Search Results (36)

The continuous need for simplified, minimally invasive restorative procedures with a high precision has led to the advancement of highly filled flowable resin-based materials. These materials present excellent initial outcomes in various clinical applications, including the injection molding technique. Given that several clinical reports present signs of wear and staining, this systematic review aims to investigate the mechanical and optical properties of highly filled flowable composite resins. A comprehensive literature research was conducted to identify relevant studies from the PubMed, the Cochrane Library, and Scopus databases. Data extraction and screening was performed by two independent evaluators. Both in vitro studies and clinical trials were included. A total of thirty-one studies were included in this review. A total of 27 in vitro studies investigated highly filled flowable composite resins independently, or in comparison with conventional composite resins, traditional flowable composites, bulk-fill flowable composites, glass ionomer cements, and compomers. Additionally, four randomized controlled clinical trials (RCTs) compared highly filled flowable composite resins with their conventional counterparts. Highly filled flowable composite resins exhibit adequate optical properties. Despite their significant improvements, their mechanical properties remain inferior to those of medium-viscosity composite resins. These materials demonstrate a favorable initial performance in the injection molding technique. Based on a limited number of RCTs, these materials demonstrate an adequate performance in class I and II restorations; however these findings should be interpreted with caution. The reported drawbacks in laboratory studies may contraindicate their clinical application in extensive cavities, load-bearing areas, and in cases of excessive tooth wear and parafunctional activity. A careful clinical case selection is strongly recommended. Full article

High stress and shape deviation during the glass forming process often led to low yield rates, posing a challenge in the production of high-precision smartwatch components. To address this issue, a numerical model was developed to simulate and analyze the forming behavior of 3D curved glass. The study focused on achieving a balance between energy consumption and key quality attributes, such as residual stress and shape accuracy. Results showed that forming pressure primarily affects shape deviation, while forming temperature plays a dominant role in energy usage and residual stress. Through orthogonal experiments, optimal parameters were identified: a forming temperature of 630 °C, pressure of 0.25 MPa, and cooling rate of 0.25 °C/s effectively minimize residual stress. Meanwhile, shape deviation is minimized at 630 °C, 0.30 MPa, and a cooling rate of 0.75 °C/s. Energy efficiency analysis indicated that low efficiency occurs at 610 °C with a 3 °C/s heating rate. Furthermore, NSGA-II multi-objective optimization validated the model’s accuracy, with prediction errors under 20%, offering valuable guidance for the precise fabrication of smartwatch glass. Full article

The rapid development of microfluidics has driven innovations in material engineering, particularly through its ability to precisely manipulate fluids and cells at microscopic scales. Microfluidic biomaterials, a cutting-edge interdisciplinary field integrating microfluidic technology with biomaterials science, are revolutionizing biomedical research. This review focuses on the functional design and fabrication of organ-on-a-chip (OoAC) platforms via 3D bioprinting, explores the applications of biomaterials in drug delivery, cell culture, and tissue engineering, and evaluates the potential of microfluidic systems in advancing personalized healthcare. We systematically analyze the evolution of microfluidic materials—from silicon and glass to polymers and paper—and highlight the advantages of 3D bioprinting over traditional fabrication methods. Currently, despite significant advances in microfluidics in medicine, challenges in scalability, stability, and clinical translation remain. The future of microfluidic biomaterials will depend on combining 3D bioprinting with dynamic functional design, developing hybrid strategies that combine traditional molds with bio-printed structures, and using artificial intelligence to monitor drug delivery or tissue response in real time. We believe that interdisciplinary collaborations between materials science, micromachining, and clinical medicine will accelerate the translation of organ-on-a-chip platforms into personalized therapies and high-throughput drug screening tools. Full article

