Rice is a primary food source, and height is a crucial parameter affecting its growth status. Consequently, high-precision, real-time monitoring of quantitative changes in crop height are required for improved crop production. Polarimetric interferometric SAR (PolInSAR) has both polarization and interferometric observation capabilities. Due to the short height of crops and rapid growth changes, the large spatial and short temporal baselines of PolInSAR data are essential for effective crop height inversion; however, relevant satellite-borne SAR and airborne SAR data are currently limited. This study presents a PolInSAR rice height inversion algorithm that uses the oriented volume over ground (OVoG) mode with PolInSAR 0-time and controllable spatial baseline data from a LAMP microwave anechoic chamber. Exploiting the advantages of microwave anechoic chamber measurement data, which includes continuous frequency bands, multiple baselines, and varied incidence angles, the influences of incident angles, baseline length, number of baselines, and baseline combinations are assessed. The highest accuracy rice plant height inversion has a root mean square deviation (RMSE) of 0.1093 m and is achieved with an incidence angle of 35–55°, baseline length of 0.25°, and three to four baselines. Furthermore, an imaging geometric equivalence analysis provides reliable foundation data to guide research into new earth observation SAR systems. The results indicate that, under simulated observations from the GF3 satellite at an altitude of 755 km, the optimal spatial baseline ranges for various frequency bands are as follows: L-band: 10.93–42.59 km; S-band: 4.10–15.97 km; C-band: 2.48–9.64 km; X-band: 1.36–5.32 km; Ku-band: 0.87–3.40 km. Notably, the measurement modes corresponding to the C, X, and Ku bands are ultimately identified as the most suitable for PolInSAR rice height inversion. Full article

Forests cover approximately one-third of the Earth’s land surface and constitute the core region of the carbon cycle on Earth. The paramount importance and multi-purpose applications of forest monitoring have gained widespread recognition over recent decades. Polarimetric synthetic aperture radar interferometry (PolInSAR) has been demonstrated as a promising technique to retrieve the forest height over large areas with a limited cost. This paper presents an overview of forest height inversion (FHI) techniques based on PolInSAR data. Firstly, we introduce the basic theories of PolInSAR and FHI procedures. Next, we review the established data-based algorithms for single-baseline data and describe innovative techniques related to multi-baseline data. Then, the model-based algorithms are also introduced with their corresponding forest scattering models under multiple data acquisition modes. Subsequently, a case study is presented to demonstrate the applicable scenarios and advantages of different algorithms. Model-based algorithms can provide accurate results when the scene and forest properties are well understood and the model assumptions are valid. Data-based algorithms, on the other hand, can handle complex scattering scenarios and are generally more robust to uncertainties in the input parameters. Finally, the prospect of forest height inversion was analyzed. It is our hope that this review will provide guidelines to future researchers to enhance further FHI algorithmic developments. Full article

Accurate estimation of forest height over a large area is beneficial to reduce the uncertainty of forest carbon sink estimation, which is of great significance to the terrestrial carbon cycle, global climate change, forest resource management, and forest-related scientific research. Forest height inversion using polarimetric interferometry synthetic aperture radar (PolInSAR) data through Random volume over ground (RVoG) models has demonstrated great potential for large-area forest height mapping. However, the wavelength and baseline length used for the PolInSAR data acquisition plays an important role during the forest height estimation procedure. In this paper, X–, C–, L–, and P–band PolInSAR datasets with four different baseline lengths were simulated and applied to explore the effects of wavelength and baseline length on forest height inversion using RVoG models. Hierarchical Bayesian models developed with a likelihood function of RVoG model were developed for estimated results uncertainty quantification and decrease. Then a similar procedure was applied in the L– and P–band airborne PolInSAR datasets with three different baselines for each band. The results showed that (1) Wavelength showed obvious effects on forest height inversion results with the RVoG model. For the simulated PolInSAR datasets, the L– and P–bands performed better than the X– and C–bands. The best performance was obtained at the P–band with a baseline combination of 10 × 4 m with an absolute error of 0.05 m and an accuracy of 97%. For the airborne PolInSAR datasets, an L–band with the longest baseline of 24 m in this study showed the best performance with R² = 0.64, RMSE = 3.32 m, and Acc. = 77.78%. (2) It is crucial to select suitable baseline lengths to obtain accurate forest height estimation results. In the four baseline combinations of simulated PolInSAR datasets, the baseline combination of 10 × 4 m both at the L– and P–bands performed best than other baseline combinations. While for the airborne PolInSAR datasets, the longest baseline in three different baselines obtained the highest accuracy at both L– and P–bands. (3) Bayesian framework is useful for estimation results uncertainty quantification and decrease. The uncertainties related to wavelength and baseline length. The uncertainties were reduced obviously at longer wavelengths and suitable baselines. Full article

