Search Results (7)

This study focuses on optimizing track and grouser structural parameters to enhance UATV drawbar pull, particularly under soft soil conditions. A numerical soil thrust model for single-track shoes was developed based on track–soil interaction mechanics, revealing distinct mechanistic roles: track structural parameters (length/width) govern pressure–sinkage relationships at the track base, while grouser structural parameters (height, spacing, V-shaped angle) dominate shear stress–displacement dynamics on grouser shear planes. A novel DEM-MBD coupling simulation framework was established through soil parameter calibration and multi-body dynamics modeling, demonstrating that soil thrust increases with grouser height and V-shaped angle, but decreases with spacing, with grouser height exhibiting the highest sensitivity. A soil bin test validated the numerical model’s accuracy and the coupling method’s efficacy. Parametric optimization via the Whale Optimization Algorithm (WOA) achieved a 55.86% increase in drawbar pull, 40.38% reduction in ground contact pressure and 57.33% improvement in maximum gradability. These advancements substantially improve the tractive performance of UATVs in soft beach terrains. The proposed methodology provides a systematic framework for amphibious vehicle design, integrating numerical modeling, high-fidelity simulation, and experimental validation. Full article

Accurately positioning energy-constrained devices in indoor environments is of great interest to many professional, care, and personal applications. Hybrid RF–acoustic ranging systems have shown to be a viable technology in this regard, enabling accurate distance measurements at ultra-low energy costs. However, they often suffer from self-interference due to multipaths in indoor environments. We replace the typical single loudspeaker beacons used in these systems with a phased loudspeaker array to promote the signal-to-interference-plus-noise ratio towards the tracked device. Specifically, we optimize the design of a low-cost uniform planar array (UPA) through simulation to achieve the best ranging performance using ultrasonic chirps. Furthermore, we compare the ranging performance of this optimized UPA configuration to a traditional, single-loudspeaker system. Simulations show that vertical phased-array configurations guarantee the lowest ranging errors in typical shoe-box environments, having a limited height with respect to their length and width. In these cases, a P50 ranging error of around 3 $\mathrm{c}$$\mathrm{m}$ and P95 ranging error below 30 $\mathrm{c}$$\mathrm{m}$ were achieved. Compared to a single-speaker system, a 10 × 2 vertical phased array was able to lower the P80 and P95 up to an order of magnitude. Full article

Grouser height and soil moisture content have a significant effect on the tractive performance of tracked vehicles. Paddy soil has the mechanical properties of both clay soil and sandy soil and can have a wide range of water content values, and it has a considerable influence on the tractive performance of tracked agricultural machinery. To study the influence of grouser height on the tractive performance of a single-track shoe under different soil moisture contents, a three-dimensional shearing model of the single-track shoe and the contact soil was established based on the ground vehicle mechanics theory, and an experimental platform with a soil bin, sensors, and a control system was established. Six preset levels of moisture contents (7%, 12%, 17%, 22%, 27%, and 32%) of paddy soil were prepared for the research experiment. The mechanical properties of the soil with different moisture contents were obtained through the use of a direct shear test, penetration test, and compaction test. The obtained physical parameters of the soil have special characteristics that are different from typical soil. Combined with the three-dimensional model and the obtained soil parameters, the parameters of the tractive performance, such as thrust, running resistance, and traction with different moisture contents were analyzed and calculated. The test results revealed that the thrust at different grouser heights shows a regular waveform growth trend with an increase in soil moisture content. The minimum value and the maximum value of thrust were obtained at moisture contents of 7% and 12%, respectively. The curve of different grouser heights of the running resistance shows similar changes with different moisture contents. The two peak points and inflection points of the fluctuation curve are for moisture contents of 17% and 27%. The change curve of the traction is highly similar to the curve of thrust. The maximum value of the traction was found at a moisture content of 12%, and the minimum value at 22% or 27%. Under different moisture conditions, tracked vehicles with higher grousers have better tractive performances. Full article