This study presents a sustainable approach to transform waste cooking oil (WCO) into a multifunctional 3D-printable photocurable elastomer with integrated self-healing capabilities. A linear monomer, WCO-based methacrylate fatty acid ethyl ester (WMFAEE), was synthesized via a sequential strategy of transesterification, epoxidation, and ring-opening esterification. By copolymerizing WMFAEE with hydroxypropyl acrylate (HPA), a novel photocurable elastomer was developed, which could be amenable to molding using an LCD light-curing 3D printer. The resulting WMFAEE-HPA elastomer exhibits exceptional mechanical flexibility (elongation at break: 645.09%) and autonomous room-temperature self-healing properties, achieving 57.82% recovery of elongation after 24 h at 25 °C. Furthermore, the material demonstrates weldability (19.97% retained elongation after 12 h at 80 °C) and physical reprocessability (7.75% elongation retention after initial reprocessing). Additional functionalities include pressure-sensitive adhesion (interfacial toughness: 70.06 J/m² on glass), thermally triggered shape memory behavior (fixed at −25 °C with reversible deformation/recovery at ambient conditions), and notable biodegradability (13.25% mass loss after 45-day soil burial). Molecular simulations reveal that the unique structure of the WMFAEE monomer enables a dual mechanism of autonomous self-healing at room temperature without external stimuli: chain diffusion and entanglement-driven gap closure, followed by hydrogen bond-mediated network reorganization. Furthermore, the synergy between monomer chain diffusion/entanglement and dynamic hydrogen bond reorganization allows the WMFAEE-HPA system to achieve a balance of multifunctional integration. Moreover, the integration of these multifunctional attributes highlights the potential of this WCO-derived photocurable elastomer for various possible 3D printing applications, such as flexible electronics, adaptive robotics, environmentally benign adhesives, and so on. It also establishes a paradigm for converting low-cost biowastes into high-performance smart materials through precision molecular engineering. Full article

Monitoring of molding processes is one of the most challenging future tasks in polymer processing. In this work, the in situ monitoring of the curing behavior of highly filled EMCs (silica filler content ranging from 73 to 83 wt%) and the effect of filler load on curing kinetics are investigated. Kinetic modelling using the Friedman approach was applied using real-time process data obtained from in situ DEA measurements, and these online kinetic models were compared with curing analysis data obtained from offline DSC measurements. For an autocatalytic fast-reacting material to be processed above the glass transition temperature T_g and for an autocatalytic slow-reacting material to be processed below T_g, time–temperature–transformation (TTT) diagrams were generated to investigate the reaction behavior regarding T_g progression. Incorporating a material containing a lower silica filler content of 10 wt% enabled analysis of the effects of filler content on sensor sensitivity and curing kinetics. Lower silica particle content (and a larger fraction of organic resin, respectively) favored reaction kinetics, resulting in a faster reaction towards T_g1. Kinetic analysis using DEA and DSC facilitated the development of highly accurate prediction models using the Friedman model-free approach. Lower silica particle content resulted in enhanced sensitivity of the analytical method, leading, in turn, to more precise prediction models for the degree of cure. Full article

Zr-based metallic glasses (MGs) are promising materials for mold manufacturing due to their unique mechanical and chemical properties. However, the high hardness of metallic glasses and their tendency to crystallize at high temperatures make it challenging to fabricate precise and smooth microscale structures on metallic glasses. This limitation hampers the development of metallic glasses as molds. Jet electrochemical machining (jet-ECM) is a non-contact subtractive manufacturing technology that utilizes a high-speed electrolyte to partially remove material from workpieces, making it highly suitable for processing difficult-to-machine materials. Nevertheless, few studies have explored microgroove structures on Zr-based MGs using sodium nitrate electrolytes by jet-ECM. Therefore, this paper advocates the utilization of the jet-ECM technique to fabricate precise and smooth microgroove structures using a sodium nitrate electrolyte. The electrochemical characteristics were studied in sodium nitrate solution. Then, the effects of the applied voltages and nozzle travel rates on machining performance were investigated. Finally, micro-helical and micro-S structures with high geometric dimensional consistency and low surface roughness were successfully fabricated, with widths and depths measuring 433.7 ± 2.4 µm and 101.4 ± 1.6 µm, respectively. Their surface roughness was determined to be 0.118 ± 0.002 µm. Compared to non-aqueous-based methods for jet-ECM of Zr-based MGs, the depth of the microgrooves was increased from 20 μm to 101 μm. Furthermore, the processed microstructures had no uneven edges in the peripheral areas and no visible flow marks on the bottom. Full article

In this paper, we proposed an efficient and high-precision process for fabricating large-area microlens arrays using thermal reflow combined with ICP etching. When the temperature rises above the glass transition temperature, the polymer cylinder will reflow into a smooth hemisphere due to the surface tension effect. The dimensional differences generated after reflow can be corrected using etching selectivity in the following ICP etching process, which transfers the microstructure on the photoresist to the substrate. The volume variation before and after reflow, as well as the effect of etching selectivity using process parameters, such as RF power and gas flow, were explored. Due to the surface tension effect and the simultaneous molding of all microlens units, machining a 3.84 × 3.84 mm² silicon microlens array required only 3 min of reflow and 15 min of ICP etching with an extremely low average surface roughness Sa of 1.2 nm. Full article

