Search Results (94)

Geophysical flows are characterized by rapid rotation. Simulating these flows requires small timesteps to achieve stability and accuracy. Numerical stability can be greatly improved by the implicit integration of the terms that are most responsible for destabilizing the numerical scheme. We have implemented an implicit treatment of the Coriolis force in a rotating spherical shell driven by a radial thermal gradient. We modified the resulting timestepping code to carry out steady-state solving via Newton’s method, which has no timestepping error. The implicit terms have the effect of preconditioning the linear systems, which can then be rapidly solved by a matrix-free Krylov method. We computed the branches of rotating waves with azimuthal wavenumbers ranging from 4 to 12. As the Ekman number (the non-dimensionalized inverse rotation rate) decreases, the flows are increasingly axially independent and localized near the inner cylinder, in keeping with well-known theoretical predictions and previous experimental and numerical results. The advantage of the implicit over the explicit treatment also increases dramatically with decreasing $\mathrm{Ek}$, reducing the cost of computation by as much as a factor of 20 for Ekman numbers of order of ${10}^{-5}$. We carried out continuation for both the Rayleigh and Ekman numbers and obtained interesting branches in which the drift velocity remained unchanged between pairs of saddle–node bifurcations. Full article

As interest in liquid hydrogen (LH₂) continues to grow within the energy and mobility sectors, so does the demand for testing capabilities at deep cryogenics temperatures. However, cost-, complexity-, and safety-related challenges associated with handling LH₂ effectively limit the landscape of possible options. As an alternative, LH₂ temperatures can be accessed via a helium-based cryogenic refrigerator, or “cryocooler”. Recently, NASA and its partners CB&I and Shell began the development of a cryocooler-based calorimeter to characterize the thermal performance of insulations and other materials down to 20 K. Deemed the Guarded Hot Cylinder (GHC), the apparatus utilizes a small vacuum chamber in conjunction with a GM cryocooler and trim heater to control the cold boundary temperature. A sealed, cylindrical copper cup bolts to the cryocooler and houses the material specimen, with an internal, cylindrical test heater assembly to maintain the warm boundary. The steady-state heat load, traveling radially through the specimen, is measured via the electrical input power to the test heater and then used to evaluate the material’s absolute thermal performance. Initial checkout and validation of the GHC using a common bulk-fill insulation material showed close agreement with published data from standardized LN₂ boiloff calorimetry testing. The instrument is now considered a lab standard, with the goal of incorporating it into the ASTM C1774 standard in the future, and it is in continuous use, examining insulation materials for next-generation LH₂ applications. Full article

Due to their higher strength-to-weight ratio and ability to operate in harsh environments, the usage of fiber-reinforced cylindrical shells experienced a significant increase in the past decades. The key novelty of this study lies in implementing dual analytical approaches to address the complex failure mechanisms and stress distributions in composites. Two distinct theoretical solutions were investigated, membrane theory and Mindlin–Reissner theory, for failure prediction in filament-wound structures, while uniquely providing a platform for easy comparison of theoretical approaches. Experimental data from different setups, materials, and winding angles were collected in the literature and compared using the developed online MECH-Gcomp software. Failure analysis was also carried out by applying five different failure criteria well-established for composite materials. The results from the Mindlin–Reissner theory showed 46.9% deviation and those for the membrane theory 36.2% deviation, considering more than 120 cases. Sobol sensitivity analysis identified pressure (P), transverse tensile strength, winding angle, and radius as the most influential parameters regarding the index of failure of composite cylinders. Full article

LGP cylinders are necessary for fuel storage and home heating. To avoid material and human risk, it is essential to maintain their structural integrity. Extensive mechanical research studies and physical tests are necessary for its design. This paper investigates the mechanical performance of the storage capacity of an LPG cylinder under static loading. The authors integrate and adapt IGA with the T-Splines function for geometry modeling and numerical analysis in the context of linear elasticity. The main focus is on the strains and stress numerical results. The obtained results are examined and verified with the FEM in Abaqus/Standard. The results found show that the storage capacity of a single cylinder is equivalent to 15 empty cylinders. This study also demonstrates that the T-Splines method is a promising alternative for numerically analyzing the mechanical structure performance of LPG cylinders, particularly in energy storage issues. Full article

