Search Results (18)

During the service life of a supersonic aircraft, panels are susceptible to damaged boundary supports and unexpected attached masses, which can critically alter their flutter characteristics. This paper proposes a novel two-stage assumed mode method to efficiently analyze the modal properties and expanded flutter envelopes of such compromised structures. In the first stage, the bending modes of a Euler–Bernoulli beam under elastic supports in two orthogonal directions are combined to construct the assumed modes of the intact panel, forming a modal matrix that satisfies geometric boundary conditions and establishing the baseline dynamic model. In the second stage, the method is reapplied to derive the generalized eigenvalue problem for the panel with attached masses, accurately capturing the modified mode shapes and frequencies. Subsequently, based on the principle of virtual work and first-order piston theory, the generalized aerodynamic forces are formulated. These are then incorporated into the flutter equations, which are solved in the frequency domain using the p-k method. The results demonstrate that elastic supports generally lower flutter velocities and frequencies. However, an interesting finding is that a centrally attached mass of 0.03 kg (≈10% of the panel mass) can increase the flutter speed by about 10%, whereas the same mass placed off-center may reduce it by roughly 2%. Furthermore, the proposed 9-point damper layout is shown to raise the flutter speed of an elastically supported panel with an off-center mass by up to 18% and the flutter frequency by over 13%, thereby recovering and even exceeding the design flutter boundary. Full article

The stability of a nonlinear aero-thermo-elastic panel in supersonic flow is analyzed numerically. In light of Hamilton’s principle, the governing equation of motion for a two-dimensional aero-thermo-elastic panel is established taking geometric nonlinearity and curvature effect into account. Coupling with the panel vibration, aerodynamic pressure is evaluated by first order supersonic piston theory and aerothermal load is approximated by the quasi-steady theory of thermal stress. A Galerkin method based on approximate inertial manifolds is deduced for low-dimensional dynamic modeling. The efficiency of the method is discussed. Finally, the complex stability regions of the system are presented within the parametric space. The Hopf bifurcation is found during the onset of flutter as the dynamic pressure increases. The temperature rise imposes a significant effect on the stability region of the panel. Since the material parameters of the panel (elastic modulus and thermal expansion coefficient in this case) are the function of temperature, the panel tends to lose its stability as the temperature gets higher. Full article

Agrivoltaics is a relatively new term used originally for integrating photovoltaic (PV) systems into the agricultural landscape and expanded to applications such as animal farms, greenhouses, and recreational parks. The dual use of land offers multiple solutions for the renewable energy sector worldwide, provided it can be implemented without negatively impacting agricultural production. However, agrivoltaics represent a relatively new technology, facing challenges including economic viability, vulnerability to wind loads, and interference with growing crops. This paper reviews the recent research on integrating agrivoltaics with farming applications, focusing on challenges, wind impact on agrivoltaics, and economic solutions. The effect of agrivoltaics on temperature control of the lands is a critical factor in managing (1) water and the soil of the land, (2) animal comfort, and (3) greenhouse productivity, positively or negatively. In this review, a contradiction between the different versions of the American Society of Civil Engineers (ASCE) standards and the wind tunnel results is shown. Important factors affecting the wind load, such as damping and mass increase, optimum stow position, and aerodynamic edge modification, are highlighted with emphasis on the significant knowledge gap in the wind load mitigation methods. Full article

This study investigates the application of deep learning models—specifically Deep Neural Networks (DNN), Long Short-Term Memory (LSTM), and Long Short-Term Memory Neural Networks (LSTM-NN)—to predict panel flutter in aerospace structures. The goal is to improve the accuracy and efficiency of predicting aeroelastic behaviors under various flight conditions. Utilizing a supersonic flat plate as the main structure, the research integrates various flight conditions into the aeroelastic equation. The resulting structural vibration data create a large-scale database for training the models. The dataset, divided into training, validation, and test sets, includes input features such as panel aspect ratio, Mach number, air density, and decay rate. The study highlights the importance of selecting appropriate hidden layers, epochs, and neurons to avoid overfitting. While DNN, LSTM, and LSTM-NN all showed improved training with more neurons and layers, excessive numbers beyond a certain point led to diminished accuracy and overfitting. Performance-wise, the LSTM-NN model achieved the highest accuracy in classification tasks, effectively capturing sequential features and enhancing classification precision. Conversely, LSTM excelled in regression tasks, adeptly handling long-term dependencies and complex non-linear relationships, making it ideal for predicting flutter Mach numbers. Despite LSTM’s higher accuracy, it required longer training times due to increased computational complexity, necessitating a balance between accuracy and training duration. The findings demonstrate that deep learning, particularly LSTM-NN, is highly effective in predicting panel flutter, showcasing its potential for broader aerospace engineering applications. By optimizing model architecture and training processes, deep learning models can achieve high accuracy in predicting critical aeroelastic phenomena, contributing to safer and more efficient aerospace designs. Full article