Three new methods for accurate electronic component positioning for thermoformed electronics are presented in this paper. To maintain the mechanical and electrical properties of printed-ink tracks, prevent deformation and stretching during thermoforming, and ensure reproducibility, the component positioning principle for all three proposed methods is based on keeping the temperature of some regions in the thermoplastic substrate less than the glass transition temperature of the thermoplastic carrier, to keep those regions resistant to plastic deformation. We have verified the accuracy of the different approaches by implementing these methods in a semi-sphere mold for positioning seven LEDs and one printed capacitive touch sensor. We compared the result of our fabrication processes with the typical fabrication process of in-mold electronics (direct printing on a thermoplastic foil and followed by a thermoforming step) and noticed that the sample produced by the typical process had tracks that were randomly stretched, tracks were not in a straight path after thermoforming and they were not electrically conductive. Furthermore, the final 3D position of the components was not reproducible sample by sample. However, with our proposed fabrication methods, the tracks and pads do not deform or expand during thermoforming and are electrically conductive after. Moreover, the round shape of the touch sensor remains the same as in the 2D design. Based on the results of the experiments, it appears that the proposed methods are capable of positioning electronic components with high precision in thermoformed electronics. Full article

The high level of stress and dimension deviation induced by glass molding are the main causes of the low yield rate of large, irregular glass components on vehicles. To solve this issue, a numerical model of large glass component molding was established in this study, which aimed to analyze the dominant factors of molding quality and achieve a synergistic balance between quality characteristics and energy consumption. The results show that molding temperature is the dominant factor affecting the energy consumption and residual stress, and the molding pressure is the main factor affecting the dimension deviation. Furthermore, the NSGA-II optimization algorithm was used to optimize the maximum residual stress, dimension deviation, and energy consumption with the numerical results. The combination of a heating rate of 1.95 °C/s, holding time of 158 s, molding temperature of 570 °C, molding pressure of 34 MPa, and cooling rate of 1.15 °C/s was determined to be the optimized scheme. The predictive error of the numerical result, based on the optimized scheme, was experimentally verified to be less than 20%. It proved the accuracy of the model in this study. These results can provide guidance for the subsequent precision molding of large, irregular glass components. Full article

Precision glass molding (PGM) is an efficient process used for manufacturing high-precision micro lenses with aspheric surfaces, which are key components in high-resolution systems, such as endoscopes. In PGM, production costs are significantly influenced by the lifetimes of elaborately manufactured molding tools. Protective coatings are applied to the molding tools to withstand severe cyclic thermochemical and thermomechanical loads in the PGM process and, in this way, extend the life of the molding tools. This research focuses on a new method which combines metallographic analysis and finite element method (FEM) simulation to study the interaction of three protective coatings—diamond-like carbon (DLC), PtIr and CrAlN—each in contact with the high Abbe number glass material S-FPM3 in a precision glass molding process. Molding tools are analyzed metallographically using light microscopy, white light interferometry, scanning electron microscopy (SEM), and energy dispersive X-ray spectroscopy (EDX). The results show that the DLC coating improved process durability more than the PtIr and CrAlN coatings, in which the phenomenon of coating delamination and glass adhesion can be observed. To identify potential explanations for the metrological results, FEM is applied to inspect the stress state and stress distribution in the molding tools during the molding process. Full article

Microlens arrays have been widely employed to control the reflection, refraction, and diffraction characteristics of light due to its distinctive surface properties. Precision glass molding (PGM) is the primary method for the mass production of microlens arrays, of which pressureless sintered silicon carbide (SSiC) is a typical mold material due to its excellent wear resistance, high thermal conductivity, high-temperature resistance, and low thermal expansion. However, the high hardness of SSiC makes it hard to be machined, especially for optical mold material that requires good surface quality. The lapping efficiency of SSiC molds is quite low. and the underlying mechanism remains insufficiently explored. In this study, an experimental study has been performed on SSiC. A spherical lapping tool and diamond abrasive slurry have been utilized and various parameters have been carried out to achieve fast material removal. The material removal characteristics and damage mechanism have been illustrated in detail. The findings reveal that the material removal mechanism involves a combination of ploughing, shearing, micro-cutting, and micro-fracturing, which aligns well with the results obtained from finite element method (FEM) simulations. This study serves as preliminary reference for the optimization of the precision machining of SSiC PGM molds with high efficiency and good surface quality. Full article

