Search Results (59)

Gas turbines in land-based microgrids and shipboard-isolated power grids frequently face operational challenges, such as the startup and shutdown of high-power equipment and sudden load fluctuations, which significantly impact their performance. To examine the dynamic behavior of gas turbines under transitional operating conditions, a three-dimensional computational fluid dynamic simulation is employed to create a model of the gas turbine rotor, incorporating thermal inertia, which is then analyzed in conjunction with three-dimensional finite element methods. The governing equations of the flow field are discretized, providing results for the flow and temperature fields throughout the entire flow path. A hybrid approach, combining temperature differences and heat flux density, is applied to set the thermal boundary conditions for the walls, with the turbine’s operational state determined based on the direction of heat transfer. Additionally, mesh division techniques and turbulence models are selected based on the geometric dimensions and operating conditions of the compressor and turbine. The simulation results reveal that thermal inertia induces a shift in the dynamic characteristics of the rotor components. Under the same heat transfer conditions, variations in rotational speed have a minimal impact on the shift in the characteristic curve. The working fluid temperature inside the compressor components is lower, with a smaller temperature difference from the wall, resulting in less intense heat transfer compared to the turbine components. Overall, heat transfer accounts for only about 0.1% of the total enthalpy at the inlet. When heat exchange occurs between the working fluid and the walls, around 6–15% of the exchanged heat is converted into changes in technical work, with this percentage increasing as the temperature difference rises. Full article

With the increasing capacity of wind turbines, key components including the rotor diameter, tower height, and tower radius expand correspondingly. This heightened inertia extends the response time of pitch actuators during rapid wind speed variations occurring above the rated wind speed. Consequently, wind turbines encounter significant output power oscillations and complex structural loading challenges. To address these issues, this paper proposes a novel pitch control strategy combining an effective wind speed estimation with the inverse system method. The developed control system aims to stabilize the power output and rotational speed despite wind speed fluctuations. Central to this approach is the estimation of the aerodynamic rotor torque using an extended Kalman filter (EKF) applied to the drive train model. The estimated torque is then utilized to compute the effective wind speed at the rotor plane via a differential method. Leveraging this wind speed estimate, the inverse system technique transforms the nonlinear wind turbine dynamics into a linearized, decoupled pseudo-linear system. This linearization facilitates the design of a more agile pitch controller. Simulation outcomes demonstrate that the proposed strategy markedly enhances the pitch response speed, diminishes output power oscillations, and alleviates structural loads, notably at the tower base. These improvements bolster operational safety and stability under the above-rated wind speed conditions. Full article

Unlike diesel generators or energy storage systems, photovoltaic (PV) arrays lack inherent rotational inertia and have output limitations due to their operational environmental dependencies. These characteristics restrict their suitability as primary power system backbone components. This study proposes a grid-forming (GF) control strategy for PV inverters in low voltage grid (LVG) using a model predictive control (MPC) approach. The proposed method introduces a novel predictive model accounting for capacitor dynamics to precisely regulate both AC-side output voltage and DC-side voltage. Furthermore, in this paper, P-V droop control replaces the traditional frequency regulation, achieving the real-time balance of DC/AC power and seamless sharing of multiple photovoltaic power sources. By integrating a modified cost function, the controller can flexibly switch between maximum power point tracking (MPPT) mode and power reserve mode according to varying output demands. The proposed strategy can provide advanced frequency stability, MPPT accuracy, and fast dynamic response under rapidly changing solar irradiance and load conditions. Simulation and experimental tests are carried out to validate the effectiveness of the proposed strategy. Full article

Marine diesel engines face persistent challenges in balancing transient black smoke emissions and maneuverability under low-speed conditions due to inherent limitations of single turbocharger systems, such as high inertia and delayed intake response, compounded by control strategies prioritizing steady-state efficiency. To address this gap, this study proposes a dual -turbocharger dynamic matching framework integrated with a speed–pitch synergistic control strategy—the first mechanical-control co-design solution for transient emission suppression. By establishing a λ-opacity correlation model and a multi-physics ship–engine–propeller simulation platform, we demonstrate that the Type-C dual turbocharger reduces rotational inertia by 80%, shortens intake pressure buildup time to 25.8 s (54.7% faster than single turbochargers), and eliminates high-risk black smoke regions (maintaining λ > 1.5). The optimized system reduces the fuel consumption rate by 12.9 g·(kW·h)⁻¹ under extreme loading conditions and decreases the duration of high-risk zones by 74.4–100%. This study provides theoretical and practical support for resolving the trade-off between transient emissions and maneuverability in marine power systems through synergistic innovations in mechanical design and control strategies. Full article