Polarimetric Synthetic Aperture Radar Interferometry (Pol-InSAR) based forest height estimation for ecosystem monitoring and management has been developing rapidly in recent years. Spaceborne Pol-InSAR systems with long temporal baselines of several days always lead to severe temporal decorrelation, which can cause a forest height overestimation error. However, most forest height estimation studies have not considered the change in dielectric property as a factor that may cause temporal decorrelation with a long temporal baseline. Therefore, it is necessary to propose a new method that considers dielectric fluctuations and random motions of scattering elements to compensate for the temporal decorrelation effect. The lack of ground truth for forest canopy also needs a solution. Unsupervised methods could be a solution because they do not require the use of true values of tree heights as the ground truth to calculate their estimation accuracies. This paper aims to present an unsupervised forest height estimation method called Dielectric Fluctuation and Random Motion over Ground (DF-RMoG) to improve accuracy by considering the dielectric fluctuations and random motions. Its performance is investigated using Advanced Land Observing Satellite (ALOS)-1 Pol-InSAR data acquired over a German forest site with temporal intervals of 46 and 92 days. The authors analyze the relationship between forest height and different parameters with DF-RMoG and conventional models. Compared with conventional models, the proposed DF-RMoG model significantly reduces the overestimation error due to temporal decorrelation in forest height estimation according to its lowest average forest height. Full article

Forest density affects the inversion of forest height by influencing the penetration and attenuation of synthetic aperture radar (SAR) signals. Traditional forest height inversion methods often fail in low-density forest areas. Based on L-band single-baseline polarimetric SAR interferometry (PolInSAR) simulation data and the BioSAR 2008 data, we proposed a forest height optimization model at the stand scale suitable for various forest densities. This optimization model took into account shortcomings of the three-stage inversion method by employing height errors to represent the mean penetration depth and SINC inversion method. The relationships between forest density and extinction coefficient, penetration depth, phase, and magnitude were also discussed. In the simulated data, the inversion height established by the optimization method was 17.35 m, while the RMSE value was 3.01 m when the forest density was 100 stems/ha. This addressed the drawbacks of the conventional techniques including failing at low forest density. In the real data, the maximum RMSE of the optimization method was 2.17 m as the stand density increased from 628.66 stems/ha to 1330.54 stems/ha, showing the effectiveness and robustness of the optimization model in overcoming the influence of stand density on the inversion process in realistic scenarios. This study overcame the stand density restriction on L-band single baseline PolInSAR data for forest height estimation and offered a reference for algorithm selection and optimization. The technique is expected to be extended from the stand scale to a larger area for forest ecosystem monitoring and management. Full article

This paper proposes an improved model-based forest height inversion method for airborne L-band dual-baseline repeat-pass polarimetric synthetic aperture radar interferometry (PolInSAR) collections. A two-layer physical model with various volumetric scattering attenuation and dynamic motion properties is first designed based on the traditional Random Motion over Ground (RMoG) model. Related PolInSAR coherence functions with both volumetric and temporal decorrelations incorporated are derived, where the impacts of homogenous and heterogeneous attenuation and dynamic motion properties on the performance of forest height inversion were investigated by the Linear Volume Attenuation (LVA), Quadratic Volume Attenuation (QVA), Linear Volume Motion (LVM), and Quadratic Volume Motion (QVM) depictions in the volume layer. Dual-baseline PolInSAR data were acquired to increase the degree of freedom (DOF) of the coherence observations and thereby provide extra constraints on the forest parameters to address the underdetermined problem. The experiments were carried out on a boreal forest in Canada and a tropical one in Gabon, where physical models with LVA + QVM (RMSE: 3.56 m) and QVA + LVM (RMSE: 6.83 m) exhibited better performances on the forest height inversion over the boreal and tropical forest sites, respectively. To leverage the advantages of LVA, QVA, LVM, and QVM, a pixel-wise optimization strategy was used to obtain the best forest height inversion performance for the range of attenuation and motion profiles considered. This pixel-wise optimization surpasses the best-performing single model and achieves forest height inversion results with an RMSE of 3.21 m in the boreal forest site and an RMSE of 6.48 m in the tropical forest site. Full article

