Geophysics is a discipline that studies the properties of subsurface media using physical methods, among which electromagnetic methods have long been an important technical approach in resource exploration. The anisotropy of resistivity in underground media objectively exists in electromagnetic exploration. However, most borehole-to-surface electromagnetic methods (BSEMs) currently process and interpret data based on the assumption of isotropy, which can lead to misinterpretations of observational data in regions where an isotropy is significant. To address this, we propose a 3D edge-based finite element method on unstructured meshes for simulating resistivity anisotropy in BSEMs. A principal-axis anisotropic tensor is introduced to model anisotropy, and the vertical-line transmitter is transformed into an equivalent set of point sources, enabling efficient computation. The accuracy and effectiveness of the proposed numerical algorithm are validated through comparisons with the solutions from Dipole1D and MARE2D. Furthermore, a comparative analysis of reservoir dynamic monitoring under isotropic and anisotropic conditions using the same model reveals that the relative errors in amplitude and phase exceed 40%, and anisotropy must be adequately considered in reservoir monitoring with borehole-to-surface electromagnetic methods. For reservoir models with varying extraction rates, this study further examines the influence of a transmitter’s position on the electromagnetic response characteristics in anisotropic reservoir dynamic monitoring. The results indicate that effective monitoring cannot be achieved when the transmitter is located above the reservoir; however, when the transmitter is positioned below the reservoir, the borehole-to-surface electromagnetic method can significantly enhance the monitoring of reservoir dynamics. Full article

Geophysical methods detecting electromagnetic properties (e.g., conductivity, relative permittivity, and dielectric loss factor) have been developed into an important tool to accurately assess the hydrate-bearing reservoirs. The key to the satisfying inversion of the electromagnetic collected data is the precise understanding of the electromagnetic responses in hydrate-bearing reservoirs. However, the frequency-dependent anisotropic electromagnetic responses in fracture-filling hydrate reservoirs remain poorly understood. To acquire the above understanding, we use a numerical simulation method to investigate the frequency-dependent anisotropic conductivities, relative permittivities, and dielectric loss factors of the constructed fracture-filling hydrate digital cores. The fractures in digital cores are aligned along a certain direction and contain the hydrate with various distributions and saturations. The simulated electromagnetic behaviors are comprehensively analyzed and explained by the effects of the electrical polarization, the aligned fractures, as well as the occurrence of hydrate with various distributions and saturation in fractures. The results show that the conductivities enhance while the relative permittivities reduce with increasing frequency, respectively, and their dispersion amplitudes at the frequency scope roughly between 100 MHz and 3000 MHz are more dramatic than that at other frequency ranges. The obtained dielectric loss factors increase first and then decrease with frequency and display peak value at the frequency of approximately 1000 MHz. The conductivities, relative permittivities, and loss factor peak values vertical to the fractures are lower than that in the other direction under the same conditions, respectively. It is found that these three parameters for all hydrate distributions and frequencies reduce with the enhancement of hydrate saturation, whereas the decreasing trends in conductivities and relative permittivities are distinct among the various hydrate distributions. The research results would be possible to pave a way for better identifying and evaluating hydrate resources of fractured reservoirs using the collected electromagnetic data. Full article

