Search Results (549)

The optimization of Fused Filament Fabrication (FFF) process parameters is commonly performed using room-temperature mechanical properties as the main decision criteria, while the temperature-dependent thermomechanical response of printed polymers is often not explicitly considered. This limitation is relevant for functional components intended to operate above room temperature, where stiffness retention and viscoelastic behavior may strongly affect service performance. This work proposes an experimental–statistical framework for selecting FFF parameters by integrating Design of Experiments (DoE), tensile testing, dynamic mechanical analysis (DMA), Analysis of Variance (ANOVA), the Entropy Weight Method (EWM) and the VIKOR method. Two materials with contrasting thermomechanical behavior were investigated: a high-performance semicrystalline polymer, Z-PEEK, and an elastomeric thermoplastic, TPU 95A. For each material, a DoE was defined to evaluate the influence of key printing parameters, and the manufactured specimens were characterized in terms of maximum tensile force, maximum deformation and storage modulus at selected temperatures. The ANOVA results showed a material-dependent influence of the processing parameters, with thermally driven parameters being especially relevant for Z-PEEK and deposition-related parameters having a stronger influence on TPU 95A. The EWM–VIKOR analysis identified the optimal Z-PEEK configuration as 400 °C extrusion temperature, 200 °C build plate temperature and 150 °C chamber temperature, whereas the optimal TPU 95A configuration corresponded to 225 °C extrusion temperature, 0.10 mm layer height, 50 mm/s printing speed and 80 °C build plate temperature. Overall, the results demonstrate that incorporating DMA-derived thermomechanical indicators into MCDM-based optimization provides a more application-oriented basis for FFF parameter selection than approaches based only on room-temperature mechanical properties. Full article

The synthesis of reactive sucrose derivatives is of significant interest for the development of novel biocompatible polymers. In this study, an octa-substituted sucrose derivative containing isocyanate groups was synthesized via a urethane-forming reaction carried out in an aprotic solvent at the phase interface. This approach exhibits high selectivity and provides a target product yield of up to 60%. Subsequently, using the same reaction mechanism, the isocyanate derivative was converted into an octa-functional methacrylate derivative capable of forming three-dimensional cross-linked networks. The structures of both the intermediate and final products were confirmed by IR, ¹H NMR, and mass spectrometry. The sucrose-based prepolymer was further evaluated in the formation of cross-linked structures for potential application as bone-substituting implants. Using various photocuring techniques, including two-photon 3D printing, both plates and microstructured scaffolds were fabricated. These structures exhibited high thermal stability, elastic properties comparable to those of bone tissue, and no toxic effects on cells. Full article

Additive manufacturing by material extrusion enables the fabrication of geometrically complex components, yet the extent to which process parameters can be used to tailor stiffness and damping in a frequency-dependent manner remains insufficiently understood. This study investigates the influence of key material-extrusion process parameters (layer height, printing speed, extrusion temperature, build plate temperature, and flow rate) on the flexural storage modulus $E^{\prime }$ and loss factor $\eta$ of PETG specimens over a frequency range of 125 to 4000 Hz. Frequency-resolved regression models were established for six reference frequencies using VIF-based term reduction and hierarchical backward elimination. The results reveal a clear contrast between stiffness- and damping-related responses. The model structure for $E^{\prime }$ remained invariant across all frequencies, achieving consistently high coefficients of determination ($R^2$ = 0.831–0.847). In contrast, the model structure for $\eta$ varied markedly with frequency ($R^2$ = 0.215–0.763). Extrusion temperature was identified as a consistently significant factor for $\eta$ across all frequencies ($p<0.05$), while a robust nonlinear dependence on flow rate dominated most frequency bands. Reduced model adequacy for $\eta$ was observed at specific bands, showing significant lack-of-fit at 500 Hz ($p_{LOF}=0.049$) and non-normal residuals at 4000 Hz ($p_{JB}=0.003$). These findings demonstrate that stiffness can be tuned reliably using frequency-invariant process relationships, whereas damping requires frequency-aware parameter selection. This approach provides a statistically rigorous basis for optimizing additively manufactured components where both stiffness and energy dissipation are performance-critical. Full article