Burst pressure is one of the critical strength parameters used in the design and operation of pressure vessels because it represents the maximum pressure that a vessel can withstand before failing. Historically, the Barlow formula was used as a design base for estimating burst pressure. However, it does not consider the plastic flow response for ductile steels and is applicable only to thin-walled cylinders (i.e., the diameter to thickness ratio D/t ≥ 20). A new multiaxial plastic yield theory was developed to consider the plastic flow response, and the associated theoretical (i.e., Zhu–Leis) solution of burst pressure was obtained and has gained extensive applications in the pipeline industry because it was validated by different full-scale burst test datasets for large-diameter, thin-walled pipelines in a variety of steel grades from Grade B to X120. The Zhu–Leis flow theory of plasticity was recently extended to thick-walled pressure vessels, and the associated exact flow solution of burst pressure was obtained and is applicable to both thin and thick-walled cylindrical shells. Many full-scale burst tests are available for thin-walled line pipes in the pipeline industry, but limited pressure burst tests exist for thick-walled vessels. To validate the newly developed exact solutions of burst pressure for thick-walled cylinders, this paper conducts a series of burst pressure tests on small-diameter, thick-walled pipes. In particular, six burst tests are carried out for three thick-walled pipes in Grade B carbon steel. These pipes have a nominal diameter of 2.375 inches (60.33 mm) and three nominal wall thicknesses of 0.154, 0.218, and 0.344 inches (3.91, 5.54, and 8.74 mm), leading to D/t = 15.4, 10.9, and 6.9, respectively. With the burst test data, comparisons show that the Zhu–Leis flow solution of burst pressure matches well the burst test data for thick-walled pipes. Thus, these burst tests validate the accuracy of the Zhu–Leis flow solution of burst pressure for thick-walled cylindrical vessels. Full article

This study investigates the influence of various printing parameters on the tensile, compressive, and bending stiffness of fused deposition modeling (FDM)-printed polylactic acid (PLA) parts through a comprehensive full factorial design of experiment. Key factors, including infill percentage, infill pattern, number of outer shells, and part orientation, were systematically varied to quantify their impact on mechanical performance. A total of 36 parameter combinations, selected based on a literature review and experimental feasibility, were tested using standardized specimens: beams for bending, cylinders for compression, and dogbones for tensile testing. Mechanical tests were performed according to ISO 5893:2019, employing a 1 kN load cell to determine stiffness and elastic modulus. The results indicate that the number of outer shells and infill density are the most influential parameters, whereas infill pattern and part orientation have a minor effect, depending on the loading condition. This study provides a novel and robust evaluation of the interactions between key printing parameters, offering new insights into optimizing the mechanical properties of FDM-printed parts. These findings establish a foundation for further optimization and material selection in future additive manufacturing research. Full article

A robust and elegant approach, based on the Two-Zone Moment Analysis (TZMA) method, is proposed to assess the contributions of the mobile and stationary zones, $H_{Cm}$ and $H_{Cs}$, to the C term $H_C$ in the van Deemter equation for plate height. The TZMA method yields two formulations for $H_{Cm}$ and $H_{Cs}$, both fully equivalent in terms of $H_C$, yet offering different decompositions of the contributions from the mobile and stationary zones. The first formulation proposes an expression for the term $H_{Cs}$ that has strong similarities, but also significant differences, from the well-known and widely used one proposed by Giddings. While it addresses the inherent limitation of Giddings’ approach—namely, the complete decoupling of transport phenomena in the moving and stationary zones—it introduces the drawback of a non-unique decomposition of $H_C$. Despite this, it proves highly valuable in highlighting the limitations and flaws of Giddings’ method. In contrast, the second formulation not only properly accounts for the interaction between the moving and stationary zones, but provides a unique and consistent decomposition of $H_C$ into its components. Three different geometries are investigated in detail: the 2D triangular array of cylinders (pillar array columns), the 2D array of rectangular pillars (radially elongated pillar array columns) and the 3D face-centered cubic array of spheres. It is shown that Giddings’ approach significantly underestimates the $H_{Cs}$ term, especially for porous-shell particles. Its accuracy is limited, being reliable only when intra-particle diffusivity ($D_s$) and the zone retention factor ($k^{″}$) are very low, or when axially invariant systems are considered. Full article

