This study analyzes the injection behavior of fossil and sustainable aviation fuel blends, in comparison with conventional diesel fuel, using a common-rail injection system applied to reciprocating engines. Neat commercial diesel and Jet A1 were tested as fossil fuels. A neat Fischer–Tropsch Synthetic Paraffinic Kerosene was tested and blended with Jet A1. Another alternative fuel, Hydrotreated Vegetable Oil, was also blended with Jet A1. The blending proportion was established to meet 51 as the derived cetane number, as required for fuels used in diesel reciprocating engines. Experimental tests were carried out under an energizing time of 2 ms at injection pressures between 50 and 110 MPa, with a fuel temperature ranging from 293 to 313 K, and a constant back pressure of 5 MPa, using a 130 µm single-hole injector. The results show that kerosene fuel exhibits slightly lower injection rates and total injected mass than diesel fuel, mainly due to their lower density. Under low-pressure conditions, an increase in hydraulic injection delay with diesel fuel is observed, mainly at the highest tested temperature. Mass flow rate, hydraulic injection delay, injection duration, total mass injected, and nozzle discharge coefficient do not show significant variations within the tested temperatures. Fossil kerosene fuel and its blend with Synthetic Paraffinic Kerosene show slightly higher injection rates. Overall, the results indicate that both neat kerosene and the studied blends may achieve injection characteristics comparable to diesel fuel, supporting their technical feasibility in reciprocating engines within the framework of the Single Fuel Concept. Full article

Numerical and experimental approaches are conducted to investigate the flow features and secondary combustion performance induced by different air–fuel ratios in a boron-based solid-ducted rocket engine. The results indicated that the afterburning chamber flow features become more complicated owing to the multiple nozzles of the gas injector, and a number of recirculation zones are generated. Because of this, the mixing of the fuel gas and incoming air is enhanced. When the air–fuel ratio decreases, the heat release in the afterburning chamber increases continuously, which causes the pre-combustion shock train to continue to propagate upstream in the subsonic diffuser of the inlet isolator, along with the boundary layer separation zone also moving forward, and the stability margin of the direct-connect inlet decreasing gradually. Furthermore, the direct-connect inlet works at a critical state with an air–fuel ratio of 11.5. As the mass flow rate of the fuel-rich gas rises gradually, the engine thrust gradually increases, and the number of vortexes in the afterburning chamber and the corresponding region affected by the vortexes generally decrease. Meanwhile, the mixing and combustion of the fuel-rich gas and incoming flow were not substantially changed. Additionally, the combustion efficiency and specific impulse are proportional to the air fuel ratio. Full article

Two-phase evaporative spray cooling technology can significantly reduce power consumption in data centre cooling applications. However, the literature lacks an established methodology for assessing the overall performance of such evaporation systems in terms of the water-energy nexus. The current study develops a Lagrangian–Eulerian computational fluid dynamics (CFD) modelling approach to examine the functionality of these two-phase evaporative spray cooling systems. To replicate a modular system, a hollow spray cone nozzle with Rosin–Rammler droplet size distribution is simulated in a turbulent convective natural-air environment. The model was validated against the available experimental data from the literature. Parametric studies on geometric, flow, and climatic conditions, namely, domain length, droplet size, water mass flow rate, temperature, and humidity, were performed. The findings indicate that at elevated temperatures and low humidity, evaporation results in a bulk temperature reduction of up to 12 °C. A specific focus on the climatic conditions of Dublin, Ireland, was used as an example to optimize the evaporative system. A new formulation for the coefficient of performance (COP) is established to assess the performance of the system. Results showed that doubling the injector water mass flow rate improved the evaporated mass flow rate by 188% but reduced the evaporation percentage by 28%, thus reducing the COP. Doubling the domain length improved the temperature drop by 175% and increased the relative humidity by 160%, thus improving the COP. The COP of the evaporation system showed a systematic improvement with a reduction in the droplet size and the mass flow rate for a fixed domain length. The evaporated system COP improves by two orders of magnitude (~90 to 9500) with the reduction in spray Sauter mean diameter (SMD) from 292 μm to 8–15 μm. Under this reduction, close to 100% evaporation rate was achieved in comparison to only a 1% evaporation rate for the largest SMD. It was concluded that the utilization of a fine droplet spray nozzle provides an effective solution for the reduction in water consumption (97% in our case) for data centres, whilst concomitantly augmenting the proportion of evaporation. Full article

