The fracture toughness of nuclear reactor pressure vessel (RPV) steel is an important basis for the structural integrity evaluation of equipment. SA508 Gr.4N (Cr–Ni–Mo) low-alloy steel has attracted people’s attention because of its excellent strength and toughness, and it is considered as a candidate material for the next generation of RPV. The fracture toughness of SA508 Gr.4N alloy steel was analyzed from the perspective of macroscopic mechanical properties and microstructure, and compared with that of the SA508 Gr.3 (Mn–Ni–Mo) steel used in commercial PWR nuclear power plants. SA508 Gr.4N steel showed better toughness reserve than SA508 Gr.3 steel in terms of fracture toughness parameters such as the reference nil-ductility transition temperature RT_NDT, brittleness transition characteristic temperature T_41J, upper shelf energy and master curve reference temperature T₀. The reasons for the excellent fracture toughness of SA508 Gr.4N steel were analyzed from the aspects of microstructure, precipitation and grain boundary structure. Full article

Nanoscale Cu-rich precipitates (CRPs) play a crucial role in the irradiation embrittlement of reactor pressure vessels (RPVs), and binary Fe-Cu alloys serve as practical models to study the evolution of these precipitates. This study investigates the electrical resistivity of an Fe-1.17 wt.% Cu model alloy aged at 450 °C to enhance the understanding of electrical measurements for the non-destructive assessment of RPV irradiation embrittlement. Multi-level characterization methods were used to obtain quantitative data on multi-scale microstructures, including precipitates, dislocations, and grains. The formation and growth of CRPs were found to align closely with the Johnson–Mehl–Avrami model, and the variation in electrical resistivity showed a strong correlation with the evolution of the microstructure. Combined with detailed quantitative microstructure evolution analysis, an electrical resistivity prediction model that considers microstructural mechanisms has been developed. This model can accurately show the effect of CRPs on resistivity and can potentially be extended to RPV steels with other solute-rich precipitates, with a maximum absolute percentage error not exceeding 5%. These results provide a robust basis for the non-destructive and in-service evaluation of RPV irradiation embrittlement using electrical resistivity. Full article

The reactor pressure vessel (RPV) is a critical barrier in nuclear power plants, but its embrittlement during service poses a significant safety challenge. This study investigated the effects of Cu-enriched clusters on the mechanical and magnetic properties of Fe-0.9 wt.%Cu model alloys through thermal aging. Using Vickers hardness tests, Magnetic Barkhausen Noise (MBN) detection, and Atom Probe Tomography (APT), the study aimed to establish a quantitative correlation between MBN signals, Vickers hardness, and Cu-enriched clusters, facilitating the non-destructive testing of RPV embrittlement. Experimental results showed that the hardness and MBN parameters (RMS and V_pp values) changed significantly with aging time. The hardness increased rapidly in the early stage (under-aged), followed by a plateau and then a decreasing trend (over-aged). In contrast, MBN parameters decreased initially and then increased. APT analysis revealed that Cu-enriched clusters increase in size to 4.60 nm and coalesced during aging, with their number density peaking to 3.76 × 10²³ m⁻³ before declining. An inverse linear correlation was found between MBN signals and the combined factor N_d²R_g (product of the number density squared and the mean radius of Cu-enriched clusters). This correlation was consistent across both under-aged and over-aged states, suggesting that MBN signals can serve as applicable indicators for the non-destructive evaluation of RPV steel embrittlement. Full article

Reactor pressure vessel (RPV) steels are highly susceptible to irradiation embrittlement due to prolonged exposure to high temperature, high pressure, and intense neutron irradiation. This leads to the shift in nil-ductility transition reference temperature—∆RT_NDT. The change in ∆RT_NDT follows a certain distribution pattern and is impacted by factors including chemical composition, neutron fluence, and irradiation temperature. Existing empirical procedures can estimate ∆RT_NDT based on fitting extensive irradiation embrittlement data, but their reliability has not been thoroughly investigated. Probability statistical distributions and the Gamma stochastic process were performed to model material property degradation in RPV steels from a pressurized water reactor due to irradiation embrittlement, with the probability models considered being normal, Weibull, and lognormal distributions. Comparisons with existing empirical procedures showed that the Weibull distribution model and the Gamma stochastic model demonstrate good reliability in predicting ∆RT_NDT for RPV steels. This provides a valuable reference for studying irradiation embrittlement in RPV materials. Full article