This research investigates the influence of various concentrations of BaTiO₃ nanofluid on adsorption energy and improved oil recovery. BaTiO₃ nanoparticles were successfully synthesized using a Sol-gel approach at temperatures of 400 °C, 500 °C, 800 °C, and 1000 °C and characterized for their structural and morphological properties and interfacial tension (IFT)/Wettability measurement. The study focuses on using ferroelectric nanofluid in combination with an electromagnetic field to enhance oil recovery mechanisms. Three concentrations of BaTiO₃ nanofluid were prepared, and their effects on pressure and recovery factors were examined. The results demonstrate that BaTiO₃ nanofluids increase the reservoir fluid’s ionic conductivity, leading to environmental polarization. Applying BaTiO₃ nanofluid on glass bead samples resulted in a significant 42.15% increase in the recovery factor at a 0.3% concentration in various measurements, including interfacial tension, core-flooding, and wettability. The nanofluid caused a reduction in interfacial tension and a shift in wettability from oil-wet to water-wet. The higher adsorption energy of the nanofluid corresponded to more significant oil recovery. The optimal concentration for maximum adsorption energy (−2.566331 × 10⁴) and oil recovery (22.5%) was 0.3wt%. At 0.1% concentration, the IFT value was 0.023 mN/m, at 0.3% concentration the IFT was 0.017 mN/m and at 0.5% concentration IFT value was 0.032 mN/m. The contact angle of the brine with the oil was 89.39% compared to the contact angle of 0.1%, 0.3%, and 0.5% which were 64.25%, 10.57%, and 44.63%, respectively. It was revealed from the result that 0.3% of nanofluid decreased the contact angle from 89.39% to 10.57 at a 0.3% concentration of BaTiO₃ nanofluid. This shows that the wettability of the rock surface changed from oil-wet to water-wet with the novel application of BaTiO₃ nanoparticles. This improvement in recovery can be attributed to the modification of wettability and reduction of interfacial tension. Full article

Conventional thermal recovery methods for heavy oil suffer from significant issues such as high water consumption, excessive greenhouse gas emissions, and substantial heat losses. In contrast, electromagnetic heating, as a waterless method for heavy oil recovery, offers numerous advantages, including high thermal energy utilization, reduced carbon emissions, and volumetric heating of the reservoir, making it a focus of recent research in heavy oil thermal recovery technologies. This paper presents a numerical simulation study of electromagnetic heating for heavy oil recovery, using a heavy oil block in the Bohai Bay oilfield in China as a case study. Firstly, a multiphysics field coupled to a mathematical model was established, considering the impact of the temperature on the heavy oil viscosity, the threshold pressure gradient of non-Darcy flow, and the dielectric properties of the reservoir, along with heat dissipation from overlying and undercover sandstone and gravitational effects on fluid flow. Secondly, a numerical simulation method for the coupled multiphysics fields was developed, and the convergence and stability of the numerical simulation method were tested. Finally, a sensitivity analysis based on the numerical simulation results identified the factors affecting heavy oil production. It was found that electromagnetic heating significantly enhances heavy oil production, and the threshold pressure gradient greatly influences the prediction of heavy oil production. Moreover, heat dissipation from the overlying and undercover sandstone severely reduces cumulative oil production. When the production well is located below the electromagnetic heating antenna, larger well spacing results in higher cumulative heavy oil production. Higher heavy oil production is achieved when the antenna is positioned at the center of the reservoir for the studied cases. Power has a big effect on increasing heavy oil production, but its influence diminishes as power increases. There exists an optimal range of electromagnetic frequencies for maximum cumulative production, and higher water saturation leads to poorer electromagnetic heating efficiency. This study provides a theoretical foundation and technical support for the numerical simulation technology and development plan optimization of heavy oil reservoirs subjected to electromagnetic heating. Full article

The saline aquifer CCS is a crucial site for carbon storage. Safety monitoring is a key technology for saline aquifer CCS. Current CO₂ leakage detection methods include microseismic, electromagnetic, and well-logging techniques. However, these methods face challenges, such as difficulties in determining CO₂ migration fronts and predicting potential leakage events; as a result, the formulation of test timing and methods for these safety monitoring techniques are somewhat arbitrary. This study establishes a gas–water two-phase seepage model and solves it using a semi-analytical method to obtain the injection pressure and the derivative curve characteristics of the injection well. The pressure derivative curve can reflect the physical properties of the reservoir through which CO₂ flows underground, and it can also be used to determine whether CO₂ leakage has occurred, as well as the timing and amount of leakage, based on boundary responses. This study conducted sensitivity analyses on eight parameters to determine the impact of each parameter on the bottom-hole pressure and its derivatives, thereby obtaining the influence of its parameters on different flow stages. The research indicates that, when a steady-state flow characteristic appears at the outer boundary, CO₂ leakage will occur. Additionally, the leakage location can be determined by calculating the distance from the injection well. This can guide the placement and measurement of safety monitoring methods for saline aquifer CCS. The method proposed in this paper can effectively monitor the timing, location, and amount of leakage, providing a technical safeguard for promoting CCS technology. Full article

