To commercialize supersonic and hypersonic passenger aircraft and reusable spaceplanes, we are developing a small-scale supersonic flight experiment vehicle as a flying testbed for technical demonstrations in high-speed flight environments. This experiment vehicle is equipped with a fuel tank and an oxidizer tank, and the propellants inside the tanks slosh due to changes in acceleration during flight. In this situation, there is a risk of gas entrainment during liquid discharge, which could potentially cause an engine malfunction. To avoid such a situation, we considered installing a propellant management device (PMD) inside the tank to suppress the gas entrainment. In this study, a capillary type PMD with a screen channel structure, commonly used in satellites featuring no moving parts, was adopted due to its applicability to a wide acceleration range. The PMD was designed with a structure featuring cylindrical mesh screen nozzles installed at the top and bottom of a cylindrical tank. A one-dimensional flow analysis model was developed taking into account factors such as the pressure loss across the mesh screens and the flow loss within the mesh screen nozzles, which enabled the identification of conditions under which gas entrainment occurred. In this analytical model, separate formulations were developed using Hartwig’s and Ingmanson’s formulas for evaluating the flow losses through the mesh screens. Furthermore, by applying the flow analysis model, the specifications of the mesh screens as key parameters of the PMD, together with the nozzle diameter and nozzle length, were selected. Moreover, we fabricated prototype PMDs with each nozzle and conducted visualization tests using a transparent tank. The tests were conducted under static conditions, where a gravitational acceleration acted downward, and the effects of the cylindrical mesh screen length and discharge flow rate on the free surface height at which gas entrainment occurred were investigated. This experiment demonstrated the effectiveness of the propellant acquisition mechanism of the present PMD. The height of the free surface was also compared with the experimental and analytical results, and it was shown that the results obtained by using Ingmanson’s formula for pressure loss through the screen mesh were closer to the experimental results. These findings demonstrated the validity of the one-dimensional flow analysis model. Full article

Owing to the increasing g lobal demand for natural gas, the construction of liquefied natural gas (LNG) carriers has become a key trend in the shipbuilding market. In the design of membrane-type LNG carriers, a sloshing analysis is crucial for cargo containment systems (CCSs). In this study, structural responses due to impulsive sloshing loads were observed, including the effects of hydroelasticity and the test medium. To this end, the structural responses were first observed with and without hydroelastic coupling between the liquid and structure. When fluid–structure coupling is considered, a finite element analysis is performed for the integrated structure of the hull and CCS. This method was then applied to evaluate the capacity and safety of the inner hull structures of actual LNG vessels in cases where different sloshing pressures occurred owing to the different liquid–gas media. The structural capacity was evaluated using the utilization factor (UT). The results confirm that the effects of the hydroelasticity, density ratio, and phase transition of the experimental medium are essential for the evaluation of the structural responses of LNG CCSs. Full article

The efficient testing and validation of the high-voltage (HV) insulation of small-outline integrated circuit (SOIC) packages presents numerous challenges when trying to achieve faster and more accurate processes. The complex behavior these packages when submerged in diverse physical media with varying densities requires a detailed analysis to understand the factors influencing their behavior. We propose a systematic and scalable mathematical model based on trapezoidal motion patterns and a deterministic analysis of hydrodynamic forces to predict SOIC package misalignment during automated high-voltage testing in a dielectric fluid. Our model incorporates factors known to cause misalignment during the maneuvering of packages, such as surface tension forces, sloshing, cavity formation, surface waves, and bubbles during the insertion, extraction, and displacement of devices while optimizing test speed for minimum testing time. Our model was validated via a full-factorial statistical experiment for different SOIC package sizes on a pick-and-place (PNP) machine with preprogrammed software and a zero-insertion force socket immersed in different dielectric fluids under controlled thermal conditions. Results indicate the model achieves 99.64% reliability with a margin of error of less than 4.78%. Our research deepens the knowledge and understanding of the physical and hydrodynamic factors that impact the automated testing processes of high-voltage insulator SOIC packages of different sizes for different dielectric fluids. It enables improved testing times and higher reliability than traditional trial-and-error methods for high-voltage SOIC packages, leading to more efficient and accurate processes in the electronics industry. Full article

Pump-turbines experience complex flow phenomena and fluid–structure interactions during transient operations, which can significantly impact their stability and performance. This paper presents a comprehensive field test study of the pump mode startup process for a 150 MW prototype pump-turbine. By analyzing pressure fluctuations, structural vibrations, and their short-time Fourier transform (STFT) results, multiple stages were identified, each exhibiting distinct characteristics. These characteristics were influenced by factors such as runner rotation, free surface sloshing in the draft tube, and rotor–stator interactions. The natural frequencies of the metallic components varied during the speed-up and water-filling stages, potentially due to gyroscopic effects or stress-stiffening phenomena. The opening of the guide vanes and dewatering valve inside the guide vanes significantly altered the amplitude of the rotor–stator interaction frequency, transitioning the vibration behavior from forced to self-excited regimes. Interestingly, the draft tube pressure fluctuations exhibited sloshing frequencies that deviated from existing prediction methods. The substantial phenomena observed in this study can help researchers in the field to deepen the understanding of the complex behavior of pump-turbines during transient operations and identify more meaningful research directions. Full article

