The thrust system, an important subsystem of a tunnel boring machine (TBM), primarily provides thrust force and adjusts TBM’s attitude in real time. In the tunneling process, only controlling the thrust speed causes pressure oscillations, increases soil deformation, and leads to surface subsidence or upheaval. Conversely, solely relying on pressure control causes fluctuations in speed, making it difficult to ensure that the deviation between the designed tunneling axis (DTA) and the actual tunneling axis (ATA) remains within the permissible range. Due to the increase in geological complexity and higher construction quality standards, primarily relying on single-mode speed or pressure control has become inadequate to meet operational demands. Therefore, to realize higher safety and precise trajectory tracking, it is necessary to ensure speed and pressure compound control for thrust systems. This paper proposes a novel adaptive sliding mode control (ASMC) strategy for thrust systems, which is composed of a proportional pressure relief valve (PPRV) and a proportional flow control valve (PFCV). Firstly, PPRV and PFCV are modeled as a second-order system and an ASMC is employed to control the pressure and speed. Next, to assess the performance of the ASMC controller, simulation experiments were conducted under various conditions, including speed regulation, sudden changed load, and disturbed load. The simulation results indicate that compared to the Proportion–Integral–Differential (PID) controller, the ASMC controller shows almost no overshoot in speed and pressure control during the initial stages, with the response time reduced by approximately 70%. During speed regulation process and sudden changed load process, the response time for both speed and pressure control is shortened by about 80%. In the disturbed load process, the ASMC controller maintains pressure stability. In conclusion, the ASMC controller significantly improves the response speed and stability of the thrust system, exhibiting better control performance under various operating conditions. Full article

Tension control in cold-rolling pilot mills (CRPMs) with hydraulic tension is subject to extraneous forces resulting from positional disturbances, strong coupling, and time-varying characteristics, making it challenging to achieve ideal control results using the existing control methods. Therefore, in this study, a mathematical model of tension is first derived and then used to analyze the properties and difficulties associated with tension control. Second, a hydraulic servo-control system based on servovalves and proportional pressure relief valves is developed. In this system, redundant feedforward flow is generated by a servovalve according to the rolling schedule. The surplus flow is absorbed by a proportional pressure relief valve in the closed-loop control of tension. Third, simulation analysis is performed. Under severe friction disturbance (maximum 0.2 kN), and with the wide range of forward and backward slip, an accuracy of ±0.27 kN in tension control can still be achieved using the proposed control strategy, thereby demonstrating its effectiveness. Moreover, it has obvious advantages over existing control methods. Finally, an experimental study of tension is carried out in the cold-rolling mill with a maximum tension capacity of 50 kN, achieving ±0.2 kN tension control precision in the multipass rolling process. Full article

Hydraulic valves are used to determine the set values of hydraulic quantities (flow rate, pressure, or pressure difference) in a hydraulic system or its part. This is achieved through the appropriate throttling of the stream flowing through the valve, which is automatically set by the operator (e.g., opening the throttle valve). The procedures for determining its static and dynamic properties were described using the example of modeling a two-stage proportional relief valve. Subsequently, the importance of the design and operational parameters was determined using multi-valued logic trees. Modeling began with the determination of equations describing the flow and movement of moving parts in a valve. Based on the equations, a numerical model was then created, e.g., in the Matlab/Simulink environment (R2020b). The static characteristics were obtained as the result of a model analysis of slow changes in the flow rate through the valve. Various coefficients of logical products have not been taken into account in the separable and common minimization processes of multi-valued logic equation systems in any available literature. The results of the model tests can be used to optimize several types of hydraulic valve constructions. Full article