China’s argillaceous limestone reservoir has a lot of oil and gas resources, and hydraulic fracturing of the argillaceous limestone reservoir faces many difficulties. The first problem is that the heterogeneity of the argillaceous limestone reservoir is strong, and it is difficult to optimize fracturing parameters. The second problem is that there are a lot of natural fractures in the argillaceous limestone reservoir, which leads to a lot of fracturing fluid loss. The third problem is that the closure pressure of the argillaceous limestone reservoir is high, and the conductivity of fractures decreases rapidly under high closure pressure. The last problem is that the fracture shape of the argillaceous limestone reservoir is complex, and the law of proppant migration is unclear. The main research methods in this paper include reservoir numerical simulation, fluid-loss-reducer performance evaluation, flow conductivity tests and proppant migration visualization. To solve the above problems, this paper establishes the fracturing productivity prediction model of complex lithology reservoirs and defines the optimal hydraulic fracturing parameters of the argillous limestone reservoir in the Sichuan Basin. The 70/140 mesh ceramide was selected as the fluid loss additive after an evaluation of the sealing properties of different mesh ceramides. At the same time, the hydraulic fracture conductivity test is carried out in this paper, and it is confirmed that the fracture conductivity of 70/140 mesh and 40/70 mesh composite particle-size ceramics mixed according to the mass ratio of 5:5 is the highest. When the closure pressure is 40 MPa, the conductivity of a mixture of 70/140 mesh ceramic and 40/70 mesh ceramic is 35.6% higher than that of a mixture of 70/140 mesh ceramic and 30/50 mesh ceramic. The proppant migration visualization device is used to evaluate the morphology of the sand dike formed by the ceramsite, and it is clear that the shape of the sand dike is the best when the mass ratio of 70/140 mesh ceramsite and 40/70 mesh ceramsite is 6:4. The research results achieved a good stimulation effect in the SC1 well. The daily oil production of the SC1 well is 20 t, and the monitoring results of the wide-area electromagnetic method show that the fracturing fracture length of the SC1 well is up to 129 m. Full article

The Controlled-Source ElectroMagnetic (CSEM) method provides crucial information about reservoir fluids and their spatial distribution. Carbon dioxide (CO₂) storage, enhanced oil recovery (EOR), geothermal exploration, and lithium exploration are ideal applications for the CSEM method. The versatility of CSEM permits its customization to specific reservoir objectives by selecting the appropriate components of a multi-component system. To effectively tailor the CSEM approach, it is essential to determine whether the primary target reservoir is resistive or conductive. This task is relatively straightforward in CO₂ monitoring, where the injected fluid is resistive. However, for scenarios involving brine-saturated (water-wet) or oil-wet (carbon capture, utilization, and storage—CCUS) reservoirs, consideration must also be given to conductive reservoir components. The optimization of data acquisition before the survey involves analyzing target parameters and the sensitivity of multi-component CSEM. This optimization process typically includes on-site noise measurements and 3D anisotropic modeling. Based on our experience, subsequent surveys tend to proceed smoothly, yielding robust measurements that align with scientific objectives. Other critical aspects to be considered are using magnetotelluric (MT) measurements to define the overall background resistivities and integrating real-time quality assurance during data acquisition with 3D modeling. This integration allows the fine tuning of acquisition parameters such as acquisition time and necessary repeats. As a result, data can be examined in real-time to assess subsurface information content while the acquisition is ongoing. Consequently, high-quality data sets are usually obtained for subsequent processing and initial interpretation with minimal user intervention. The implementation of sensitivity analysis during the inversion process plays a pivotal role in ensuring that the acquired data accurately respond to the target reservoirs’ expected depth range. To elucidate these concepts, we present an illustrative example from a CO₂ storage site in North Dakota, USA, wherein the long-offset transient electromagnetic method (LOTEM), a variation of the CSEM method, and the MT method were utilized. This example showcases how surface measurements attain appropriately upscaled log-scale sensitivity. Furthermore, the sensitivity of the CSEM and MT methods was examined in other case histories, where the target reservoirs exhibited conductive properties, such as those encountered in enhanced oil recovery (EOR), geothermal, and lithium exploration applications. The same equipment specifications were utilized for CSEM and MT surveys across all case studies. Full article

