During atmospheric reentry, a significant number of chemical reactions are produced inside the high-temperature shock wave formed upstream of the spacecraft. Chemical reactions can significantly alter the flowfield structure surrounding the vehicle and affect surface properties, including heat transfer, pressure, and skin friction coefficients. In this scenario, the primary goal of this investigation is to evaluate the Quantum-Kinetic chemistry model for computing rarefied reactive gas flow over simple and complex geometries. The results are compared with well-established reaction models available for the transitional flow regime. The study focuses on two configurations, a sphere and the Orion capsule, analyzed at different altitudes to assess the impact of chemical nonequilibrium across varying flow rarefaction levels. Including chemical reactions led to lower post-shock temperatures, broader shock structures, and significant species dissociation in both geometries. These effects strongly influenced the surface heat flux, pressure, and temperature distributions. Comparison with results from the literature confirmed the validity of the implemented QK model and highlighted the importance of including chemical kinetics when simulating hypersonic flows in the upper atmosphere. Full article

This paper presents a mission concept for a Low Earth Orbit (LEO) satellite equipped with a payload for space experiments, designed to be recovered on Earth post-mission. The focus of this study is on developing a mission concept with fast de-orbit and accurate landing capability for a small satellite payload. Two re-entry configurations are analyzed: one employing a deployable aero-brake heat shield for aerodynamic descent and another integrating a propulsion system. Aerodynamic analysis of the capsule, including drag coefficient and stability at relevant altitudes, was conducted using the Direct Simulation Monte Carlo (DSMC) method. A trade-off analysis, accounting for uncertainties such as C_D, atmospheric density, and ignition timing, revealed significant differences in mission profiles. A propulsion system providing a ΔV of approximately 100 m/s reduces descent time from 54 days (aerodynamic-only re-entry) to under 1 h, without altering trajectory. Drag-related uncertainties contribute to a landing dispersion of ~100 km, while a ±1% error in total impulse increases dispersion to 400 km. A monopropellant rocket engine was preliminarily designed, meeting constraints such as catalytic chamber pressure and performance targets. The resulting thruster, weighing under 4 kg and contained within a 250 mm-high, 350 mm-diameter cylinder, supports three potential component layouts. Full article

Lunar DRO pinpoint return is the final stage of manned deep space exploration via a lunar DRO station. A re-entry capsule suffers from complicated dynamic and thermal effects during an entire flight. The optimization of the lunar DRO return trajectory exhibits strong non-linearity. To obtain a global optimal return trajectory, an entire-flight lunar DRO pinpoint return model including a Moon–Earth transfer stage and an Earth atmosphere re-entry stage is constructed. A re-entry point on the atmosphere boundary is introduced to connect these two stages. Then, an entire-flight global optimization framework for lunar DRO pinpoint return is developed. The design of the entire-flight return trajectory is simplified as the optimization of the re-entry point. Moreover, to further improve the design efficiency, a rapid landing point prediction method for the Earth re-entry is developed based on a deep neural network. This predicting network maps the re-entry point in the atmosphere and the landing point on Earth with respect to optimal control re-entry trajectories. Numerical simulations validate the optimization accuracy and efficiency of the proposed methods. The entire-flight return trajectory achieves a high accuracy of the landing point and low fuel consumption. Full article