Because the penetration depth of electromagnetic waves in forests is large in the longer wavelength band, most traditional forest height estimation methods are carried out using polarimetric interferometry synthetic aperture radar (PolInSAR) data of the L or P band, and the estimation method is a three-stage method based on the random volume over ground (RVoG) model. For X-band electromagnetic waves, the penetration depth of radar waves in forests is limited, so the traditional forest height estimation method is no longer applicable. In view of the above problems, in this paper we propose a new forest height estimation strategy for airborne X-band PolInSAR data. Firstly, the sub-view interferometric SAR pairs obtained via frequency segmentation (FS) in the Doppler domain are used to extend the polarimetric interferometry coherence coefficient (PolInCC) range of the original SAR image under different polarization states, so as to obtain the accurate ground phase. For the determination of the effective volume coherence coefficient (VCC), part of the fitting line of the extended-range PolInCC distribution that is intercepted by the fixed extinction coherence coefficient curve (FECCC) of the fixed range is averaged to obtain the accurate effective VCC. Finally, the high-precision forest canopy height in the X-band is estimated using the effective VCC with the ground phase removed in the look-up table (LUT). The effectiveness of the proposed method was verified using airborne-measured data obtained in Shaanxi Province, China. The comparison was carried out using different strategies, in which we substituted one step of the process with the conventional method. The results indicated that our new strategy could reduce the root mean square error (RMSE) of the predicted canopy height vastly to 1.02 m, with a lower estimation height error of 12.86%. Full article

During unexpected earthquake catastrophes, timely identification of damaged areas is critical for disaster management. On the 24 March 2021, Baicheng county was afflicted by a Mw 5.3 earthquake. The disaster resulted in three deaths and many human injuries. As an active remote sensing technology independent of light and weather, the increasingly accessible Synthetic Aperture Radar (SAR) is an attractive data for assessing building damage. This paper aims to use Sentinel-1A radar images to rapidly assess seismic damage in the early phases after the disaster. A simple and robust method is used to complete the task of surface displacement analysis and building disaster monitoring. In order to obtain the coseismic deformation field, differential interferometry, filtering and phase unwrapping are performed on images before and after the earthquake. In order to detect the damage area of buildings, the Interferometric Synthetic Aperture Radar (InSAR) and Polarimetric Synthetic Aperture Radar (PolSAR) techniques are used. A simple and fast method combining coherent change detection and polarimetric decomposition is proposed, and the complete workflow is introduced in detail. In our experiment, we compare the detection results with the ground survey data using an unmanned aerial vehicle (UAV) after the earthquake to verify the performance of the proposed method. The results indicate that the experiment can accurately obtain the coseismic deformation field and identify the damaged and undamaged areas of the buildings. The correct identification accuracy of collapsed and severely damaged areas is 86%, and that of slightly damaged and undamaged areas is 84%. Therefore, the proposed method is extremely effective in monitoring seismic-affected areas and immediately assessing post-earthquake building damage. It provides a considerable prospect for the application of SAR technology. Full article

Polarimetric Interferometric Synthetic Aperture Radar (PolInSAR) has many useful applications, especially in forest areas. With the development of SAR miniaturization technology, researchers can install PolInSAR on small unmanned aerial vehicles (UAV), which can reduce flight costs. Limited by size and power, UAV-borne SAR usually works in a high-frequency band, which restricts its application to such things as vegetation height inversion. While on the other hand, the high resolution acquired under a short wavelength promises its application in urban areas. However, there are fewer studies on the application of PolInSAR in urban areas compared with that in forest areas. In this paper, we propose a processing method for a Ku-band multi-rotor-UAV-borne PolInSAR and provide a preliminary analysis of height inversion results on its data from the Fudan campus in Shanghai. We obtain the digital surface model (DSM) of different polarization modes and the DSM of polarimetric interferometry optimal decomposition in this area, whose RMSE is 2.88 m. On this basis, the elevation inversion results of targets such as buildings, lampposts, and trees are compared and analyzed. We preliminarily explore and analyze the reasons for the different results of different targets. To this end, we propose a mathematical derivation of the relationship between the interferometric phase between PolInSAR and InSAR of Pauli decomposition. We also perform a simulation to analyze the relationship between the phase center height of Pauli decomposition and PolInSAR under different cases. It provides a reference for the application of small UAV-borne PolInSAR in urban areas. Full article

