As a main apparatus, the oxygen lance is used to deliver the oxygen element and transfer kinetic energy into the molten bath in the steelmaking process. However, the Laval nozzle exit would be gradually worn out during the service life, which suppresses the performance of the oxygen lance. This paper investigated three different wear length (L_w) conditions at the exit of the Laval nozzle through numerical simulations and high-temperature experiments with various oxygen flow rates. The result showed that the entrainment of the ambient gas was the key factor of the wear phenomenon for the Laval nozzle exit. The maximum total temperature of the gas phase at the Laval nozzle exit formed by the L_w of 0 mm, 2 mm, and 4 mm were 300 K, 959 K, and 1700 K, respectively. Thus, by increasing the L_w value, the total temperature of the gas phase was rapidly improved at the exit of the Laval nozzle, which further accelerated the wear phenomenon at the exit of the Laval nozzle. Besides, axial velocities at the end of the potential core formed by the L_w of 0 mm, 2 mm, and 4 mm were 483.7 m/s, 480.0 m/s, and 478.7 m/s, respectively. As a result, the wear phenomenon reduced the impaction ability of the oxygen jet, which suppressed the impaction depth and radius, resulting in a smaller droplet generation rate. Full article

Printed circuit boards (PCBs) are the main components of e-waste. In order to reduce the negative impact of waste PCBs on human health and the environment, they must be properly disposed of. A new method is demonstrated for recycling waste PCBs. It is referred to as the high-temperature thermo-mechano-chemical gasification (TMCG) of PCBs by the detonation-born gasification agent (GA), which is a blend of H₂O and CO₂ heated to a temperature above 2000 °C. The GA is produced in a pulsed detonation gun (PDG) operating on a near-stoichiometric methane–oxygen mixture. The PDG operates in a pulsed mode producing pulsed supersonic jets of GA and pulsed shock waves possessing a huge destructive power. When the PDG is attached to a compact flow reactor filled with waste PCBs, the PCBs are subject to the intense thermo-mechano-chemical action of both strong shock waves and high-temperature supersonic jets of GA in powerful vortical structures established in the flow reactor. The shock waves grind waste PCBs into fine particles, which undergo repeated involvement and gasification in the high-temperature vortical structures of the GA. Demonstration experiments show full (above 98%) gasification of the 1 kg batch of organic matter in a setup operation time of less than 350 s. The gaseous products of PCB gasification are mainly composed of CO₂, CO, H₂, N₂, and CH₄, with the share of flammable gas components reaching about 45 vol%. The solid residues appear in the form of fine powder with visible metal inclusions of different sizes. All particles in the powder freed from the visible metal inclusions possess a size less than 300–400 μm, including a large fraction of sizes less than 100 μm. The powder contains Sn, Pb, Cu, Ni, Fe, In, Cd, Zn, Ca, Si, Al, Ti, Ni, and Cl. Among these substances, Sn (10–20 wt%), Pb (5–10 wt%), and Cu (up to 1.5 wt%) are detected in the maximum amounts. In the powder submitted for analysis, precious elements Ag, Au, and Pt are not detected. Some solid mass (about 20 wt% of the processed PCBs) is removed from the flow reactor with the escaping gas and is partly (about 10 wt%) trapped by the cyclones in the exhaust cleaning system. Metal inclusions of all visible sizes accumulate only in the flow reactor and are not detected in powder samples extracted from the cyclones. The gasification degree of the solid residues extracted from the cyclones ranges from 76 to 91 wt%, i.e., they are gasified only partly. This problem will be eliminated in future work. Full article

The paper presents the results of experimental studies on the production of fine char powder from sunflower seed husks by a novel method of thermomechanical treatment with pulsed shock waves and supersonic jets of the mixture of ultra-superheated (above 2000 °C) steam and carbon dioxide, as well as the results of examination of the produced char powder in terms of its chemical, phase, and granulometric composition and structural, morphological, and texture characteristics. The objective of the research is to explore the possibility of using the resulting char powder as a sorption-active material for organic substances. It is shown that the obtained char particles and their agglomerates have an average size of 20–30 nm and 12–24 µm, respectively, have the shape of disks and ellipsoids, consist mainly of amorphous carbon (up to 56 wt%) and oxygen (up to 42 wt%), and have a specific surface area of 1.1–1.7 m²/g. It is concluded that such a char powder can be used as an absorbent for organic substances when dried and deagglomerated. Full article

