Search Results (80)

Barrel tools are increasingly used in high-precision machining of free-form surfaces. However, limited studies evaluate their performance specifically on spherical geometries, where tool–surface contact characteristics differ significantly. Understanding how tool geometry and process parameters influence surface quality and cutting forces in such cases remains underexplored. This study evaluates how barrel cutter radius and varying machining parameters affect cutting forces and surface roughness when milling internal and external spherical surfaces. Machining tests were conducted on structural steel 1.1191 using two barrel cutters with different curvature radii (85 mm and 250 mm) on a 5-axis CNC machine. Feed per tooth and radial depth of cut were systematically varied. Cutting forces were measured using a dynamometer, and surface roughness was assessed using the Rz parameter, which is more sensitive to peak deviations than Ra. Novelty lies in isolating spherical surface shapes (internal vs. external) under identical path trajectories and systematically correlating tool geometry to force and surface metrics. The larger curvature tool (250 mm) consistently generated up to twice the cutting force of the smaller radius tool under equivalent conditions. External surfaces showed higher Rz values than internal ones due to less favorable contact geometry. Radial depth of the cut had a linear influence on force magnitude, while feed rate had a limited effect except at higher depths. Smaller-radius barrel tools and internal geometries are preferable for minimizing cutting forces and achieving better surface quality when machining spherical components. The aim of this paper is to determine the actual force load and surface quality when using specific cutting conditions for internal and external spherical machined surfaces. Full article

To evaluate the performance of quasi-planetary cutting tools, three shrubs were selected and studied using a combination of numerical simulation and cutting test bench experiments. Based on the constitutive model of shrub material and LS-DYNA simulation, the effects of tool speed (n), feed speed (v), and shrub diameter (D_a) on peak cutting force (F_max) and peak cutting power (P_max) were analysed through a single-factor simulation test. Using the shrub-cutting test bench, an orthogonal test was designed with n, v, and moisture content (w) as factors and F_max and P_max as indicators. A regression model was established, and a single-factor comparison test for w was conducted. The results indicate that F_max decreases as n increases, while P_max initially decreases and then increases. Both F_max and P_max increase with rising v and D_a. As w increases, F_max and P_max first decrease and then increase. When n is 1813 r/min, v is 30 mm/s, and w is 10.9%, F_max and P_max reach their optimal values of 8.42 N and 282.99 W, respectively, with verification test errors of 2.68% and 1.56%. The findings provide methodological and data support for studying the cutting performance of new cutting tools. Full article

The overload protection device is crucial in ensuring the orderly absorption of kinetic energy by the coupler buffer device. This paper studies an overload protection bolt with a cut-out zone. In the bolt impact experiment, a premature fracture of 10.9-grade M24 bolts was observed. Based on the analysis of the results, it was concluded that this phenomenon was caused by the mismatch between the mechanical properties of the bolts and the dynamic performance of the coupler. Building on this test, a numerical simulation model was established and subsequently validated. The width and depth of the inducing structure were selected as the research objects. Using the Latin Hypercube method, 78 sets of cut-out zone structure parameters were generated, and numerical simulations were performed on the cut-out induced bolts. The simulation results indicate that the peak force generated by the coupler collision leads to necking in the cut-out induced bolts, which consequently weakens their mechanical properties to some extent. Therefore, it is necessary to consider a strength margin when designing cut-out induced bolts. Based on the simulation results, a surrogate model was constructed, and the optimal bolt cut-out zone was obtained through optimization: a width of 17.74 mm and a depth of 1.37 mm. The surrogate model predicted a fracture force of 1894.13 kN for the bolts. An impact test was conducted to verify the performance of the optimized cut-out induced bolts. The experimental results showed that the cut-out induced bolts broke after the crush tube completed its kinetic energy absorption, with a fracture force of 1828.44 kN, which was a 3.59% difference from the predicted value of the surrogate model. After optimization, the fracture force of the cut-out induced bolts increased from 1147.5 kN to 1828.44 kN (a 59.34% improvement), while the fracture time extended from 20.9 ms to 69 ms, fully meeting the design requirements of the overload protection device. Full article