Offshore wind turbines (OWTs) exhibit inherent directional variations in inertia, stiffness, and damping properties. This study examines the directionality effect of a 10 MW monopile-supported OWT using an integrated rotor-nacelle assembly (RNA) and support structure model. Through combined theoretical analysis and numerical simulations, this paper systematically investigates the following: (1) the anisotropic characteristics of RNA rotational inertia and blade stiffness, (2) the natural frequency and aerodynamic damping properties of the system, and (3) the directional mechanisms governing seismic responses of MOWTs during parked and running states. The key findings reveal substantial structural anisotropies. The second-order natural frequencies display a 15% disparity between fore–aft (1.43 Hz) and side–side (1.24 Hz) tower modes. The blade frequencies show over 50% differences between flap-wise (0.60 Hz/1.69 Hz) and edge-wise (0.91 Hz/2.71 Hz) modes in first-/second-order vibrations. Moreover, the aerodynamic damping ratios show marked directional contrast, with first-mode fore–aft damping (8%) exceeding side–side values (1.11%) by a factor of 7.2. Consequently, the seismic input directionality induces peak yaw-bearing bending moment variations of 38% (running condition) and 73% (parked condition). The directional effects in parked OWTs are attributed to RNA inertia anisotropy and blade stiffness disparities, while the running condition demonstrates combined influences from inherent system parameters (inertia, stiffness, aerodynamic damping) and wind–wave environmental loading. Full article

The startup dynamics of wind turbines have a direct impact on their cut-in speed and thus their capacity factor, considering highly transient winds in urban environments. Due to the complex nature of the startup dynamics, the published research on it is severely lacking. Unless the startup dynamics and cut-in speed of a wind turbine are known, it is difficult to evaluate its capacity factor and levelized cost of energy (LCoE) for commercial viability. In this study, a Savonius vertical-axis wind turbine (VAWT) has been considered and its startup dynamics evaluated using numerical techniques. Moreover, the effects of turbine inertia, arising from bearing frictional losses, generator load, etc., on the startup dynamics have been studied. Advanced computational fluid dynamics (CFD)-based solvers have been utilized for this purpose. The flow-induced rotation of the turbine blades has been modeled using a six degree of freedom (6DoF) approach. Turbine inertia has been modeled using the mass moment of inertia of the turbine rotor and systematically increased to mimic the additional inertia and losses due to bearings and the generator. The results indicate that inertia has a significant impact on the startup dynamics of the VAWT. It was observed that as the turbine inertia increased, it took longer for the turbine to reach its steady or peak operational speed. Increasing the inertia by 10%, 20% and 30% increased the time taken by the turbine to reach its peak rotational speed by 13.3%, 16.7% and 23.2%, respectively. An interesting observation from the results obtained is that an increase in turbine inertia does not change the peak rotational speed. For the Savonius rotor considered, the peak rotational speed remained 122 rpm, and its tip speed ratio (TSR) remained 0.6 while increasing the turbine inertia. Full article

Historically, a large fraction of fatigue testing of both components and structures has been performed using hydraulic actuators. These are typically driven by servo-valves, which are in themselves very inefficient. But, as most tests involve elastically stressing mechanical components, a lot of stored energy could be recovered. Unfortunately, servo-valves are not regenerative—simply metering out fluid in order to relax the system prior to the start of the next cycle. There is much to be gained with a more intelligently controlled system. The FastBlade facility in Scotland uses a new type of regenerative test hydraulics. Digital displacement pump/motors (DDPMs), originated by Artemis Intelligent Power, now Danfoss Scotland, are used to load and unload the test structure directly via hydraulic rams. The DDPMs are driven by induction motors supplied by three-phase frequency converters, each with a very loose speed correction target, such that they can speed up or slow down according to the instantaneous torque exerted by the load. The rotating assembly of the induction motor and DDPM is designed to have sufficient inertia so as to function as a kinetic energy storage flywheel. The loading energy is then cyclically transferred between the rotating inertia of the motor/DDPM and the spring energy in the test structure. The electric motor provides sufficient energy to maintain the target average cyclical shaft speed of the DDPM whilst the bulk of the system energy oscillates between the two storage mechanisms. Initial tests (at low load) suggest that this technique requires only 30% of the energy previously needed. FastBlade is a unique facility built by the University of Edinburgh and Babcock, with support from the UK EPSRC, conceived as a means of testing and certifying turbine blades for marine current turbines. However, this approach can be used in any cyclical application where elastic energy is stored. Full article

