Parallel–serial (hybrid) manipulators represent robotic systems composed of kinematic chains with parallel and serial structures. These manipulators combine the benefits of both parallel and serial mechanisms, such as increased stiffness, high positioning accuracy, and a large workspace. This study discusses the existing architectures and applications of parallel–serial robots and the methods of their design and analysis. The paper reviews around 500 articles and presents over 150 architectures of manipulators used in machining, medicine, and pick-and-place tasks, humanoids and legged systems, haptic devices, simulators, and other applications, covering both lower mobility and kinematically redundant robots. After that, the paper considers how researchers have developed and analyzed these manipulators. In particular, it examines methods of type synthesis, mobility, kinematic, and dynamic analysis, workspace and singularity determination, performance evaluation, optimal design, control, and calibration. The review concludes with a discussion of current trends in the field of parallel–serial manipulators and potential directions for future studies. Full article

The main objective of this paper is to discuss the experimental validation of a tele-operation system for remote center-of-motion tasks, such as laparoscopic surgery. This validation is based on the use of an extra sensor placed on the master manipulator. The tele-operation system is composed of a new hybrid haptic device (nHH) intended to be used as a master manipulator controlling a collaborative robot, used as a slave surgical robot. The resolution of the forward kinematic model (FKM) of the master device is performed experimentally thanks to the use of an extra sensor. The IMU, as the extra sensor, is installed on the serial part of the nHH device to measure the orientation and is enabled to solve the FKM of the parallel part of the nHH device. The use of an extra sensor reduces the calculation time, improves the accuracy of the KFM, and makes it suitable for real-time applications. The preliminary validation of the force feedback in the nHH workspace is validated. Experiments were conducted on the master–slave platform to validate the proposed approach. The results are promising, which proves that the nHH device presents a suitable performance for the desired task. Full article

The article proposes an approach for synthesizing hybrid (parallel-serial) manipulators with five degrees of freedom (5-DOF) using open kinematic chains. The method idea consists in taking an open kinematic chain, selecting a subchain within it, and replacing the subchain with a parallel mechanism. The article considers 5-DOF open chains and 3-DOF subchains, substituted for 3-DOF parallel mechanisms with the same motion pattern as the subchain. Thus, synthesized hybrid manipulators have a 3-DOF parallel part and a 2-DOF serial part. First, we grouped 26 structures of open chains with revolute and prismatic joints into five types and 78 subtypes. Next, for each type, we selected one subtype and presented several hybrid mechanisms that can correspond to it. We considered hybrid manipulators that included 3-DOF parallel mechanisms with planar, spherical, and other commonly used motion types. The suggested synthesis method is intuitive for a designer, and it does not need any mathematical formulations like screw theory or group theory approaches. Full article

The development of serial or parallel manipulator robots is constantly increasing due to the need for faster productivity and higher accuracy. Therefore, researchers have turned to combining both mechanisms, sharing the advantage from serial to parallel or vice versa. This paper proposes a new configuration design for a serial-parallel hybrid manipulator (SPHM) using the industrial robotic KUKA Kr6 R900 and 3-DOF parallel spherical mechanism. The Kr6 R900 has six degrees of freedom (6-DOF) divided into three joints for translation (x, y, z) and another three joints for orientation (A, B, C) of the end-effector and the 3-DOF parallel spherical mechanism with three paired links. On the contrary, each limb of the parallel spherical mechanism consists of revolute–revolute–spherical joints (3-RRS). This mechanism allows translation movement along the Z-axis and orientation movements about the X- and Y- axes. The new hybrid will enrich the serial manipulator in movement flexibility and expand the workspace for serial and parallel manipulator robots. In addition, a complete conceptual design is presented in detail for the new robot configuration with a schematic and experimental setup. Then, a comprehensive mathematical model was derived and solved. The forward, inverse kinematics, and workspace analyses were derived using the graphical solution. Additionally, the new hybrid manipulator was tested for path planning. Moreover, an experimental setup was prepared to test the selected path. Finally, the new robot configuration can enlarge the workspace of both manipulators and the selected path matched to the experimental test. Full article

