Search Results (306)

Grinding is the final precision machining step for bearing rings, which induces subsurface gradients in microstructure and mechanical properties. Rolling contact fatigue life and service reliability are directly determined by the gradients. Current research of the grinding metamorphic layer in bearing steels is synthesized in this review. The formation mechanisms, characterization approaches, and the influence of grinding parameters on metamorphic layers is covered. The coupled thermal–mechanical–phase transformation framework encompasses heat-driven phase transformation, high-strain-rate gradient plastic deformation, and their interactions, which collectively govern the formation of the three-layer gradient structure. When the surface temperature exceeds the austenitization threshold, the governing regime shifts from mechanically dominated to thermally dominated, producing an abrupt increase in white layer thickness and concurrent dark layer softening. The capabilities and limitations of characterization techniques for probing the gradient microstructure and residual stress profile are evaluated. The influence of grinding depth, wheel speed, feed rate, wheel characteristics, and cooling conditions on the metamorphic layer is analyzed. The areas requiring deeper investigation are identified. These insights aim to establish correlations between the grinding process and the surface integrity and service performance of bearing components, and to provide directions for future research on the grinding metamorphic layer. Full article

Octopus arms combine a compliant continuum body with distributed suckers, providing a biological reference for soft manipulators that require large deformation and stable local contact. Inspired by this functional organization, this study presents an octopus-inspired two-segment pneumatic soft manipulator with passive suction cups at the distal end. The manipulator consists of a cylindrical proximal segment, a tapered distal segment, and a thermoplastic polyurethane (TPU) suction-cup array. The proximal segment provides structural support and global bending, whereas the tapered distal segment improves local compliance and contact posture adjustment near the target surface. Each segment contains three independently driven pneumatic chambers arranged at 120° intervals, enabling spatial bending through differential pressurization. The distal suction cups are not connected to an active vacuum source; instead, attachment is assisted by mechanical pressing, partial air expulsion from the cup cavity, and elastic recovery of the cup lip. Finite element simulations were conducted to examine pressure-driven bending of the soft arm and deformation of the suction cups under equivalent sealing loads. A piecewise constant curvature model was established to estimate the posture and reachable workspace of the two-segment manipulator. A prototype was fabricated and tested on a pneumatic control platform. Within the pressure range of 50–200 kPa, both segments exhibited increasing bending angles with increasing input pressure; at 200 kPa, the maximum observed bending angles were approximately 70° for the proximal segment and 87° for the distal segment. Distal-segment tests demonstrated passive contact holding on a brown glass bottle and a black roll of electrical tape. Coordinated actuation further produced compound bending and twisting postures. These results show that the proposed design translates the functional division of octopus arms into a modular pneumatic soft manipulator with controllable spatial deformation and passive distal contact support. Full article

While the beneficial effect of residual compressive stress (RCS) on rolling bearing fatigue life is empirically well-established, the underlying mechanisms, particularly its influence on the subsurface stress field responsible for fatigue initiation, remain inadequately explored. This study employs a sophisticated finite element (FE) model of a ball–raceway contact, which incorporates a depth-dependent gradient of RCS, to elucidate the underlying mechanisms. The results demonstrate that RCS not only reduces the contact stress at the interface but also fundamentally alters the subsurface stress field by shifting the location of the maximum shear stress to a greater depth and reducing its inclination angle. These changes collectively delay crack initiation and propagation, explaining the observed enhancement in fatigue life. Furthermore, the study demonstrates that the beneficial effect of RCS is depth-dependent and persists significantly even under high-friction conditions. Full article

Surface-dominated failures such as micropitting, scuffing, and rolling contact fatigue remain critical challenges for 20CrMnTi gear steel under high-stress and poor lubrication conditions. Inspired by the composite bionic “checkerboard + dot-matrix dimple” architecture found in natural surfaces, this study aims to develop an optimized biomimetic texture combined with a graphene solid lubricant coating to enhance the tribological performance of 20CrMnTi alloy. Laser surface texturing was employed to fabricate the bionic pattern on 20CrMnTi substrates, followed by deposition of an oxysilane-graphene coating. Reciprocating ball-on-disc tribological tests were conducted under both dry friction and oil-lubricated conditions. The results showed that under dry friction, the optimized textured and coated specimen achieved an average friction coefficient of ~0.18, representing a ~62% reduction compared to the untextured surface (~0.47). Under oil lubrication, the friction coefficient was further reduced to ~0.10–0.11, demonstrating a synergistic effect among the texture, graphene coating, and lubricant. Wear volume decreased by over 70% under dry conditions. The dominant wear mechanism shifted from severe adhesive–abrasive–oxidative wear to mild adhesive and abrasive wear. These findings suggest that the proposed composite bionic texture combined with a graphene coating offers an effective strategy for improving the tribological durability of 20CrMnTi gear. Full article

