This paper details the design and implementation of a fuzzy logic control system for an advanced driver-assistance system (ADAS) that adjusts brake force based on proximity sensing, vehicle speed, and road conditions. By employing a cost-effective ultrasonic sensor (HC-SR04) and an STM32 microcontroller, the system facilitates real-time adjustments to braking force, enhancing both vehicle safety and driver comfort. The fuzzy logic controller processes three inputs to deliver a smooth and adaptive brake response, thus addressing the shortcomings of traditional binary systems that can lead to abrupt and unsafe braking actions. The effectiveness of the system is validated through several test cases, demonstrating improved responsiveness and safety across various driving scenarios. This paper presents a cost-effective model for a straightforward braking system using fuzzy logic, laying the groundwork for the development of more advanced systems in emerging technologies. Full article

Flooding is an issue that affects many cities during periods of heavy rain, especially in developing countries. This issue often happens due to the lack of timely maintenance and cleaning of rainwater drains. This work presents a proposal to detect blockages in rainwater drains to determine where maintenance and cleaning need to be performed promptly. An architecture that includes sensor nodes, a Gateway, and a cloud application was defined. The sensor nodes, which detect potential blockages in the drains, send data and status signals to the Gateway using LoRaWAN. The Gateway then passes the data to a cloud platform that records the data and issues an alert when a blockage is detected in a drain. The sensor node prototype is based on a Heltec LoRa WiFi board and has two sensors: an HC-SR04 ultrasonic sensor to measure distance and a DHT22 sensor to measure humidity and temperature. The cloud application was developed on the Arduino Cloud platform. A decision tree is proposed to detect blockages based on the readings from these sensors, particularly the distance sensor, considering four main possible states: clear, possibly blocked, potentially blocked, and blocked. The decision tree is implemented in each node. Periodically, the node collects data from the sensors and transmits them to the cloud, and if a potential blockage is detected, it sends a message that triggers an alert on the platform. Preliminary tests of the prototype show accurate and timely results in detecting potential blockages, allowing for a better use of resources allocated for maintaining drainage systems. Full article

Flow is a crucial variable in water resources, although its determination is challenging. Rating curves are standard but have conceptual limitations, leading to significantly high uncertainties. Hydrodynamic models offer a more precise alternative, but they necessitate continuous measurements of velocities, which are complex and expensive to obtain. Thus, this article aimed to validate a hydrodynamic model that estimates flows and velocities in transient conditions based on water levels measured using a low-cost ultrasonic sensor. The results indicated that these estimates can be reliable if (1) hydrodynamic models are used to represent the flow, (2) the channel bed slope is well represented in the geometric data, and (3) Manning’s coefficients are accurately estimated during calibration. The calculated flow and velocity showed a maximum variation of 40% for the same water level compared to estimates using the rating curve. The model exhibited higher sensitivity in terms of the flow when varying the channel bed slope, highlighting the importance of topographic surveys for the estimates. The validity of the implemented model was assessed with experimental data, indicating precision and reliability for practical applications in natural channels. Full article

Our society has a large population of visually impaired people. If you notice them, you will know they cannot walk without help; they need guidance to reach their destination. They face many struggles in their daily lives. Even though technology is advancing rapidly today, there is no affordable device available for people with visual impairments. Blind people have difficulty performing their daily activities, so a Smart Blind Stick was designed to help them move and perform their tasks more easily. However, when visually impaired people are walking on the road, they find it difficult to see obstacles along the way, which makes it very dangerous. A smart stick is one of the best ways to point around. This stick is equipped with infrared sensors to detect stair cases, and a pair of ultrasonic sensors to detect any other obstacles in front of the user, within a range of four meters. A water sensor is also used in the system, which detects water on the user’s path. All found obstacles are alerted to the user through a buzzer. Full article

Monitoring flow in channels is difficult, expensive, and potentially dangerous; hence, alternatives minimizing these factors are sought and indirect methods to measure the flow based on water-level information, among others, are employed. Ultrasonic sensors along with Arduino are widely used to monitor levels in reservoirs; however, the accuracy of this method in turbulent flow regimes has not been evaluated. Therefore, in this study, we evaluated the level of open channel flows using a combination of Arduino and ultrasonic sensors whilst considering turbulence. Additionally, we statistically compared the simultaneous measurements of levels obtained using five ultrasonic sensors with those of five rulers filmed individually along an artificial channel, for four permanent and two transient regimes. The results showed that the errors in measurements increased with increasing turbulence. These errors were within the range of hydraulic measurements (<0.020 m), indicating that the procedure is valid for experienced conditions. Therefore, the combination of Arduino and ultrasonic sensors is a technically and economically viable alternative. However, calibrating and validating the sensors for distances greater than 0.400 m should be performed with care because the bench tests performed in static conditions were limitedly accurate in measuring distances greater than 0.200 m. Full article

