Reasonable and effective control of a cathode air supply system is conducive to improving the dynamic response, operating efficiency, and reliability of fuel cell systems. This paper proposes a novel data-driven adaptive oxygen excess ratio (OER) control strategy based on online parameter identification for fuel cell systems. The proposed control scheme employs a second-order active disturbance rejection controller (ADRC) derived from the proportional-integral-derivative tuning rule to effectively deal with model uncertainties and external disturbances. Online parameter identification continuously translates the cathode air supply system into the second-order model, enabling the real-time adaptation of controller parameters to varying operating conditions. Simulation results demonstrate that the OER control strategy proposed significantly improves voltage stability and system efficiency under dynamic conditions compared to traditional methods. The innovation of this paper is that, based on consideration of the nonlinear slow time-varying characteristics of a PEMFC and the frequent disturbance of load current, adaptive control under system dynamic conditions can be considered. Combining the parameter identification scheme, an adaptive online self-tuning scheme is designed for the identified system model, which avoids the tediousness of a complex modeling process and has promotion value in practical applications. Full article

The proton exchange membrane fuel cell (PEMFC) is the most widely used fuel cell, but it also has some limitations. One of the research pain points is controlling the oxygen content in PEMFCs. A moderate excess of oxygen boosts electrochemical reaction efficiency, while an appropriate oxygen content ensures system stability. In this paper, a fourth-order nonlinear mathematical model of a PEMFC stack air supply system is established to solve the problem of optimal oxygen excess ratio (OER) control under dynamic load conditions. Based on the model, a nonsingular terminal sliding mode controller (NTSMC) based on a sliding mode observer (SMO) is proposed. The NTSM exhibits superior robustness and performance compared to other sliding mode structures. Meanwhile, the SMO accurately predicts system states, facilitating precise control actions. Additionally, the dual sliding mode surfaces enhance system stability against parameter uncertainties and external disturbances. Our results demonstrate that the proposed controller outperforms traditional ones in terms of robustness and performance, which significantly enhances PEMFC system efficiency and stability. Full article

The stability of hydrogen fuel cell system power generation is affected by key variables such as oxygen excess ratio (OER), electric stack temperature, and cathode–anode differential pressure. To increase the fuel cell’s stability, a sliding mode integral separation proportional–integral–derivative (SMC−IS−PID) control strategy was proposed by combining the four−segment integral separation PID (IS−PID) control with the switching control in the sliding mode control (SMC). The control mode is selected through the system variable error and the current variable value; if there are significant systematic variable errors, the switching control in the SMC adopts the four−segment integral separation PID control, which determines the values of the segmentation thresholds and controls the integral weights to reduce the amount of overshoot. When the error of the system variables is small, the switching control in the SMC adopts the improved convergence law control, which introduces the hyperbolic tangent exponential power term, the nonlinear function term, and the saturation function term to improve the convergence law and decrease the control’s convergence time. Experimentally verifying the effectiveness of the control strategy above, the results show that for the OER, the SMC−IS−PID overshoots 0 and realizes no overshooting with a regulation time of 5.019 s. For the temperature of the stack, the SMC−IS−PID overshoots only 0.134% with a regulation time of 40.521 s. For the pressure of the stack, the SMC−IS−PID realizes the system is basically free of oscillation. Full article

The control strategy of the gas supply subsystem is very important to ensure the performance and stability of the fuel cell system. However, due to the inherent nonlinear characteristics of the fuel cell gas supply subsystem, the traditional control strategy is mainly based on proportional integral (PI) control, which has the disadvantages of large limitation, large error, limited immunity, and inconsistent control performance, which seriously affects its effectiveness. In order to overcome these challenges, this paper proposes an optimal control method for air supply subsystems based on nonlinear active disturbance rejection control (ADRC). Firstly, a seven-order fuel cell system model is established, and then, the nonlinear ADRC and traditional PI control strategies are compared and analyzed. Finally, the two strategies are simulated and compared. The validation results indicate that the integral absolute error (IAE) measure of PI control is 0.502, the integral square error (ISE) measure is 0.1382, and the total variation (TV) measure is 399.1248. Compared with the PI control, the IAE and ISE indexes of ADRC were reduced by 61.31% and 58.03%, respectively. ADRC is superior to PI control strategy in all aspects and realizes the efficient adjustment of the system under different working conditions. ADRC is more suitable for the nonlinear characteristics of the gas supply system and is more suitable for the oxygen excess ratio (OER). Full article