A one-micron-thick pure zinc oxide (ZnO) and nitrogen-doped zinc oxide (N-ZnO) film were fabricated on p-type, pristine (non-porous), and porous gallium nitride (GaN) substrates using a radio frequency (RF) sputtering technique at room temperature. The doping medium was nitrogen gas, which has a flow rate that ranges from 0 to 10 sccm (0 sccm refers to pure ZnO). The photoelectrochemical etching process, using ultraviolet light, was employed to etch the wafer surface and create a porous GaN substrate. ZnO films were developed on GaN with ZnO powder as the target material under vacuum conditions. This research aimed to investigate how variations in substrate and doping influenced the structural, optical, and electrical characteristics of the resulting thin films. The SEM images indicated that the pores developed on the etched GaN surface had a spherical shape. The A₁ (LO) phonon peak at 750.2 cm⁻¹ was observed in the Raman spectrum of the etched porous GaN. The X-ray diffraction (XRD) analysis confirmed that the films grown on GaN possessed a hexagonal wurtzite structure and the observed peak shift of (101) in all N-ZnO films suggested interstitial nitrogen doping. For the N-ZnO films, the UV-visible cut-off wavelength shifted towards the blue region. The root mean square (RMS) roughness of the N-ZnO films, measured using atomic force microscopy (AFM), was found to decrease with an increasing N-doping concentration. The 10 sccm sample exhibited the lowest roughness value of 1.1 nm, whereas the pure ZnO film showed the highest roughness of 3.4 nm. The N-ZnO thin films were found to exhibit p-type conductivity, as computed by Hall measurements using the van der Pauw method, and the higher value of carrier concentration obtained for the nitrogen gas flow rate of 8 sccm was 5.29 × 10²¹ cm⁻³. Full article

This study investigates the effectiveness of trochoidal (adaptive) milling in machining Glass Fiber Reinforced Polymer (GFRP), emphasizing its potential advantages over conventional milling. Six coated solid carbide end mills, each with distinct geometries, were evaluated under identical conditions to assess the cutting forces, surface quality, dimensional accuracy, burr formation, chip size distribution, and tool wear. Trochoidal milling demonstrated shorter cycle times—up to 23% faster—and higher material removal rates (MRRs), while conventional milling provided superior dimensional control and smoother surfaces in certain fiber-sensitive regions. A four-tooth cutter with a low helix angle (10°) and aluminum-oxide coating delivered the best overall performance, balancing minimal tool wear with high-quality finishes (arithmetic mean roughness, Ra, as low as 1.36 μm). The results indicate that although conventional milling can exhibit a 25%-lower RMS cutting force, its peak forces and extended machining times may limit the throughput. Conversely, trochoidal milling, when coupled with an appropriately robust tool, effectively manages the cutting forces, improves the surface quality, and reduces the machining time. Most chips produced were less than 11 μm in size, highlighting the need for suitable dust extraction. Notably, a hybrid approach—trochoidal roughing followed by conventional finishing—offers a promising method for achieving both efficient material removal and enhanced dimensional accuracy in GFRP components. Full article

Friction has a significant impact on chip formation, so modeling it accurately is crucial in numerical cutting simulations. However, there is still controversy regarding the application scope and effectiveness of various friction models. A two-dimensional orthogonal cutting thermomechanical coupled finite element model is established. Critical strain values, recrystallization temperature, and recrystallization flow stress are introduced, and a power-law-modified softening coefficient is used to modify the standard Johnson–Cook constitutive model to simulate material mechanical properties. Zorev’s friction model, velocity-dependent friction model, and temperature-dependent friction model are separately employed to describe the friction behavior between the tool and workpiece. The contact and friction characteristics between the workpiece and tool, material damage, and temperature field are evaluated. Predicted cutting forces are compared and analyzed with experimental values. The friction coefficient can adjust the contact length between the tool and chip, the high-temperature range on the tool surface, and the fluctuation of temperature throughout the entire cutting process. The friction coefficient is more sensitive to sliding velocity, and the temperature distribution is more sensitive to the friction model than to different working conditions. Whether by modifying the friction coefficient or maximum friction shear stress, and regardless of whether adding parameters affected by velocity or temperature changes the fluctuation range, period, and local peaks of the cutting force prediction curve, improving the accuracy of predictions within certain working condition ranges to some extent. However, the overall trend of error fluctuations obtained from these friction models is similar, and the accuracy of predictions from these friction models tends to become more inaccurate with increasing cutting thickness. Full article

