Currently, resin polymer anchoring agents are widely used for bolting support in coal mine roadways to anchor the bolts to the surrounding rock mass. However, due to the relatively low strength of the resin anchoring agent itself, the required anchoring length tends to be excessively long. Based on this, this paper proposes the use of resin concrete as a replacement for resin. Compared to resin anchoring agents, resin concrete offers greater mechanical interlocking force with anchor rods, which can reduce the theoretical anchoring length. To systematically investigate the influence of factors such as the diameter and anchorage length of Glass Fiber-Reinforced Polymer (GFRP) bolt on the bond behavior between GFRP bolts and resin concrete, 33 standard pull-out tests were designed and conducted in accordance with the CSA S807-19 standard. Taking the 18 mm-diameter bolt as an example, when the bond lengths were 2D, 3D, 4D, and 5D, the average bond strengths were 41.32 MPa, 39.18 MPa, 38.84 MPa, and 37.44 MPa, respectively. This represents a decrease of 5.18%, 6.00%, and 9.39% for each subsequent increase in bond length. The results indicate that the bond strength between GFRP anchors and resin decreases as the anchorage length increases. Due to the shear lag effect, the average bond strength also decreases with increasing anchor diameter. Taking a 5D (where D is the anchor diameter) anchorage length as a reference, the average bond strengths for anchor diameters of 18 mm, 20 mm, 22 mm, and 24 mm were 37.44 MPa, 33.97 MPa, 32.18 MPa, and 31.50 MPa, respectively. The corresponding reductions compared to the 18 mm diameter case were 9.27%, 14.05%, and 15.87%. Based on the experimental results, this paper proposes a bond–slip constitutive model between the bolt and resin concrete, which consists of a rising branch, a descending branch, and a residual branch. A differential equation relating shear stress to displacement was established, and the functions describing the variation in displacement, normal stress, and shear stress along the position were solved for the ascending branch. Although an analytical solution for the differential equation of the descending branch was not obtained, it will not affect the subsequent derivation of the theoretical anchorage length for the GFRP bolt–resin concrete system, as structural components in practical engineering are not permitted to undergo excessive bond-slip. Full article

The disadvantages of traditional bolt support technology relying too much on engineering experience in slope engineering in China are becoming more and more obvious. Aiming at this problem, this paper establishes an intelligent bolt pull-out test system based on the Internet of Things, monitors the whole process of a bolt pull-out test, determines the ultimate pull-out bearing capacity, and grasps the friction of a bolt in real time. Based on the local common deformation theory, the force of the bolt is analyzed theoretically. The results show that the stress process of bolt rod end tension–rod end displacement is divided into quasi-elastic stage, strengthening stage and failure stage. The stress history of bolts with different anchorage lengths is the same, but the curve shape changes from steep to slow with the increase in anchorage length. Increasing the length of the long bolt can increase the ultimate pull-out bearing capacity of the bolt. Full article

Strengthening lapped spliced reinforced concrete (RC) beams using tiny-diameter steel wires as near-surface-mounted (NSM) rods has not been carried out previously. Thus, the purpose of this work is to examine the behavior of RC beams with insufficient lap splices that are strengthened by NSM steel wires with different schemes to improve durability, efficiency, and effectiveness. At the middle of the beam, a splice length equal to 25 times the diameter of the rebar was used to join two tension bars. Many different schemes were implemented in strengthening the splice region, such as attaching longitudinal wires to the sides and/or bottom of the beam in different quantities with/without end anchorage, placing perpendicular and inclined U-shaped wires at the splice region in different quantities, and implementing a network of intersecting and opposite wires in two different directions. The effect of variables on the behavior of strengthened beams was studied. The findings proved that when the longitudinal wire reinforcement-to-lapped rebars area ratio was 9.4%, 18.7%, and 28%, the ultimate load of the beams was improved by 15.71%, 71.43%, and 104.57%, respectively. When the transverse U-shaped wire reinforcement ratio was 0.036, 0.051, 0.064, 0.075, and 0.150, the ultimate load of the beams was improved by 3.7%, 20%, 31.4%, 50%, and 80%, respectively, and the ultimate deflection was enhanced by 2%, 32%, 19%, 67%, and 62.4% compared to the unstrengthened beam. Full article