Polymer-based composites with magnetic properties are promising materials that are able to combine the usual polymer features (low density, high electrical resistance, enhanced flexibility, and processability, etc.) with magnetic properties typically associated with ferro- or ferrimagnetic metals, alloys or metal oxide. The combination of recycled NdFeB powders with additive manufacturing techniques based on material extrusion enables the production of magnetic composites. The novelty of this approach lies in the use of 3D printing supported by an external magnetic field, which is used to align the particles during the printing process and thus improve the final magnetic properties. This approach represents a sustainable strategy for the recovery of electronic waste, converting it into high-value-added magnetic materials intended for additive manufacturing applications. Micrometric particles made of a Neodymium–Iron–Boron (NdFeB) alloy are compounded with a flexible thermoplastic matrix made of polybutylene adipate-co-terephthalate (PBAT). The NdFeB alloy is recovered from permanent magnets of obsolete hard drives and is demagnetized, ground to powder under an inert atmosphere, and finally sieved to a particle size below 50 µm. The obtained powder is mixed with the polymer using a twin-screw extruder. The composite material containing the NdFeB particles is then processed to obtain a calibrated filament, used for the fused deposition modeling (FDM) three-dimensional (3D) printing of magnetic composites. To improve the composite’s ferromagnetic behavior, the particles were aligned along the stacking direction of the layers during the 3D FDM process by printing directly onto a permanent magnet placed on the build plate. Composites containing up to 50% by weight of recycled NdFeB powder were successfully processed using FDM technology, exhibiting increased stiffness, with the storage modulus rising from 123 to 178 MPa at 20 °C, while magnetic field-assisted printing increased the remanence from 11 to 28 emu/g and improved the reduced remanence from 0.21 to 0.49, corresponding to an estimated fourfold improvement in the magnetic energy product. Full article

SITSCAN CS is an original tactile system, which was primarily developed to investigate pressure distribution on uneven surfaces, e.g., chairs; however, due to its flexibility and modular conception, it can be utilized in other industrial or medical applications too. It consists of a flexible, PET-based PCB print-made sensing plate with active area of 50 × 50 cm with a placed matrix of 50 × 50 individual sensors. It uses the piezoresistive effect of the conductive ink layer as the transducing technology between the applied pressure and the output electrical signal. The tactile system further consists of control electronic circuits which process the measured data with up to 1000 fps with a maximal possible resolution 80 × 80 sensing points. The acquired data can be visualized, stored and further processed by means of the respective PC control program. The article describes the theoretical basis for the tactile system, as well as its development, construction, technical specifications and the testing process. Full article

Bone plates are widely used in orthopaedic surgery to stabilise fractured bones and support healing following traumatic injuries or osteotomies. However, conventional metallic bone plates suffer from stress shielding and stiffness mismatch with bone, which can hinder optimal healing. Additive manufacturing enables the incorporation of novel metamaterial architectures into polymer-based implants to enhance mechanical properties. The fatigue behaviour of these implants during the healing period is critical to ensuring their structural integrity and long-term performance. In this study, the compressive fatigue performance of fused deposition modelling (FDM)-printed carbon fibre-reinforced polylactic acid (CF-PLA) bone plates were investigated. Four metamaterial structures—tetrachiral, re-entrant, rotating square, and hexagonal—were evaluated under strain-controlled cyclic loading at 20%, 40%, 60%, and 80% of their respective yield strains. The results showed a strong dependence of fatigue behaviour on lattice geometry. Among the tested configurations, the re-entrant structured bone plate exhibited the best overall fatigue performance, sustaining up to 100,000 cycles at moderate strain levels and showing delayed stiffness degradation under high strain conditions. In contrast, rotating square and hexagonal structures showed early stiffness loss and failure at higher strain levels. These findings highlight the importance of lattice design in fatigue performance, although FDM-induced printing defects significantly influence overall fatigue behaviour. Full article