The nanoscale Cu-rich precipitates (CRPs) are one of the most critical microstructural features responsible for degrading the mechanical properties of reactor pressure vessel (RPV) steels. The prospect of the rapid regeneration of the service performance of degraded materials through electropulsing is attractive, and electropulsing has been proven to have the application potential to eliminate the CRPs and recover the mechanical properties of RPV materials. However, few studies have investigated the secondary service issue of electropulsing. This paper provides experimental findings from microstructural investigations and property evaluations of a FeCu RPV model alloy subjected to re-aging following recovery electropulsing and annealing treatments. The evolution behavior of CRPs and the changes in the hardness of the alloy during the re-aging process after electropulsing treatment were consistent with the initial aging process, while the re-aging process of the annealing treatment group was quite different from the initial aging. The difference between the electropulsing and annealing treatment groups was that the annealing treatment failed to eliminate the precipitates completely, leaving behind some large precipitates. This work demonstrates the potential application of EPT in this field. Full article

Ion irradiation combined with nanoindentation is a promising tool for studying irradiation-induced hardening of nuclear materials, including reactor pressure vessel (RPV) steels. For RPV steels, the major sources of hardening are nm-sized irradiation-induced dislocation loops and solute atom clusters, both representing barriers for dislocation glide. The dispersed barrier hardening (DBH) model provides a link between the irradiation-induced nanofeatures and hardening. However, a number of details of the DBH model still require consideration. These include the role of the unirradiated microstructure, the proper treatment of the indentation size effect (ISE), and the appropriate superposition rule of individual hardening contributions. In the present study, two well-characterized RPV steels, each ion-irradiated up to two different levels of displacement damage, were investigated. Dislocation loops and solute atom clusters were characterized by transmission electron microscopy and atom probe tomography, respectively. Nanoindentation with a Berkovich indenter was used to measure indentation hardness as a function of the contact depth. In the present paper, the measured hardening profiles are compared with predictions based on different DBH models. Conclusions about the appropriate superposition rule and the consideration of the ISE (in terms of geometrically necessary dislocations) are drawn. Full article

Ion irradiation is a promising tool to emulate neutron-irradiation effects on reactor pressure vessel (RPV) steels, especially in the situation of limited availability of suitable neutron-irradiated material. This approach requires the consideration of ion-neutron transferability issues, which are addressed in the present study by comparing the effect of ions with neutron-irradiation effects reported for the same materials. The first part of the study covers a comprehensive characterization, based on dedicated electron microscopy techniques, of the selected unirradiated RPV materials, namely a base metal and a weld. The results obtained for the grain size, dislocation density, and precipitates are put in context in terms of hardening contributions and sink strength. The second part is focused on the depth-dependent characterization of the dislocation loops formed in ion-irradiated samples. This work is based on scanning transmission electron microscopy applied to cross-sectional samples prepared by the focused ion beam technique. A band-like arrangement of loops is observed in the depth range close to the peak of injected interstitials. Two levels of displacement damage, 0.1 and 1 dpa (displacements per atom), as well as post-irradiation annealed conditions, are included for both RPV materials. Compared with neutron irradiation, ion irradiation creates a similar average size but a higher number density of loops presumably due to the higher dose rate during ion irradiation. Full article