The goal of this paper is to investigate the aerodynamic and aerothermodynamic behavior of the Schiaparelli capsule after the deployment of a supersonic disk-gap-band (DGB) parachute during its re-entry phase into the Martian atmosphere. The novelty of this work lies in the investigation by LES (large-eddy simulations) of the coupled interaction of the flow field generated behind the capsule and that in front of the flexible DGB parachute. These simulations are performed at an altitude of 10 km and a Mach number around 2, i.e., a regime in which large canopy-area oscillations are observed. LES results have shown a strong interaction between the bow shock, the recompression and expansion waves, high pressure, density and temperature gradients, heat flux towards the airstream and the body implying turbulence generation, ingestion, and amplification through the shock waves. Vortices released from the capsule at a frequency of about 52 Hz and 159 Hz, corresponding to Strouhal numbers of ~0.2 and 0.75, respectively, are the main factors responsible for the instabilities of the hypersonic re-entry capsule and the disk-gap-band parachute coupled system. The nonlinear turbulence flow field generated at the capsule back is amplified when passing the parachute bow shock, and this is responsible for the non-axisymmetric behavior around and behind the parachute that caused the uncontrolled capsule oscillations and the Schiaparelli mission failure. In fact, an LES of the parachute without the capsule, for the same conditions, show a completely axisymmetric field, varying in time, but axisymmetric. In order to avoid this turbulence amplification, dampening of the vortex shedding is critical. Different techniques have been already proposed for other applications. In the case of capsule re-entry, due to the high temperatures in front of the capsule behind the bow shock since air plasma is generated, damping of the vortex shedding could be achieved by means of magnetohydrodynamic (MHD) control. Full article

Advancements in space exploration and sample return technology present a unique opportunity to leverage sample return capsules (SRCs) towards studying atmospheric entry of meteoroids and asteroids. Specifically engineered for the secure transport of valuable extraterrestrial samples from interplanetary space to Earth, SRCs offer unexpected benefits that reach beyond their intended purpose. As SRCs enter the Earth’s atmosphere at hypervelocity, they are analogous to naturally occurring meteoroids and thus, for all intents and purposes, can be considered artificial meteors. Furthermore, SRCs are capable of generating shockwaves upon reaching the lower transitional flow regime, and thus can be detected by strategically positioned geophysical instrumentation. NASA’s OSIRIS-REx (Origins, Spectral Interpretation, Resource Identification, and Security-Regolith Explorer) SRC is one of only a handful of artificial objects to re-enter the Earth’s atmosphere from interplanetary space since the end of the Apollo era and it will provide an unprecedented observational opportunity. This review summarizes past infrasound and seismic observational studies of SRC re-entries since the end of the Apollo era and presents their utility towards the better characterization of meteoroid flight through the atmosphere. Full article

Morphing technology is increasingly emerging as a novel and alternative approach for performing the controlled re-entry and precise landing of space vehicles by using adaptive aeroshell structure designs. This work is intended as a preliminary conceptual design of an innovative shape-changing mechanism for the controlled re-entry and safe recovery of CubeSat class systems aimed at recovering payloads and data from LEO at low cost for post flight inspections and experimentations. Such an adaptive and mechanically deployable aeroshell consists of a multi-hinge assembly based on a set of finger-like articulations having two-modal capabilities. The deployable surface can be modulated by a single translational actuator in order to adapt the lift-to-drag ratio for guided entry. Furthermore, once deployed, the system can activate eight small movable aerodynamic flaps that can be individually morphed via an SMA-based actuation to enhance the capsule maneuverability during the re-entry trajectory, by using exclusively aerodynamic forces to guarantee additional precision in landing. Multi-body simulations on retraction/deployment of the system are addressed to investigate the most critical aspects for actual implementation of the concept. Additionally, the morphing behavior and the control effect of the shape memory alloy actuation are preliminary assessed through parametric analysis. This paper is framed within a scientific cooperation between Italy and Brazil in the framework of the SPLASH project, funded in part for the Italian side by a grant from the Italian Ministry of Foreign Affairs and International Cooperation (MAECI), and by CONFAP through the involved State Funding Agencies (FAPs) for the Brazilian side. Full article

