Additive manufacturing (AM) is widely recognized as a prominent tool to maximize the potential of internal cooling systems for gas turbine applications. Several past studies have been undertaken in order to assess the effect of additive manufactured components peculiar characteristics, mainly in the form of surface roughness, on heat transfer and pressure losses. On the other hand, impingement constitutes one of the most adopted solutions for turbine vane internal cooling; also, its heat transfer performance has been shown to be potentially improved through the use of roughened target surfaces in several studies. In this work, the effect of AM-generated roughness on the performance of impingement systems has been experimentally investigated. A lumped approach was used to test additive manufactured coupons reproducing an impingement array in 1:1 scale and retrieve an average heat transfer assessment. The Laser Powder Bed Fusion (L-PBF) technique was used for the manufacturing process. As one of the main parameters affecting AM-generated roughness, the building direction of the target surface was varied in order to highlight its impact on the overall performance comparing four different building directions with a smooth reference target plate made by standard CNC machining. Full article

The causes of many bridge failures have been reported to be local scour around abutments. This study examines roughening elements as devices with which to intercept the downflow responsible for the formation of the principal vortex, which is what triggers local scour around abutments. Two vertical wall abutments with different widths were examined under four different hydraulic conditions in a clear-water regime. Elements with different thicknesses (t) and protrusions (P) with the same dimensions, (P = t = 0.05 L, 0.1 L, 0.2 L, and 0.3 L, where L is the length of the abutment) and with varying depths of installation (Z) were considered. Elements were installed in two positions: between the sediment surface and water elevation and buried within the sediment. To determine the optimum depth of installation, one element was first installed on the sediment surface, and the number of elements was increased in each subsequent test. The results show that installing elements between water surface elevation and the sediment’s initial level did not show any defined trend on scour depth reduction. However, the optimum installation depth of the elements is 0.6–0.8 L below the initial bed level. Moreover, the roughening elements with thickness and protrusion of P = t = 0.2 L resulted in the most effective protection of the foundation. The best arrangement, (P = t = 0.2 L and Z = >0.6–0.8 L) reduced the maximum scour depth by up to 30.4% and 32.8% for the abutment with smaller and larger widths, respectively. Full article

Stilling basins with sudden expansions are one of the energy dissipation structures. In the hydraulic jump, pressure fluctuations cause significant damages in stilling basins by cavity formation, erosion, and vibration. Roughness can also lead to changes of the behavior of stream lines and vortices. Despite the large number of works on the topic, the role of roughness in spatial hydraulic jumps is not yet fully understood. Present research aimed to study the influence of rough bed on pressure fluctuations of S-jump in abrupt expanding stilling basin. Experiments were conducted in a 0.8 m width and 12 m length flume. Channel expansions ratios were 0.33, 0.5, 0.67, and 1 within the range of Froude numbers, 2 to 9.5. The results showed that roughness decreases intensity of pressure fluctuations in an abrupt expansion stilling basin. Additionally, in sudden expanding sections, the energy loss increases, and the intensity of pressure fluctuations decrease due to the formation of lateral vortices. The reduction rate of maximum pressure fluctuation was 27%, 46%, and 58% for expansion ratio of 0.67, 0.5, and 0.33, respectively. The results revealed the clear dependence of these variables on the Froude number and the distance to the hydraulic jump toe. The maximum values of extreme pressure fluctuations occur in the range 0.609 < X < 3.385, where X is dimensionless distance from the toe of the hydraulic jump, which makes it highly advisable to reinforce the bed of stilling basins in this range. Full article

In the stepped spillway, the steps, by providing an artificial roughening bed, dissipate the flow of energy more than other types of spillways, so the construction costs for stilling basin are reduced. However, what is important in this type of spillway is increasing the effectiveness of steps in the rate of energy dissipation. The present study deals with experimental and numerical simulations regarding the influence of geometric appendance elements on the steps and its impact on the energy dissipation performances, flow patterns properties, turbulent kinetic energy, flow resistance and the Darcy roughness. The localization of inception point of air entrainment is also assessed. To this aim, different configurations are taken into account. The computational procedure is validated with experimental results and then used to test the hydraulic behavior of different geometric configurations. The results showed that the appendance elements on the steps increased the turbulent kinetic energy (TKE) values and Darcy–Weisbach friction and the energy dissipation increased significantly. By reducing the height of the elements, energy dissipation and the TKE value increase more significantly. With the appendance elements on step, the air entrainment inception locations a positioning further upstream than the flat step stepped spillway. Full article