This research aimed to detect the defects of anchoring agents’ empty slurries in anchor support. The influence of anchoring defects on the propagation law of stress waves was comprehensively investigated using laboratory tests, theoretical calculations, and other methods. The characteristic modal components with symmetry and periodicity laws were extracted by adopting a variable modal decomposition (VMD) signal decomposition method. It was found that the bottom reflection time of stress waves had an inverse function relationship with the length of the anchorage flaw. The average propagation speed of the stress wave in the free rod was obtained as 5150 m/s, and the average consolidation wave speed was 4198 m/s. The calculation method of the bolt flaw length was finally proposed. After experimental verification, the average error rate was 2.65%, which meets the requirement of testing accuracy in the engineering field, which provides a guarantee for safe production. Full article

Aiming at solving the problem of support failure caused by a large deformation of roadway surrounding rock in a deep soft coal seam, and taking the surrounding rock control of the roadway in the 11-2 coal seam in Zhujidong Coal Mine as the research background, numerical simulation and field industrial test and inspection methods were used to study the support effect of a supporting system of gob-side entry in deep soft coal seam. The deformation characteristics of various supporting systems of metal mesh, diamond mesh, metal mesh with anchor rod, steel ladder beam, M-shaped steel belt, 14#b channel steel, and 11# I-steel in the goaf supporting body of deep soft coal seam were studied under vertical load. The supporting effect of effective compressive stress zone generated by bolt and cable under different row spacings and lengths was analyzed, and the law of variation in the compressive stress field generated by supporting members with supporting parameters was explored. The length and interrow distance of bolt and cable were compared, respectively, and reasonable supporting parameters were selected. Based on the abovementioned research results and the geological conditions of the 1331 (1) track roadway, the support scheme of the 1331 (1) track roadway was designed, and the industrial test was carried out. The results show that the surrounding rock of the roadway is within the effective anchorage range of the supporting body, the active support function of the supporting components has been fully brought into play, and the overall control effect of the surrounding rock of the roadway is good, which can ensure the safety and stability of the goaf roadway. The maximum displacement of the roof and floor of the roadway is 86 mm, the maximum displacement of the solid coal side is 50 mm, the maximum displacement of the coal pillar side is 70 mm, and the maximum separation of layers is 22 mm. There is no failure phenomenon in relation to the anchor bolt and cable, and the overall deformation of the roadway surrounding the rock is good, which can provide some references for roadway-surrounding-rock control under similar conditions in deep coal seams. Full article

A new moment-resisting mass timber connection was designed based on the principles of force equilibrium in applied mechanics. The connection configuration utilizing two mechanically fastened threaded steel rods embedded into the end of a glulam beam section was experimentally investigated in this study. A gradually increasing transverse load was applied to the free end of a cantilevered beam, causing a bending moment on the beam-end connection until failure. Four different connection configurations were examined, each replicated twice to verify results. The beam connection parameters investigated were rod anchorage length (200 and 250 mm) and square washer size (38.1 and 50.8 mm). Test results show that increasing the washer size increased the connection bending strength by increments more significantly than those due to increasing the rod anchorage length. However, the connection configurations with the smaller-size washer, which failed mainly due to wood crushing under the washer, had higher ductility ratios than those with the larger-size washer, which failed due to steel rod yielding. In a real-life scenario, a structural element such as a glulam beam is usually loaded to approximately 50% to 70% of its design capacity, considering a reasonable margin of safety. The study estimates a maximum possible bending moment utilization factor for the strongest connection configuration that ranged between 34% and 48% compared to the maximum moment resistance of a supported glulam beam spanning an average length of 4.0 m to 6.0 m (a common span length in framed timber buildings) and has a cross-section size same as the one utilized in this study. This utilization factor is quite large for a timber connection, and thus, confirms a considerable moment-resisting capability of the new configuration developed in this study. Full article

