An autocollimator is a popular angle measuring apparatus which lacks the capability to measure the roll angle. This paper proposes a novel roll angle sensor with a large measuring range that is based on the autocollimation principle. A modified right-angle prism (MRP) functions as a reflector to admit a collimated beam and return two outgoing beams to the sensor head. The roll angle of the MRP can be attained by analyzing the moving tracks of the two light spots focused on a photodetector. The mathematical model is derived in detail, and the experimental results show that the measuring accuracy of the proposed sensor is ±13.85 arcsec over a range of 360°. These results verify the feasibility of the proposed sensor for roll angle measurements that require a large measuring range. Full article

Polarizing beam splitters (PBSs) are fundamental components of optical systems and are crucial for sensing, communication, and imaging tasks. Traditional PBS devices, assembled using right-angle prisms with dielectric coatings, face challenges such as bulkiness and limited versatility in deflection directions. To address these limitations, we meticulously make metasurfaces for enhanced PBS performance. Metasurfaces, composed of subwavelength structures, manipulate wavefronts, polarization, and light intensity. Using metasurfaces in the design of PBS devices, we can precisely tailor the structure to manipulate the deflection angles of light beams, ensuring that they align with the desired specifications. Our experimental results closely align with simulation outcomes, showcasing deflection angles of a 1.5 mm diameter metasurface near ±15 degrees for s- and p-polarizations in a wavelength of 940-nm. Full article

Biodigestion in farming and agriculture offers environmental and economic benefits, but investing in biodigesters carries real-world risks for enterprises. This study analyzes methane (CH₄) emissions from a poultry farm biodigester in Tenerife Island, Canary Islands, Spain, conceptualized as a right-angled prism measuring 45 m wide, 25 m long, and 12 m tall, with an internal volume of approximately 13,500 m³. Using a Neon tracer gas technique, CH₄ emission rates were quantified in situ during two surveys in February 2021 and October 2022, capturing seasonal variability in ambient conditions. Biogas analysis was performed using a portable micro-gas chromatograph in less than 5 min, revealing stable CH₄ production rates of approximately 200 kg·d⁻¹ (~310 m³·d⁻¹) and 330 kg·d⁻¹ (~500 m³·d⁻¹) for the two experiments, respectively. The composition of biogas indicated CH₄ concentrations of around 38–43%, with the remaining composition consisting of carbon dioxide (19–26%), nitrogen (36–27%), oxygen (7–4%), and trace amounts of other gases. A comparison with a theoretical model showed a good correlation. This approach enhances biodigester investment attractiveness by enabling enterprises to optimize efficiency promptly. The obtained data were used to estimate the energy potential of biogas from chicken farms in the Canary Islands. Full article

We investigate the combined effects of surface diffraction and total internal reflection (TIR) in the design of 3-dimensional materials exhibiting distinct structural colour on various facets. We employ mechanical wrinkling to introduce surface diffraction gratings (from the nano to the micron scales) on one face of an elastomeric rectangular parallelepiped-shaped slab and explore the roles, in the perceived colours, of wrinkling pattern, wavelength, the directionality of incident light and observation angles. We propose a simple model that satisfactorily accounts for all experimental observations. Employing polydimethylsiloxane (PDMS), which readily swells in the presence of various liquids and gases, we demonstrate that such multifaceted colours can respond to their environment. By coupling a right angle triangular prism with a surface grating, we demonstrate the straightforward fabrication of a so-called GRISM (GRating + prISM). Finally, using a range of examples, we outline possibilities for a predictive material design using multi-axial wrinkling patterns and more complex polyhedra. Full article

For optical beams transmitted by a right-angle prism, the Goos–Hänchen shift can never be seen as a pure effect. Indeed, the lateral displacement, caused by the total internal reflection, will always be accompanied by angular deviations generated by the transmission through the incoming and outgoing interfaces. This combined effect can be analyzed by using the Taylor expansion of the Fresnel coefficients. The analytic expression found for the transmitted beam allows us to determine the beam parameters, the incidence angles, and the axial distance for which lateral displacements are compensated by angular deviations. Proposals to optimize experimental implementations are also briefly discussed. Full article

The fluorescence microscope has been widely used to explore dynamic processes in vivo in mouse brains, with advantages of a large field-of-view and high spatiotemporal resolution. However, owing to background light and tissue scattering, the single-photon wide-field microscope fails to record dynamic neural activities in the deep brain. To achieve simultaneous imaging of deep-brain regions and the superficial cortex, we combined the extended-field-of-view microscopy previously proposed with a novel prism-based cranial window to provide a longitudinal view. As well as a right-angle microprism for imaging above 1 mm, we also designed a new rectangular-trapezoidal microprism cranial window to extend the depth of observation to 1.5 mm and to reduce brain injury. We validated our method with structural imaging of microglia cells in the superficial cortex and deep-brain regions. We also recorded neuronal activity from the mouse brains in awake and anesthesitized states. The results highlight the great potential of our methods for simultaneous dynamic imaging in the superficial and deep layers of mouse brains. Full article