The utilization of the spiral tube heat exchanger (SHE) has become increasingly prevalent in large-scale liquefaction processes. However, the flow pattern and frictional pressure drop of two-phase flow in the spiral tube have been scarcely studied, particularly under offshore sloshing conditions. An experimental system had been developed to explore the flow pattern and frictional pressure drop characteristics of mixed hydrocarbon fluid in a spiral tube. Moreover, these have been developed in order to examine the effects of sloshing style (roll, pitch, heave), sloshing period (5–15 s), sloshing amplitude (5–15° or 50–150 mm), mass flux (200–800 kg/(m²·s)), vapor quality (0–1), and saturation pressure (2–4 MPa) on the frictional pressure drop of methane/ethane mixture in the spiral tube. The results indicated that sloshing conditions reduce the frictional pressure drop, thereby enhancing fluid flow. A correlation was established to predict the sloshing factor of frictional pressure drop, and the MARD under verification conditions was 6.04%. Furthermore, three flow pattern boundaries were proposed based on We* as an indicator. Full article

Liquid sloshing is a common phenomenon in ocean engineering, and one which not only affects the stability of ship navigation, but also poses a threat to both the marine environment and human life. Ascertaining how best to reduce the amplitude of liquid sloshing has always been a key problem in ocean engineering. In this study, based on an improved moving-particle semi-implicit method, the BM-MPS method, the damping effect of a vertical slotted screen under rotation excitation was simulated and studied, and the influence of baffle porosity and the rotation amplitude on the resonance period and impact pressure was discussed. The results showed that the porosity had an obvious effect on the resonance period. A significant resonance period transformation happened when the porosity was 0.1, but a porosity of 0.15 was the point at which the maximum impact pressure in the resonance was at its minimum. Meanwhile, the impact duration curve was related to porosity. With the increasing of porosity, the impact duration curve changed from having no peak to a single peak, and then to double peak. In addition, the amplitude of rotation excitation was also one of the factors that affected the resonance period. Full article

The LNG cargo containment system used in membrane-type LNG cargo tanks must have sufficient dynamic strength to withstand the impact of sloshing loads. However, performing direct dynamic nonlinear transient finite element assessments against design sloshing impact loads with different design specifications can be complicated and time-consuming. To address this, it is effective to use linear superposition methods, such as the triangular impulse response function (TIRF) method, to conduct dynamic transient FE assessments of LNG cargo containment systems. However, as LNG cargo containment systems have a high level of nonlinearities in terms of geometry, material, and boundary effects, it is necessary to evaluate the applicability of the TIRF method in advance. This study investigates the dynamic responses of an LNG cargo containment system using the TIRF method and compares the ultimate value of the structural responses and impulses with that obtained using direct dynamic nonlinear transient assessments. Based on a comparison of a series of FE analyses, the study proposes a design for the partial safety factors for calculating the ultimate bending and shear capacities of an LNG cargo containment system, taking into consideration the dynamic impact of sloshing loads using the TIRF method. Finally, the ultimate shear and bending capacities are calculated using the proposed method and compared with those obtained through direct dynamic nonlinear transient assessments. The results show that the proposed method provides conservative estimates against direct nonlinear finite element simulations, with a difference of around 10% for the mean minus two standard deviations. This approach can be practically applied for early basic design purposes in the shipbuilding industry. Full article

In this paper, a new type of total spray tray (TST) with gas–liquid countercurrent contact is proposed to solve the problem of slight operation flexibility and poor sloshing resistance in towers under offshore conditions. Its hydrodynamic performance indicators, such as pressure drop, weeping, entrainment, and liquid level unevenness, were experimentally studied under rolling motion. A tower with an inner diameter of 400 mm and tray spacing of 350 mm was installed on a sloshing platform to simulate offshore conditions. The experimental results show that the rolling motion affected the hydrodynamic performance of the tray under experimental conditions. When the rolling amplitude did not exceed 4°, the degree of fluctuation of the hydrodynamic performance was small, and the tray could still work stably. With increasing rolling amplitude, the TST wet plate pressure drop, weeping, and liquid level unevenness fluctuations also increased. When the rolling amplitude reached 7°, the maximum fluctuation of the wet plate pressure drop was 8.9% compared to that in the static state, and the plate hole kinetic energy factor, as the TST reached the lower limit of weeping, increased rapidly from 6.2 at rest to 7.8 under the experimental conditions. It can be seen that the TST still exhibits good hydrodynamic performance under rolling motion. Full article