This cross-sectional laboratory-based study investigates the stress characteristics of the anterior cruciate ligament (ACL) during side-cutting using a knee finite element (FE) model and identifies biomechanical factors influencing ACL stress. Kinematics and ground reaction forces (GRF) were collected from eight participants (age: 30.3 ± 5.3 years; BMI: 25.6 ± 2.4 kg/m²; time since surgery: 12.8 ± 1.2 months) one year post–ACL reconstruction during side-cutting tasks. A knee FE model incorporating time-varying knee angles, knee forces, and femoral translation was developed to simulate the knee biomechanics. The relationships between ACL stress and lower limb biomechanics were analyzed. The results indicated the highest stress concentrations at the femoral attachment during the early landing phase. Posterior femoral displacement relative to the tibia was significantly correlated with peak ACL equivalent stress (r = 0.89, p = 0.003) and peak ACL shear stress (r = 0.82, p = 0.023). Peak ACL equivalent stress also showed positive correlations with posterior GRF (r = 0.77, p = 0.025) and knee extension moments (r = 0.71, p = 0.049). In contrast, peak ACL shear stress exhibited a significant negative correlation with hip extension moment (r = −0.80, p = 0.032). This study identified key biomechanical factors affecting ACL stress, highlighting the roles of femoral displacement, knee extension moments, and ground reaction forces, while demonstrating a negative relationship with hip extension moments. Full article

Mechanical construction has gradually been applied in cross passages of metro lines, but more mechanical mechanisms should be revealed. The section between Jingrong Street Station and Kunjia Road Station in Suzhou Metro Line 11 adopts a mechanical construction method to construct a cross passage. A novel flat-face cutterhead, which is different from curved cutter head is first used to cut and break the main tunnel in construction of cross passage. Based on the background of practical engineering, the finite element method was applied to simulate the breaking process of the main tunnel to explore the dynamic variation in the mechanical response of the segments cut by the flat-face cutterhead. The results indicate that the maximum vertical displacement caused by cutting mainly concentrates on the top of the fully cut rings. The maximum horizontal displacement occurs at the waist on the side of the tunnel portal in the semi-cut rings. The axial force level inside both types of segment rings reaches its peak after the tunnel is formed. The maximum axial force exists at the bottom and top of the fully cut ring and semi-cut ring, respectively. The change in the displacement around the portal is not substantial before the third stage, and it begins to increase significantly from the moment the concrete at the portal is penetrated. The existence of the pre-support system effectively controls the displacement of the third and fourth fully cut rings. Emphasis should be placed on reinforcing the soil near the top and waist of the second to fifth rings. The findings demonstrate that the application of flat-face cutterhead in mechanical construction of cross passages is safe, reliable, and efficient, and can provide valuable suggestions for further cutting parameters and soil reinforcement as well. Full article

Addressing the challenge of weak interface strength in 3D-printed mortars, this study introduces a novel technique using sinuous printing trajectories. The self-locking interface is formed by different meandering print trajectories, and the changes in the strength of the test interface are investigated by adjusting the trajectories to form different amplitudes. This ensures alignment of peaks and troughs between layers, aiming for enhanced interfacial cohesion. Experimental tests measured mechanical properties of printed mortar specimens with varying amplitudes. Using Digital Image Correlation technology, strain fields and fracture surfaces were analyzed. Initial results revealed a 28% decrease in shear resistance for side-by-side printed interfaces compared to traditional layered interfaces. As amplitude increased, shear load-bearing capacity improved. Specifically, a 15 mm amplitude saw a 40% rise in interlayer shear strength. However, a 20 mm amplitude led to reduced shear capacity, with even slight forces causing potential fractures. Tensile strength also increased with amplitude. Specimens up to 15 mm amplitude primarily followed the printing interface in fractures, while a 20 mm amplitude cut through mortar strips. Post-fracture analysis showed the highest surface irregularity at a 15 mm amplitude, aligning with tensile load-bearing capacity. Full article