In this paper the phase formation and mechanical properties of VVER-type reactor pressure vessel (RPV) steels with various Ni (1.57–5.95 wt.%) and Mn (0.03–0.76 wt.%) content after neutron irradiation up to fluences in the range of (53–120) × 10²² n/m² at 400 °C were studied. The possibility of carbonitride formation under these irradiation conditions is shown. In case of sufficient Ni (>1.5 wt.%) and Mn (>0.3 wt.%) content formation of Ni-Si-Mn precipitates is observed. Their chemical composition is close to G-phase and Γ₂-phase and differs from that of radiation-induced precipitates in VVER-1000 RPV steels. This indicates the prerequisites for thermally conditioned mechanism of Ni-Si-Mn precipitates formation and growth at 400 °C enhanced by irradiation. It is also shown that the optimized steel manufacturing technology coupled with an ultralow Mn content (≤0.03 wt.%) in steel with increased up to 5.26 wt.% Ni content facilitates suppressing the Ni-Si-Mn precipitates and carbonitrides formation. This, in turn, reduces the contribution of the hardening embrittlement mechanism and, correspondingly, facilitates high radiation resistance of the steels with ultralow Mn content at the increased irradiation temperature (400 °C). Full article

Understanding the mechanical behaviour of reactor pressure vessel (RPV) steels at high fluences has become an important topic in regard to Long-Term Operations (LTO) of existing nuclear power plants (NPP). The effectiveness of thermal annealing treatments to recover the mechanical properties of compositionally tailored pressurised water reactor (PWR) model steels irradiated to high neutron fluences, up to 1.22 × 10²⁰ n·cm⁻², is analysed in this study. Tensile testing of four different PWR RPV steels was performed after irradiation and subsequent recovery annealing treatment at 450 °C for 40 h. Irradiation-induced hardening and the effectiveness of recovery thermal annealing have been assessed by comparing the strength and ductility properties of irradiated and irradiated and subsequently annealed samples with unirradiated reference samples for all four model steel. The annealing treatment resulted in a significant recovery of the yield strength (~75–89%) and the ultimate tensile strength (~78–96%) of all four PWR model steels. This study proves that substantial irradiation-induced hardening (up to ~389 MPa) observed in steels containing high Ni and Mn contents can still be recovered using the thermal annealing treatment. No influence of annealing on ductility properties has been observed for all four model steels. Microscopy analyses of these steels to understand the underlying irradiation damage and recovery mechanisms are planned for the near future. Full article

Surface quality measures such as roughness, and especially its uncertain character, affect most magnetic non-destructive testing methods and limits their performance in terms of an achievable signal-to-noise ratio and reliability. This paper is primarily focused on an experimental study targeting nuclear reactor materials manufactured from the milling process with various machining parameters to produce varying surface quality conditions to mimic the varying material surface qualities of in-field conditions. From energising a local area electromagnetically, a receiver coil is used to obtain the emitted Barkhausen noise, from which the condition of the material surface can be inspected. Investigations were carried out with the support of machine-learning algorithms, such as Neural Networks (NN) and Classification and Regression Trees (CART), to identify the differences in surface quality. Another challenge often faced is undertaking an analysis with limited experimental data. Other non-destructive methods such as Magnetic Adaptive Testing (MAT) were used to provide data imputation for missing data using other intelligent algorithms. For data reinforcement, data augmentation was used. With more data the problem of ‘the curse of data dimensionality’ is addressed. It demonstrated how both data imputation and augmentation can improve measurement datasets. Full article

The reactor pressure vessel (RPV) is one of the most important elements of a nuclear power plant (NPP). The RPV determines the plant operational lifetime since it is not replaceable economically. The purpose of the RPV steel study and enhancement to increase the NPP’s (Nuclear Power Plants) operation lifetime from the original 30–40 years up to 60–80 years or even beyond. The RPV lifetime limited by ageing of the RPV steels. RPV ageing highly depends on the main environmental effects: fast neutron radiation, thermal effects causing thermal ageing and low-cycle fatigue. Firstly, the chemical composition via aged mechanical properties was studied. Efforts to increase the toughness against the radiation embrittlement was enhanced by the appearance of the modern microstructural testing devices such as APFIM (atom probe field ion microscopy), SANS (small-angle neutron scattering) positron annihilation spectroscopy (PAS), transmission electron microscopy (TEM) and Mössbauer spectroscopy (MS). The information on the effect of alloying and polluting elements for the microstructure allowed us to produce increased ageing toughness of the RPVs, and to enhance the safety and lifetime calculations of them, supporting long-term safe operation (LTO). Full article