Tribological systems involving rolling and sliding contacts generate coupled mechanical interactions that govern friction, wear, and surface degradation. These interactions produce multiaxial residual stresses that influence crack initiation, accelerate wear, and promote environmentally assisted damage. In corrosive environments, tribo-corrosion further intensifies material degradation through the combined action of mechanical wear and electrochemical reactions. Protective organic and metallic coatings are widely used to mitigate these effects; however, their performance depends on adhesion, stress evolution, and resistance to coupled mechanical and chemical degradation. Among the principal failure mechanisms, cathodic blistering is strongly influenced by diffusion, interfacial stresses, and tribological loading. This review therefore links cathodic blister evolution with coating degradation under combined tribological and corrosive conditions. The review critically examines the Khan–Nazir meso-mechanics Models I, II, and III, which integrate stress-assisted diffusion, residual stress development, mixed-mode fracture, and coating–substrate delamination. Recent developments have extended these models through substrate deformation, multilayer coating architectures, and electro-chemo-mechanical phase-field simulations. The models demonstrate how diffusion-induced and residual stresses interact with tribological loading to initiate and propagate interfacial defects. The analysis shows that blister evolution is primarily governed by elastic modulus mismatch and friction-induced stress fields, while stability criteria predict non-axisymmetric blister morphologies associated with buckling and delamination. Overall, this review highlights the significance of the Khan–Nazir models for understanding wear, friction, and coating durability in engineering systems. The unified framework provides valuable guidance for the design and optimisation of advanced multilayer protective coatings for marine, automotive, energy, and manufacturing applications operating under rolling/sliding contact and tribo-corrosion environments. Full article

Amphibious robots must reconcile two distinct mechanical requirements within a compact locomotion architecture. Terrestrial operation requires limb structures with sufficient load-bearing capacity, contact stability, and bending resistance, whereas aquatic operation benefits from a larger projected area for drag-based thrust generation. Conventional amphibious platforms often address these requirements by combining separate land and water propulsion modules, which increases structural redundancy, system mass, and hydrodynamic resistance. To reduce this conflict at the structural level, this study proposes a bioinspired origami morphing limb based on a modified Yoshimura pattern. The limb transforms between a closed cylindrical configuration for terrestrial support and an unfolded planar configuration for aquatic paddling. A vertex-splitting topology and thick-panel geometric constraints are introduced to suppress the bifurcation instability associated with the zero-thickness Yoshimura vertex, thereby obtaining a deterministic single-degree-of-freedom folding path suitable for robotic actuation. A screw-theory-based kinematic model is established to relate the active driving angle to the passive folding angle, and geometric parameter analysis is used to connect the folding state with load-bearing and paddling morphologies. A quadruped amphibious robot prototype is fabricated using rigid polylactic acid panels and flexible thermoplastic polyurethane hinges. Prototype-level observations qualitatively demonstrate reversible transformation within the tested operating range and show walking, crawling, rolling, water-entry, and underwater locomotion modes. Full article

Intumescent coatings are widely used to enhance the fire resistance of structural steel. In contrast to traditional fire protection methods, this novel flexible intumescent protection offers several key advantages: universal compatibility with other coatings (via non-contact wrapping), resistance to extreme temperatures (−60 °C to +90 °C), all-weather usability, and suitability for light-gauge cold-formed thin-walled steel structures. This paper describes the development and investigation of these fire-protective, flexible intumescent coatings based on eco-friendly binders (silicone polymers and acrylic resins) with varying intercalated graphite (IG) content from 0% to 40%. An IG content of 25–40% enables a steel I-section with a section factor of 294 mm⁻¹ to reach its limit state at 44 min (compared to 15 min for unprotected steel). Fire tests on steel beams with a section factor of 172 mm⁻¹ demonstrated that samples reached the deflection limit state at the 64th and 66th minutes, respectively. Thermogravimetric analysis (TGA) was used to determine the temperature ranges for the thermal decomposition and expansion of the IG. Mechanical property studies revealed the influence of IG on the elastic modulus and tensile strength. Accelerated climatic testing in moderately cold conditions and salt spray chamber tests confirmed that the intumescent roll coating has no negative impact on the steel substrates. Full article