Proton exchange membrane fuel cells (PEMFCs) are attracting attention for their green, energy-saving, and high-efficiency advantages, becoming one of the future development trends of renewable energy utilization. However, there are still deficiencies in the gas supply system control strategy that plays a crucial role in PEMFCs, which limits the rapid development and application of PEMFCs. This paper provides a comprehensive and in-depth review of the PEMFC air delivery system (ADS) and hydrogen delivery system (HDS) operations. For the ADS, the advantages and disadvantages of the oxygen excess ratio (OER), oxygen pressure, and their decoupling control strategies are systematically described by the following three aspects: single control, hybrid control, and intelligent algorithm control. Additionally, the optimization strategies of the flow field or flow channel for oxygen supply speeds and distribution uniformity are compared and analyzed. For the HDS, a systematic review of hydrogen recirculation control strategies, purge strategies, and hydrogen flow control strategies is conducted. These strategies contribute a lot to improving hydrogen utilization rates. Furthermore, hydrogen supply pressure is summarized from the aspects of hybrid control and intelligent algorithm control. It is hoped to provide guidance or a reference for research on the HDS as well as the ADS control strategy and optimization strategy. Full article

Proton exchange membrane water electrolysis is hindered by the sluggish kinetics of the anodic oxygen evolution reaction. RuO₂ is regarded as a promising alternative to IrO₂ for the anode catalyst of proton exchange membrane water electrolyzers due to its superior activity and relatively lower cost compared to IrO₂. However, the dissolution of Ru induced by its overoxidation under acidic oxygen evolution reaction (OER) conditions greatly hinders its durability. Herein, we developed a strategy for stabilizing RuO₂ in acidic OER by the incorporation of high-valence metals with suitable ionic electronegativity. A molten salt method was employed to synthesize a series of high-valence metal-substituted RuO₂ with large specific surface areas. The experimental results revealed that a high content of surface Ru⁴⁺ species promoted the OER intrinsic activity of high-valence doped RuO₂. It was found that there was a linear relationship between the ratio of surface Ru⁴⁺/Ru³⁺ species and the ionic electronegativity of the dopant metals. By regulating the ratio of surface Ru⁴⁺/Ru³⁺ species, incorporating Re, with the highest ionic electronegativity, endowed Re_0.1Ru_0.9O₂ with exceptional OER activity, exhibiting a low overpotential of 199 mV to reach 10 mA cm⁻². More importantly, Re_0.1Ru_0.9O₂ demonstrated outstanding stability at both 10 mA cm⁻² (over 300 h) and 100 mA cm⁻² (over 25 h). The characterization of post-stability Re_0.1Ru_0.9O₂ revealed that Re promoted electron transfer to Ru, serving as an electron reservoir to mitigate excessive oxidation of Ru sites during the OER process and thus enhancing OER stability. We conclude that Re, with the highest ionic electronegativity, attracted a mass of electrons from Ru in the pre-catalyst and replenished electrons to Ru under the operating potential. This work spotlights an effective strategy for stabilizing cost-effective Ru-based catalysts for acidic OER. Full article

