This study presents a comprehensive investigation into multi-directional fatigue damage characteristics of fixed offshore wind turbine tower roots through comparative analysis using FAST (3.5.0) and Bladed (4.3) software platforms. The research methodology encompasses three principal phases: First, a stochastic wind field model was developed through statistical analysis of historical wind speed measurements, achieving superior correlation (R² = 0.983) in goodness-of-fit tests. Subsequently, the rain flow counting technique was employed to characterize equivalent cyclic load spectra. Building upon these foundations, an integrated predictive fatigue life evaluation framework was formulated by synergistically combining S–N curve principles with Palmgren–Miner’s linear cumulative damage theory. The methodology was further validated through cross-platform verification with Bladed software, revealing only a 7.4% deviation in predicted fatigue lives between the two computational models, confirming the technical feasibility of the proposed simplified model. Full article

The corrosion of the rotating axis pins of the short suspender will lead to the rotating restriction of its end, which will lead to the corrosion of the parallel wires and affect the performance of the short suspender. In this study, the technical condition of the rotating restricted short suspender unfixed from the suspension bridge was carefully detected. An axial tensile performance test was carried out on these short suspenders, and the subsequent availability of the rotating restricted suspender was evaluated based on the size of the fracture gap. The rotationally limited working conditions of these short suspenders were skillfully simulated by the specially designed tooling, and the fatigue performance test of the rotating restricted short suspender was carried out. A simplified simulation method was proposed based on the random traffic theory. By introducing traffic data obtained from the WIM system, the stress response of the short suspenders caused by vehicles on each lane was simulated, and the simulation results were converted by the rain flow counting method. The residual life of the rotating restricted short suspender was predicted by the comparison between the fatigue test results and the fitting curve of the simulation results. From this study, several of the following conclusions can be summarized: The measured fracture gap size is negatively correlated with the effective area of the suspender, and the gap size of 8mm is a key value. When the fatigue load cycle reaches 345,000 times, the suspender is already in a dangerous state. Additionally, the fractured gap size is considered as the judgment basis for the usability of rotating restricted short suspenders. When the gap size is less than 8 mm, the suspender can be continually used after maintenance and should be updated after 6 years. Otherwise, the suspender needs to be replaced immediately. Full article

Under the action of wind load, a wind turbine tower will produce alternating stress, which leads to fatigue failure. According to the mean wind speed at the wind turbine impeller collected from the SCADA system, the mean wind speed of the simulation point is calculated by using the wind speed exponential model formula. Davenport spectra are used to simulate the pulsating wind speed time series. The wind spectrum is obtained using the harmonic superposition method. Subsequently, the wind speed time series and wind load time series at the simulation point are calculated. Structural modeling of a 5 MW wind turbine tower is performed in ABAQUS 2021. The modal shape and natural frequency are obtained by modal analysis to verify the rationality of the model. Subsequently, wind loads are applied to the model, and structural stress time history is obtained by transient modal dynamics analysis. The stress time history of the maximum stress area of the tower structure is extracted, and the rain flow counting method is applied to it to obtain the stress spectrum. The Weibull distribution of the stress spectrum is fitted, the mean and variance of the total damage in one day are calculated, and the fatigue reliability analysis of the maximum stress area of the tower structure is carried out. And the nonlinear fatigue cumulative damage analysis of the region is carried out. This work has implications for fatigue reliability studies for approximate operating conditions. Full article

The wear phenomenon that occurs on the blades during operation has a significant impact on the fatigue life of the blades. To address the issue of fatigue life assessment for turbine runner blades subjected to increased dynamic stress due to sediment wear, taking a specific high-head hydropower unit’s mixed-flow turbine as the research subject, a hydraulic model of the turbine was established. The wear zones of the runner blades are determined based on the distribution of the flow field’s velocity and the sediment volume fraction. According to the wear rate formula for runner blade material, the amount of wear on the blades is determined, and the dynamic stress data for the dangerous areas of the blades under different degrees of wear are calculated using a unidirectional fluid–structure coupling method. The load spectrum of the time–stress history data for the dangerous area at different levels of wear was compiled using the rain-flow counting statistical method. The operating time ratios for the flood season and the non-flood season are combined. Based on the fatigue cumulative damage theory, the total fatigue damage at the maximum stress part of the runner blade was calculated for different stages of wear, providing a reference for the life calculation of mixed-flow hydraulic turbines. Full article

