Road structures undergo a series of chemical and physical processes once they are put into service. This phenomenon results from the action of the load and the influence of the environment, which causes their progressive deterioration. In order to mitigate the risk of progressive deterioration and guarantee their stability and durability, various maintenance tasks are required, including visual inspections. The Intelligent Bridge Management System of Colombia (SIGP) includes visual inspection as one of its modules. The system has been designed based on state-of-the-art criteria and national experience with relevant damages and bridge collapses. This paper presents the visual inspection methodology, which includes several stages such as a classification scale, condition index, evaluation areas, damage catalog, and evaluation criteria. In addition, a digital application has been developed to facilitate real-time data collection during field inspections using mobile devices, which can be uploaded directly to the system database hosted in the cloud. The results from the inspection of bridges of different typologies and years of construction are presented, as well as general inspection results from 150 bridges in Colombia. The relevance, comprehensiveness, and accuracy of the inspection are supported by a damage catalog, which allows the identification of intervention needs and reduces the bias of the collected data. Full article

This paper outlines an initial analysis of 20 years of data held on an electronic bridge management database for approximately 3500 arch bridges across Northern Ireland (NI) by the Department for Infrastructure. Arch bridges represent the largest group of bridge types, making up nearly 56% of the total bridge stock in NI. This initial analysis aims to identify trends that might help inform maintenance decisions in the future. Consideration of the Bridge Condition Indicator (BCI) average value for the overall arch bridge stock indicates the potential for regional variations in the overall condition and the potential for human bias in inspections. The paper presents the most prevalent structural elements and associated defects recorded in the inspections of arch bridges. This indicated a link to scour and undermining for the worst-conditioned arch bridges. An Analysis of Variance (ANOVA) analysis identified function, number of spans, and deck width as significant factors during the various deterioration stages in a bridge’s lifecycle. Full article

Compared with common bridges, large-span cable-supported bridges contain more components, are located in a more complex environment, and play a more important role in traffic system sustainability. Throughout the service life, it is more necessary to evaluate their safety, functionality, and environmental status. In this study, a comprehensive evaluation system is proposed to fill the gap using advanced sensor-guided structural health monitoring data and probability-based digital twins. Safety evaluation is the basis of the system and can be divided into overall and component levels. The former includes an over-limit analysis of main structural responses and degradation identification of dynamic characteristics. The abnormal areas discovered in this phase and the hot spots prompted by prior information during the design process will be checked in the latter. The functional assessment of this system is mainly based on checklist-type inspection and is often carried out together with appearance inspection and non-main structural component detection. Environmental assessment includes the monitoring and analysis of wind fields, temperature, humidity, foundation scour, and traffic flow and is the source of external information in the aforementioned two modules. The temperature and humidity of the example bridges are basically uniformly distributed along the spatial dimension, fluctuating over a period of one day. Full article

After a lengthy period of scouring, the reinforced concrete surface of the dam spillway (i.e., drift spillways and flood discharge spillways) will suffer from deterioration and damage. Regular manual inspection is time-consuming and dangerous. This paper presents a robotic solution to detect automatically, count defect instance numbers, and reconstruct the surface of dam spillways by incorporating the deep learning method with a visual 3D reconstruction method. The lack of a real dam defect dataset and incomplete registration of minor defects on the 3D mesh model in fusion step are two challenges addressed in the paper. We created a multi-class semantic segmentation dataset of 1711 images (with resolutions of 848 × 480 and 1280 × 720 pixels) acquired by a wall-climbing robot, including cracks, erosion, spots, patched areas, and power safety cable. Then, the architecture of the U-net is modified with pixel-adaptive convolution (PAC) and conditional random field (CRF) to segment different scales of defects, trained, validated, and tested using this dataset. The reconstruction and recovery of minor defect instances in the flow surface and sidewall are facilitated using a keyframe back-projection method. By generating an instance adjacency matrix within the class, the intersection over union (IoU) of 3D voxels is calculated to fuse multiple instances. Our segmentation model achieves an average IoU of 60% for five defect class. For the surface model’s semantic recovery and instance statistics, our method achieves accurate statistics of patched area and erosion instances in an environment of 200 m${}^2$, and the average absolute error of the number of spots and cracks has reduced from the original 13.5 to 3.5. Full article

Aiming at the structural safety of the offshore wind power installation during a ship’s bottom operation, taking the wind power installation in a certain sea area of the East China Sea as an example. Water was found in the pump room of the Wind Power Installation Vessel during the bottom operation. After inspection, it was found that the ship was obviously arched, the deck was deformed, the right side of the hull had cracks in the front and rear, and the left side of the hull was bulging. According to the different draught depths of the ship, three operating conditions are selected, namely, sitting on the bottom, the highest tide level on the day of incident, and at the time of the incident. Finite element analysis on hull structural strength is carried out to find out the cause of the hull rupture and water flooding in owing to the arch-in-the-ship accident. The calculation results show that due to the large area of scouring on the bottom of the ship, the bottom of the ship is not solid, and with the alternate change of the tide, there are both middle arching and sagging phenomenon on the ship. Hence, the force acting on the ship sitting on the bottom changes periodically, resulting in large local stresses in ship structures, which is the main cause of ship accidents. Full article