This study investigates the use of Ge₂₈Sb₁₂Se₆₀ chalcogenide glass for the compression molding of an infrared optical lens with a diffractive structure. Firstly, a mold core was prepared through ultra-precision grinding of tungsten carbide, and a chalcogenide glass preform was crafted through a polishing process and designed with a radius that would prevent gas isolation during the molding process. The test lens was then molded at various temperature conditions using the prepared mold core and preform. The diffractive structures of both the mold core and the resulting molded lens were analyzed using a microscope and white light interferometer. The comparison of these diffractive structures revealed that the molding temperature had an effect on the transferability of the diffractive structure during the molding of the chalcogenide glass lens. Furthermore, it was determined that, when the molding temperature was properly adjusted, the diffractive structure of the core could be fully transferred to the surface of the chalcogenide lens. Optimized chalcogenide glass-based lenses have the potential to serve as cost-effective yet high-performance IR optics. Full article

Precise infrared (IR) optics are core elements of infrared cameras for thermal imaging and night vision applications and can be manufactured directly or using a replicative process. For instance, precision glass molding (PGM) is a replicative manufacturing method that meets the demand of producing precise and accurate glass optics in a cost-efficient manner. However, several iterations in the PGM process are applied to compensate the induced form deviation and the index drop after molding. The finite element method (FEM) is utilized to simulate the thermomechanical process, predicting the optical properties of molded chalcogenide lenses and thus preventing costly iterations. Prior to FEM modelling, self-developed glass characterization methods for the stress and structure relaxation of chalcogenide glass IRG 26 are implemented. Additionally, a ray-tracing method is developed in this work to calculate the optical path difference (OPD) based on the mesh structure results from the FEM simulation. The developed method is validated and conducted during the production of molded lenses. Full article

In this study, we determined the effects of design and processing parameters of precision injection molding (PIM) to minimize warpage phenomena of micro-sized parts using various plastics (polyoxymethylene (POM), acrylonitrile-butadiene-styrene (ABS), polypropylene (PP), polyamide (PA), and ABS+ polycarbonate (PC)). We applied a numerical simulation (Moldflow) to determine the runner’s balance in multi-cavities of the micro-sized part and simulate the warpage phenomenon of micro-parts with PIM. We used simulation data to fabricate a steel mold by computer numerical control (CNC) machining. In this, we study manufactured a micro-sized part and measured its warpage value using various PIM process parameters (melt temperature, mold temperature, injection pressure, and filling time). In order to obtain optimal results (i.e., minimum warpage), we employed the Taguchi method and grey theory to discern the influence of each process parameter on PIM. Finally, we determined that the most significant PIM process parameter influencing the warpage phenomenon of micro-sized parts was the mold temperature, regardless of whether in terms of the experimental results, numerical simulations, or grey theory. The PA material had the most suitable properties for application for micro-sized parts, regardless of whether in terms of experimental results, numerical simulations, or grey theory for PIM. This study also illustrates that micro-sized parts can be fabricated by PIM without the use of micro-injection molding, and we determined that the mold temperature required for molding does not need to be higher than the glass-transition temperature of the material. Full article

This paper aims to present a novel rapid hot embossing approach and to study filling capacity of optical glass in the hot embossing process. Firstly, a novel rapid hot embossing device is developed, which consists of a rapid heating module and a precision loading module. Particularly, the rapid heating module allows a maximum temperature of 800 °C and a heating rate of 300 °C/min, with decent temperature control accuracy and uniform temperature distribution. In hot embossing process, by incompletely filling the microhole of silicon carbide mold, a microlens would be formed on the surface of glass disc, and the filling capacity of glass is quantified by the maximum height of the microlens. The tailor-made hot embossing device was exploited to conduct a series of experiments for evaluating effects of process parameters on the filling capacity of N-BK7 glass. Experimental results indicate that the filling capacity of glass could be enhanced by increasing the embossing force, the embossing temperature, the soaking time but decreasing the annealing rate. Furthermore, compared to soaking time and annealing rate, embossing force and embossing temperature have more significant influence on the filling capacity of N-BK7 glass. Therefore, the novel rapid hot embossing is a practical and promising technology for fabricating microstructures on glass materials with high softening points. Full article