Spaceborne polarimetric synthetic aperture radar interferometry (PolInSAR) has the potential to deal with large-scale forest height inversion. However, the inversion is influenced by strong temporal decorrelation interference resulting from a large temporal baseline. Additionally, the forest canopy induces phase errors, while the smaller vertical wavenumber ($k_z$) enhances the sensitivity of the inversion to temporal decorrelation, which limits the efficiency in forest height inversion. This research is based on the random volume over ground (RVoG) model and follows the assumptions of the three-stage inversion method, to quantify the impact of repeat-pass spaceborne PolInSAR temporal decorrelation on the relative error of retrieval height, and develop a semi-empirical improved inversion model, using ground data to eliminate the interference of coherence and phase error caused by temporal decorrelation. Forest height inversion for temperate forest in northern China was conducted using repeat-pass spaceborne L-band ALOS2 PALSAR data, and was further verified using ground measurement data. The correction of temporal decorrelation using the improved model provided robust inversion for mixed conifer-broad forest height retrieval as it addressed the over-sensitivity to temporal decorrelation resulting from the inappropriate $k_z$ value. The method performed height inversion using interferometric data with temporal baselines ranging from 14 to 70 days and vertical wavenumbers ranging from 0.015 to 0.021 rad/m. The R² and RMSE reached 0.8126 and 2.3125 m, respectively. Full article

Spaceborne and airborne polarimetric synthetic-aperture radar interferometry (PolInSAR) data have been extensively used for forest parameter retrieval. The PolInSAR models have proven their potential in the accurate measurement of forest vegetation height. Spaceborne monostatic multifrequency data of different SAR missions and the Global Ecosystem Dynamics Investigation (GEDI)-derived forest canopy height map were used in this study for vegetation height retrieval. This study tested the performance of PolInSAR complex coherence-based inversion models for estimating the vegetation height of the forest ranges of Doon Valley, Uttarakhand, India. The inversion-based forest height obtained from the three-stage inversion (TSI) model had higher accuracy than the coherence amplitude inversion (CAI) model-based estimates. The vegetation height values of GEDI-derived canopy height map did not show good relation with field-measured forest height values. It was found that, at several locations, GEDI-derived forest height values underestimated the vegetation height. The statistical analysis of the GEDI-derived estimates with field-measured height showed a high root mean square error (RMSE; 5.82 m) and standard error (SE; 5.33 m) with a very low coefficient of determination (R²; 0.0022). An analysis of the spaceborne-mission-based forest height values suggested that the L-band SAR has great potential in forest height retrieval. TSI-model-based forest height values showed lower p-values, which indicates the significant relation between modelled and field-measured forest height values. A comparison of the results obtained from different SAR systems is discussed, and it is observed that the L-band-based PolInSAR inversion gives the most reliable result with low RMSE (2.87 m) and relatively higher R² (0.53) for the linear regression analysis between the modelled tree height and the field data. These results indicate that higher wavelength PolInSAR datasets are more suitable for tree canopy height estimation using the PolInSAR inversion technique. Full article

As an essential parameter in synthetic aperture radar (SAR) images, the equivalent number of looks (ENL) not only indicates the speckle noise level in multi-look SAR data but also can be used for evaluating the region homogeneity level. Currently, time-series polarimetric (interferometric) SAR (TSPol(In)SAR) data are increasingly abundant, but traditional equivalent number of looks (ENL) estimators only use polarimetric information from a mono-temporal observation and do not consider the temporal characteristics or interferometric coherence of ground targets. Therefore, this paper puts forward four novel ENL estimators to overcome the restrictions of inadequate observation information. Firstly, based on the traditional trace moment estimator for polarimetric SAR data (TM-PolSAR), we extend it to both PolInSAR and TSPolInSAR data and then propose both TM-PolInSAR and TM-TSPolInSAR estimators, respectively. Secondly, for both TSPolSAR and single-reference TSPolInSAR data, we estimate the ENL by stacking the trace moments (STM) of multitemporal coherency matrices, called STM-TSPolSAR and STM-TSPolInSAR estimators, respectively. Therefore, these proposed ENL estimators can effectively deal with most of the requirements of TSPol(In)SAR data types in practical applications, mainly including statistical distribution modeling and region homogeneity evaluation. The simulation and real experiments detailedly compare the proposed four ENL estimators to the classical TM-PolSAR estimator and quantitatively analyze the estimation performance. The proposed estimators have obtained the ENL with less bias and standard deviation than the traditional estimator, especially in case of small spatial samples coherency matrices. Additionally, these STM-TSPolSAR, STM-TSPolInSAR, and TM-TSPolInSAR estimators have provided more effective statistical characteristics with the increase of the time-series size. It has been demonstrated that the proposed STM-TSPolSAR estimator considers the time-varying polarimetric characteristics of the crop and detects many edges that the traditional estimator cannot discover, which means a superior capability of region homogeneity evaluation. Full article