The marine controlled-source electromagnetic (CSEM) method has been used in different applications, such as oil and gas reservoir exploration, groundwater investigation, seawater intrusion studies and deep-sea mineral exploration. Recently, the utilization of the marine CSEM method has shifted from petroleum exploration to active monitoring due to increased environmental concerns related to hydrocarbon production. In this study, we utilize the various dynamic reservoir properties available through reservoir simulation of the Wisting field in the Norwegian part of the Barents Sea. In detail, we first developed geologically consistent rock physics models corresponding to reservoirs at different production phases, and then transformed them into resistivity models. The constructed resistivity models pertaining to different production phases can be used as input models for a finite difference time domain (FDTD) forward modeling workflow to simulate EM responses. This synthetic CSEM data can be studied and analyzed in the light of production-induced changes in the reservoir at different production phases. Our results demonstrate the ability of CSEM data to detect and capture production-induced changes in the fluid content of a producing hydrocarbon reservoir. The anomalous CSEM responses correlating to the reservoir resistivity change increase with the advance of the production phase, and a similar result is shown in anomalous transverse resistance (ATR) maps derived from the constructed resistivity models. Moreover, the responses at 30 Hz with a 3000 m offset resulted in the most pronounced anomalies at the Wisting reservoir. Hence, the method can effectively be used for production-monitoring purposes. Full article

Transient electromagnetic (TEM) surveys constitute an important element in exploration projects and can be successfully used in the search for oil and gas. Different modifications of the method include shallow (sTEM), 2D, 3D, and 4D (time-lapse) soundings. TEM data allow for solving a large scope of problems for estimating resources and reserves of hydrocarbons, discriminating reservoir rocks, detecting tectonic features, and characterizing drilling conditions. TEM surveys are applicable at all stages, from initial prospecting to production, and are especially efficient when combined with seismic surveys. Each stage has its specific objectives: estimation of net pay thickness, porosity, and fluid type during prospecting, optimization of well placement and prediction of drilling conditions in exploration, and monitoring of flooding during production. Electromagnetic soundings resolve permafrost features well and thus have a high potentiality for exploration in the Arctic petroleum province. At the first reconnaissance stage of regional prospecting in East Siberia, electromagnetic and seismic data were used jointly to map the junction of the Aldan basin (part of the Aldan-Maya foredeep) with the eastern slope of the Aldan uplift and to constrain the limits of Neoproterozoic sediments. The TEM-based images revealed reservoir rocks in the Upper and Middle Neoproterozoic strata. TEM data have implications for the amount of in-place oil and gas resources in prospects, leads, and plays (Russian categories D_1–3) at the prospecting and exploration stages and contingent recoverable reserves (C₂) during exploration (latest stage). The contribution of the TEM survey to oil and gas evaluation is quantified via economic variables, such as the value of information (VOI) and expected monetary value (EMV). Full article

Offshore geological sequestration of CO₂ offers a viable approach for reducing greenhouse gas emissions into the atmosphere. Strategies include injection of CO₂ into the deep-ocean or ocean-floor sediments, whereby depending on pressure–temperature conditions, CO₂ can be trapped physically, gravitationally, or converted to CO₂ hydrate. Energy-driven research continues to also advance CO₂-for-CH₄ replacement strategies in the gas hydrate stability zone (GHSZ), producing methane for natural gas needs while sequestering CO₂. In all cases, safe storage of CO₂ requires reliable monitoring of the targeted CO₂ injection sites and the integrity of the repository over time, including possible leakage. Electromagnetic technologies used for oil and gas exploration, sensitive to electrical conductivity, have long been considered an optimal monitoring method, as CO₂, similar to hydrocarbons, typically exhibits lower conductivity than the surrounding medium. We apply 3D controlled-source electromagnetic (CSEM) forward modeling code to simulate an evolving CO₂ reservoir in deep-ocean sediments, demonstrating sufficient sensitivity and resolution of CSEM data to detect reservoir changes even before sophisticated inversion of data. Laboratory measurements place further constraints on evaluating certain systems within the GHSZ; notably, CO₂ hydrate is measurably weaker than methane hydrate, and >1 order of magnitude more conductive, properties that may affect site selection, stability, and modeling considerations. Full article