In electric arc furnace (EAF) steelmaking, oxygen jets play a crucial role in controlling stirring ability, chemical reactions, and energy consumption. During the EAF lifetime, refractory wear leads to a decrease in the molten steel level and an increase in the nozzle-to-steel distance, thereby negatively affecting the overall energy efficiency of the process. The objective of this study is to optimize the energy efficiency of the EAF refining process by adjusting the nozzle flow conditions and conducting an analysis of jet performance using computational fluid dynamics (CFD) simulation. Three types of injection jets were considered: the conventional jet, the CH₄ coherent jet, and the CH₄ + O₂ coherent jet. The findings reveal that the shrouded flame of the coherent jet enhances jet performance by maintaining the maximum velocity, extending the potential core length, and increasing the penetration depth in the molten steel bath. To maintain the jet performance in response to an increased nozzle-to-steel distance resulting from refractory wear, transitions from the conventional jet to the CH₄ coherent jet and the CH₄ + O₂ coherent jet are recommended once the nozzle-to-steel distance increases from its initial level of 1000 mm to 1500 mm and 2000 mm, respectively. Full article

The supersonic flow of a reactive gas mixture with Mach reflection of oblique shocks and pulsed energy supply at the Mach stem is considered within the framework of the Chapman–Jouguet theory. An approximate analytical model is proposed that quickly determines the shape and size of the shock-wave structure as well as the flow parameters in various flow regions. As an example of the application of the proposed analytical model, the “first barrel” of a highly overexpanded jet flow of an air-methane mixture with a high supersonic velocity, is studied. Flows of hydrogen–air and hydrogen–oxygen mixtures were also considered for comparison with preceding numerical results. The height of the triple point of the Mach reflection is determined in the presence of a change in the chemical composition of the mixture and an isobaric pulsed energy supply at the main shock. Full article

A coherent jet oxygen supply plays a key role in the process of electric arc furnace steelmaking: it provides the necessary oxygen for the smelting of molten steel and promotes the flow of the molten pool. Compared with coherent jets in current use, the supersonic combustion coherent jet shrouded in supersonic methane gas could improve the impact capacity and stirring intensity of the molten pool. In order to reduce the smelting cost, the characteristics of the supersonic combustion coherent jet shrouding the supersonic methane and nitrogen mixtures must be studied. Computational fluid dynamics software is used to simulate the supersonic combustion coherent jet under various methane–nitrogen mixing conditions. The six-component combustion mechanism of methane and the Eddy Dissipation Concept combustion reaction model are selected. In agreement with thermal experiments, the simulation results show that the inclusion of a small amount of nitrogen has little effect on the combustion of supersonic shrouding methane gas. However, as the nitrogen content increases, the combustion region of supersonic shrouding gas becomes shorter in length, resulting in decreases in the lengths of the high-temperature, low-density region, and the high-turbulence-intensity region. These effects weaken the ability of the shrouding gas to envelop the main oxygen jet. The potential core length of the main oxygen jet decreases significantly; this decrease first accelerates and then decelerates. These results demonstrate the feasibility of including a small amount of nitrogen (about 10 wt%) in the supersonic shrouding methane gas without substantial negative impacts on the characteristics of the supersonic combustion coherent jet. Full article