Hypersonic vehicles are susceptible to considerable aerodynamic heating and noticeable aerothermoelastic effects during flight due to their high speeds. Functionally graded materials (FGMs), which enable continuous changes in material properties by varying the ratio of different materials, provide both thermal protection and load-bearing capabilities. Therefore, they are widely used in thermal protection structures for hypersonic vehicles. In this work, the aerothermoelastic behaviors of functionally graded (FG) plates under arbitrary temperature fields are analyzed via a semianalytical method. This research develops a method considering the influence of thermal loading, specifically the decrease in stiffness due to thermal stresses, as well as the correlation between material properties and temperatures under arbitrary temperature fields, based on Ritz’s method. The classical plate theory, von–Karman’s large defection plate theory and piston theory are employed to formulate the strain energy, kinetic energy and external work functions of the system. This paper presents a novel analysis of static aerothermoelasticity of FG plates, in addition to the linear/nonlinear flutter under arbitrary temperature fields, such as uniform, linear and nonlinear temperature fields. In addition, the effects of the volume fraction index, dynamic pressure, and temperature increase on the aerothermoelastic characteristics of FG plates are analyzed. Full article

Recent trends in aeroelastic analysis have shown a great interest in understanding the role of shock boundary layer interaction in predicting the dynamic instability of aircraft structural components at supersonic and hypersonic flows. The analysis of such complex dynamics requires a time-accurate fluid-structure interaction solver. This study focuses on the development of such a solver by coupling a finite-volume Navier-Stokes solver for fluid flow with a finite-element solver for structural dynamics. The coupled solver is then verified for the prediction of several panel instability cases in 2D and 3D uniform flows and in the presence of an impinging shock for a range of subsonic and supersonic Mach numbers, dynamic pressures, and shock strengths. The panel deflections and limit cycle oscillation amplitudes, frequencies, and bifurcation point predictions were compared within $10\%$ of the benchmark results; thus, the solver was deemed verified. Future studies will focus on extending the solver to 3D turbulent flows and applying the solver to study the effect of turbulent load fluctuations and shock boundary layer interactions on the fluid-structure coupling and structural dynamics of 2D panels. Full article

Understanding aeroelastic issues related to isolators is pivotal for the structural design and flow control of scramjets. However, research on fluid–structure interactions (FSIs) between thin-walled structures and the isolator flow remains limited. This study delves into the FSIs between thin-walled panels and the isolator flow, as characterized by an oblique shock train, by quantitatively analyzing 11 flow parameters assessing the structural response, separation zones, shock structures, flow symmetry, and performance. The results reveal that an FSI triggers panel flutter under oblique shock train conditions, with the panel shapes exhibiting a combination of first- and second-mode responses, peaking at 0.75 of the panel length. Compared to rigid wall conditions, isolators with a flexible panel at the bottom wall experience downstream movement of the separation zones and shock structures, reduced flow symmetry, and minor changes in performance. Transient fluctuations occur due to the panel flutter. Two flexible panels at the top and bottom walls have a comparatively lesser influence on the averaged parameters but exhibit more violent transient fluctuations. Furthermore, the FSI effects under oblique shock train conditions are contrasted with those under normal shock train conditions. The flutter response under normal shock train conditions is more pronounced, with a larger amplitude and higher frequency, driven by the heightened participation of the first-mode response. The effects of FSIs under normal shock train conditions on the averaged parameters are the opposite (with a larger influence) to those under oblique shock train conditions, with significantly more drastic transient fluctuations. Overall, this study sheds light on the complex and substantial influence of FSIs on the isolator flow, emphasizing the necessity of considering FSIs in future isolator design and development endeavors. Full article

The vibrations of plate structures placed in a supersonic flow was considered. The undisturbed fluid flow was parallel to the plate. This type of problem is especially important in the aerospace industry, where it is named panel flutter. It has been noticed for a long time that panel flutter may be problematic at high speeds. In this article, two specific problems were treated: in the first one, the plate was in the form of an infinite strip and the flow was in the direction of its finite length. Rigid walls indefinitely extended from the sides of the plate. In the second problem, the plate was a finite rectangle and the flow was parallel to one of its sides. The rest of the plane of the rectangle was again rigid. The first problem was a limiting case of the second problem. The flow was modeled by piston theory, which assumes that the fluid pressure on the plate is proportional to its local slope. This approximation is widely used at high speeds (supersonic speeds in the range of M > 1), and reduces the interaction between the fluid flow and the vibrations of the plate to an additional term in the vibration equation. The resulting problem can be solved by assumed mode methods. In this study, the solution was also found by using the collocation method. The contribution of this study is the correlation between the flutter velocity and the other parameters of the plate. The main result is the flutter velocity of the free fluid flow under which the plate vibrations become unstable. Finally, simple expressions are proposed between the various non-dimensional parameters that allows for the quick estimation of the flutter velocity. These simple expressions were deduced by least squares fits to the computed flutter velocities. Full article