A transient multibody dynamics simulation of rolling-element bearings is the basis for the design of high-speed rotating machinery; however, the established solvers are proprietary, cannot be used with automatic differentiation, and offer no built-in measure of their own physical consistency. We present OpenBEARD, an open-source, fully differentiable transient dynamics solver for angular-contact ball bearings. The solver steps a $40+13Z$-component state (inner ring, cage, and Z balls with quaternion attitude, plus guide-patch, lumped-thermal, and energy-audit states) forward in time under coupled Hertzian contact, Hamrock–Dowson and full-multigrid elastohydrodynamic lubrication, thermal–elastohydrodynamic traction, and centrifugal/press-fit clearance models, using nondimensionalized implicit stiff time integration. A built-in metriplectic conservation audit checks energy closure, the second law per dissipation channel, and the gyroscopic-power identity at every output step. OpenBEARD is cross-verified against two published ADORE references of Gupta. For a high-speed NASA angular-contact ball bearing, the quasi-static contact loads, angles, stresses, and centrifugal force match the published values to within $0.3\%$, and the ball spin and orbital velocities and the spin-axis orientation to ≤0.1%. The inner-race spin-to-roll ratio—a slip-derived secondary quantity that is the most model-sensitive metric in this class of solvers—differs from the NASA quasi-static reference by $8.8\%$. In the separate caged BallBearingTestCase benchmark, the corresponding quasi-static difference is $3.2\%$, and the transient settled value is $\approx 16\%$ above the ADORE step-100 snapshot; these bounded offsets reflect different spin-moment constitutive models. The BallBearingTestCase comparison—a caged bearing under combined thrust and radial load—matches the per-ball contact angles and loads to within $0.23\%$ RMS, and a single published dynamic snapshot (step 100) agrees with the transient contact mechanics to within a few percent. The built-in energy-closure residual stays of order ${10}^{-5}$ with no second-law violations. In the fully transient regime, race control emerges as a dynamical attractor of the coupled traction balance—ball-spin states perturbed by $\pm 12\%$ converge to a single outer-race-control solution—rather than the kinematic hypothesis assumed by quasi-static theory. OpenBEARD is released under the MIT license. Full article

In response to the vibration and noise issues of metro vehicles, this article uses a resilient wheel. The finite element method (FEM) and the boundary element method (BEM) were employed to establish the vehicle-track coupled rolling contact model and the acoustic boundary element model. The reliability of the acoustic boundary element model was verified by comparing simulation results with field measurement data. The effects of different structures on wheel-rail forces and noise were investigated. Compared with a standard wheel, the resilient wheel significantly reduces vibration and noise. The influence of rubber with or without clearances on resilient wheel vibration and noise was further analyzed. Results show that in the 2000–5000 Hz frequency band, the resilient wheel reduces wheel noise by 6–10 dB(A), rail noise by approximately 5 dB(A), and total wheel-rail rolling noise by 5–8 dB(A). The physical mechanisms underlying the vibration and noise reduction performance of the resilient wheel are elucidated, and high-frequency operating noise is examined. Full article