The transient electroosmotic response in a charged porous medium consisting of a uniform array of parallel circular cylindrical fibers with arbitrary electric double layers filled with an electrolyte solution, for the stepwise application of a transverse electric field, is analyzed. The fluid momentum conservation equation is solved for each cell by using a unit cell model, where a single cylinder is surrounded by a coaxial shell of the electrolyte solution. A closed-form expression for the transient electroosmotic velocity of the bulk fluid in the Laplace transform is obtained as a function of the ratio of the cylinder radius to the Debye screening length and the porosity of the fiber matrix. The effect of the fiber matrix porosity on the continuous growth of the electroosmotic velocity over time is substantial and complicated. For a fiber matrix with larger porosity, the bulk fluid velocity takes longer to reach a certain percentage of its final value. Although the final value of the bulk fluid velocity generally increases with increasing porosity, early velocities may decrease with increasing porosity. For a given fiber matrix porosity, the transient electroosmotic velocity is a monotonically increasing function of the ratio of the cylinder radius to the Debye length. Full article

Taking pressure-bearing equipment as a prototype, the mechanical behavior of hollow corrugated sandwich cylinders under inner pressure loading was investigated. Considering the hollow cylindrical shell with finite length, the elastic closed-form solutions of hollow corrugated sandwich cylinders under inner pressure loading were presented. The optimization for minimum weight was performed. The stress distribution characteristics of the structures with different topological parameters were discussed. It can be found that an inflection point of the structure loading efficiency exists during an increase in the pressure, providing that under lower inner pressure loading, the loading efficiency of hollow corrugated sandwich structures is not invariably superior to homogeneous structures, yet while subjected to higher inner pressures, the sandwich structures exhibit a significant advantage in load-bearing efficiency. Full article

At high speeds, flow-induced vibration noise is the main component of underwater vehicle noise. The turbulent fluctuating pressure is the main excitation source of this noise. It can cause vibration of the underwater vehicle’s shell and eventually radiate noise outward. Therefore, by reducing the turbulent pressure fluctuation or controlling the vibration of the underwater vehicle’s shell, the radiation noise of the underwater vehicle can be effectively reduced. This study designs a cone–column–sphere composite structure. Firstly, the effect of fluid–structure coupling on pulsating pressure is studied. Next, a machine learning method is used to predict the turbulent pressure fluctuations and the fluid-induced vibration response of the structure at different speeds. The results were compared with experimental and numerical simulation results. The results show that the deformation of the structure will affect the flow field distribution and pulsating pressure of the cylindrical section. The machine learning method based on the BP (back propagation) neural network model can quickly predict the pulsating pressure and vibration response of the cone–cylinder–sphere composite structure under different Reynolds numbers. Compared with the experimental results, the error of the machine learning prediction results is less than 7%. The research method proposed in this paper provides a new solution for the rapid prediction and control of hydrodynamic vibration noise of underwater vehicles. Full article

The research presents a novel approach to develop high-strength functionally graded composite materials (FGCMs) by using recycled coconut shell ash (CSA) particles as reinforcement for a hypereutectic Al-Si alloy matrix. Using a centrifugal casting technique, test specimens are prepared for the study under ASTM standards. The optimal combination of materials to maximise the materials’ overall tensile strength is obtained through the mixture methodology approach. The results show that CSA particles in the matrix material increase the tensile strength of the produced material. Process parameters, melting temperature and rotating speed were found to play a pivotal role in determining the tensile strength. A better tensile strength of the material is obtained when Al-Si = 90.5 wt%, CSA = 9.5 wt%, rotating speed = 800 RPM, and melting temperature = 800 °C; the proposed regression model developed has substantial predictability for tensile strength. This work presents a methodology for enhancing the tensile strength of FGCMs by optimising both the material composition and processing parameters. The achieved tensile strength of 197.4 MPa, at 800 RPM and 800 °C, for a concentration of 7.5 wt% CSA particles, makes these FGCMs suitable for use in multiple engineering sectors. Full article