In order to improve the fuel economy of heavy-duty diesel engines under high-load conditions, based on the combustion pathway model, it is proposed that the proportion of lean mixture with 0 < Φ < 1 is the most important spray characteristic affecting the overall diesel combustion process. Answering the question of how to increase the proportion of lean mixture inside the spray is the key to achieving the efficient and clean combustion of diesel engines. This paper investigated the mechanism of injector nozzle diameter on the in-cylinder air–fuel mixture and combustion process based on a high-density and lean mixture characteristic combustion strategy. The experimental results show that with an increase in nozzle diameter, the peak pressure and instantaneous heat release rate significantly increase, the combustion duration is shortened by about 20%, and the heat release becomes more concentrated. At 1200 rpm and IMEPg~2.3 MPa conditions, the indicated thermal efficiency increases by 1.3%, reaching a maximum of 51.5%. The numerical simulation results show that with the increase in nozzle diameter from 0.169 mm to 0.218 mm, the spray ejection momentum per unit time increases by 30%, the momentum transferred to the air by the spray increases, the oxygen transport process becomes more intense, and the air entrainment mass during the spray free development stage increases by 42%. The proportion of lean mixture inside the spray throughout the entire spray development process increases, resulting in an increase in the heat release rate of the lean mixture, making the overall combustion more intense and concentrated. Full article

Additive manufacturing technologies such as directed energy deposition use powder as their raw material, and it must be deposited in a precise and controlled manner. Venturi injectors could be a solution for the highly precise transport of particulate material. They have been studied from different perspectives, but they are always under high-pressure conditions and mostly fed by gravity. In the present study, an optimization of the different dimensional parameters needed for the manufacturing of a Venturi injector in relation to a particle has been carried out to maximize the amount of powder capable of being sucked and transported for a specific flow in a low-pressure system with high precision in transport. For this optimization, simulations of Venturi usage were performed using the discrete element method, generating different variations proposed by a genetic algorithm based on a preliminary design of experiments. Statistical analysis was also performed to determine the most influential design variables on the objective, with these being the suction diameter (D3), the throat diameter (d2), and the nozzle diameter (d1). The optimal dimensional relationships were as follows: a D3 34 times the particle diameter, a d2 26.5 times the particle diameter, a d1 40% the d2, a contraction angle alpha of 18.73°, and an expansion angle beta of 8.28°. With these proportions, an 85% improvement in powder suction compared to the initial attempts was achieved, with a maximum 2% loss of load. Full article

In order to optimize the slit/slot geometry design of a bipropellant pintle injector, the impinging spray development of a pintle injector was numerically investigated. The VOF (volume of fluid) and LES (large eddy simulation) methods were employed for an analysis to capture the gas–liquid interface by means of the AMR (adaptive mesh refinement) method. In those simulation cases, different flowrates, slot numbers, pintle diameters, slot thicknesses and slot shapes were compared for an analysis. In a comparison of visualization and quantification, a high flowrate and large pintle diameter were shown to be more positive features for improving the atomization quality and mixing effect. As for the slot parameters and shape, the spray development was mainly determined by the flow proportion between the slit jet and slot jet. The simulation results indicated that dominant slot jets cause a more dispersed spatial distribution, which is more conducive to the subsequent improvement of combustion efficiency in a limited space. However, an excessive increase in the number of slot jets can weaken the overall atomization quality and mixing effect, so it is suggested to ensure a balance for geometry design optimization. Full article

The article discusses the results of experimental studies on the course of pyrolysis oil injection through the high-pressure injector of a direct-injection engine. The pyrolysis oil used for the tests was derived from waste plastics (mainly high-density polyethylene—HDPE). This oil was then distilled. The article also describes the production technology of this pyrolysis oil on a laboratory scale. It presents the results of the chemical composition of the raw pyrolysis oil and the oil after the distillation process using GC-MS analysis. Fuel injection tests were carried out for the distilled pyrolysis oil and a 91 RON gasoline in order to perform a comparative analysis with the tested pyrolysis oil. In this case, the research was focused on the injected spray cloud analysis. The essential tested parameter was the Sauter Mean Diameter (SMD) of fuel droplets measured at the injection pressure of 400 bar. The analysis showed that the oil after distillation contained a significant proportion of light hydrocarbons similar to gasoline, and that the SMDs for distilled pyrolysis oil and gasoline were similar in the 7–9 µm range. In conclusion, it can be considered that distilled pyrolysis oil from HDPE can be used both as an additive for blending with gasoline in a spark-ignition engine or as a single fuel for a gasoline compression-ignition direct injection engine. Full article