Accurate discrete element simulation parameters for the mechanically harvested cotton stalks and cotton residues mixture are currently unavailable. This lack hinders the effective design and optimization of equipment for separating and recovering cotton residues from the mixture. This study focused on the cotton stalks and cotton residues mixture. The intrinsic parameters of cotton residues were measured through physical experiments. Using the inclined plane and collision methods, the coefficients of restitution for cotton residues–cotton stalks and cotton residues–steel were determined to be 0.228 and 0.364, respectively. The corresponding static friction coefficients were 0.632 and 0.266, and the rolling friction coefficients were 0.199 and 0.156. The Hertz–Mindlin with JKR contact model was employed. Combined with repose angle tests, the coefficient of restitution, rolling friction coefficient, static friction coefficient, and surface energy for cotton residues–cotton residues were calibrated as 0.393, 0.140, 0.742, and 1.471 J/m², respectively. A vibrating spreading test was conducted to validate the calibrated parameters. The proportion of cotton residues on the material surface was used as the test index. The mean relative error between simulation and physical test results under four working conditions was 4.91%. The results indicate that acceptable consistency is achieved between simulation and experimental results under the tested conditions, and the calibrated discrete element parameters are applicable for the simulation of cotton stalk–cotton residue mixture systems. This study provides a theoretical basis and data support for the development of equipment to separate and recover cotton residues from cotton stalk and cotton residue mixtures. Full article

Pearlitic wheel steel subjected to thermal–mechanical fatigue (TMF) during braking can undergo catastrophic fracture. This study clarifies the microstructural evolution governing the macroscopic cyclic hardening/softening behavior of pearlitic wheel steel under thermal–mechanical fatigue (TMF) with a constant mechanical strain range of −0.4% to +0.2%. At lower temperature amplitudes (200–500 °C), the geometrically necessary dislocation (GND) density reaches 20.4 × 10¹⁴/m² during initial cycles, corresponding to cyclic hardening due to dislocation pile-ups at cementite lamellae interfaces. With increasing cycles, the GND density decreases to 12.3 × 10¹⁴/m², concurrent with softening arising from lamellar bending/fracture, partial spheroidization, and dynamic recrystallization of ferrite. At higher temperature amplitudes (200–730 °C), the GND density decreases from 8.8 × 10¹⁴/m² to 3.5 × 10¹⁴/m², reflecting sustained cyclic softening dominated by thermally activated mechanisms, including cementite spheroidization and dislocation annihilation. The resulting softened microstructure consists of ferrite grains, intragranular dispersed cementite, and chain-like coarse cementite at boundaries. Unlike previous studies that focused on single loading conditions (e.g., thermal fatigue, rolling contact fatigue, or wear), the present work addresses the more complex TMF scenario and quantitatively elucidates the interplay between mechanical response and microstructural evolution in pearlitic steel. This work provides theoretical guidance for the development of a fatigue life prediction model for pearlitic wheels under braking. Full article

Accurate quantitative diagnosis of spall sizes in rolling bearings is often hindered by the limitations of conventional dynamic models in characterizing temperature-dependent contact behavior. To address this issue, this paper presents a quantitative diagnosis method that incorporates point-contact thermo-elastohydrodynamic lubrication (TEHL) characteristics into a classical bearing dynamic framework. Specifically, rather than using prescribed or constant contact parameters, an improved equivalent stiffness–damping representation of the bearing contact interface is formulated based on TEHL-derived oil-film pressure, thickness, and temperature, while taking into account the inner–outer raceway thermal asymmetry. This localized lubricated contact representation is subsequently integrated into a classical five-degree-of-freedom (5-DOF) dynamic model to evaluate the double-impact response caused by outer-ring spalls. Comparative simulations using conventional 5-DOF, 4-DOF, and 2-DOF models, alongside experiments on a 6205-2-RS bearing with a 0.6 mm outer-ring defect, validate the proposed method. The results demonstrate that utilizing the TEHL-derived stiffness–damping representation significantly reduces spall-size estimation errors, improving both the accuracy and the physical interpretability of bearing fault quantification under thermally coupled conditions. Full article