Positron annihilation spectroscopy (PAS) is widely recognized as a powerful characterization technique in all types of radiation damage studies in nuclear materials. In the past, fission reactor irradiation of reactor pressure vessel (RPV) steels was a primary aim in most studies, while today’s applications of PAS in this field are centered around ion implantation experiments in advanced structural materials. These experiments use hydrogen, helium, heavy ions, and their combination to simulate various radiation environments of future nuclear reactors or nuclear research facilities. The spectrum of ion energies used ranges from a few tens of keV to tens or even hundreds of MeV in proton irradiation or spallation neutron source irradiation experiments. The variety of ion energies, irradiation temperatures, and other experimental conditions poses a major challenge to researchers, who often fail to successfully incorporate the lessons learned from their research. In this paper, we review and supplement recent PAS studies in which structural materials irradiated under a variety of irradiation conditions were investigated using positron annihilation spectroscopy. It summarizes the most important conclusions and lessons learned from the application of PAS in accelerator-based irradiation experiments. Full article

In this work, the stabilities of secondary phases, including carbides, brittle phases, and inclusions, were simulated by computational thermodynamics. Calphad strategical optimization is preferable for all steel alloys regarding energy resource consumption during manufacturing and processing. The alloy composition has been changed to enhance the strength, hardenability, and longevity of a reactor pressure vessel (RPV) steel by computing the phase equilibrium calculations and predicting mechanical properties such as yield and tensile strengths hardness and martensitic and bainitic volume fractions. The stabilities of the pro-eutectoid carbides (cementite), inclusions, and brittle phases in SA508 steel are critical to the toughness and fatigue life related to the crack initiation and expansion of this steel. Overall, the simulations presented in this paper explain the mechanisms that can affect the fatigue resistance and toughness of steel and offer a possible solution to controlling these properties at elevated temperatures by optimizing the steel composition and heat treatment process parameters. Full article

The embrittlement of two types of nuclear pressure vessel steel, 15Kh2NMFA and A508 Cl.2, was studied using two different methods of magnetic nondestructive testing: micromagnetic multiparameter microstructure and stress analysis (3MA-X8) and magnetic adaptive testing (MAT). The microstructure and mechanical properties of reactor pressure vessel (RPV) materials are modified due to neutron irradiation; this material degradation can be characterized using magnetic methods. For the first time, the progressive change in material properties due to neutron irradiation was investigated on the same specimens, before and after neutron irradiation. A correlation was found between magnetic characteristics and neutron-irradiation-induced damage, regardless of the type of material or the applied measurement technique. The results of the individual micromagnetic measurements proved their suitability for characterizing the degradation of RPV steel caused by simulated operating conditions. A calibration/training procedure was applied on the merged outcome of both testing methods, producing excellent results in predicting transition temperature, yield strength, and mechanical hardness for both materials. Full article

Safe and long term operation of nuclear reactors is one of the most discussed challenges in nuclear power engineering. The radiation degradation of nuclear design materials limits the operational lifetime of all nuclear installations or at least decreases its safety margin. This paper is a review of experimental PALS/PLEPS studies of different nuclear reactor pressure vessel (RPV) steels investigated over last twenty years in our laboratories. Positron annihilation lifetime spectroscopy (PALS) via its characteristics (lifetimes of positrons and their intensities) provides useful information about type and density of radiation induced defects. The new results obtained on neutron-irradiated and hydrogen ions implanted German steels were compared to those from the previous studies with the aim to evaluate different processes (neutron flux/fluence, thermal treatment or content of selected alloying elements) to the microstructural changes of neutron irradiated RPV steel specimens. The possibility of substitution of neutron treatment (connected to new defects creation) via hydrogen ions implantation was analyzed as well. The same materials exposed to comparable displacement damage (dpa) introduced by neutrons and accelerated hydrogen ions shown that in the results interpretation the effect of hydrogen as a vacancy-stabilizing gas must be considered, too. This approach could contribute to future studies of nuclear fission/fusion design steels treated by high levels of neutron irradiation. Full article