A numerical method using advanced nonlinear shear is used to study the thermal vibration of functionally graded material (FGM) thick circular cylindrical shells. The third-order shear deformation theory (TSDT) of displacements is applied and the equations are derived of the motion of cylindrical shells and the expression of the advanced nonlinear varied shear factor. The expressions of stiffness of thick composited two-layer FGM circular cylindrical shells with sinusoidal rising temperature are applied. The partial differential equation (PDE) in dynamic equilibrium of thick FGM circular cylindrical shells is derived with respect to shear rotations and displacements under terms of thermal–mechanical loads and density inertia terms. Important parametric effects of the advanced nonlinear varied shear factor, power law index, and temperature on the stress and displacement of thick FGM circular cylindrical shells are studied. Additionally, the advanced nonlinear varied shear factor effect is included and studied for a vibrating frequency using a fully homogeneous equation. Full article

This paper proposes a beam model integrating the Timoshenko beam theory with Vlasov beam theory to capture the coupled behavior of bidirectional bending, torsion, and axial vibration in thin-walled beams subjected to axial loads. Our model incorporates the effects of shear deformation, rotational inertia, and axial loads, offering a comprehensive approach to complex dynamic behaviors. By utilizing Hamilton’s principle, we derived a complete set of coupled dynamic equations and boundary conditions. The highlight of this model is its capacity to accurately predict the dynamic response of thin-walled beams under multifaceted loading conditions, surpassing traditional models by integrating coupled axial vibrations. This research significantly advances the understanding of the dynamic behavior of thin-walled beams, providing a precise analytical tool for structural design and safety assessment. The robustness and accuracy of the proposed model were validated through extensive theoretical analysis and empirical validation, equipping engineers with critical insights to optimize the design of engineering structures subjected to complex dynamic loads. Full article

In this paper, the design of a driving mechanism for a heavy-duty collaborative robot (cobot) capable of lifting payloads up to 20 kg is presented. This study focuses on an articulated robot utilizing a water-based Electro-Hydraulic Actuator (EHA). The Denavit–Hartenberg (D–H) representation was employed to relate the rotational angles and the end-effector’s location, facilitating the design of the actuators. The maximum required torques for joints 2 and 3, responsible for lifting for 12 s, were calculated under quasi-static and dynamic loading conditions. The results showed that the maximum required torques were 126.67 Nm and 58.86 Nm for joint 2 and 3, respectively. The maximum torque for joint 2 occurs when the pitch links are fully extended, whereas the maximum torque for joint 3 occurs when the third link is parallel to the ground. The torques, due to the inertia and Coriolis dynamic terms, were also calculated and found to be lower than those required for the gravitational term. Various maneuvering scenarios, along with Ansys Motion simulation, were analyzed for the verification of the results. Based on the calculated maximum torques, the linear actuators of the EHA were designed. The heavy-duty cobot can be built with the developed actuator proposed in this paper. The total weight of the entire frame was measured to be 14.59 kg, resulting in a high Payload/Weight (P/W) ratio of 1.37. In conclusion, the robot was made lighter and can operate more efficiently, particularly for heavy loads up to 20 kg. Full article

For floating offshore wind turbines, a significant pitch and roll motion response of the platform can affect the acceleration and power generation of the nacelle. The damping plate is considered a type of attachment that can be used to reduce rotational motion, but research on its anti-rotational effect is limited. The objective of this work is to analyze the impact of installing damping plates and varying their sizes on the pitch motion response of semi-submersible platforms, while also proposing optimization strategies for damping plate design. Firstly, a comparison between numerical simulations and experimental measurements validates the accuracy of the CFD calculations. Subsequently, different sizes of damping plates are proposed for the platforms, followed by simulations under various conditions. Finally, comprehensive data analysis is conducted. The findings suggest that installing damping plates enhances both the platform’s added moment of inertia and damping coefficients while simultaneously amplifying its motion response in regular waves. Furthermore, increasing the size of damping plates leads to an increase in both the added moment of inertia and motion response for the platform, whereas the damping coefficient exhibits an initial increasing trend followed by a subsequent decrease. Ultimately, it is found that increasing the distance between damping plates and the free surface significantly reduces wave-induced loads on the platform. Full article