Oil shale constitutes an important proportion of unconventional resources, and its efficient exploitation helps alleviate the Chinese oil shortage situation. Nowadays, microwave heating is a promising method for in situ development of oil shale. However, the corresponding numerical simulation lacks in guiding the retorting optimization under microwave heating. A novel pseudo three-dimensional model, considering electromagnetics, temperature field, and chemical reactions coupling was developed and implemented to investigate oil shale reservoirs’ retorting performance under microwave heating based on the finite element method (FEM). The effects of microwave power, antenna number, and antenna position were analyzed creatively to optimize the microwave heating parameters. Numerical results showed high microwave power increased the maximum reservoir temperature quickly near the heating well, but the thermal conductivity of oil shale dominated the temperature of distal formation. For a typical case of two antennas at 0.9 m spacing and 500 W, the maximum temperature can reach 443 °C at 100 days, and the kerogen near the wellbore quickly converts to hydrocarbon products. Moreover, increasing antennas can improve the heating rate, and the specific distance between two antennas should be designed based on the microwave power and oil shale properties. Full article

Ground Penetrating Radar (GPR) is a geophysical method that uses antennas to transmit and receive high-frequency electromagnetic waves to detect the properties and distribution of materials in media. In this paper, geological observation, UAV detection and GPR technology are combined to study the recent sediments of the Yungang braided river study area in Datong. The application of the GPR technique to the description of fluvial facies and reservoir architecture and the development of geological models are discussed. The process of GPR detection technology and application includes three parts: GPR data acquisition, data processing and integrated interpretation of GPR data. The geological surface at different depths and scales can be identified by using different combinations of frequencies and antenna configurations during acquisition. Based on outcrop observation and lithofacies analysis, the Yandong Member of the Middle Jurassic Yungang Formation in the Datong Basin has been identified as a typical sandy braided river sedimentary system. The sandy braided river sandbody changes rapidly laterally, and the spatial distribution and internal structure of the reservoir are very complex, which has a very important impact on the migration and distribution of oil and gas as a reservoir. It is very important to make clear the characteristics of each architectural unit of the fluvial sand body and quantitatively characterize them. The architectural elements of the braided river sedimentary reservoir in the Datong-Yungang area can be divided into three types: Channel unit, bar unit and overbank assemblages. The geological radar response characteristics of different types of sedimentary units are summarized and their interfaces are identified. The channel sediments form a lens-shaped wave reflection with a flat at the top and convex-down at the bottom in the radar profile, and the angles of the radar reflection directional axes are different on both sides of the sedimentary interface. In the radar profile, the deposit of the unit bar is an upward convex reflection structure. The overbank siltation shows a weak amplitude parallel reflection structure. The flood plain sediments are distributed continuously and stably in the radar profile, showing weak reflection characteristics. Different sedimentary units are identified by GPR data and combined with Unmanned Aerial Vehicle (UAV) detection data, and the establishment of the field outcrop geological model is completed. The development pattern of the diara is clarified, and the swing and migration of the channel in different stages are identified. Full article