Morphodynamic changes in the riverbed may be accelerated by the climate change-induced effects, mostly through the increase of the frequency of extreme climatic events such as floods. This can lead to scouring of the riverbed around the bridge substructure and consequently reduces its overall stability. In order to better understand hydromorphological processes at the local scale, the influence of floods on bridge scour requires a detailed analysis of several interacting flood hydrograph characteristics. This paper presents a multivariate analysis of the annual maximum (AM) flood discharge data at four gauging stations on the Drava and Sava Rivers in Croatia (Europe). As part of the hydrograph analysis, multiple baseflow separation methods were tested. Flood volumes and durations were derived after extracting the baseflow from measured discharge data. Suitable marginal distribution functions were fitted to the peak discharge (Q), flood volume (V) and duration (D) data. Bivariate copula analyses were conducted for the next pairs: peak discharge and volume (Q–V), hydrograph volume and duration (V–D) and peak discharge and hydrograph duration (Q–D). The results of the bivariate copula analyses were used to derive joint return periods for different flood variable combinations, which may serve as a preliminary analysis for the pilot bridges of the R3PEAT project where the aim is to investigate the influences on the riverbed erosion around bridges with installed scour countermeasures. Hence, a design hydrograph was derived that could be used as input data in the hydraulic model for the investigation of the bridge scour dynamics within the project and a preliminary methodology is proposed to be applied. The results indicate that bivariate frequency analysis can be very sensitive to the selected baseflow separation methodology. Therefore, future studies should test multiple baseflow separation methods and visually inspect the performance. Full article

The present study deals with the structural safety evaluation of a 50-year-old river bridge, called Baghetto Bridge, located in north Italy on the Adda River. Generally speaking, hydraulic processes are the main cause of bridge failure. Scour and hydrodynamic loads have been largely studied by the hydraulic engineering community; however, in practice, integration with structural analysis is often missing. The aim of this research is to provide a multidisciplinary procedure based on hydraulic and dynamic investigations devoted to the structural verification and monitoring of river bridges with traditional mechanical bearings. The deck–river interaction is addressed, studying the influence of debris accumulation on the bridge and performing structural verification of the bearing supports. The actions exerted on the bridge deck by the river current were estimated following the recommendations of the Italian code and making some further assumptions. In addition, dynamic investigations and FE modelling were performed. The results show (1) a relatively fast procedure that can be applied by practitioners to perform structural verification of river bridges with traditional mechanical bearings, and (2) an investigation method to evaluate temperature–frequency correlation as a reference for future inspections. Full article

Inspections of engineered structures below water level are essential to ensure the long-term serviceability of bridge infrastructure and to avoid major damage or failure. This research aimed to investigate integrated geophysical technologies for the underwater inspection of bridge foundation-related scour and erodible scour-based infill. Survey methods focused on Water-Penetrating Radar (WPR), supplemented by sonar. Whilst the survey benefits of the sonar imaging water–sediment interface and structures are well known, those of WPR are not. However, it is ideally suited to the survey of the water base and sub-sediment in shallow (>10 m) freshwater, especially where suspended sediment, weed infestation or methane impede sonar results. Our work produced good WPR imagery acquired from small, manoeuvrable boats that allowed bathymetric profiles to be plotted, as well as the likely locations of soft-sediment scour in future high-water flow events. This study provides clear benefits for integrated sonar and WPR surveys in the quantitative assessment of engineered structures within freshwater. Full article

Bridge health monitoring is increasingly relevant for the maintenance of existing structures or new structures with innovative concepts that require validation of design predictions. In the United States there are more than 600,000 highway bridges. Nearly half of them (46.4%) are rated as fair while about 1 out of 13 (7.6%) is rated in poor condition. As such, the United States is one of those countries in which bridge health monitoring systems are installed in order to complement conventional periodic nondestructive inspections. This paper reviews the challenges associated with bridge health monitoring related to the detection of specific bridge characteristics that may be indicators of anomalous behavior. The methods used to detect loss of stiffness, time-dependent and temperature-dependent deformations, fatigue, corrosion, and scour are discussed. Owing to the extent of the existing scientific literature, this review focuses on systems installed in U.S. bridges over the last 20 years. These are all major factors that contribute to long-term degradation of bridges. Issues related to wireless sensor drifts are discussed as well. The scope of the paper is to help newcomers, practitioners, and researchers at navigating the many methodologies that have been proposed and developed in order to identify damage using data collected from sensors installed in real structures. Full article