This study investigated the innovative incorporation of Artocarpus altilis leaves into potato-based gnocchi, demonstrating a sustainable approach to valorizing underutilized plant materials. Breadfruit leaves, often discarded as agricultural waste, represent an untapped resource rich in bioactive compounds and antioxidants. By incorporating these leaves into pasta products, we demonstrate a promising strategy for enhancing food systems’ nutritional profile and sustainability. The research examined the functional, pasting, and bioactive properties of Artocarpus altilis leaf blends with potato flakes. The blends showed significant water-holding capacity (4.88–8.58 g H₂O/g DM) and notable antioxidant activity in both aqueous and ethanolic extracts (DPPH: 1.95–3.35 mg TE/g DM). Pasting profiles revealed that increasing the Artocarpus altilis concentration progressively modified the starch behavior, reducing the peak viscosity from 972.5 to 530.0 mPa·s. Gnocchi formulated with 10% Artocarpus altilis leaves demonstrated good stability during 4-day storage, with minimal color changes (ΔL* ≈ 2) and predictable textural evolution (cutting force increase from 4.5 to 5.8 N). The incorporation of these leaves enhances the nutritional profile through increased antioxidant content and promotes sustainable food production by utilizing agricultural by-products. This approach demonstrates the potential for developing eco-friendly food products while supporting local agricultural economies in tropical regions with abundant Artocarpus altilis. The successful integration of these leaves into a popular food product opens new possibilities for sustainable food innovation and waste reduction in the food industry. Full article

The application of dynamic data in biomechanics is crucial; traditional laboratory-level force measurement systems are precise, but they are costly and limited to fixed environments. To address these limitations, empirical evidence supports the widespread adoption of portable force-measuring platforms, with recommendations for their ongoing development and enhancement. Taiyuan University of Technology has collaborated with KunWei Sports Technology Co., Ltd. to develop a portable 3D force measurement system. To validate the reliability of this equipment, 15 male collegiate students were randomly selected to perform four distinct movements: walking, running, CMJ, and side-cutting. The Bertec system served as a reference device alongside the KunWei system to collect the kinetic characteristics of the test movements. The consistency and fitting quality between the two devices were evaluated through t-tests, ICC, and NRMSE. The research results indicated that there were no significant differences in peak force between the KunWei system and the Bertec system across all four movements (p > 0.05). The ICC values for force-time curves were all above 0.98, with NRMSE not exceeding 0.165. The KunWei system exhibited high consistency and reliability under various motion conditions compared to the Bertec system. This system maintains data accuracy, significantly broadens the application scope of force measurement systems, and reduces procurement and maintenance costs. It has been successfully applied in technical support for multiple water sports and winter projects with ideal results achieved. Full article

The simulator for hydrological unstructured domains (SHUD) is a cutting-edge, distributed hydrological model based on the finite volume method, representing the next generation of coupled surface–subsurface hydrological simulations. Its applicability in high-altitude, cold regions covered by snow and permafrost, such as the Yellow River source region, necessitates rigorous validation. This study employed the China Meteorological Forcing Dataset (CMFD) to simulate streamflow in the Yellow River source region from 2006 to 2018, comprehensively assessing the suitability of the SHUD model in this area. The SHUD model excels in simulating monthly streamflow in the Yellow River source region, while its performance at the daily scale is comparable to existing models. It demonstrated significantly better performance in the warm season compared to the cold season, particularly in the middle and lower reaches of the region. Distinct seasonal and regional differences were observed in simulation performance across sub-basins. However, the model encounters limitations when simulating the extensively distributed permafrost areas in the upstream region, primarily due to oversimplification of the permafrost thawing and freezing processes, which points the direction for future model improvements. Additionally, the model’s shortcomings in accurately simulating peak streamflow are closely related to uncertainties in calibration strategies and meteorological data inputs. Despite these limitations, the calibrated SHUD model meets the hydrological simulation needs of the Yellow River Source Region across various temporal scales, providing significant scientific reference for hydrological simulation and streamflow prediction in cold regions with snow and permafrost. Full article