Grid-forming inverters (GFMIs) have been identified as critical assets in ensuring modern power system reliability. Their ability to synthesize an internal voltage reference while emulating synthetic inertia has sparked extensive research. These characteristics have recently piqued interest in their capacity to provide blackstart ancillary services. The blackstart of a bulk power system poses significant challenges, namely the large transients from the energization of unloaded transformers, rotational motor loads, and long transmission cables, which have been effectively studied using conventional synchronous generators (SGs). The concept of an inverter-based resource (IBR)-based blackstart continues to be an open research area necessitating further investigations due to the known limitations of IBRs such as low short-circuit current capabilities. This paper presents a blackstart case study of a bulk power system investigating the performances of a conventional SG to a GFMI when utilizing hard switching methods. The paper qualitatively investigates the transient inrush currents from the transformer and rotational load energization sequences. Additional examinations into the significance of the GFMI’s current-limiting schemes and voltage control loop compensator gains are presented. Furthermore, the harmonic distortions from the transformer energization sequence are also evaluated. Finally, a full network energization case is presented to demonstrate how both sources can provide blackstart provisioning services. The models are developed in EMTDC/PSCAD using real-world transmission planning data. Full article

In mini-grids and marine-isolated grids, power generation gas turbines are subjected to rapid start-up, shutdown, and acceleration/deceleration. This sudden load change can pose a significant impact on the power grid, severely affecting the operational characteristics of gas turbines. To understand the dynamic characteristics of the gas turbine in the transitional processes, this testing takes twin-shaft medium-sized power generation gas turbines as the test object, and goes through the process of startup, acceleration, deceleration, acceleration, shutdown in one hour, and repeats this process 40 times continuously. With fuel flow as the control parameter and power turbine outlet temperature and high-pressure turbine speed as the controlled parameters, the parameter response rate of the gas turbine under various transition processes is analyzed and the effect of thermal inertia on the gas turbine mass temperature as well as speed is studied. Research findings: During the transition processes, the gas temperature exhibited an axial gradient distribution in the channel. In both the acceleration and deceleration processes, the working fluid temperature gradually decreased along the flow direction. And thermal inertia posed different extents of impact on the dynamic characteristics of the gas turbine under different transitional processes. In the same transition process, the impacts of thermal inertia on the response speeds of temperature and rotational speed varied. The results of this study help to more accurately predict the operating state of the gas turbine during the transition process and lay the foundation for the dynamic simulation model of the non-adiabatic gas turbine. Full article

The paper relates to the development of an algorithm applicable for maintaining the rotational speed of low-speed drives using PMSM motors and operating under a sign-changing load. The moment of inertia of rotating parts does not play the role of a mechanical stabilizer for the speeds discussed in the article. Simulation studies are presented with the aim of developing a rotational speed control algorithm that utilizes only positional feedback and the previously assumed sign-changing load on the shaft. For the purposes of this research, a mathematical model was developed to calculate transient processes in a PMSM machine operating in the conditions of a sign-changing load on the shaft. This model assumes a deterministic control principle adapted to the known nature of the load change. In this model, the mutual influence occurring between the phase fluxes, the electromagnetic torque, the electric currents and the rotor position angle are established on the basis of FEM analysis of a two-dimensional magnetic field using a quasi-stationary approximation. Principles applicable for controlling a direct low-speed servo drive based on a PMSM machine operating with a known variable shaft load using only positional feedback and a predetermined shaft load change law are defined. The proposed regulation method is verified in an experimental manner. For this purpose, an experimental setup was built, which includes a PMSM with a load imitator on a variable sign shaft, an inverter providing sine-shaped power supply to the machine and a digital dual-processor control system. The discussed rotational speed stabilization algorithm was implemented in the form of a program for a microcontroller, which forms a part of the control system. The results of experimental tests confirm the adequacy of mathematical modeling and the effectiveness of the proposed rotational speed stabilization algorithm. Full article

Asymptotic analysis for an elastic layer under light fluid loading was developed. The ratio of fluid and solid densities was chosen as the main small parameter determining a novel scaling. The leading- and next-order approximations were derived from the full dispersion relation corresponding to long-wave, low-frequency, antisymmetric motions. The asymptotic plate models, including the equations of motion and the impenetrability condition, motivated by the aforementioned shortened dispersion equations, were derived for a plane-strain setup. The key findings included, in particular, the necessity of taking into account transverse plate inertia at the leading order, which is not the case for heavy fluid loading. In addition, the transverse shear deformation, rotation inertia, and a number of other corrections appeared at the next order, contrary to the previous asymptotic developments for fluid-loaded plates not assuming a light fluid loading scenario. Full article