The mining emulsion pump is mainly used on a fully mechanized coal mining face, but it is rarely used on other occasions, so research on its loading test method is relatively limited. This paper proposes the application of a digital relief valve to the emulsion pump loading test. In addition, the small number of plungers in the emulsion pump will lead to large flow pulsation and pressure pulsation, and the nominal flow of different types of emulsion pumps varies greatly. These factors lead to the deficiency of a traditional PID control algorithm in control accuracy and efficiency. In order to improve control accuracy and efficiency, firstly, the influence of the flow rate of the tested pump and extension of the linear stepping motor shaft on the working pressure is studied. A backpropagation (BP) artificial neural network (ANN) model is used to fit a functional relationship between the three parameters. The flow rate of the tested pump and target pressure were provided as inputs to predict the extension of the linear stepping motor shaft, thereby realizing the remote intelligent control of the system pressure. Next, a BP ANN model is constructed, and its reliability is verified; the BP neural network algorithm and proportional-integral-derivative (PID) algorithm are compared through simulation. The simulation results show that the BP neural network algorithm has high control accuracy and small overshoot. Finally, two pumps with different flows are tested in a self-developed digital relief valve and test platform. The test results show that the proposed loading test method is intelligent and efficient, and it has high accuracy. Full article

Most sewer networks collect domestic wastewater and a variable proportion of extraneous water, such as rainwater, through surface runoff and industrial discharges. Accounting for wastewater dilution is essential to properly quantify wastewater particle loads, whether these are molecular fragments of SARS-CoV-2, or other substances of interest such as illicit drugs or microplastics. This paper presents a novel method for obtaining real-time estimates of wastewater dilution and total daily volume through wastewater treatment works, namely when flow data is not available or unreliable. The approach considers the levels of several physico-chemical markers (ammonia, electrical conductivity, and orthophosphate) in the wastewater against their dry-weather levels. Using high-resolution data from the national Wastewater Surveillance Programme of Wales, we illustrate how the method is robust to spikes in markers and can recover peaks in wastewater flow measurements that may have been capped by hydraulic relief valves. We show the method proves effective in normalising SARS-CoV-2 viral loads in wastewater samples and discuss other applications for this method, looking at wastewater surveillance as a vital tool to monitor both human and environmental health. Full article

The valve-controlled hydraulic cylinder system (VCHCS) is commonly utilized in the underwater manipulator, which is the most important tool for subsea tasks. Hydraulic oil viscosity is very sensitive to pressure. Therefore, when working at different depths under different ambient pressures in the sea, the hydraulic oil viscosity and the pipeline pressure loss in the deep-sea VCHCS vary greatly, which seriously affects the energy efficiency of the system. In addition, the control accuracy of the deep-sea VCHCS is also influenced by changes in the hydraulic oil viscosity and the pipeline pressure loss. In order to realize energy-saving control, this research introduces a proportional relief valve and develops a variable pump pressure control strategy. At the same time, a variable gain proportional-integral-derivative (PID) algorithm is designed to achieve precise control. A co-simulation model of the deep-sea VCHCS is then established, and many simulation analyses are carried out. Compared with traditional PID control with a constant pump pressure, the proposed method presents advantages such as lower energy consumption, better control accuracy, better resistance to load impact, and accuracy consistency under different working depths. Among them, when working at 11 km depth in the sea, the proposed method is capable of saving energy by 36.5% for the multi-step movement, by 30% for the harmonic movement, and by 47% for the complex movement. The present work in this research provides a solution that can realize energy saving and precise control of the deep-sea VCHCS at the same time in the wide span of depth in the sea. Full article

Mechanical ventilators are vital components of critical care services for patients with severe acute respiratory failure. In particular, pressure- and volume-controlled mechanical ventilation systems are the typical modes used in intensive care units (ICUs) to ventilate patients who cannot breathe adequately on their own. In this paper, a Simulink model is proposed to simulate these two typical modes employed in intensive care lung ventilators. Firstly, these two modes of ventilation are described in detail in the present paper. Secondly, the suggested Simulink model is analysed: it consists of using well-established subroutines already present in Simulink through the Simscape Fluids (gas) library, to simulate all the pneumatic components employed in some commercial ICU ventilators, such as pressure reducing valves, pressure relief valves, check valves, tanks, ON\OFF and proportional directional valves, etc. Finally, the simulation results of both modes in terms of pressure, tidal volume, and inspired/expired flow are compared with the real-life quantitative trends taken from previously recorded real-life experiments in order to validate the Simulink model. The accuracy of the model is high, as the numerical predictions are in good agreement with the real-life data, the percentage error being less than 10% in most comparisons. In this way, the model can easily be used by manufacturers and start-ups in order to produce new mechanical ventilators in the shortest time possible. Moreover, it can also be used by doctors and trainees to evaluate how the mechanical ventilator responds to different patients. Full article