The safe landing and rapid recovery of the reentry capsules are very important to manned spacecraft missions. A variety of uncertain factors, such as flight control accuracy and wind speed, lead to a low orbit prediction accuracy and a large landing range of reentry capsules. It is necessary to realize the autonomous tracking and continuous video observation of the reentry capsule during the low-altitude phase. Aiming at the Shenzhou return capsule landing mission, the paper proposes a new approach for the autonomous tracking of Shenzhou reentry capsules based on video detection and heterogeneous UAV swarms. A multi-scale video target detection algorithm based on deep learning is developed to recognize the reentry capsules and obtain positioning data. A self-organizing control method based on virtual potential field is proposed to realize the cooperative flight of UAV swarms. A hardware-in-the-loop simulation system is established to verify the method. The results show that the reentry capsule can be detected in four different states, and the detection accuracy rate of the capsule with parachute is 99.5%. The UAV swarm effectively achieved autonomous tracking for the Shenzhou reentry capsule based on the position obtained by video detection. This is of great significance in the real-time searching of reentry capsules and the guaranteeing of astronauts’ safety. Full article

In the last decade, the increasing use of NanoSats and CubeSats has made the re-entry capsule an emerging research field needing updates in configuration and technology. In particular, the door to advancements in terms of efficiency and re-usability has been opened by the introduction of inflatable and/or deployable aerodynamic brakes and the use of on-board electronics for active control. Such technologies allow smaller sizes at launch, controlled re-entries, and safe recovery. This paper deals with the design of a guidance and control algorithm for the re-entry of a capsule with a deployable aero-brake. A trajectory optimization model is used both in the mission planning phase to design the reference re-entry path and during the mission to update the trajectory in case of major deviations from the prescribed orbit, thanks to simplifications aimed at reducing the computational burden. Successively, a trajectory tracking controller, based on Nonlinear Model Predictive Control (NMPC), is able to modulate the opening of the aero-brake in order to follow the planned trajectory towards the target. A robustness analysis was carried out, via numerical simulations, to verify the reliability of the proposed controller in the presence of model uncertainties, orbital perturbations, and measurement noise. Full article

The design and optimization of re-entry spacecraft or its subsystems is a multidisciplinary or multiobjective optimization problem by nature. Multidisciplinary design optimization (MDO) focuses on using numerical optimization in designing systems with several subsystems or disciplines that have interactions and independent actions. In the present paper, the system-level optimizer, trajectory, geometry and shape, aerodynamics, and aerothermodynamics differential equations, are converted to algebraic equations using the Radau pseudospectral method (RPM) since a spacecraft is a nonlinear, extensive, and sparse system. The solution to the problem with the help of MDO is reached by iterating all the disciplines together; one can simultaneously enhance the design, decrease the time and cost of the entire design cycle, and minimize the structural mass of a re-entry spacecraft. Considering various methods presented in earlier research works, a combined and innovative all-at-once (AAO), RPM-based MDO method, including the key subsystems in the design process of a re-entry capsule-shape spacecraft with a low lift-to-drag ratio (L/D), is presented. Considering the applicable state and control variables, various constraints, and parameters applied to several geometric shapes of a blunt capsule and using Apollo’s aerodynamic and aerothermodynamic coefficients, the optimized dimensions for a re-entry spacecraft are presented. The introduced optimization scheme led to a 17% mass reduction compared to the original mass of the Apollo vehicle. Fast computing and simplified models are used together in this method to analyze a wide range of vehicle shapes and entry types during conceptual design. Full article

In the present study, a multiphysics mathematical model for reproducing the flow field characteristics of an inflatable aeroshell was developed to study the aerodynamic properties of the flow around a membrane reentry vehicle. Firstly, the configuration and flight sequence of a membrane reentry vehicle used in the experiment were introduced. Secondly, mathematical equations of multiphysics fields, such as the Navier–Stokes equations, the heat conduction equation, and the membrane deformation equation, were introduced and numerically solved. The variation characteristics of the flow properties during the aerodynamic heating of a membrane vehicle were studied and discussed in detail under the conditions of different flight altitudes. The results showed that for the membrane vehicle, the high-temperature flow field at the front of its capsule was in a state of thermal non-equilibrium with the decrease of flight altitude and its membrane deformation degree was proportional to the pressure. The translational temperature and electron number density of the plasma flow around the aeroshell remained at a relatively low level for the membrane vehicle so that the blackout phenomenon scarcely occurred during its atmospheric reentry. Full article