The stress and fatigue of the runner during the operation of the large Kaplan turbine are one of the key issues in the operation of turbines. Due to the complexity of the working load and the geometric configuration of the Kaplan turbine runner, the different contact modes between the internal components of the runner will have an impact on the stress and fatigue results. Therefore, the unsteady CFD calculation of the full channel is conducted in this article to analyze the hydraulic characteristics of the turbine blades in the unsteady flow field, such as pressure and torque. The pressure load is loaded onto the runner using a fluid–structure interaction (FSI) theory, and the stress characteristics of the blade, blade lever, and runner body are compared under three contact modes. Based on the dynamic stress spectrum of the blade lever calculated under three contact conditions, the life of the blade lever is predicted using the rain flow counting method and the Palmgren–Miner theory. The results indicate that the rotation of the runner has a significant impact on the hydraulic and structural characteristics of the Kaplan turbine. The non-uniform and asymmetric stress and torque conditions gradually cause fatigue in the components of the runner. The average and amplitude of dynamic stress on the blade, blade lever, and runner body under frictional and frictionless contact are greater than those of fixed contact. The life of the blade lever calculated under fixed contact is much greater than that under frictional and frictionless contact; therefore, the contact conditions have a significant impact on the structural characteristics of the runner. Full article

The penetration of electric vehicles (EVs) in vehicle-to-grid (V2G) interaction can effectively assist the grid in achieving frequency regulation and peak load balancing. However, the customer perceives that participating in V2G services would result in the additional cycling of the battery and the accelerated aging of the EVs’ power battery, which has become a major obstacle to the widespread adoption of V2G services. Most existing methods require long-term cycling data and battery parameters to quantify battery aging, which is not suitable for the V2G scenario with large-scale and short-time intervals. Consequently, the real-time and accurate quantification of battery aging for optimization remains a challenge. This study proposes a charging scheduling method for EVs that can accurately and online quantify battery aging. Firstly, V2G scheduling is formulated as an optimization problem by defining an online sliding window to collect real-time vehicle information on the grid, enabling online optimization. Secondly, battery aging is more accurately quantified by proposing a novel amplitude-based rain-flow cycle counting (MRCC) method, which utilizes the charging information of the battery within a shorter time period. Lastly, an intelligent optimization algorithm is employed to optimize the charging and discharging power of EVs, aiming to minimize grid fluctuations and battery aging. The proposed method is validated using a V2G scenario with 50 EVs with randomly generated behaviors, and the results demonstrate that the proposed online scheduling method not only reduces the EFCC of the battery by 8.4%, but also achieves results close to global optimization. Full article

The tension cable-supported power transmission structure (TC-PTS) is a new type of power transmission structure suitable for mountainous terrain, and is sensitive to wind load. In this regard, a nonlinear finite element analysis model of wind-induced vibration is proposed for the TC-PTS, and the wind-induced vibration response of the structure is analyzed. Firstly, the tangent stiffness matrix of the three-dimensional truss element for the supporting suspension cable and transmission line, considering the geometric nonlinearity of structures, is derived through the relationship between the element elastic energy and its displacement. Subsequently, the element mass matrix and damping matrix of the supporting suspension cable and transmission line, as well as the element nodal load vector obtained from wind load equivalence, are given. Then, based on the nonlinear finite element theory, the nonlinear dynamic equation of wind-induced vibration is established for the TC-PTS and solved using the Newmark-β method combined with the Newton–Raphson iterative method. Furthermore, the rain-flow counting method and Miner’s linear fatigue cumulative damage theory were used for wind-induced fatigue damage assessment. Finally, a two-span TC-PTS was selected as an example, and the wind-induced nonlinear vibration and fatigue damage assessment were analyzed through the proposed model. The results show that the proposed model has high computational accuracy and efficiency. The first three order vibration modes of the supporting-conductor part of the two-span TC-PTS were antisymmetric vertical bending, symmetric side bending, and antisymmetric side bending. With the increase in wind speed and wind direction angle, the maximum lateral displacement and tension of the supporting suspension cable and transmission line increased, and their degree of increase showed a nonlinear trend. In terms of the wind-induced fatigue analysis results of TC-PTS, the fatigue damage at the end of the supporting-conductor suspension cable was greater than the fatigue damage at its midpoint. Compared to the fatigue damage at the midpoint of the conductor, the fatigue damage at the end of the conductor was less affected by the wind direction angle, and both were more significantly affected by the wind speed. Full article

