The use of Rectangular Hollow Sections (RHS) as columns in steel construction includes important advantages like higher mechanical strength and fire resistance. However, the practical demountable bolted joints between beams and columns are not easy to execute, due to impossibility of access to the inner part of the tube. The use of threaded studs welded to the face of the tube and bolted to the beam by means of angle cleats is one of the cheaper and most efficient solutions to obtain beam–column joints with a semi-rigid behavior, as is usually sought in building structures. Nevertheless, it is important to point out that the stud-diameter and the stud-class selection may affect the mechanical properties of the welded parts of the joint. In this paper, 8MnSi7 (with a commercial designation K800) and 4.8 threaded studs were welded to RHS steel tubes and mechanical properties on the weld, the Heat Affected Zones (HAZ), and the base metal were obtained in two different ways: through a correlation with the Vickers hardness and by means of the Small Punch Test (SPT). A study of the microstructure and tensile tests on the threaded studs and in the columns was also carried out. The research involved different types of stud qualities, tube wall thicknesses, and stud diameters. The work presented in this paper proved that in most cases, the welded joint between these studs and the RHS steel tubes present a reasonable static behavior that fulfils the requirements for the beam–column joints under static loading. Full article

The microstructural evolution and mechanical behavior of cast duplex stainless steels (CDSSs) at 400 °C for different thermal aging times were investigated by transmission electron microscope (TEM) and small punch test (SPT). The results showed that the spinodal decomposition in ferrite was the main reason for the decrease in toughness, and G-phase did not play an important role in the embrittlement process. The change of membrane stretching zone (W_m) played an important role in the SPT load-displacement curve before and after thermal aging. During the deformation process of W_m in the SPT, for thermal aging for 10,000 h, some completely curved slip bands were generated inside the ferrite phase, which had no contact with the δ/γ phase interface and belonged to the slip bands produced by the independent deformation of ferrite. The combined effect of the curved slip bands and stress concentration led to the initiation of obvious micro-cracks at the δ/γ phase interface. The micro-cracks propagated along the ferrite phase curved slip bands, and eventually penetrated the entire hardened ferrite phase. Full article

Quinary AlCoCrFeNi high entropy alloy (HEA) is one of the most studied alloys in the recent decade due to its outstanding properties. However, it is still far from becoming an applicable industrial alloy. To our understanding, in order to promote this, the role of elements, constituting the quinary alloy, needs to be defined. Knowing the role of each element, modification of the quinary alloy toward minimization of its disadvantages will be possible. In the current research, we shed some light on this subject, presenting a thorough investigation of the microstructure (carried out using scanning and transmission electron microscopy) and mechanical properties, performed by microhardness and fractography post small punch test (SPT), of five equiatomic quaternary alloys, constituting the quinary system, namely: CoCrFeNi, AlCoFeNi, AlCoCrNi, AlCoCrFe, and AlCrFeNi. CoCrFeNi (i.e., w/o Al) was found to be Face Centered Cubic (FCC) solid solution, exhibiting relatively low micro-hardness and ductile fracture post SPT measurement. AlCoFeNi (i.e., w/o Cr) was essentially single phase B2. Other alloys had a mixed BCC + B2 dual phase content with variable microstructures and sizes of particles. The fine microstructure of the alloy without Ni implies eutectic solidification or spinodal decomposition. This fine microstructure imposed remarkable high hardness though the alloy was too brittle and unmachinable. Among the BCC/B2 mixture alloys, Fe and Co-less ones resembled the most quinary AlCoCrFeNi in terms of microstructure and mechanical properties. Full article

The dissimilar joining of T2 copper to 45 steel was performed by electron beam welding (EBW). Full-strength joints were obtained, and the highest tensile strength was found to be 270 MPa, which is almost equal to the strength of copper. Moreover, the macroscopic morphology of the tensile fracture exhibited an obvious necking phenomenon and features such as dimples, and spherical structures were found via scanning electron microscopy (SEM). These results indicated that the fracture of the T2 copper–45 steel joint is a mixed mode of cleavage and ductile fracture. Meanwhile, the fracture toughness was determined using the small punch test (SPT) with a drop rate of 0.5 mm/min. SEM imaging of the fracture surfaces revealed that the fracture was controlled by microscopic void nucleation and always occurred in the copper-side heat affected zone (HAZ). Finally, mutual verification between the numerical simulation of the finite element and the SPT results confirmed that the fracture first occurred in the copper-side HAZ due to the toughness difference. Full article