In this work, the vibration analysis of a layered, cylinder-shaped shell is undertaken. The structure of the shell layers is composed of functionally graded and isotropic materials. The vibrations of four-layered cylindrical shells with a ring support along the axial direction are investigated in this research. The two internal layers are composed of isotropic materials, and the external two layers are composed of functionally graded materials. The outer functionally graded material layers considered are stainless steel, zirconia, and nickel. The inner two isotropic layers considered are aluminum and stainless steel. The shell frequency equation is acquired by employing the Rayleigh–Ritz method under the shell theory of Sanders. The trigonometric volume fraction law is used to sort the functionally graded material composition of the FGM layers. The natural frequencies are attained under two boundary conditions, namely simply supported–simply supported and clamped–clamped. Full article

A novel method is introduced in this study for producing ceramisite coarse aggregates that are both lightweight and possess high strength. The process involves utilizing fly ash as the primary material, along with coal ash floating beads (CAFBs) that have high softening temperature and a spherical hollow structure serving as the template for forming pores. This study examined the impact of varying particle size and quantity of floating beads on the composition and characteristics of ceramisite aggregates. Results showed that the high softening temperature of floating beads provided stability to the spherical cavity structure throughout the sintering process. Furthermore, the pore structure could be effectively tailored by manipulating the size and quantity of the floating beads in the manufacturing procedure. The obtained ceramisite aggregates feature a compact outer shell and a cellular inner core with uniformly distributed pores that are isolated from each other and mostly spherical in form. They achieve a low density ranging from 723 to 855 kg/m³, a high cylinder compressive strength between 8.7 and 13.5 MPa, and minimal water absorption rates of 3.00 to 4.09%. The performance metrics of these coarse aggregates significantly exceeded the parameters specified in GB/T 17431.1-2010 standards. Full article

The capability of dielectric measurements was significantly increased with the development of capacitive one-side access physical sensors. Complete samples give no opportunity to study electric susceptibility at a partial coverage of the one-side access sensor’s active area; therefore, partial samples are proposed. The electric susceptibility at the partial coverage of a circular one-side access sensor with cylinders and shells is investigated for polyurethane materials. The implementation of the relative partial susceptibility permitted us to transform the calculated susceptibility data to a common scale of 0.0–1.0 and to outline the main trends for PU materials. The partial susceptibility, relative partial susceptibility, and change rate of relative partial susceptibility exhibited dependence on the coverage coefficient of the sensor’s active area. The overall character of the curves for the change rate of the relative partial susceptibility, characterised by slopes of lines and the ratio of the change rate in the centre and near the gap, corresponds with the character of the surface charge density distribution curves, calculated from mathematical models. The elaborated methods may be useful in the design and optimization of capacitive OSA sensors of other configurations of electrodes, independent of the particular technical solution. Full article

The use of Type IV cylinders for gas storage is becoming more widespread in various sectors, especially in transportation, owing to the lightweight nature of this type of cylinder, which is composed of a polymeric liner that exerts a barrier effect and an outer composite material shell that primarily imparts mechanical strength. In this work, the failure analysis of an HDPE liner in a Type IV cylinder for high-pressure storage was carried out. The breakdown occurred during a cyclic pressure test at room temperature and manifested in the hemispherical head area, as cracks perpendicular to the liner pinch-off line. The failed sample was thoroughly investigated and its characteristics were compared with those of other liners at different stages of production of a Type IV cylinder (blow molding, curing of the composite material). An examination of the liner showed that no significant chemical and morphological changes occurred during the production cycle of a Type IV cylinder that could justify the liner rupture, and that the most likely cause of failure was a design-related fatigue phenomenon. Full article