The thrust system of a tunnel boring machine plays a crucial role by driving the machine ahead and supporting the gripper shoes stably. A thrust hydraulic control system, assembled with a proportional flow control valve and a pressure relief valve, is established with system operating parameters. The mathematical model of a thrust electrohydraulic system is presented. To improve the control characteristics of the thrust system, a self-tuning fuzzy PID controller was introduced in synchronization motion control situations. To attain the best control parameters, three synchronization motion control systems were used to control the thrust propel cylinders. Tests on a Ø2.5 m scaled TBM test rig were carried out to verify the capabilities of the ISCS, SRSCS and CRSCS. Comparative tests were conducted, and the results showed that the thrust system adopting SRSCS achieved the least oscillation and the quickest response. The steady-state displacement error decreased by about 33.3% in contrast to the ISCS and CRSCS. Full article

As a rotational speed controller, a hydro-viscous clutch (HVC) is usually used in the constant pressure water supply system to maintain the needed water pressure constant. However, when the hydro-viscous clutch is working, it often suffers from the problem of output rotational speed fluctuation since the spool of proportional relief valve can easily get stuck. Consequently, water pressure will fluctuate too. A special pump control system of HVC was proposed based on the Fuzzy-PID controller for the purpose of reducing the fluctuation rate. The MATLAB simulation was carried out according to the mathematical model and the results show that the Fuzzy-PID control strategy is superior to traditional PID control. The corresponding experiment was performed and the result indicate that through applying the Fuzzy-PID controller based pump control system, the rotational output speed fluctuation of HVC can be inhibited from ±60π to ±6π rad/min, and the water pressure fluctuation is dropped from ±0.1 to ±0.002 MPa. Full article

Overflow loss is one of the main reasons for the inefficiency of the hydraulic system. Aiming at the overflow loss in the hydraulic system, an energy recovery system based on a hydraulic motor and generator is proposed. Further, a pressure monitoring and control strategy based on variable speed control for electric generator is adopted, which can control the pressure differential between the inlet and outlet of the proportional relief valve as a small value, and achieve the purpose of energy recovery by reducing the loss of the pressure differential between the inlet and outlet of the relief valve. Through establishing a simulation system model and test platform, the stability, step response characteristics and energy saving of the system are studied. The results show that the energy recovery unit at the outlet of the relief valve does not affect the normal operation of the relief valve, but also greatly reduces the pressure regulation deviation. Besides, the efficiency of overflow loss recovery system about is 67%. Full article

This research developed a novel proportional pressure control valve for an automobile hydraulic braking actuator. It also analyzed and simulated solenoid force of the control valves, and the pressure relief capability test of electromagnetic thrust with the proportional valve body. Considering the high controllability and ease of production, the driver of this proportional valve was designed with a small volume and powerful solenoid force to control braking pressure and flow. Since the proportional valve can have closed-loop control, the proportional valve can replace a conventional solenoid valve in current brake actuators. With the proportional valve controlling braking and pressure relief mode, it can narrow the space of hydraulic braking actuator, and precisely control braking force to achieve safety objectives. Finally, the proposed novel proportional pressure control valve of an automobile hydraulic braking actuator was implemented and verified experimentally. Full article

In order to improve the performance of the hydraulic support electro-hydraulic control system test platform, a self-tuning proportion integration differentiation (PID) controller is proposed to imitate the actual pressure of the hydraulic support. To avoid the premature convergence and to improve the convergence velocity for tuning PID parameters, the PID controller is optimized with a hybrid optimization algorithm integrated with the particle swarm algorithm (PSO) and genetic algorithm (GA). A selection probability and an adaptive cross probability are introduced into the PSO to enhance the diversity of particles. The proportional overflow valve is installed to control the pressure of the pillar cylinder. The data of the control voltage of the proportional relief valve amplifier and pillar pressure are collected to acquire the system transfer function. Several simulations with different methods are performed on the hydraulic cylinder pressure system. The results demonstrate that the hybrid algorithm for a PID controller has comparatively better global search ability and faster convergence velocity on the pressure control of the hydraulic cylinder. Finally, an experiment is conducted to verify the validity of the proposed method. Full article