Hypersonic vehicles or engines usually employ complex thermal protecting shells. This sometimes brings multi-physics difficulties, e.g., thermal-aeroelastic problems like panel flutter etc. This paper aims to propose a novel optimization method versus thermal dynamic influence on panel vibration. A traditional panel structure was modelled and analyzed. After analyzing its dynamic characteristics of panel flutter, thermal effects were also included to propose thermal-aeroelastic analysis results of the present hypersonic panel. Then, a MMC (Moving Morphable Component) method was proposed to suggest dynamic optimization for such panel structures. The proposed method can provide arbitrary frequency control result in order to suggest a newly generated panel structure. Based on the optimal structures, dynamic analysis was presented again to verify the effectiveness of the optimization method. So aero-thermo-dynamic characteristics of the optimal panel structures could be investigated. It can be seen that the computational results presented significantly improved panel flutter results. The proposed dynamic optimization method can be employed for the design of panel structures versus high combustion temperatures or hypersonic aerodynamics. Full article

The aeroelastic characteristics of the panel under the action of coolant are obviously different from the flutter characteristics of the traditional panel. In order to solve this problem, the dynamics model of the panel flutter was established in this paper based on von Karman’s large deformation theory and the Kirchhoff–Love hypothesis. The panel dynamics equations were discretized into constant differential equations with finite degrees of freedom by Galerkin’s method, and solved by the fourth Runge–Kutta method in the time domain. The nonlinear modified piston theory was used to predict the unsteady aerodynamic loads, and the accuracy of the flutter analysis model was verified. On this basis, the effects of the head-panel pressure of coolant, the pressure drop ratio, the coolant injection direction, and the inertial resistance and viscous resistance on panel stability and flight stability were investigated, respectively. The results showed that reducing the pressure drop ratio, and reducing or increasing the head-panel pressure (valuing away from the freestream pressure) can improve the critical dynamic pressure when bifurcation occurs. At $M_{\infty }=5.0$, the pressure drop ratio causes a 22.1% increment in the critical dynamic pressure. The influence of the coolant injection direction on the panel bifurcation is mainly influenced by the head-panel pressure. The inertial resistance slows down the convergence process of the panel response, increases the limit cycle amplitude, and reduces the critical dynamic pressure of the panel, while the viscous resistance plays the opposite role. Based on these conclusions, this paper finally proposes the suppression method of panel fluttering from head-panel pressure, inertial resistance, viscous resistance, etc. Full article

Inspired by the mass amplification property of inerters, an inerter-based passive panel flutter control procedure is developed and proposed. Formulations of aeroelastic equations of motion are based on the use of a wide-beam (flat panel) element stiffness equation subjective to supersonic flow using piston theory. The onset of flutter is analyzed using an eigenvector orientation approach, which may provide the advantage of lead time while the angle between eigenvectors of the first two coalescing modes reduces towards zero. The mass amplification effect of inerters is described and incorporated into the aeroelastic equation of motion of the passive actuation system for the investigation of flutter control. To demonstrate the potential applicability and usefulness of the proposed formulation and procedure, two numerical examples with one and two inerters, respectively, to optimally control the flutter of the panel modeled by wide-beam elements are presented. The results of the numerical simulation of the present examples demonstrate that the present inerter-based method can offset the onset of flutter to a higher level of aerodynamic pressure by optimizing the effective mass ratios and locations of inerters. In addition, this paper demonstrates that fundamental modes may be playing a role when identifying the optimal location of the inerters. It appears that the placement of the inerters may be more effective in controlling flutter at the highest amplitude of the mode shape along the wide beam. The procedure developed in this study may be of use for practical application for passive panel flutter control. Full article