In marine storage and transportation, the sloshing of liquid oxygen disturbs the thermodynamic equilibrium and induces stress on tank walls. Numerous problems are associated with the sloshing mechanism and demand a detailed investigation. In this study, a numerical model is developed by coupling the Eulerian framework and the algebraic interface area density (AIAD) method while considering the interphase drag force to investigate the thermal behavior of sloshing liquid oxygen. The effect of the sloshing frequency on the evaporation performance of liquid oxygen is studied. Moreover, anti-sloshing is conducted by employing a T-shaped baffle. The results show that the sloshing induced a vapor explosion phenomenon due to the invalidation of the surface impedance and thermal destratification to enhance free convection, resulting in rapid depressurization and increased evaporation loss. In addition, maximum evaporation loss occurred under the vapor–liquid coupling excitation condition. The T-shaped baffle has an excellent anti-sloshing effect because of the generating tip vortices and the enhanced shearing effect of the walls, which are regarded as motion damping factors. Full article

The sloshing behavior of systems is influenced by different factors related to the liquid level and tank specifications. Different approaches are applicable for the assessment of sloshing behavior in a tank. In this paper, a new numerical model based on the differential quadrature method and boundary element approaches is adopted to investigate the sloshing behavior of a tank with an elastic thin-walled beam. The model is developed based on small slope considerations of the free surface. The main assumption of fluid modeling is homogeneity, isotropy, inviscid, and only limited compressibility of the liquid. Indeed, the formulation is represented based on the reduced-order method and then is employed for simulating the coupling between structure and fluid in symmetric test cases. The results are verified with the ANSYS and literature for symmetric rigid structural walls and then the code is employed to study the behavior of fluid-structure interaction in a symmetric tank with new and efficient immersed structure. Full article

In this manuscript, the optimal design of geometry for a forced sloshing in a rigid container based on the entropy generation minimization (EGM) method is presented. The geometry of the vessel considered here is two dimensional rectangular. Incompressible inviscid fluid undergoes horizontal harmonic motion by interaction with a rigid tank. The analytical solution of a fluid stream function is obtained and benchmarked by Finite element results. A parameter study of the aspect ratio, amplitude, and frequency of the horizontal harmonic motion is performed. As well, an analytical solution for the total entropy generation in the volume is presented and discussed. The total entropy generation is compared with the results of the Reynolds-Averaged Navier–Stokes (RANS) solver and the Volume-of-Fluid (VOF) method). Then, the effect of parameters is studied on the total entropy generated by sway motion. Finally, the results show that, based on the excitation frequency, an optimal design of the tank could be found. Full article

Road safety depends on several factors associated with the vehicle, to the infrastructure, as well as to the environment and experience of vehicle drivers. Concerning the vehicle factors influencing the safety level of an infrastructure, it has been shown that the dynamic interaction between the carried liquid cargo and the vehicle influences the operational safety limits of the vehicle. A combination of vehicle and infrastructure factors converge when a vehicle carrying liquid cargo at a partial fill level performs a braking maneuver along a curved road segment. Such a maneuver involves both longitudinal and lateral load transfers that potentially affect both the braking efficiency and the lateral stability of the vehicle. In this paper, a series of models are set together to simulate the effects of a sloshing cargo on the braking efficiency and load transfer rate of a partially filled road tanker. The model assumes the superposition of the roll and pitch independent responses, while the vehicle is equipped with Anti-lock braking System brakes (ABS) in the four wheels. Results suggest that cargo sloshing can affect the performance of the vehicle on the order of 2% to 9%, as a function of the performance measure considered. A dedicated ABS system could be considered to cope with such diminished performance. Full article

This paper presents for the first time observations of a self-induced sloshing phenomenon in the water-retaining weir model. Fast Fourier Transform method is used to detect the dominant frequency for the sloshing water. The characteristics of the sloshing water in terms of sloshing strength and frequency are experimentally studied for six different cases. Results show that both sloshing regions and sloshing strength depends on not only the water levels but also the inlet velocities, and the relationship between them is displayed in this paper. Different prediction models for sloshing frequencies are built and compared with the experimental results, with discussions of the differences between them. For higher water level sloshing region, a new factor is introduced to the Faltinsen’s prediction formula, leading to a better agreement between prediction and experimental results. The mechanism of the self-induced sloshing is also discussed in this paper. Full article

Parallel analyses about the dynamic responses of a large-scale water conveyance tunnel under seismic excitation are presented in this paper. A full three-dimensional numerical model considering the water-tunnel-soil coupling is established and adopted to investigate the tunnel’s dynamic responses. The movement and sloshing of the internal water are simulated using the multi-material Arbitrary Lagrangian Eulerian (ALE) method. Nonlinear fluid–structure interaction (FSI) between tunnel and inner water is treated by using the penalty method. Nonlinear soil-structure interaction (SSI) between soil and tunnel is dealt with by using the surface to surface contact algorithm. To overcome computing power limitations and to deal with such a large-scale calculation, a parallel algorithm based on the modified recursive coordinate bisection (MRCB) considering the balance of SSI and FSI loads is proposed and used. The whole simulation is accomplished on Dawning 5000 A using the proposed MRCB based parallel algorithm optimized to run on supercomputers. The simulation model and the proposed approaches are validated by comparison with the added mass method. Dynamic responses of the tunnel are analyzed and the parallelism is discussed. Besides, factors affecting the dynamic responses are investigated. Better speedup and parallel efficiency show the scalability of the parallel method and the analysis results can be used to aid in the design of water conveyance tunnels. Full article