Sakiadis rheology of a generalised polymeric material, as well as a heat source or sink and a magnetic field, are all part of this study. Thermal radiations have been introduced into the convective heating process. The translation of a physical situation into a set of nonlinear equations was achieved through mathematical modelling. To convert the resulting partial differential equation into a set of nonlinear ordinary differential equations, appropriate transformations have been used. The velocity and temperature profiles are generated both analytically by HAM and numerically by the Runge–Kutta method (RK-4). In order to analyse the behaviour of the physical quantities involved, numerical and graphical depictions have been offered. To show that the acquired findings are correct, a nonlinear system error analysis has been offered. The heat flux study has been shown using bar charts. For the essential factors involved, the local Nusselt number and local Skin friction are calculated in tabular form. The fluid particles’ molecular mobility was slowed due to the magnetic field and porosity, and the heat transfer rates were demonstrated to be lowered when magnetic and porosity effects are present. This magnetic field and porosity effects regulating property has applications in MHD ion propulsion and power production, the electromagnetic casting of metals, etc. Furthermore, internal heat absorption and generation have diametrically opposed impacts on fluid temperature. The novelty of the present study is that no one has investigated the Sakiadis flow of thermal convection magnetised Oldroyd-B fluid in terms of a heat reservoir across a porous sheet. In limited circumstances, a satisfactory match is revealed when the collected values are compared to the existing work published corroborating the current attempt. The findings of this study are expected to be applicable to a wide range of technical and industrial processes, including steel extrusion, wire protective layers, fiber rolling, fabrication, polythene stuff such as broadsheet, fiber, and stainless steel sheets, and even the process of depositing a thin layer where the sheet is squeezed. Full article

Electromagnetic impact on oil reservoir manifests itself in various physical and chemical phenomena and attracts a significant scientific and technological interest. Microwave (MW) radiation heating can be more efficient for the oil recovery than heat transfer by convection or by thermal conduction. MW influence can also lead to significant changes in the physicochemical and rheological properties of oil caused by chemical processes of transformation of the oil high-molecular components such as resins and asphaltenes. The efficiency of transition-metal catalysts applied for the in-situ conversion of hydrocarbons directly in the reservoir might be significantly increased by exposing the oil formation to MW radiation. Actually, transition metals nanoparticles and their oxides are considered as active absorbers of MW radiation and; therefore, they can be used to intensify MW impact on the reservoir. Catalyst particles dispersed in the formation provide enhanced MW sweep. Taken together, the functioning of the catalysts and the effect of microwave radiation provide deep conversion of resins and asphaltenes, a decrease in the viscosity of the produced oil and an increase in oil recovery factor, along with a decrease in water cut of the well production. The present review analyzes the latest works on the combined application of microwave exposure and dispersed catalysts. In addition, this review discusses the prospects and perspectives of practical application of electromagnetic heating to enhance heavy oil recovery in the presence of nanoparticles. Full article

The utilization of metal-oxide nanoparticles in enhanced oil recovery (EOR) has generated considerable research interest to increase the oil recovery. Among these nanoparticles, alumina nanoparticles (Al₂O₃-NPs) have proved promising in improving the oil recovery mechanism due to their prominent thermal properties. However, more significantly, these nanoparticles, coupled with electromagnetic (EM) waves, can be polarized to reduce water/oil mobility ratio and create disturbances at the oil/nanofluid interface, so that oil can be released from the reservoir rock surfaces and travelled easily to the production well. Moreover, alumina exists in various transition phases (γ, δ, θ, κ, β, η, χ), providing not only different sizes and morphologies but phase-dependent dielectric behavior at the applied EM frequencies. In this research, the oil recovery mechanism under EM fields of varying frequencies was investigated, which involved parameters such as mobility ratio, interfacial tension (IFT) and wettability. The displacement tests were conducted in water-wet sandpacks at 95 °C, by employing crude oil from Tapis. Alumina nanofluids (Al₂O₃-NFs) of four different phases (α, κ, θ and γ) and particle sizes (25–94.3 nm) were prepared by dispersing 0.01 wt. % NPs in brine (3 wt. % NaCl) together with SDBS as a dispersant. Three sequential injection scenarios were performed in each flooding scheme: (i) preflushes brine as a secondary flooding, (ii) conventional nano/EM-assisted nanofluid flooding, and (iii) postflushes brine to flush NPs. Compared to conventional nanofluid flooding (3.03–11.46% original oil in place/OOIP) as incremental oil recovery, EM-assisted nanofluid flooding provided an increase in oil recovery by approximately 4.12–12.90% of OOIP for different phases of alumina. It was established from these results that the recovery from EM-assisted nanofluid flooding is itself dependent on frequency, which is associated with good dielectric behavior of NPs to formulate the oil recovery mechanism including (i) mobility ratio improvement due to an electrorheological (ER) effect, (ii) interfacial disturbances by the oil droplet deformation, and (iii) wettability alteration by increased surface-free energy. Full article