In this study, to evaluate the safety of the fastening device, which is a vulnerable part of the agricultural by-product collector, the stress in fastening devices was measured, and the operational and driving safety were analyzed by deriving the static safety factor and fatigue life. The position with the maximum stress in fastening devices was identified through structural analysis simulation, and a stress measurement system was constructed using strain gauges. Test conditions for stress measurement were classified into three operating conditions (collection operation, driving with the loading part lifted to the highest point, and driving with the loading part lifted to the lowest point) and three soil conditions (even pavement, sloped pavement, and farmland). A process for deriving the fatigue life based on the measured stress was constructed by applying the rain-flow counting method, Goodman equation, and Palmgren–Miner’s rule via commercial software. From the stress measurement results, the collection operation exhibited the highest maximum stress, followed by driving with the loading part lifted to the highest point and driving with the loading part lifted to the lowest point. Under all conditions, the static safety factor of the fastening devices was found to be higher than 1.0 (1.16–1.33). The fatigue life of the fastening devices was also found to be longer than the service life of Korean agricultural machinery under all operating conditions. Therefore, the fastening devices are expected to operate safely under generated static and dynamic loads. The agricultural by-product collector can perform agricultural work and drive stably and is expected to contribute to reducing unnecessary labor force for Korean farms. Full article

A novel method is proposed to investigate the pattern of variation in the residual strength and reliability of wind turbine gear. First, the interaction between loads and the effect of the loading sequence is considered based on the fatigue damage accumulation theory, and a residual strength degradation model with few parameters is established. Experimental data from two materials are used to verify the predictive performance of the proposed model. Secondly, the modeling and simulation of the wind turbine gear is conducted to analyze the types of fatigue failures and obtain their fatigue life curves. Due to the randomness of the load on the gear, the rain flow counting method and the Goodman method are employed. Thirdly, considering the seasonal variation of load, the decreasing trend of gear fatigue strength under multistage random load is calculated. Finally, the dynamic failure rate and reliability of gear fatigue failure under multistage random loads are analyzed. The results demonstrate that the randomness of residual strength increases with increasing service time. The seasonality of load causes fluctuations in the reliability of gear, providing a new idea for evaluating the reliability of the wind turbine gear. Full article

To investigate the maintenance effect of diaphragm-to-rib fatigue cracks via steel plate reinforcement, finite element models of different-shaped steel plates were established. Stress intensity factors at the crack tip before and after reinforcement were obtained, and the variations in stresses were studied. Polygonal steel plate reinforcements were then carried out on a real bridge based on the finite element calculation results. The changes in stress amplitudes and fatigue damage degrees at the crack tip were analyzed via the rain-flow counting method and Miner’s linear damage accumulating theory. The results show that both the polygonal steel plate and the rectangular steel plate could effectively eliminate the stress concentration and restrain the propagation of cracks. The stresses in other parts of the arc notch increased after reinforcement and polygonal steel plates had less influence. After the reinforcement in a real bridge, the cycle number of high stress amplitudes at the crack tip decreased significantly. The fatigue damage degree of the repaired part reduced by 70.1%, which verified the maintenance effect via polygonal steel plate reinforcement on diaphragm-to-rib fatigue cracks. Full article

With the promotion of carbon peaking and carbon neutrality goals and the construction of renewable-dominated electric power systems, renewable energy will become the main power source of power systems in China. Therefore, ensuring frequency stability and system security will emerge as pivotal challenges in the future development process. Created by combining a Li-ion battery and a supercapacitor, a hybrid energy storage system (HESS), which possesses robust power regulation capabilities and rapid response capabilities, holds promise for supporting the frequency stability of power systems. In this context, the assessment of the economic viability of HESSs providing multitype frequency response services becomes a critical factor in their deployment and promotion. In this paper, an economic analysis approach for a Li-ion battery–supercapacitor HESS towards a multitype frequency response is presented. First, a multitype frequency response-oriented operational mode for the HESS is designed, outlining the roles and functions of the Li-ion battery and the supercapacitor in delivering distinct services. Moreover, building upon the analysis of the power trajectory of Li-ion batteries, a lifetime model for the HESS is proposed based on the rain-flow counting method. Furthermore, considering the competitive landscape for the HESS in the frequency regulation ancillary service market, a full lifecycle economic assessment model is proposed. Finally, case studies on actual power system frequency data and PJM market data are performed to verify the effectiveness of the proposed method, and the simulation results confirm that the HESS exhibits robust performance and a competitive advantage in providing multitype frequency response services. Additionally, it demonstrates commendable economic benefits, establishing its potential as a valuable contributor to frequency response services. Full article