Based on our direct shear creep experiment and the direct shear rheological constitutive model, a semi-empirical time-dependent parameter of the shear strength is obtained by Mohr–Coulomb shear strength theory, and different time-dependent traction force calculations between deep-sea sediment and a tracked miner are conducted by the work-energy principle. The time-dependent traction force calculation under its influencing factors, including the time, track shoe number, and grounding pressure, are analyzed and proved to be valid by the traction force experiment of a single-track shoe. The results show that the time-dependent cohesion force obtained by a semi-empirical way can be easily used to deduce the time-dependent traction force models under the different grounding pressure distributions and applied into deep-sea engineering application conveniently; the verified traction force models by the traction force experiment of a single-track shoe illustrate that traction force under the decrement grounding pressure distribution is the worst among the four kinds of grounding pressure distributions and suggested for evaluating the most unfavorable traction force and calculating the trafficability and stability of the deep-sea tracked miner. Full article

The grouser height and soil conditions have a considerable influence on the tractive performance of single-track shoe. A soil bin-based research was conducted to assess the influence of grouser height on the tractive performance of single-track shoe at different moisture contents of clay loam soil. Eight moisture contents (7.5, 12, 16.7, 21.5, 26.2, 30.7, 35.8, and 38%) and three grouser heights (45, 55, and 60 mm) were comprised during this study. The tractive performance parameters of (thrust, running resistance, and traction) were determined by penetration test. A sensor-based soil bin was designed for penetration tests, which was included penetration system (AC motor, loadcell, and displacement sensor). The test results revealed that soil cohesion was decreased, and adhesion was increased after 16.7% moisture content. Soil thrust at lateral sides and bottom of grouser were increased before 16.7%, and then decreased for all the three heights but the major decrease was observed at 45 mm height. The motion resistance was linearly decreased, the more reduction was on 45 mm at 38% moisture content. The traction of the single-track shoe was decreased with a rise in moisture content, the maximum decrease was on 45 mm grouser height at 38% moisture content. It could be concluded that an off-road tracked vehicle (crawler combine harvester) with 45 mm grouser height of single-track shoe could be operated towards a moderate moisture content range (16.7–21.5%) under paddy soil for better traction. Full article

This paper describes a single body-mounted sensor that integrates accelerometers, gyroscopes, compasses, barometers, a GPS receiver, and a methodology to process the data for biomechanical studies. The sensor and its data processing system can accurately compute the speed, acceleration, angular velocity, and angular orientation at an output rate of 400 Hz and has the ability to collect large volumes of ecologically-valid data. The system also segments steps and computes metrics for each step. We analyzed the sensitivity of these metrics to changing the start time of the gait cycle. Along with traditional metrics, such as cadence, speed, step length, and vertical oscillation, this system estimates ground contact time and ground reaction forces using machine learning techniques. This equipment is less expensive and cumbersome than the currently used alternatives: Optical tracking systems, in-shoe pressure measurement systems, and force plates. Another advantage, compared to existing methods, is that natural movement is not impeded at the expense of measurement accuracy. The proposed technology could be applied to different sports and activities, including walking, running, motion disorder diagnosis, and geriatric studies. In this paper, we present the results of tests in which the system performed real-time estimation of some parameters of walking and running which are relevant to biomechanical research. Contact time and ground reaction forces computed by the neural network were found to be as accurate as those obtained by an in-shoe pressure measurement system. Full article

Gyroscopes have been used in previous studies to measure the peak angular velocity of the shoe or foot in the frontal plane (evVel). However, it is not clear whether different test conditions (footwear hardness or locomotion speed) can influence the accuracy of evVel. The purpose of the present study was to compare the accuracy of gyroscopes and electrogoniometers when measuring evVel and the time until evVel (t_evVel) in 12 different conditions using a single axis gyroscope attached to the heel cap. Twenty-four recreational runners were instructed to walk and run on a 15-m indoor track at four locomotion speeds (1.5, 2.5, and 3.5 m/s, and individual running speed) and in three footwear conditions (low to high hardness). The gyroscope data and electrogoniometer data were sampled at a rate of 1000 Hz. Comparisons between both measurement devices showed small mean differences up to 49.8 ± 46.9 deg/s for evVel and up to 5.3 ± 3.5 ms for t_evVel. Furthermore, strong relationships between gyroscope and electrogoniometer data were found for evVel as well as for t_evVel for all conditions. It can be concluded that gyroscopes can be used to accurately determine evVel and t_evVel under a variety of conditions. Full article