The hydrogen fuel cell is a quite promising green device, which could be applied in extensive fields. However, as a complex nonlinear system involving a number of subsystems, the fuel cell system requires multiple variables to be effectively controlled. Oxygen excess ratio (OER) is the key indicator to be controlled to avoid oxygen starvation, which may result in severe performance degradation and life shortage of the fuel cell stack. In this paper, a nonlinear air supply system model integrated with the fuel cell stack voltage model is first built, based on physical laws and empirical data; then, conventional proportional-integral-derivative (PID) controls for the oxygen excess ratio are implemented. On this basis, fuzzy logic inference and neural network algorithm are integrated into the conventional PID controller to tune the gain coefficients, respectively. The simulation results verify that the fuzzy PID controller with seven subsets could clearly improve the dynamic responses of the fuel cells in both constant and variable OER controls, with small overshoots and the fastest settling times of less than 0.2 s. Full article

Proton exchange membrane fuel cells (PEMFC) are vulnerable to oxygen starvation when working under variable load. To address these issues, a cascade control strategy of sliding mode control (SMC) and Proportion Integration Differentiation (PID) control is proposed in this study. The goal of the control strategy is to enhance the PEMFC’s net power by adjusting the oxygen excess ratio (OER) to the reference value in the occurrence of a load change. In order to estimate the cathode pressure and reconstruct the OER, an expansion state observer (ESO) is developed. The study found that there is a maximum error of about 2200Pa between the estimated cathode pressure and the actual pressure. Then the tracking of the actual OER to the reference OER is realized by the SMC and PID cascade control. The simulation study, which compared the control performance of several methods—including PID controller, adaptive fuzzy PID controller and the proposed controller, i.e., the SMC and PID cascade controller—was carried out under various load-changing scenarios. The outcomes demonstrate that the proposed SMC and PID cascade controller method really does have a faster response time. The overshoot is reduced by approximately 3.4% compared to PID control and by about 0.09% compared to fuzzy adaptive PID. SMC and PID cascade control reference OER performs more effectively in terms of tracking compared to PID control and adaptive fuzzy PID control. Full article

In this paper, a novel second-order active disturbance rejection control (2-ADRC) algorithm is proposed to optimize the control of the air supply subsystem for Proton Exchange Membrane Fuel Cell (PEMFC). To improve the optimal control effect of the air supply subsystem for PEMFC, the modeling theory of the air supply subsystem considering dynamic characteristics of the PEMFC system is first studied, and the dynamic Simulink model of the PEMFC system is established and verified. Then, the optimal oxygen excess ratio (OER) parameters under different load currents are obtained, and the optimal OER parameters are also used as the OER control reference for the designed algorithms. In addition, a 2-ADRC algorithm is designed and proposed to make the actual OER parameters close to the optimal OER in real time. Furthermore, compared with PID and MPC algorithms, the 2-ADRC algorithm can comprehensively consider the two parameters of mass flow and pressure ratio to make the compressor work in the high-efficiency zone and improve the net power and efficiency of the PEMFC system. Full article

The development of highly stable and active electrocatalysts for the oxygen evolution reaction (OER) has attracted significant research interest. IrO₂ is known to show good stability during the OER however it is not known to be the most active. Thus, significant research has been dedicated to enhance the activity of IrO₂ toward the OER. In this study, IrO₂ catalysts were synthesized using a modified Adams fusion method. The Adams fusion method is simple and is shown to directly produce nano-sized metal oxides. The effect of the Ir precursor salt to the NaNO₃ ratio and the fusion temperature on the OER activity of the synthesized IrO₂ electrocatalysts, was investigated. The OER activity and durability of the IrO₂ electrocatalysts were evaluated ex-situ via cyclic voltammetry (CV), chronopotentiometry (CP), electrochemical impedance spectroscopy (EIS) and linear sweep voltammetry (LSV). Physical properties of the IrO₂ electrocatalysts were evaluated via X-ray diffraction (XRD), transmission electron microscopy (TEM), thermal gravimetric analysis (TGA), differential thermal analysis (DTA), and energy dispersive spectroscopy (EDS). The results show that the addition of excess NaNO₃ during the modified Adams fusion reaction is not a requirement and that higher synthesis temperatures results in IrO₂ electrocatalysts with larger particle sizes and reduced electrocatalytic activity. Full article