Adolescent idiopathic scoliosis (AIS) is a three-dimensional growth disorder. Corrective surgical procedures are the recommended treatment option for a thoracic angle exceeding 50° and a lumbar major curve of 40°. Over the past few years, dynamic growth modulation implants have been developed as alternatives to permanent fusion. The ApiFix system was designed as a 2D “posterior dynamic device” for curve correction. After implantation in a minimally invasive procedure, it uses polyaxial joints and a self-adjusting rod to preserve the degree of motion and to accommodate the patient’s growth. It provides an effective method of controlling deformity and fills the gap between the conservative treatment of major curves that are >35° and the fusion procedure. The objective of the two-center cohort study was the analysis of the correction results of patients, who underwent surgical intervention with the ApiFix system. The inclusion criteria were AIS, Lenke type 1 or type 5, a major curve on bending films of ≤30°, and an angle of the major curve of between 35° and 60°. Postoperative radiograph data were obtained longitudinally for up to 24 months of follow-up and compared to preoperative (preop) values. For comparisons of the different time points, non-parametric tests (Wilcoxon) or paired t-tests for normally distributed values were used to analyze repeated measures. Overall, 36 patients (25 female and 11 male) were treated with the ApiFix system from April 2018 to October 2020. Lenke type 1 was identified in 21 (58%) cases and Lenke type 5 was identified in 15 (42%) cases. The average angle of the thoracic major curve for Lenke 1 was 43°. The preoperative lumbar major curve (Lenke 5) was determined to be 43°. Over a follow-up of 24 months, a correction of the major curve to an average of 20° was observed for Lenke 1 and that to an average of 15° was observed for Lenke 5. Lenke type 1 and type 5 showed significant changes in the major curve over the individual test intervals in the paired comparisons compared to the starting angle (Lenke 1: preop—24 months, 0.002; Lenke 5: preop—24 months, 0.043). Overall, 11 events were recorded in the follow-up period, that required revision surgery. We distinguished between repeated interventions required after reaching the maximum distraction length of the implant due to the continued growth of the patient (n = 4) and complications, such as infections or problems associated with the anchorage of the implant (n = 7). The results from the present cohort revealed a statistically significant improvement in the postoperatively measured angles of the major and minor curves in the follow-up after 24 months. Consequently, the results were comparable to those of the already established vertebral body tethering method. Alignment in AIS via dynamic correction systems in combination with a possible growth modulation has been a treatment alternative to surgical fusing procedures for more than a decade. However, the long-term corrective effect has to be validated in further studies. Full article

The bond between a steel reinforcement/rod and glulam plays a crucial role in the resistance and deformation capacity of timbers joints. Existing studies provide different bond–slip models for reinforcements and rods with different anchorage lengths, in which the relationship between local bond stress and global bond behaviour cannot not be established. This study presents a unified analytical method for predicting the bond–slip behaviour of ribbed bars and threaded rods along the grain using a local bond–slip model of reinforcement at the elastic and post-yield stages. In the analytical method, equilibrium, compatibility, and constitutive models for reinforcement and rods are considered. The method is verified using test data of rebars and rods with different anchorage lengths. Comparisons between the experimental and calculated results suggest that the analytical method yields reasonably good predictions of the load–slip relationship and failure mode. Furthermore, the embedment lengths required for yield and the ultimate strengths of the reinforcement and rods along the grain are determined by assuming uniform bond stress distributions over the elastic and post-yield steel segment. The average bond stress over the entire anchorage length is calculated and compared with existing equations. Design recommendations for anchorage lengths are proposed for ribbed bars and threaded rods glued in glulam. Full article

We conducted anchoring performance, stress distribution, and full-scale indoor pulling tests on glass-fiber-reinforced polymer (GFRP) bolts. The tests were conducted using finite element software while considering the multi-interface contact and BK criterion by using the cohesive element to simulate the contact relations between the anchor rod body and concrete and building an axial symmetry calculation model of the GRFP bolt and concrete. The results indicated that the finite element model based on cohesive element accurately represents the load–displacement relationship of the GFRP bolt and the distribution law of axial stress along the anchoring length. In addition, the simulation outcomes of the load–displacement relationship were in good agreement with the measured test values. Under the same load, the axial-force-transferred depth of the bolt body was identical regardless of the anchorage length. As anchoring length increases, the pull load on the bolt and the decay rate of axial stress along the anchoring length rises gradually. There is a critical value for the anchorage length of the bolt. Full article

With the increase of mining depth and strength, the evolution of bolt axial force is increasingly becoming important for ensuring the reliability and safety of support. To improve the problem of the existing coal mine roadway pressure-monitoring method, whereby it is difficult to continuously monitor the axial force of the bolt over a long period of time, a full rod fiber bragg grating (FBG) force-measuring bolt and system were designed based on the principle of fiber grating sensing. It was found that a trapezoidal groove is a relatively better groove. The linearity between the center wavelength offset of the fiber grating and the axial force was more than 0.99, and the conversion formula between the axial force of the bolt rod and the wavelength change of the fiber grating were obtained. The real-time monitoring revealed that the axial force of the bolt obviously changed before and after compression. The axial force distribution curve can be divided into the stable zone, growth zone, and peak zone. The influence of the roadway abutment pressure was approximately 130 m ahead of the working face, and the peak area was within the 25–35 m range of the advance working face. The axial force of the bolt rod at the end of the anchorage linearly increased with the tail end of the bolt, the axial force of the free segment was the largest, and the overall stress was essentially the same. The application results demonstrate the feasibility and effectiveness of the FBG full-length force bolt. Full article