This article presents the velocity and singularity analysis for a five-degree-of-freedom (5-DOF) parallel-serial manipulator. The hybrid structure of the manipulator combines a tripod-like parallel part and a serial part, represented as two carriages moving in perpendicular directions. This manipulator provides its end-effector with a 3T2R motion pattern, which includes three independent translations and two independent rotations. First, the study briefly discusses the manipulator design and the results of the position analysis. These results form the basis for the subsequent velocity and singularity analysis, performed by screw theory. The screw coordinates of the unit twists are written for each manipulator joint, and then through the reciprocal screw approach, the actuation and constraint wrenches of the manipulator are obtained by simple inspection. Based on these twists and wrenches, the paper forms the velocity equation and shows an example of the inverse velocity analysis for a given end-effector trajectory. The same example is solved by numerical differentiation to verify the proposed approach. Next, the paper investigates singular configurations by analyzing the wrench system of the manipulator and presents several conditions for serial and parallel singularities. Each condition has both a symbolic representation, given by an equation for screw coordinates of certain wrenches, and a visual representation, which shows the manipulator in a singular configuration. Full article

The paper analyzes a planar three degrees of freedom manipulator with cable actuation. Such a system can be understood as a special type of hybrid parallel kinematic mechanism composed of the rigid serial chain and the additional auxiliary cable system. The advantage of the auxiliary cable mechanism is the ability to reconfigure the whole system. The fulfillment of sufficient prestressing is the constraint of the optimization process. Computed Torque Control with a cable force distribution algorithm is implemented. The control algorithm performance is examined on different trajectories, including non-smooth motion requests, and its robustness is tested by randomly generated errors of the model parameters in regulators. The results demonstrate that the optimized structure is capable of controlling the manipulator motion and keeping the cable prestressing within the given limits. Full article

In this work, we present methods allowing parallel, hybrid, and serial manipulators to be analyzed, calibrated, and controlled with the same analytical tools. We introduce a general approach to describe any robotic manipulator using established serial-link representations. We use this framework to generate analytical kinematic and calibration Jacobians for general manipulator constructions using null space constraints and extend the methods to hybrid manipulator types with complex geometry. We leverage the analytical Jacobians to develop detailed expressions for post-calibration pose uncertainties that are applied to describe the relationship between data set size and post-calibration uncertainty. We demonstrate the calibration of a hybrid manipulator assembled from high precision calibrated industrial components resulting in 91.1 $\mathsf{\mu }$m RMS position error and 71.2 $\mathsf{\mu }$rad RMS rotation error, representing a 46.7% reduction compared to the baseline calibration of assembly offsets. Full article

In this paper, the real-time joint stiffness configuration strategy of a series parallel hybrid 7-DOF (degree of freedom) humanoid manipulator with flexible joints in continuous motion is studied. Firstly, considering the potential human robot accidental collision, combined with the manipulator safety index (MSI) and human body injury thresholds, the motion speed and joint stiffness of the robot are optimized in advance. Secondly, using hyperbolic tangent function for reference, the relationship between joint torques and passive joint deflection angles of the robot is given, which is beneficial for the real-time calculation of joint stiffness and obtain reasonable joint stiffness. Then, the structural model of the selected humanoid manipulator is described, on this basis, the relationship between the joint space stiffness and the Cartesian space stiffness of the humanoid manipulator is analyzed through Jacobian matrix, and the results show that the posture and joint space stiffness of the humanoid manipulator directly affect the Cartesian space stiffness of the humanoid manipulator. Finally, according to whether the humanoid manipulator works in the human-robot interaction environment, the real-time joint stiffness configuration of the humanoid manipulator in continuous motion is simulated and analyzed. The research shows that the humanoid manipulator with flexible joints can adjust the joint stiffness in real-time during continuous motion, and the joint stiffness configuration strategy can effectively improve the safety of human body in human-robot collision. In addition, in application, when the joint space stiffness of the robot is lower, the position accuracy can be improved by trajectory compensation. Full article