Hypernasality is a common characteristic of several speech disorders and can significantly affect perceived speech intelligibility and quality. Nasometry quantifies nasalance by calculating the proportion of acoustic energy emitted from the nasal cavity relative to the combined nasal and oral acoustic output during speech production and is commonly used in clinical assessment and research. However, commercially available nasometers are costly and limited in portability, restricting their use in resource-limited or remote settings. The primary purpose of this study was to design and build a low-cost, open-source mobile nasometer prototype (“mNasometer”) by leveraging advances in 3D printing, off-the-shelf electronic components, and a custom open-source mobile application. A secondary aim was to compare the electroacoustic and subjective performance of mNasometer with that of a gold-standard commercial nasometer. Electroacoustic analyses focused on comparing long-term averaged spectra and the oral/nasal acoustic isolation between the gold-standard commercial nasometer and the proposed mNasometer, which incorporates a 3D-printed nasal separation plate. In addition, nasalance scores were collected from ten healthy young adult participants using both systems during structured speech production tasks (i.e., reading standard passages or nasal sentences). Agreement between devices was evaluated using correlational analyses and comparative statistical procedures. Long-term averaged spectra exhibited similar profiles between the commercial nasometer and the mNasometer across different test stimuli, indicating comparable capture of stimulus energy distributions. Although the mNasometer demonstrated reduced oral–nasal acoustic isolation relative to the commercial system, objective nasalance scores followed similar overall trends between devices, with statistically significant stimulus-dependent differences observed. Frame-wise correlational analyses revealed significant correlations between nasalance measures obtained from the commercial nasometer and the mNasometer across most of the speech production tasks, suggesting that the reduced isolation did not critically compromise measurement correspondence. In summary, the low-cost, open-source mNasometer prototype provides nasalance measurements that show promising agreement with those of a gold-standard commercial device. Its reduced cost and increased portability suggest potential for expanded research and field-based applications in the objective assessment of nasalance. Full article

The optimization of impact localization in 3D-printed structures is critical for their application in smart monitoring and damage detection systems. This study investigates the influence of infill density on the accuracy of low-velocity impact localization in 3D-printed plates. Specimens with cubic infill patterns and varying densities (30%, 50%, and 100%) were fabricated and subjected to impacts with varying locations and magnitudes using two different sensor network configurations. A genetic algorithm integrated with continuous wavelet transform was employed to simultaneously determine impact coordinates and group velocity. Key findings reveal that lower infill structures act as mechanical low-pass filters, producing clean and low-frequency signals, while higher densities support complex wave propagation with higher energy and broader frequency content. The dominant frequency of first arrival shifts toward lower values with increasing impact energy across all densities. Group velocity increases with both impact energy and infill density. For 30% infill, it averages around 450 m/s, while for 100% infill it exceeds 800 m/s. The genetic algorithm demonstrated robust performance across all experimental conditions, simultaneously estimating impact coordinates and group velocity with average errors below 6% for all infill densities. Spatial probability mass functions revealed tightly clustered predictions around true impact locations, with maximum probabilities reaching 68% and uncertainties below 5%. Computational efficiency varied modestly with infill density. These findings provide quantitative relationships between infill density, wave propagation characteristics, and localization performance for designing a reliable structural health monitoring of additively manufactured structures. Full article

Airfoil fin Printed Circuit Heat Exchangers (PCHEs) offer significant advantages in reducing flow resistance, promoting turbulence, and enhancing heat transfer performance due to their discrete fin configuration. However, compared with conventional continuous-channel structures, the geometric discontinuities and sharp trailing edges introduced by discrete fins tend to induce severe stress concentration at the fin roots, resulting in a more complex structural response. In this study, a PCHE core with NACA0020 airfoil fins is investigated. Finite element analysis combined with a sequential one-way thermo-structural coupling approach is conducted to characterize the fins’ stress and deformation behavior under high temperature and pressure. The plate region is evaluated based on the linear elastic stress criteria specified in ASME Boiler and Pressure Vessel Code Section III, while localized yielding regions such as the fin roots are assessed using an equivalent plastic strain indicator. Results indicate that the structural response of the PCHE core is dominated by pressure loading under the investigated operating conditions with ΔT = 18 °C and ΔP = 12.05 MPa, whereas thermal stress caused by constrained thermal expansion mainly modifies local stress distributions and has a limited effect on global deformation. Owing to the discontinuous support provided by discrete airfoil fins, the fin roots act as the primary load-transfer path and sustain higher stress levels. The maximum von Mises stress is observed at the trailing edge of the fin root on the high-pressure side, while the largest deformation occurs in the unsupported plate region and is governed by bending. Parametric analysis indicates that, within the investigated parameter range, a fully staggered fin arrangement promotes more uniform load distribution and exhibits the most favorable structural response. In contrast, increasing the fin chord length and relative thickness reduces the overall load-carrying capacity of the core. Finally, a power-law predictive correlation for the maximum total plate deformation was developed, showing that the parameter influence on plate structural response follows the order horizontal pitch (L_h) > vertical pitch (L_v) > channel etching depth (L_e) > staggered pitch (L_s). In contrast, normalized sensitivity analysis of the maximum fin-root von Mises stress shows the order staggered pitch (L_s) > horizontal pitch (L_h) > vertical pitch (L_v) > channel etching depth (L_e), indicating that global plate deformation and local fin-root response are governed by different structural mechanisms. Full article