A spillway is a structure used to regulate the discharge flowing from hydraulic structures such as a dam. It also helps to dissipate the excess energy of water through the still basins. Therefore, it has a significant effect on the safety of the dam. One of the most serious problems that may be happening below the spillway is bed scouring, which leads to soil erosion and spillway failure. This will happen due to the high flow velocity on the spillway. In this study, an alternative to the conventional methods was employed to predict scour depth (SD) downstream of the ski-jump spillway. A novel optimization algorithm, namely, Harris hawks optimization (HHO), was proposed to enhance the performance of an artificial neural network (ANN) to predict the SD. The performance of the new hybrid ANN-HHO model was compared with two hybrid models, namely, the particle swarm optimization with ANN (ANN-PSO) model and the genetic algorithm with ANN (ANN-GA) model to illustrate the efficiency of ANN-HHO. Additionally, the results of the three hybrid models were compared with the traditional ANN and the empirical Wu model (WM) through performance metrics, viz., mean absolute error (MAE), root mean square error (RMSE), coefficient of correlation (CC), Willmott index (WI), mean absolute percentage error (MAPE), and through graphical interpretation (line, scatter, and box plots, and Taylor diagram). Results of the analysis revealed that the ANN-HHO model (MAE = 0.1760 m, RMSE = 0.2538 m) outperformed ANN-PSO (MAE = 0.2094 m, RMSE = 0.2891 m), ANN-GA (MAE = 0.2178 m, RMSE = 0.2981 m), ANN (MAE = 0.2494 m, RMSE = 0.3152 m) and WM (MAE = 0.1868 m, RMSE = 0.2701 m) models in the testing period. Besides, graphical inspection displays better accuracy of the ANN-HHO model than ANN-PSO, ANN-GA, ANN, and WM models for prediction of SD around the ski-jump spillway. Full article

Scour jeopardises the safety of many civil engineering structures with foundations in riverbeds and it is the leading cause for the collapse of bridges worldwide. Current approaches for bridge scour risk management rely mainly on visual inspections, which provide unreliable estimates of scour and of its effects, also considering the difficulties in visually monitoring the riverbed erosion around submerged foundations. Thus, there is a need to introduce systems capable of continuously monitoring the evolution of scour at bridge foundations, even during extreme flood events. This paper illustrates the development and deployment of a scour monitoring system consisting of smart probes equipped with electromagnetic sensors. This is the first application of this type of sensing probes to a real case-study for continuous scour monitoring. Designed to observe changes in the permittivity of the medium around bridge foundations, the sensors allow for detection of scour depths and the assessment of whether the scour hole has been refilled. The monitoring system was installed on the A76 200 Bridge in New Cumnock (S-W Scotland) and has provided a continuous recording of the scour for nearly two years. The scour data registered after a peak flood event (validated against actual measurements of scour during a bridge inspection) show the potential of the technology in providing continuous scour measures, even during extreme flood events, thus avoiding the deployment of divers for underwater examination. Full article

In recent years, widespread use of scanning sonars for acoustic imaging of the seabed surface can be observed. These types of sonars are mainly used with tripods or special booms, or are mounted onboard remotely operated or unmanned vehicles. Typical scanning sonar applications include search and recovery operations, imaging of underwater infrastructure, and scour monitoring. The use of these sonars is often limited to shallow waters. Diver teams or underwater remotely operated vehicles (ROV) are commonly used to inspect shipwrecks, port wharfs, and ship hulls. However, reduced underwater visibility, submerged debris, and extreme water depths can limit divers’ capabilities. In this paper, a novel, nonstandard technique for use of a scanning sonar is proposed. The new application for scanning sonar technology is a practical solution developed on the Polish Navy’s search and rescue ship “Lech.” To verify the effectiveness of the proposed technique, the author took part in four different studies carried out in the southeastern Baltic Sea. The tests were performed using the MS 1000 scanning sonar. The results demonstrate that the proposed technique has the potential to provide detailed sonar images of the seabed and underwater objects before the descent of divers. The divers get acquainted with the underwater situation, which undoubtedly increases the safety of the entire operation. Scanning sonars are unlikely to completely replace the work of divers but may reduce the number and duration of dives. The sonar use technique turned out to be useful when rescuing a crew of a submarine that crashed and settled on the sea bottom as part of a naval exercise. The sonar data obtained during four experimental tests performed in the Baltic Sea prove the validity, usefulness, and significance of the proposed technique, especially from the standpoint of safety of underwater work. Full article

In this paper, findings of a research project about river bridges in Turkey are shared and details of the developed safety-inspection method based on hydrological and hydraulic factors are presented. In the project, the Western Black Sea Basin was chosen as the pilot area, where the basin is mountainous with steep slopes and has a rainy climate with frequent flash floods. Many river bridges in the basin were inspected at different flow conditions throughout the project duration of three years. The developed safety-inspection method is composed of four main parts: evaluation of watershed hydrology and its flood potential, stream stability, bridge characteristics and a rapid scour assessment. A structural assessment is also included in the method. Five river bridges in the area were chosen for detailed inspection and application of the method. Results showed that the method was capable of identifying and ranking the bridges in regard to maintenance needs and forming a comprehensive inventory for bridge engineers. Full article