This paper investigated the fatigue life of offshore wind turbine (OWT) support structures. For this purpose, a 3 MW-capacity typical wind turbine is investigated using time-domain finite element simulations. In numerical simulations, different stochastic wind models corresponding to different accumulation periods are applied. Then, the stress-based fatigue life is estimated following the rain-flow counting algorithm and Palmgren-Miner linearly cumulative damage rule. The study also addresses the joint distribution of loads at the site of interest. Generally, the study emphasizes the significance of the long-term distribution of the applied environment loads and its influence on the fatigue life of OWT’s substructures. The results imply that the wind measurement period is directly linked to the fatigue life of offshore wind turbine support structures. Accordingly, its fatigue life is significantly reduced at the 25-year accumulative period of wind. Therefore, this study recommends that a sufficient number of accumulative periods of wind and other environmental loads should be considered appropriately. Full article

The fatigue problem of hangers is fatal for the safety of the whole bridge structure. The objective of this study is to present a strain monitoring-based method to assess the fatigue performance of stiff hangers in highway arch bridges and predict their remaining life. A vehicle–bridge interaction system was constructed to analyze the dynamic behavior in the area close to the key welding line where the hanger was connected to the deck slab. Then, the empirical mode decomposition (EMD) algorithm and rain-flow counting algorithm were used in signal preprocessing and statistical analysis of field monitoring data. Finally, the fatigue life was assessed according to the standards in the Chinese Code for the Design of Steel Structures, as well as the Eurocode 3 and AASHTO codes. Differences were found in the fatigue behavior of hangers, and the shortest hanger was shown to surfer more serious fatigue damage. The influence of vehicle volume growth and low-stress amplitude on the fatigue performance was also discussed. Full article

Metro vehicles have always been known for their high passenger density, frequent traffic flow and strong alternating loads due to their severe running environment. As the major support component, the bogie frame suffers from fatigue damages and receives a high intensity of interest. In this work, a theoretical model is presented between the measured strain and the structural stress via multiple load identification, wherein recognition matrices and stress evaluations of the bogie frame are defined according to the locations found in finite element analysis (FEA). The model is validated through random loading in FE simulation, and the load deviation is within 1.1 kN. A vehicle experiment was performed on the second bogie of the head car on a six-car metro train. The signed von Mises (SVM) stress was calculated at critical locations with the proposed method and compared with what was measured. The excessive part was no more than 14.97%, comparing the reconstructed with the measured amounts. Stress spectra were developed utilizing rain-flow counting and evaluated in terms of the damage accumulation rule with the optimal spectra groups determined from convergence analysis. The evaluation indicates that, when the running mileage increases to the full life cycle of 3,960,000 km, the maximum equivalent damage reaches 0.35 and 0.46 at the gear box base for measured and reconstructed amounts, respectively. Research outcomes suggest that the proposed method offers an alternative for fatigue assessment and maintenance strategies on metro vehicles, as well as other types of rail-transit vehicles. Full article

The goal of this research was to analyze the load and safety of the transplanting device of the 4-bar link type semi-automatic vegetable transplanter under different workload conditions. To measure the strain at the transplanting device, a load measurement system was developed using 15 strain gauges. Field tests were conducted at 4 levels of engine speeds (750, 1000, 1250, and 1500 rpm) and 10 levels of the planting distance (0.29–0.47 m). The static safety factor was defined as the ratio between the strength of the material and the maximum stress in the transplanting device. The calculated stress data were converted from the time domain to the frequency domain using the rain-flow counting methods and Goodman’s Equation. The sum of fatigue damage was acquired based on the Palmgren–Miner’s rule. It was observed that the stresses increased with increasing engine speed and planting distance. The results show the higher engine speed and the longer planting distance will decrease the static safety factor and fatigue life. The static safety factor value was more than 1.0 for all locations and all working conditions. The minimum fatigue life was 49,153.3 h at link A (S_14), under the working condition of engine speed 750 rpm and planting distance of 0.35 m. Full article