In this study, the effect of the presence of bed-block roughness in an ogee spillway on energy dissipation and jet length is investigated. A series of experimental and numerical tests were conducted using an ogee spillway with block roughness on the bed without a flip bucket and with a flip bucket at different take-off angles (32 °C and 52 °C). To model the free-flow surface, the volume-of-fluid (VOF) method and turbulence model from RNG k–ε were used. Results indicated that the numerical model is fairly capable of simulating a free-flow surface over an ogee spillway; using block roughness on the spillway chute without a bucket, relative energy dissipation increased by 15.4% compared to that in the spillway with a smooth bed, while for the spillway with 32 °C and 52 °C buckets, it increased by 9.5%. The jet length for a spillway with a flip bucket and roughened bed decreased by 8% to 58% compared to that in a smooth bed. Lastly, the relationships for the estimation of relative energy dissipation and jet length are presented. Full article

The present research describes a laboratory study of hydraulic jump in the abrupt asymmetric expansion stilling basin as an energy dissipator by changing the geometry of walls and bed roughness elements. The experiments were carried out in a horizontal flume with 10 m length, 0.5 m width, and 0.5 m depth for a range of the upstream Froude numbers ( $F{r}_1$ ) from 5 to 11. Four physical models with expansion ratio of $\alpha$ = 0.33, 0.5, 0.67, and 1 and asymmetry ratio of $\Delta$ = 0.16 were installed in the flume and two different heights of roughness elements ( $h$ = 1.4 and 2.8 cm) were also considered. The results indicated that the sequent depth and the jump length as well as the roller length below abrupt asymmetric expansion on the rough bed were decreased in comparison to the same parameters of the jump in a prismatic channel with smooth bed. It was revealed that the roughness elements have the effective role on stabilization of the hydraulic jump location. The analysis of energy dissipation efficiency confirmed that the spatial jump in the abruptly expanded basin with roughened bed was more efficient than classical jump. In order to estimate the hydraulic jump characteristics, empirical relationships associated with expansion ratio of basin walls, relative height of roughness elements and upstream Froude number were proposed based on the experimental data that resulted in preliminary design of an abrupt asymmetric enlarged basin. Full article

The paper presents the results of an experimental study carried out to investigate the effect of geometric and hydraulic parameters on energy dissipation and location of the hydraulic jump, with a change in the height of roughness elements and the divergence of walls in different discharges. Experiments were conducted in a horizontal rectangular basin with gradual expansion 0.5 m wide and 10 m long. Four physical models were fixed in the flume. The measured characteristics of the hydraulic jump with different divergences ratio (B = b₁/b₂ = 0.4, 0.6, 0.8, 1) and the inflow Froude numbers (6 < Fr₁ < 12) were compared with each other and with the corresponding values measured for the classical hydraulic jump. The results showed that the tailwater depth required to form a hydraulic jump and also the roller length of the hydraulic jump and the length of the hydraulic jump on a gradual expansion basin with the rough bed were appreciably smaller than that of the corresponding hydraulic jumps in a rectangular basin with smooth and rough bed. With the experimental data, empirical formulae were developed to express the hydraulic jump characteristics relating to roughness elements height and divergence ratio of wall. Also, the applicability of some empirical relationships for estimating the roller length was tested. Full article

Large-eddy simulations (LES) of the flow over a non-uniformly roughened channel bed are carried out to study the effect of non-uniform bed roughness on turbulence driven secondary currents and turbulence statistics. The channel bed is comprised of alternating rough and smooth strips, the width of which corresponds to the water depth. The Reynolds number based on hydraulic radius and bulk velocity is 34,000. The LES are successfully validated using experimental data. The secondary flow and bed roughness have a significant effect on the streamwise velocity and second order turbulence statistics. Turbulence is enhanced over rough strips and suppressed over smooth strips. Significant lateral momentum transfer takes place due to both advection and turbulence. The bed shear stresses over the smooth strips are approximately four times less than over the rough strips a result of near bed low momentum fluid being transported from the rough strips to the smooth strips and high momentum fluid being convected from the surface towards the bed. The most significant terms in the streamwise momentum equation are quantified and discussed with regard to momentum transfer. Full article