This article presents an approach to extend the capabilities of vat photopolymerization (VPP) 3D printing using a robotic arm, with a focus on robust path planning. The robotic cell consists of a Mecademic Meca500 six-axis robot mounted on a Zaber X-LRQ300AP linear guide. The kinematic chain is inverted to reflect the logic of VPP: the world reference frame is fixed to the robot’s tool (the build plate), while the tool frame is attached to the polymerization zone. A virtual degree of freedom for screen image rotation is introduced, bringing the system to eight degrees of freedom. Inverse kinematics are solved under constraints (pose tolerance, joint limits, collision avoidance, and continuity) and evaluated using multi-criteria metrics: manipulability, normalized joint-limit margin, and positional/angular sensitivity. The algorithm follows a deterministic coarse-to-fine search procedure: discrete sweeping of global part orientations, initial sampling with Halton sequences, abd feasibility filtering on a sparsified trajectory, followed by refinement and multi-criteria ranking. The pipeline successfully discarded infeasible orientations and identified feasible printing trajectories for six of the seven benchmark parts, while the remaining case highlights a limitation that may be addressed in future improvements. Full article

Background: Additive manufacturing provides a rapid and flexible alternative to conventional micromolding for producing microneedle systems. This study evaluates the potential of a cost-effective LCD 3D printer for fabricating microneedle arrays (MNAs) and investigates how the geometry of MNAs and the formulation of hydrogel influence the performance of lidocaine-coated arrays. Methods: Conical and pyramidal MNAs, along with a reservoir plate, were designed and manufactured. Lidocaine-loaded and placebo hydrogels with two different polymer concentrations were prepared for dip-coating using both single and multilayer applications. Mechanical resistance and insertion efficiency were evaluated under controlled compression. The physicochemical behavior of the hydrogels were characterized, including pH, spreadability, adhesiveness, and rheological behavior. The uniformity of the coating was analyzed using 3D confocal microscopy. Drug loading was quantified by HPLC, drug release was studied using Franz diffusion cells, and skin penetration was confirmed by 3D confocal imaging and Raman mapping. Results: Conical microneedles exhibited high mechanical integrity, showing only a 2% reduction in height compared to 4% for pyramidal MNAs. Stronger drug signals were achieved in deeper skin layers with the conical geometry, indicating enhanced penetration, while pyramidal MNAs provided slightly higher lidocaine loading due to their larger lateral surface. Hydrogels with higher polymer content produced more stable, uniform coatings, particularly when applied in three layers. Rapid drug release was observed, with over 70% of the drug delivered within minutes. Conclusions: LCD 3D printing offers a cost-effective approach for fabricating MNAs with suitable structural stability and sharpness. The optimized hydrogel formulation ensured uniform coverage, as well as maximal and consistence penetration, making this platform a promising candidate for the dermal delivery of other potent drugs. Full article

The Fused Filament Fabrication (FFF) process has established itself as a key technology in prototyping and development and has garnered increasing interest in academic research. A substantial body of research on the FFF process has focused on the influence of process parameters on the resultant material/part properties. The thermal history of the printed part has proven itself as one of the most important factors in the printing process. It influences warping behavior, dimensional accuracy, build plate adhesion, as well as the mechanical properties of the finished part. A key requirement for understanding the influence of thermal history is the knowledge of the thermal properties of the considered material. In this study, the temperature-dependent thermal properties (isobaric heat capacity, thermal conductivity and density) of an unfilled polyamide 6 material for 3D printing are provided. Special attention is given to discussing the challenges associated with measuring these properties, particularly regarding how well the measured values represent the actual conditions during the printing process. Full article