The development of optical systems is heading to multi-branch circuit design and miniaturization. A beam splitter is a common device for dividing an incident beam into two separate beams. Conventional beam splitters are constructed using coated prisms or glass plate. Their bulky size, right-angled output direction, and fixed splitting ratio greatly limit the design of optical arrangement and also hinder the system integration. Here, an all-dielectric metasurface composed of symmetric nano-rings as a beam splitter are designed by Finite-Difference Time-Domain method. By changing the inner and outer radiuses of the nano-rings, the wavefront phase of the emergence beam can be adjusted to form a phase gradient, and the incident beam of arbitrary polarization is divided into two beams according to the designed transmittance and angle. The initial phase of the emergence beam can be changed by adjusting the refractive index of the substrate or adding the silicon film to the substrate, and the splitting ratio can be adjusted from 0.5:1 to 1:1. The simulation demonstrates that the metasurface-based beam splitter is independent of polarization and the power efficiency is over 92% with a compact area of 33.6 μm × 33.6 μm. This compact metasurface-based beam splitter has promising potential for enabling new types of compact optical systems and advancing metasurface-based functional integrated photonic applications. Full article

A photoacoustic spectroscopy (PAS)-based carbon monoxide (CO) gas sensor with a high-power laser and an enhanced gas absorption was demonstrated. The light source was a distributed feedback (DFB), continuous wave (CW) diode laser with a high output power of ~8 mW to give a strong excitation. The target gas received optical absorption enhanced two times by using a right-angle prism reflecting the laser beam. In order to reduce the noise from the background, wavelength modulation spectroscopy (WMS) and second-harmonic detection techniques were used. The modulation frequency and modulation depth were optimized theoretically and experimentally. Water vapor was added in the PAS sensor system to increase the vibrational–translational (V–T) relaxation rate of the CO molecule, which resulted in an ~8 times signal enhancement compared with the using of a dry CO/N₂ gas mixture. The amplitude of the 2f signal had a 1.52-fold improvement compared to the one with only one time absorption. The experimental results showed that such a sensor had an excellent linear response to the optical power and gas concentration. At 1 s integration time, a minimum detection limit (MDL) for CO detection of 9.8 ppm was achieved. The long-term stability of the sensor system was evaluated with an Allan deviation analysis. When the integration time was 1100 s, the MDL improved to be 530 ppb. The detection performance of such a PAS-based CO sensor can be further improved when a laser with a higher output power and increasing optical absorption times is used. Full article

This paper proposes a new optical design that will cooperate with 3D image technology, infrared spectrum technology, future medical diagnostics, the cloud, and big data analysis. We first conducted image recognition experiments to compare the pros and cons of 2D and 3D frameworks in order to make sure that the optical and mechanical framework of a glasses-type 3D ophthalmoscope would be a better choice. The experimental results showed that a 3D image recognition rate (90%) was higher than a 2D image recognition rate (84%), and hence the 3D mechanism design was selected. The glasses-type 3D ophthalmoscope design is primarily based on the specification of indirect ophthalmoscope requirements and two working spectrums: a near infrared and a visible spectrum. The design is a 2.5x magnification fixed focal telecentric relay system with a right-angle prism, which uses a large aperture to increase the amount of incident light (F/# = 2.0). As the infrared spectrums that have better transmittance towards human eye tissue are 965 nm and 985 nm, so that we took account of the visible spectrum and the near-infrared spectrum simultaneously to increase the basis of the physician’s diagnosis. In this research, we conclude that a wearable ophthalmoscope can be designed optically and mechanically with 3D technology, an infrared and a visible working spectrum and further, possibly in cooperation with the cloud and big data analysis. Full article

A right-angle prism was used to enhance the acoustic signal of a quartz-enhanced photoacoustic spectroscopy (QEPAS) system. The incident laser beam was parallelly inverted by the right-angle prism and passed through the gap between two tuning fork prongs again to produce another acoustic excitation. Correspondingly, two pairs of rigid metal tubes were used as acoustic resonators with resonance enhancement factors of 16 and 12, respectively. The QEPAS signal was enhanced by a factor of 22.4 compared with the original signal, which was acquired without resonators or a prism. In addition, the system noise was reduced a little with double resonators due to the Q factor decrease. The signal-to-noise ratio (SNR) was greatly improved. Additionally, a normalized noise equivalent absorption coefficient (NNEA) of 5.8 × 10⁻⁸ W·cm⁻¹·Hz^−1/2 was achieved for water vapor detection in the atmosphere. Full article

The aim of this study was to develop a circuit for an inexpensive portable biosensing system based on surface plasmon resonance spectroscopy. This portable biosensing system designed for field use is characterized by a special structure which consists of a microfluidic cell incorporating a right angle prism functionalized with a biomolecular identification membrane, a laser line generator and a data acquisition circuit board. The data structure, data memory capacity and a line charge-coupled device (CCD) array with a driving circuit for collecting the photoelectric signals are intensively focused on and the high performance analog-to-digital (A/D) converter is comprehensively evaluated. The interface circuit and the photoelectric signal amplifier circuit are first studied to obtain the weak signals from the line CCD array in this experiment. Quantitative measurements for validating the sensitivity of the biosensing system were implemented using ethanol solutions of various concentrations indicated by volume fractions of 5%, 8%, 15%, 20%, 25%, and 30%, respectively, without a biomembrane immobilized on the surface of the SPR sensor. The experiments demonstrated that it is possible to detect a change in the refractive index of an ethanol solution with a sensitivity of 4.99838 × 10⁵ ΔRU/RI in terms of the changes in delta response unit with refractive index using this SPR biosensing system, whereby the theoretical limit of detection of 3.3537 × 10⁻⁵ refractive index unit (RIU) and a high linearity at the correlation coefficient of 0.98065. The results obtained from a series of tests confirmed the practicality of this cost-effective portable SPR biosensing system. Full article