In the present study, a hydrogen and oxygen heat-sink engine thrust chamber and the corresponding injection faceplate with discrete slot orifices are devised to study the cooling performance near the faceplate region. Moreover, a set of experiments and numerical simulations are conducted to evaluate the effects of various factors on combustion performance and film cooling efficiency. According to the obtained result, the circumferential cooling efficiency has an M-shaped distribution in the near-injector region. Furthermore, it has been discovered that when the film flow ratio increases, so does the cooling efficiency. This is especially more pronounced in the range of 30–80 mm from the faceplate. The cooling efficiency is found to be proportional to the film flow rate ratio’s 0.4 power. Compared with the slot thickness, the reduction in the slot width is more beneficial in improving the cooling efficiency, and the advantage is more prominent for small film flow ratios. In addition, when the amount of coolant is not enough, the cooling effect of the discrete slot film orifice is better than that of the common cylindrical orifice. The present article demonstrates that setting the area ratio of the adjacent film orifices is an effective way to reduce the uneven circumferential distribution of the wall surface temperature. Full article

According to the basic structure and working principle of the excitation signal sensors of a diesel engine electronic control unit (ECU), a segmentation model of an ECU excitation signal based on characteristic parameters (ESCP-SM) is proposed. In the ESCP-SM, the ECU excitation signal is divided into several parts, and each part has its characteristic parameters model. By using the same global parameters and strictly controlling each part’s proportional parameters, the ESCP-SM can achieve signal alignment and dynamic frequency modulation. Based on the simulation experiment, spectrum analysis proves that this modeling method ensures that the original signal’s effective information is not lost. Pearson similarity analysis shows that the similarity between the simulation signal and practical signal reaches 74%, exhibiting strong correlation. In addition, we set up a physical testing environment. ESCP-SM is realized based on virtual instrument technology, and provides excitation signals for a Komatsu 8 ECU. By modifying the parameter configuration, the ECU can drive the injector to work correctly. Full article

The 3-component velocity distribution of two lean-burn gas turbine fuel injectors are measured at a planar location near and parallel to the injector outlet. The two injectors are nominally the same design, but one features blocked central passages to study the effects of the presence of multi-streams and reveal the single stream characteristics embedded within the multi-stream configuration. Stereoscopic particle image velocimetry is used in an isothermal, non-reacting water analogue flow facility at an engine relevant Reynolds number. The velocity data is analysed using proper orthogonal decomposition (POD) and the work introduces the concept of Zonal POD. This is the splitting of the velocity field into zones prior to the calculation of POD modes to better identify prominent structures and features associated with each zone. Because modes are sorted by the area averaged energy contribution, zoning of a velocity field of interest may change the individual modes and will almost certainly change their order for anything other than trivial flow fields. Analysis of ensemble average and velocity fluctuation profiles reveals a radial shift outboard of the mains flow with the presence of the pilot as well as a general increase in RMS across the intermediate region between the pilot and mains flows. Analysis of POD temporal coefficients in the frequency domain reveals a low-frequency peak is evident in the mains flow region, but which may be affected by the presence of pilot flow. Furthermore, application of the ZPOD technique results in a closer representation of the velocity data for a given number of modes. This shows the behaviour of the unsteady pilot flow and reveals that a significant proportion of the fluctuating energy, RMS, is caused by this characteristic. Full article

Injectors are key pieces of equipment for chemigation systems, and their hydraulic performance has a significant effect on chemigation systems and crops. In order to investigate the influence of different working parameters on hydraulic performance for a water-powered proportional injector (PI), three key parameters of inlet and injection flow rate were researched using a one-factor experimental design method. The regression equations between different factors and response variables were established through a response surface method based on one-factor experimental results. Lastly, a mathematical model of the actual injection ratio was established. Some experiments under different, randomly selected parameter combinations were carried out to verify the prediction precision of the mathematical mode. The results showed that the injection flow rate increased first within the differential pressure of 0.05 to 0.10 MPa and then tended towards stability with increasing differential pressure. The injection flow rate decreased by increasing the viscosity and the change in the injection flow rate was small enough when the viscosity was greater than 500 mPa·s. The impact factors, in order of significance, for inlet flow rate were differential pressure, viscosity of injection liquid and setting injection ratio. The impact factors, in order of significance, for injection flow rate were viscosity of injection liquid, setting injection ratio and differential pressure. The regressive model for predicting the actual injection ratio was validated using an experiment and the relative deviation between calculated value and tested value was less than 5.98%, which indicated that the mathematical model had high credibility. Full article