This paper proposes a new method for forest height estimation using single-baseline single frequency polarimetric synthetic aperture radar interferometry (PolInSAR) data. The new algorithm estimates the forest height based on the random volume over the ground with a volume temporal decorrelation (RVoG+VTD) model. We approach the problem using a four-stage geometrical method without the need for any prior information. In order to decrease the number of unknown parameters in the RVoG+VTD model, the mean extinction coefficient is estimated in an independent procedure. In this respect, the suggested algorithm estimates the mean extinction coefficient as a function of a geometrical index based on the signal penetration in the volume layer. As a result, the proposed four-stage algorithm can be used for forest height estimation using the repeat pass PolInSAR data, affected by temporal decorrelation, without the need for any auxiliary data. The suggested algorithm was applied to the PolInSAR data of the European Space Agency (ESA), BioSAR 2007 campaign. For the performance analysis of the proposed approach, repeat pass experimental SAR (ESAR) L-band data, acquired over the Remningstorp test site in Southern Sweden, is employed. The experimental result shows that the four-stage method estimates the volume height with an average root mean square error (RMSE) of 2.47 m against LiDAR heights. It presents a significant improvement of forest height accuracy, i.e., 5.42 m, compared to the three-stage method result, which ignores the temporal decorrelation effect. Full article

This paper investigates the potentials and limitations of a simple dual-baseline PolInSAR (DBPI) method for forest height inversion. This DBPI method follows the classical three-stage inversion method’s idea used in single baseline PolInSAR (SBPI) inversion, but it avoids the assumption of the smallest ground-to-volume amplitude ratio (GVR) by employing an additional baseline to constrain the inversion procedure. In this paper, we present for the first time an assessment of such a method on real PolInSAR data over boreal forest. Additionally, we propose an improvement on the original DBPI method by incorporating the sloped random volume over ground (S-RVoG) model in order to reduce the range terrain slope effect. Therefore, a digital elevation model (DEM) is needed to provide the slope information in the proposed method. Three scenes of P-band airborne PolInSAR data acquired by E-SAR and light detection and ranging (LIDAR) data available in the BioSAR2008 campaign are employed for testing purposes. The performance of the SBPI, DBPI, and modified DBPI methods is compared. The results show that the DBPI method extracts forest heights with an average root mean square error (RMSE) of 4.72 m against LIDAR heights for trees of 18 m height on average. It presents a significant improvement of forest height accuracy over the SBPI method (with a stand-level mean improvement of 42.86%). Concerning the modified DBPI method, it consistently improves the accuracy of forest height inversion over sloped areas. This improvement reaches a stand-level mean of 21.72% improvement (with a mean RMSE of 4.63 m) for slopes greater than 10°. Full article

This paper discusses the potential and limitations of high-resolution P-band polarimetric synthetic aperture radar (SAR) interferometry (PolInSAR) in underlying topography estimation over forest areas. Time-frequency (TF) analysis in the azimuth direction is utilized to separate the ground scattering contribution from the total PolInSAR signal, without the use of any physical model, because the P-band PolInSAR data have a significant penetration depth and sufficient observation angle interval. To achieve this goal, a one-dimensional polynomial fitting (PF) method is proposed for correcting the residual motion error (RME). The Krycklan catchment test site, which is covered with pine forest, was selected to test the performance of the digital elevation model (DEM) inversion. The results show that the PF method can correct the RMEs for the sub-look interferograms well. When compared to the existing line-fit method, the TF+PF method can provide a more accurate DEM (the accuracy is improved by 26.9%). Moreover, the performance of the DEM inversion is free from the random-volume-over-ground assumption. Full article