This study evaluated the behavior of different codend designs to provide the basic information that is relevant for improving the gear selectivity, energy efficiency, to better understand the fish behavior inside the codend, and prevent the probability of the fish escaping. Three different codends were designed from the standard codend commonly used in the Antarctic krill fisheries based on modified Tauti’s law and evaluated. The first and the third codends were designed with four-panel and two-panel nettings, respectively, both made of diamond meshes. While, the second one was a four-panel diamond mesh design with cutting ratio 4:1(N [NBNBN]16). We measured the drag force, codend shape, fluttering codend motions, and the flow field inside and behind the different codends composed of different catch weights under various flow velocities in flume tank. The power spectra density was undertaken to analyze the time evolution of measured parameters. The results showed that the drag force and the codend motion increased and decreased, respectively, with the number of net panels and the cutting ratio. Due to the catch weight and flow velocity, which caused significant codend motions and deformation, a complex interaction occurred between the fluid and the structure, and there was a strong correlation between the codend drag, the codend motions, and the turbulent flow inside and behind the codend. The study showed that the use of the four-panel codend with cutting ratio and the two-panel codend resulted in drag reductions of 6.07% and 6.41%, respectively, compared to the standard codend. The velocity reduction and turbulent kinetic energy were lower inside and behind the four-panel codend than inside and behind the two-panel codend, indicating that turbulent flow through the two-panel codend is more important than through the four-panel codend. The results of the power spectral density analysis showed that the drag and codend motions were mainly low frequency in all codends, with another component related to turbulent flow street. In addition, the two-panel codend showed more unstable behavior with more pendulum motion compared to the four-panel codends, resulting in a smaller mesh size in this codend that could affect swimming energy and thus influence fish escape, making it the least selective codend. The results of this study provide fundamental insights useful for understanding and improving the hydrodynamic performance and selectivity of trawls in the Antarctic krill fishery, especially to reveal the masking effects of the number of net panels on codend design. Full article

Numerical and analytical investigations were performed to study the panel flutter generated by the coupling of elastic and aerodynamic loads with thermal loads. Based on large deflection theory and piston aerodynamic theory, the nonlinear dynamic differential equations of heated panels with pre-stretch displacement are derived. The Galerkin method is applied to transform the continuous partial differential equations into a nonlinear system of ordinary differential equations. The analytical expressions of the flutter critical dynamic pressure and flutter frequency, the static divergence stability boundary and the Hopf bifurcation fluttering stability boundary for the initial equilibrium of the panel can be obtained through the algebraic criterion of the Hopf bifurcation. The results show that, compared to the non-pre-stretch condition, when the pre-strain of the panel was merely 0.0328%, the flutter critical dynamic pressure and flutter frequency increased by 380.78% and 223.43%, respectively. Moreover, the pre-stretching method can significantly enhance the capacity of the supersonic panel to sustain temperature loads. Full article

Mass attachments may exist in the design and use of an aircraft panel, such as sensor layout, internal wiring, surface icing, etc. These mass attachments can change the flutter characteristics of the panel in supersonic flight and have important impacts on structural safety. In order to investigate the flutter characteristics of the panel with mass attachments, an assumed mode method is proposed to deal with the changes in the modal properties of the panel structure. Combined with the first order piston theory and p-k method, the flutter velocities and flutter frequencies of the panel under different cases can be obtained in the frequency domain. Firstly, based on the large displacement with a small strain assumption proposed by von Kármán and the proposed assumed mode method, the structural dynamic model of a simply supported panel with mass attachments and artificial dampers is constructed. Then, modal aerodynamic forces of the simply supported panel can be obtained based on first-order piston theory. Finally, flutter equations are transformed into the frequency domain and solved by the p-k method. The results showed that the existence of mass attachments can significantly change the flutter velocities and flutter frequencies of the panel. However, the flutter characteristics of the panel can be enhanced or recovered through some appropriate damper configuration schemes. Calculating the flutter characteristics of thin-walled panels with mass attachments can more accurately simulate real situations during flight, and one can obtain a safer design scheme of thin-walled panels. Full article

In order to investigate flutter characteristics of thin-walled panels with elastically supported boundaries, a method for dealing with the stiffness matrix constraint relationship is developed based on penalty functions. Combined with the first-order piston theory, flutter velocities and frequencies of thin-walled panels with the different cases of elastically supported boundaries are calculated. Firstly, a thin-walled panel is discretized by the finite element method, and springs with real stiffness coefficients are introduced to simulate elastically supported boundaries. Then, the pressure difference between the outer and inner surfaces of the panel and modal aerodynamic expressions are obtained by introducing the first-order piston theory. Finally, flutter equations are obtained in the time domain by combining the structural dynamic equations with the modal aerodynamic forces. Subsequently, they are transformed to the frequency domain at the flutter state. Then, flutter characteristics of the panel are obtained using the $U-g$ method. The results show that the existence of elastically supported boundaries may reduce the flutter velocity and flutter frequency of the panel but can be enhanced and recovered through some appropriate damping configuration schemes. Calculating the flutter characteristics of thin-walled panels under elastically supported boundaries can more accurately simulate real supported situations and result in a safer design scheme for thin-walled panel structures. Full article