Aircraft, such as amphibious planes, airliners, helicopters and re-entry capsules, are frequently subject to impacting loads from water-landing/ditching on various free surfaces, especially under wave conditions. Understanding and quantifying the water-landing/ditching performance on wave surfaces are of fundamental important for the design and certification of crashworthiness in the field of aerospace engineering. This study aims to numerically assess the effect of wave surface on water-landing process of an amphibious aircraft. The numerical implementation is realized in Reynolds-averaged Navier–Stokes (RANS) framework by combining finite volume method (FVM), volume of fluid (VOF) approach and velocity-inlet wavemaker. The temporal-spatial characteristic of numerical wave and the accuracy of presented model are, respectively, validated by analytical wave and convergence studies. The aircraft landing simulations with different free surface conditions, i.e., calm water, regular wave with different wave heights are then performed and quantitatively compared through several physical parameters, including acceleration, velocity, pressure, pitch angle and free surface deformation. It was found that the aircraft regular wave-landing process experiences several unique stages comparing with the calm-water-landing case. The results clearly confirm that wave surface can influence the aircraft landing performance to a great extent. The fundamental mechanism is found to be that the wave surface slope and wave particle velocity remarkably change the impacting position and effective impacting velocity of the aircraft. Full article

For most re-entry capsules, the shape of the forebody of the capsule is designed based on the blunted nose cone. A similar shape can be created using a hyperboloid of revolution that can control the nose bluntness and the half angle of the cone easily. In this study, the hypersonic aerodynamic characteristics of re-entry capsules designed with hyperbolic contours were investigated using the CFD code, FaSTAR, developed by Japan Aerospace Exploration Agency (JAXA). The CFD results showed that, using the hyperbolic contours, the drag and lift coefficients can be increased compared to those for the Hayabusa re-entry capsule without changing the shape of the capsule drastically. This suggests that shape design based on the hyperbolic contours can improve the aerodynamic characteristics of re-entry capsules. Full article

Re-entry winged body vehicles have several advantages w.r.t capsules, such as maneuverability and controlled landing opportunity. On the other hand, they show an increment in design level complexity, especially from an aerodynamic, aero-thermodynamic, and structural point of view, and in the difficulties of housing in operative existing launchers. In this framework, the idea of designing unmanned vehicles equipped with deployable wings for suborbital flight was born. This work details a preliminary study for identifying the best configuration for the hinge system aimed at the in-orbit deployment of an unmanned re-entry vehicle’s wings. In particular, the adopted optimization methodology is described. The adopted approach uses a genetic algorithm available in commercial software in conjunction with fully parametric models created in FEM environments and, in particular, it can optimize the hinge position considering both the deployed and folded configuration. The results identify the best hinge configuration that minimizes interface loads, thus, realizing a lighter and more efficient deployment system. Indeed, for such a category of vehicle, it is mandatory to reduce the structural mass, as much as possible in order to increase the payload and reduce service costs. Full article

A numerical analysis of electromagnetic waves around the atmospheric reentry demonstrator (ARD) of the European Space Agency (ESA) in an atmospheric reentry mission was conducted. During the ARD mission, which involves a 70% scaled-down configuration capsule of the Apollo command module, radio frequency blackout and strong plasma attenuation of radio waves in communications with data relay satellites and air planes were observed. The electromagnetic interference was caused by highly dense plasma derived from a strong shock wave generated in front of the capsule because of orbital speed during reentry. In this study, the physical properties of the plasma flow in the shock layer and wake region of the ESA ARD were obtained using a computational fluid dynamics technique. Then, electromagnetic waves were expressed using a frequency-dependent finite-difference time-domain method using the plasma properties. The analysis model was validated based on experimental flight data. A comparison of the measured and predicted results showed good agreement. The distribution of charged particles around the ESA ARD and the complicated behavior of electromagnetic waves, with attenuation and reflection, are clarified in detail. It is suggested that the analysis model could be an effective tool for investigating radio frequency blackout and plasma attenuation in radio wave communication. Full article