This study addresses the necessity for a more profound comprehension of the mechanical behavior and fracture mechanisms of tree branches during impact pruning. The methodologies of the research are to develop a failure model of impact-cutting mechanics and a tool–branch interaction model using the finite element method (FEM). The validation of the model was conducted through the measurement of cutting forces and cross-sectional morphology in the field. A comparative analysis between experimental and simulation data revealed an average relative error below 15% for cutting force and below 10% for the cross-sectional ratio, thereby confirming the accuracy of the model. The findings indicate the presence of plastic deformation within the cutting zone, with elastic deformation prevailing in the surrounding region. As the branch approaches the yield point, the phenomenon of plastic deformation intensifies, resulting in a notable increase in internal energy demands, particularly in larger branches. The optimal pruning diameter was identified as 15 mm. An increase in cutting velocity raises the peak cutting force by 460.9 N per m/s, while a 1° increase in the blade wedge angle adds 34.9 N. A reduction in normal stress by increasing the tool back angle improves energy efficiency. This study provides insights to optimize pruning practices, enhancing efficiency and precision. Full article

In order to study the collision of sea ice on bridge piers of a sea-crossing bridge, this study establishes a finite element model of the impact of sea ice on bridge piers in aqueous media based on explicit dynamics analysis software and programming software using the arbitrary Lagrangian Eulerian (ALE) method. The results show that, when the sea-ice spacing is larger than the sea-ice edge length, the increase in sea-ice spacing leads to a decrease in the collision force and a significant increase in the probability of climbing and overturning. The increase in sea-ice mass significantly increases the impact force on the bridge abutment, and the peak value increases linearly with the increase in mass, and the sea-ice climbing and overturning phenomena are obvious. Different shapes of sea ice are obtained by cutting the sea-ice field with the two-dimensional Voronoi method, and the maximum impact force increases significantly with the increase in the average area. Irregularly shaped sea ice leads to a larger impact force and triggers the accumulation climbing phenomenon, which is verified by experiments, and the experimental values are in good agreement with the simulated values. In conclusion, this study reveals the significant effects of the spacing, mass, and shape of sea ice on the impact force of bridge piers, which provides an important reference for the design of bridge structures. Full article

This attempt covers an investigation of cutting temperature at interfaces of Fiber Metal Laminates (FMLs) made of glass fiber-reinforced polymer (GFRP) stacked with an Al2020 alloy. GFRP/Al/GFRP and Al/GFRP/Al composite stacks are both investigated to highlight the effect of stacking arrangement on thermal behavior within the interfaces. In a first test series, temperature history is recorded within the metal/composite stack interfaces using preinstalled thermocouples. In a second test series, a wireless telemetry system connected to K-type thermocouples implanted adjacent to the cutting edge of the solid carbide drill is used to record temperature evolution at the tool tip. Focus is put on the effects of cutting speed and stacking arrangement on the thrust force, drilling temperature, and delamination. From findings, the temperature histories show high sensitivity to the cutting speed. When cutting Al/GFRP/Al, the peak temperature is found to be much higher than that recorded in GFRP/Al/GFRP and exceeds the glass transition point of the GFRP matrix under critical cutting speeds. However, thrust force obtained at constitutive phases exhibits close magnitude when the stacking arrangement varies, regardless of cutting speed. Damage analysis is also discussed through the delamination factor at different stages of FML thickness. Full article