The coverage of center pivot irrigation systems used around the world has increased. One potential factor driving their adoption is improved water application efficiency relative to some other sprinkler or surface irrigation approaches. Center pivot irrigation systems may be further improved by dynamic elevation spray application (DESA). DESA systems adjust the nozzle height in response to plant growth and canopy heterogeneities. The DESA approach is relatively new and there is uncertainty in its economic viability and worthiness of further investigation. Thus, an economic scenario analysis was performed to explore the potential economic benefits of DESA based on permutations of irrigation pivot efficiency without DESA, water-saving potential of DESA, and water cost. The weighted costs and benefits of the height-adjusted approach for a set of water cost savings scenarios showed the net return price with the water cost savings per season. We show that DESA could have economic viability at current component costs and is worthy of further investigation and refinement. Full article

Today, low-cost sensors in various civil engineering sectors are gaining the attention of researchers due to their reduced production cost and their applicability to multiple nodes. Low-cost sensors also have the advantage of easily connecting to low-cost microcontrollers such as Arduino. A low-cost, reliable acquisition system based on Arduino technology can further reduce the price of data acquisition and monitoring, which can make long-term monitoring possible. This paper introduces a wireless Internet-based low-cost data acquisition system consisting of Raspberry Pi and several Arduinos as signal conditioners. This study investigates the beneficial impact of similar sensor combinations, aiming to improve the overall accuracy of several sensors with an unknown accuracy range. The paper then describes an experiment that gives valuable information about the standard deviation, distribution functions, and error level of various individual low-cost sensors under different environmental circumstances. Unfortunately, these data are usually missing and sometimes assumed in numerical studies targeting the development of structural system identification methods. A measuring device consisting of a total of 75 contactless ranging sensors connected to two microcontrollers (Arduinos) was designed to study the similar sensor combination theory and present the standard deviation and distribution functions. The 75 sensors include: 25 units of HC-SR04 (analog), 25 units of VL53L0X, and 25 units of VL53L1X (digital). Full article

Fever is a common symptom of many infections, e.g., in the ongoing COVID-19 pandemic, keeping monitoring devices such as thermometers in constant demand. Recent technological advancements have made infrared (IR) thermometers the choice for contactless screening of multiple individuals. Yet, even so, the measurement accuracy of such thermometers is affected by many factors including the distance from the volunteers’ forehead, impurities (such as sweat), and the location measured on the volunteers’ forehead. To overcome these factors, we describe the assembly of an Arduino-based digital IR thermometer with distance correction using the MLX90614 IR thermometer and HC-SR04 ultrasonic sensors. Coupled with some analysis of these factors, we also found ways to programme compensation methods for the final assembled digital IR thermometer to provide more accurate readings and measurements. Full article

Among non-destructive inspection (NDI) techniques, General Visual Inspection (GVI), global or zonal, is the most widely used, being quick and relatively less expensive. In the aeronautic industry, GVI is a basic procedure for monitoring aircraft performance and ensuring safety and serviceability, and over 80% of the inspections on large transport category aircrafts are based on visual testing, both directly and remotely, either unaided or aided via mirrors, lenses, endoscopes or optic fiber devices coupled to cameras. This paper develops the idea of a global and/or zonal GVI procedure implemented by means of an autonomous unmanned aircraft system (UAS), equipped with a low-cost, high-definition (HD) camera for carrying out damage detection of panels, and a series of distance and trajectory sensors for obstacle avoidance and inspection path planning. An ultrasonic distance keeper system (UDKS), useful to guarantee a fixed distance between the UAS and the aircraft, was developed, and several ultrasonic sensors (HC-SR-04) together with an HD camera and a microcontroller were installed on the selected platform, a small commercial quad-rotor (micro-UAV). The overall system concept design and some laboratory experimental tests are presented to show the effectiveness of entrusting aircraft inspection procedures to a small UAS and a PC-based ground station for data collection and processing. Full article

In this article, a new investigation on a low-temperature electrochemical hydrocarbon and NO_x sensor is presented. Based on the mixed-potential-based sensing scheme, the sensor is constructed using platinum and metal oxide electrodes, along with an Yttria-Stabilized Zirconia (YSZ)/Strontium Titanate (SrTiO₃) thin-film electrolyte. Unlike traditional mixed-potential sensors which operate at higher temperatures (>400 °C), this potentiometric sensor operates at 200 °C with dominant hydrocarbon (HC) and NO_x response in the open-circuit and biased modes, respectively. The possible low-temperature operation of the sensor is speculated to be primarily due to the enhanced oxygen ion conductivity of the electrolyte, which may be attributed to the space charge effect, epitaxial strain, and atomic reconstruction at the interface of the YSZ/STO thin film. The response and recovery time for the NO_x sensor are found to be 7 s and 8 s, respectively. The sensor exhibited stable response even after 120 days of testing, with an 11.4% decrease in HC response and a 3.3% decrease in NO_x response. Full article