Rectangular waveguides, serving as a standardized versatile platform for manipulating terahertz radiation within controlled environments, have been extensively employed across a broad range of terahertz systems. However, conventional fabrication methods encounter significant challenges in realizing such submillimeter-scale structures within a monolithic integration, particularly when subwavelength features or intricate geometries are incorporated for advanced functionalities. In this work, we propose a fabrication route integrating stereolithography 3D printing and electroless plating, and demonstrate its broad applicability, intrinsic benefits and limitations through the realization of various high-performance D-band terahertz rectangular waveguides and antennas. The resulting rectangular waveguides achieve an insertion loss below 0.3 dB and a return loss above 15 dB across the D-band, while remaining stable across extreme temperatures (−50 °C to 150 °C) and offering a weight reduction of over 60%. A monolithically fabricated smooth-walled conical horn antenna exhibits beam-shaping characteristics that closely align with theoretical expectations. Attempts on corrugated horn antennas in conventional design reveal degraded performance, primarily arising from the inherent staircase effect associated with 3D printing. A novel design featuring obliquely oriented corrugations is developed, effectively mitigating uncontrolled deformation in periodic subwavelength features. Compared with the classical corrugated design (θ = 90°), the proposed obliquely oriented corrugations (θ = 30°) improve the agreement between experimental and theoretical radiation patterns, reducing the gain deviation from 1.45 dB to less than 0.5 Db—a quantitative improvement of over 60% in pattern fidelity. We believe that this fabrication route together with the process-adaptive design paradigm establishes a robust technical foundation for realizing high-performance, lightweight, and design-flexible terahertz waveguide components and holds significant promise for advancing the development of next-generation integrated terahertz systems. Full article

Electromagnetic (EM) radiation emitted by various sources can cause malfunctions or damage to other electronic devices. Composite materials are widely used for EM field shielding. This work presents and analyzes the dielectric properties of 3D-printed composites containing carbon nanotubes (CNTs) and barium titanate (BaTiO₃) over a broad frequency range. The analyzed 3D structures included a fully filled plate (PL), a basic honeycomb (BH), a honeycomb with re-entrant auxetic features (HREA), and a hierarchical honeycomb (HH). It was found that the composite material containing 1.8 wt.% CNTs and 20 wt.% BaTiO₃ exhibits the highest absorption coefficient in the frequency range from 25 GHz to 53 GHz for all investigated 3D structures. A high concentration of BaTiO₃ increases dielectric loss and interfacial polarization, while providing a CNT network. The synergy of these mechanisms results in the highest absorption of EM waves in the 25–53 GHz range. Moreover, all samples containing BaTiO₃ inclusions exhibited a distinctive electrical conductivity behavior, attributed to the high complex dielectric permittivity of barium titanate, which enhances interfacial polarization. The highest conductivity and dielectric permittivity values were measured in samples containing 1.8 wt.% CNTs and 10 wt.% BaTiO₃, while a further increase in BaTiO₃ concentration caused a decline in dielectric performance. This effect is due to the dispersion and agglomeration of filler particles in composites with higher BaTiO₃ concentrations. Full article

Background/Objectives: Unilateral condylar hyperplasia is an idiopathic condition that causes facial asymmetry and occlusal problems. Currently, traditional treatment protocol is the combination of orthognathic and extra-oral condylectomy surgery via pre-auricular incision, which can create aesthetic problems with additional risks of facial nerve damage. The purpose of this study was to report management of condylar hyperplasia patients through minimally invasive condylectomy that was planned via virtual methods. Methods: The custom-made cutting guides were produced, and unilateral condylectomy operations were performed via intra-oral approach. Orthognathic surgery with/without genioplasty operations were either done with condylectomy in one session or in an additional session. Results: Custom-made cutting guides produced by virtual methods provided easy operations without any need for additional extra-oral incisions. Planned osteotomies were transferred successfully from the virtual surgical plan and resections of the excess bone tissues were performed using novel piezo surgery devices. The bones were fixed to their pre-planned position using 3D-printed titanium plates. The patients healed without any complications. Results of this innovative virtually guided protocol tested showed functional and esthetic results without any extra-oral scars with no facial nerve damage. Conclusions: Combination of intra-oral condylectomy with orthognathic surgery using 3D-printed titanium cutting guides seems to be an advantageous approach with successful results in terms of aesthetics and function for management of mandibular condylar hyperplasia patients; however, there is an urgent need in the scientific literature for further clinical research with a larger number of subjects. Full article