Utilization of CO₂ in steelmaking process has attracted extensive attention in recent years, not only because of its social benefits, but also its better metallurgical performance. Mixing CO₂ with O₂ blown by converter oxygen lance is gradually being adopted by steelmaking plants, due to its potential of reducing consumption and improving steel quality. In the present research, effect of mixing CO₂ on the jet characteristics of a four-nozzle oxygen lance was studied in detail by numerical simulation, taking the combustion behavior between supersonic jets and ambient atmosphere into consideration innovatively. The simulated results showed that the combustion flame is mainly distributed in the region between multiple jets, and the high temperature flame has a noticeable influence on the low-velocity region of the jet. Due to the dilution effect of CO₂, mixing CO₂ into the oxygen jets will reduce the maximum temperature of the flame and slow down the combustion rate. With the increase of CO₂ mixing ratio, the high-temperature zone of combustion flame moves away from the lance tip significantly. At the same distance from the nozzle, although mixing CO₂ can hardly increase the velocity magnitude of the jet, but it can achieve higher dynamic pressure, indicating stronger impacting power. Then the industrial experiment of top blowing O₂-CO₂ was carried out in a 120-ton converter. During the blowing time of 120~300 s, the mixing ratio of CO₂ was 15 vol.% for better dephosphorization, and no CO₂ was mixed in the rest time of blowing. Due to the stronger stirring and better thermodynamics, the average [P] content in the final molten steel was decreased from 0.0155 wt.% to 0.0129 wt.%, achieving higher dephosphorization efficiency. Full article

By establishing a mathematical model to simulate a mixed jet of oxygen and superheated steam from a coherent supersonic jet oxygen lance, we studied the effect of superheated steam on the fluid characteristics of the mixed jet. The model was initially verified through laboratory experiments prior to analyzing the fluid characteristics of the mixed jet in detail. These characteristics included the jet velocity, the temperature, the turbulent kinetic energy (TKE), and the mass distribution. The results showed that, at an ambient temperature of 1700 K, the jet velocity measured in the laboratory experiment was consistent with the fluid velocity obtained by numerical simulations, with an error of only 2.7%. In a high-temperature environment, the jet velocity of the mixed oxygen and superheated steam jet was increased, the TKE around the center jet was enhanced, the superheated steam exhibited an inhibitory effect on the combustion reaction of annular methane, and the potential core length of the coherent supersonic jet was reduced, which was conducive to methane combustion and delayed the reduction in the central jet velocity. Full article

An oxygen lance is the operation unit that generates supersonic oxygen jets, controls their behavior, and acts as a vital role in the steelmaking process. It is thought that airflow similar to a tornado may suppress upward splashing because of part of the jet pressure shifting from the axis of the oxygen lance to the tangential direction. Therefore, a new oxygen lance is designed to form a tornado jet, and the numerical simulation consequences are verified by the physical model. The structure of the new oxygen lance is optimized by numerical simulation results, and the comparison of simulation results before and after optimization is analyzed. On this basis, the effect of the cyclone oxygen lance on the upward splashing behavior, penetrating depth, turbulent kinetic energy, turbulent dissipation rate, and rotation of molten bath is investigated. The conclusions present that, compared with the conventional oxygen lance, the upward splashing with the cyclone oxygen lance decreases, and the penetrating depth and reaction area increase. In other words, for obtaining the same penetrating depth, the cyclone lance height can be higher than that of a conventional oxygen lance, which leads to a better protective effect on the refractories of the oxygen lance. Moreover, the average value of the turbulent kinetic energy of the cyclone nozzle is larger than that of the traditional Laval nozzle at the interface between oxygen and slag, which improves the effect of steelmaking. Full article

Plasma-assisted supersonic jet deposition (PA-SJD) is a precise technique for the fabrication of thin films with a desired nanostructured morphology. In this work, we used quadrupole mass spectrometry of the neutral species in the jet and the extensive characterization of TiO₂ films to improve our understanding of the relationship between jet chemistry and film properties. To do this, an organo–metallic precursor (titanium tetra–isopropoxide or TTIP) was first dissociated using a reactive argon–oxygen plasma in a vacuum chamber and then delivered into a second, lower pressure chamber through a nozzle. The pressure difference between the two chambers generated a supersonic jet carrying nanoparticles of TiO₂ in the second chamber, and these were deposited onto the surface of a substrate located few centimeters away from the nozzle. The nucleation/aggregation of the jet nanoparticles could be accurately tuned by a suitable choice of control parameters in order to produce the required structures. We demonstrate that high-quality films of up to several µm in thickness and covering a surface area of few cm² can be effectively produced using this PA-SJD technique. Full article