To address the complex and highly variable wheel–rail adhesion behavior on high-speed railway curves, this study establishes a numerical wheel–rail rolling contact model based on starved elastohydrodynamic lubrication (EHL) theory and Herschel–Bulkley rheological characteristics. The model validation yielded RMSE = 0.0228, MAE = 0.0217, MAPE = 11.80%, R² = 0.828, and a 95% confidence interval of the mean residual of −0.0298 to −0.0136. The study focuses on the initial operational phase after application, systematically quantifying the fluid-dynamic regulation mechanisms of water-based friction modifiers once a thin, starved lubricating film has been formed on the rail surface under curving conditions. By analyzing rail profiles (CHN60 and CHN60N), operating parameters, and track geometry, this study shows how adhesion behavior on curved track sections is governed by the coupled effects of contact mechanics and lubrication. As the outer rail superelevation increases from 0 to 70 mm, the adhesion coefficient decreases by approximately 15–25%, mainly because the reduced normal force shifts the wheel–rail interface toward the Stribeck transition regime. Increasing axle load from 14 t to 30 t reduces the dimensionless film thickness, but the enlarged contact area contributes to a more stable adhesion level, with an increase of about 12%. Compared with the CHN60 profile, the CHN60N profile exhibits better geometric conformity, producing a lubricating film that is 10–15% thicker and leading to a lower and more stable adhesion coefficient, decreasing from approximately 0.35 to 0.1. The results also identify a critical lateral displacement of around −4 mm, beyond which the contact radius becomes stable and the adhesion coefficient reaches a minimum plateau. These findings clarify the competing effects of fluid entrainment and metallic asperity contact, and provide quantitative guidance for friction management and friction modifier application on curved track sections. Full article

This study comparatively evaluated Raydent (here interpreted as a standard black chrome-type industrial condition in the present specimen context), DLC, and SiO₂ coatings for high-precision LM-guide applications as an application-oriented initial screening study. The emphasis was placed on dimensional preservation, surface integrity, and mechanical surface response rather than on complete coating-mechanism validation. Cross-sectional FE-SEM, EDS, Vickers hardness testing, surface profilometry, AFM, and SEM analyses were conducted to compare coating thickness, composite surface hardness, roughness, and morphology, and the influence of plasma pretreatment on the SiO₂ system was additionally investigated. Among the investigated coatings, SiO₂ exhibited the smallest thickness (1.03 μm), highest composite surface hardness (719.8 HV), and lowest average roughness (213.5 nm), suggesting favorable dimensional compatibility and surface integrity under the tested conditions. Plasma pretreatment increased the EDS-detected Si signal from 0.77 to 2.81 wt% and improved the composite surface hardness from 580 to 720 HV, suggesting an altered near-surface response and improvement in coating formation during pretreatment-assisted processing. AFM and SEM observations further indicated that the SiO₂ coating provided a more uniform and flatter surface morphology on the coupon specimens, whereas the DLC specimen prepared under the present commercial condition showed localized protrusions that may be associated with initial local contact disturbance. The comparative results suggest that SiO₂ coatings provide a favorable balance of thickness control, surface uniformity, composite surface hardness, and roughness for precision LM-guide applications. Although additional rolling-contact durability, adhesion, wear, friction-coefficient, and rolling-contact-fatigue studies are still required, the present findings should be interpreted as an initial screening result indicating that SiO₂ is a candidate coating condition for further engineering consideration in precision motion-guide systems, rather than as a direct validation of full tribological or long-term durability performance. Full article

End-to-end motion control of 7-degree-of-freedom (DOF) redundant manipulators under sparse reward signals presents a fundamental challenge in deep reinforcement learning (DRL) for robotics: the vast configuration space and absence of dense gradient information combine to produce severe cold-start failures and high cross-seed training variance. This paper proposes Curriculum-SAC-HER, a novel fusion framework integrating Soft Actor–Critic (SAC), Hindsight Experience Replay (HER), and a performance-driven three-stage Automatic Curriculum Learning (ACL) scheduler, designed to resolve the cold-start exploration bottleneck within a training budget of 300,000 environment interaction steps. The core methodology progressively expands the spatial target distribution across three stages of increasing difficulty, conditioning each stage transition on an 80% rolling success threshold to guarantee kinematic prior consolidation before advancing. A rigorous evaluation across 15 independent training runs (five seeds per group, all retained without filtering) demonstrates that the proposed framework achieves a final mean success rate of 84.8% (std: 11.0%), substantially surpassing the SAC + HER ablation (70.3%, Mann–Whitney U test, p = 0.028) and the DDPG baseline (22.3%, p = 0.008), while compressing cross-seed variance by 67% relative to the ablation. Zero-shot robustness evaluations under simulated domain perturbations further reveal that the learned policy maintains above 92% success across extreme friction variations and sustains 71.8% success under a 1.5× payload increase, demonstrating that the ACL module fosters generalized kinematic representations rather than over-fitting to specific contact mechanics. Full article