The present investigation uses a blend of Nigella sativa biodiesel, diesel, n-butanol, and graphene oxide nanoparticles to enhance the performance, combustion and symmetric characteristics and to reduce the emissions from the diesel engine of a modified common rail direct injection (CRDI). A symmetric toroidal-type combustion chamber and a six-hole solenoid fuel injector were used in the current investigation. The research aimed to study the effect of two fuel additives, n-butanol and synthesized asymmetric graphene oxide nanoparticles, in improving the fuel properties of Nigella sativa biodiesel (NSME25). The concentration of n-butanol (10%) was kept constant, and asymmetric graphene oxide nano-additive and sodium dodecyl benzene sulphonate (SDBS) surfactant were added to n-butanol and NSME25 in the form of nanofluid in varying proportions. The nanofluids were prepared using a probe sonication process to prevent nanoparticles from agglomerating in the base fluid. The process was repeated for biodiesel, n-butanol and nanofluid, and four different stable and symmetric nanofuel mixtures were prepared by varying the graphene oxide (30, 60, 90 and 120 ppm). The nanofuel blend NSME25B10GO90 displayed an enhancement in the brake thermal efficiency (BTE) and a reduction in brake-specific fuel consumption (BSFC) at maximum load due to high catalytic activity and the enhanced microexplosion phenomenon developed by graphene oxide nanoparticles. The heat release rate (HRR), in-cylinder temperature increased, while exhaust gas temperature (EGT) decreased. Smoke, hydrocarbon (HC), carbon monoxide (CO₂) and carbon monoxide (CO) emissions also fell, in a trade-off with marginally increased NO_x, for all nanofuel blends, compared with Nigella sativa biodiesel. The results obtained indicates that 90 ppm of graphene oxide nanoparticles and 10% n-butanol in Nigella sativa biodiesel are comparable with diesel fuel. Full article

Flame pulsation has a significant effect on combustion, and understanding its oscillatory behavior is important to the combustion community. An experiment was performed to analyze the pulsation characteristics of a swirl non-premixed flame under various parameters. The results showed that as fuel mass flow rate increased, the puffing frequency increased due to the decreased flame radiation fraction, and the puffing amplitude became smaller resulting in a more stable flame. With an increase in combustor pressure, the flickering frequency declined because of the increasing soot radiation, while the flickering amplitude uniformly increased, leading to more deteriorative flame stability. With an increment in mass flow rate of primary air, the puffing frequency decreased due to the enhanced mixing between fuel and primary air. Also, the puffing amplitude had an oscillating relationship with the mass flow rate of primary air. When the exit velocity of the injector was increased, the flickering frequency diminished nearly linearly because of the improving swirl intensity, and the flickering amplitude was approximately unaffected by injector exit velocity. Moreover, the measured puffing frequencies summarized over all cases varied within the range of 3–22 Hz, the predicted values from theoretical models based on non-swirl flame also fell within this range. The puffing frequency of swirl combustion was more sensitive to the variation in operating conditions than that of non-swirl combustion. Additionally, the obtained correlations indicated that the Strouhal number St was proportional to Fr^−1.4 (the Froude number) and Re^−2.9 (the Reynolds number), respectively. Full article

A multi-pulse injection strategy for premixed charge compression ignition (PCCI) combustion was investigated in a four-valve, direct-injection diesel engine by a computational fluid dynamics (CFD) simulation using KIVA-3V code coupled with detailed chemistry. The effects of fuel splitting proportion, injection timing, spray angles, and injection velocity were examined. The mixing process and formation of soot and nitrogen oxide (NO_x) emissions were investigated as the focus of the research. The results show that the fuel splitting proportion and the injection timing impacted the combustion and emissions significantly due to the considerable changes of the mixing process and fuel distribution in the cylinder. While the spray, inclusion angle and injection velocity at the injector exit, can be adjusted to improve mixing, combustion and emissions, appropriate injection timing and fuel splitting proportion must be jointly considered for optimum combustion performance. Full article