In the duplex steelmaking process, the oxygen flow rate is suppressed to reduce the increasing rate of the temperature in the molten bath, resulting in severe dynamic conditions. To improve the mixing effect of the molten bath, a Laval nozzle structure designed for combination gas has been proposed. In this research, five types of Laval nozzle structure have been built based on the combination gas content, and both numerical simulations and experiments are performed to analyze the flow field of the supersonic jet. The axial velocity and oxygen concentration were measured in the experiment, which agreed well with the numerically simulated data. The results show that both initial axial velocity and potential core length increase with the flow rate of combination gas. Further, applying a higher N₂ flow rate could improve the oxygen utilization rate at different ambient temperatures, but this issue increases the oxygen utilization rate; however, the latter can be reduced at higher ambient temperatures. Full article

During the converter steelmaking process, the presence of supersonic oxygen jets can provide oxygen to high-temperature metal baths that promotes chemical reactions in the bath, accelerates the smelting rhythm, and facilitates a uniform distribution of the ingredients in the bath. In this paper, a computational fluid dynamics (CFD) model with combustion reactions is established and compared to the results of combustion experiment. This paper studies the behavior and fluid flow characteristics of supersonic oxygen jets under different environmental compositions under a steelmaking temperature of 1873 K. This validated CFD model can be used to investigate the effect of furnace gas on supersonic oxygen jet characteristics during the converter steelmaking process. The results indicate that the composition of furnace gas has an impact on the characteristics of the oxygen jet. Specifically, as the carbon monoxide (CO) volume fraction increases, the high velocity region of supersonic oxygen jet increases, and the high temperature and the high turbulent kinetic energy regions expand. Full article

Basic oxygen furnace (BOF) steelmaking is widely used in the metallurgy field. The slagging reaction is a necessary process that oxidizes C, Mn, Si, P, S, and other impurities and therefore directly affects the quality of the resultant steel. Relevant research has suggested that intensifying the stirring effect can accelerate the slagging reaction and that the dynamic characteristics of the top blow are the key factor in exploring the related complex physical and chemical phenomena. To address the issue, the standard k-$\omega$ turbulence model and level-set method were adopted in the present work and a fluid dynamics model was developed for a BOF. Accordingly, the slag–metal–gas emulsion interaction and stirring effect were investigated, and the interference mechanism of a multi-nozzle supersonic coherent jet was revealed. Finally, a self-adjustment method based on fuzzy control is proposed for the oxygen lance. The results indicate that the transfer efficiency of jet kinetic energy at the gas–liquid interface is the critical factor for the slagging reaction and that multi-nozzle oxygen lances with a certain twisted angle have important advantages with respect to stirring effects and splashing inhibition. The fuzzy control method predicts that the optimal nozzle twist angle is within the range of 7.2° to 7.8°. The results presented herein can provide theoretical support and beneficial reference information for BOF steelmaking. Full article

The present study proposes a complete 3D integrated model to simulate the top-blown supersonic coherent jet decarburization in the electric arc furnace (EAF) refining process. The 3D integrated model avoids the direct simulation of the supersonic coherent jet interacting with the liquid steel bath and provides a feasible way to simulate the decarburization in the liquid steel-oxygen two-phase reacting flow system with acceptable computational time. The model can be used to dynamically predict the details of the molten bath, including 3D distribution of in-bath substances, flow characteristics and bath temperature and provide a basis for optimizing the decarburization rate or other required parameters during the refining process. Full article

During the electric arc furnace steelmaking process, the coherent jet technology was widely used to protect the kinetic energy of the supersonic oxygen jet and achieve better mixing effects. Comparing with the conventional oxygen lance, the coherent lance could increase the surface area of impaction cavity, resulting in a better stirring effect and higher reaction rate. However, there was limited research about the effect of restriction structure for the coherent lance tip on the flow field characteristic of the main oxygen jet. In this research, three kinds of restriction structures have been investigated by numerical simulation and combustion experiment at room and high ambient temperature conditions. Then an optimum restriction structure would be tested in a 75 t electrical arc furnace steelmaking process to verify its metallurgical property. Full article
