A mobile laser scanning (MLS) system can acquire railway scene information quickly and provide a data foundation for regular railway inspections. The location of the catenary support device in an electrified railway system has a direct impact on the regular operation of the power supply system. However, multi-type support device data accounts for a tiny proportion of the whole railway scene, resulting in its poor characteristic expression in the scene. Therefore, using traditional point cloud filtering or point cloud segmentation methods alone makes it difficult to achieve an effective segmentation and extraction of the support device. As a result, this paper proposes an automatic extraction algorithm for complex railway support devices based on MLS point clouds. First, the algorithm obtains hierarchies of the pillar point clouds and the support device point clouds in the railway scene through high stratification and then realizes the noise that was point-cloud-filtered in the scene. Then, the center point of the pillar device is retrieved from the pillar corridor by a neighborhood search, and then the locating and initial extracting of the support device are realized based on the relatively stable spatial topological relationship between the pillar and the support device. Finally, a post-processing optimization method integrating the pillar filter and the voxelized projection filter is designed to achieve the accurate and efficient extraction of the support device based on the feature differences between the support device and other devices in the initial extraction results. Furthermore, in the experimental part, we evaluate the treatment effect of the algorithm in six types of support devices, three types of support device distribution scenes, and two types of railway units. The experimental results show that the average extraction IoU of the multi-type support device, support device distribution scenes, and railway unit were 97.20%, 94.29%, and 96.11%, respectively. In general, the proposed algorithm can achieve the accurate and efficient extraction of various support devices in different scenes, and the influence of the algorithm parameters on the extraction accuracy and efficiency is elaborated in the discussion section. Full article

Accurate semantic segmentation results of the overhead catenary system (OCS) are significant for OCS component extraction and geometric parameter detection. Actually, the scenes of OCS are complex, and the density of point cloud data obtained through Light Detection and Ranging (LiDAR) scanning is uneven due to the character difference of OCS components. However, due to the inconsistent component points, it is challenging to complete better semantic segmentation of the OCS point cloud with the existing deep learning methods. Therefore, this paper proposes a point cloud multi-scale feature fusion refinement structure neural network (PMFR-Net) for semantic segmentation of the OCS point cloud. The PMFR-Net includes a prediction module and a refinement module. The innovations of the prediction module include the double efficient channel attention module (DECA) and the serial hybrid domain attention (SHDA) structure. The point cloud refinement module (PCRM) is used as the refinement module of the network. DECA focuses on detail features; SHDA strengthens the connection of contextual semantic information; PCRM further refines the segmentation results of the prediction module. In addition, this paper created and released a new dataset of the OCS point cloud. Based on this dataset, the overall accuracy (OA), F1-score, and mean intersection over union (MIoU) of PMFR-Net reached 95.77%, 93.24%, and 87.62%, respectively. Compared with four state-of-the-art (SOTA) point cloud deep learning methods, the comparative experimental results showed that PMFR-Net achieved the highest accuracy and the shortest training time. At the same time, PMFR-Net segmentation performance on S3DIS public dataset is better than the other four SOTA segmentation methods. In addition, the effectiveness of DECA, SHDA structure, and PCRM was verified in the ablation experiment. The experimental results show that this network could be applied to practical applications. Full article

Overhead catenary system (OCS) automatic detection is of important significance for the safe operation and maintenance of electrified railways. The vehicle-borne mobile mapping system (VMMS) may significantly improve the data acquisition. This paper proposes a VMMS-based framework to realize the automatic detection and modelling of OCS. The proposed framework performed semantic segmentation, model reconstruction and geometric parameters detection based on LiDAR point cloud using VMMS. Firstly, an enhanced VMMS is designed for accurate data generation. Secondly, an automatic searching method based on a two-level stereo frame is designed to filter the irrelevant non-OCS point cloud. Then, a deep learning network based on multi-scale feature fusion and an attention mechanism (MFF_A) is trained for semantic segmentation on a catenary facility. Finally, the 3D modelling is performed based on the OCS segmentation result, and geometric parameters are then extracted. The experimental case study was conducted on a 100 km high-speed railway in Guangxi, China. The experimental results show that the proposed framework has a better accuracy of 96.37%, outperforming other state-of-art methods for segmentation. Compared with traditional manual laser measurement, the proposed framework can achieve a trustable accuracy within 10 mm for OCS geometric parameter detection. Full article

As the railway overhead contact system (OCS) is the key component along the high-speed railway, it is crucial to detect the quality of the OCS. Compared with conventional manual OCS detection, the vehicle-mounted Light Detection and Ranging (LiDAR) technology has advantages such as high efficiency and precision, which can solve the problems of OCS detection difficulty, low efficiency, and high risk. Aiming at the contact cables, return current cables, and catenary cables in the railway vehicle-mounted LiDAR OCS point cloud, this paper used a scale adaptive feature classification algorithm and the DBSCAN (density-based spatial clustering of applications with noise) algorithm considering OCS characteristics to classify the OCS point cloud. Finally, the return current cables, catenary cables, and contact cables in the OCS were accurately classified and extracted. To verify the accuracy of the method presented in this paper, we compared the experimental results of this article with the classification results of TerraSolid, and the classification results were evaluated in terms of four accuracy indicators. According to statistics, the average accuracy of using this method to extract two sets of OCS point clouds is 99.83% and 99.89%, respectively; the average precision is 100% and 99.97%, respectively; the average recall is 99.16% and 99.42%, respectively; and the average overall accuracy is 99.58% and 99.69% respectively, which is overall better than TerraSolid. The experimental results showed that this approach could accurately and quickly extract the complete OCS from the point cloud. It provides a new method for processing railway OCS point clouds and has high engineering application value in railway component detection. Full article

As overhead contact (OC) is an essential part of power supply systems in high-speed railways, it is necessary to regularly inspect and repair abnormal OC components. Relative to manual inspection, applying LiDAR (light detection and ranging) to OC inspection can improve efficiency, accuracy, and safety, but it faces challenges to efficiently and effectively segment LiDAR point cloud data and identify catenary components. Recent deep learning-based recognition methods are rarely employed to recognize OC components, because they have high computational complexity, while their accuracy needs to be improved. To track these problems, we first propose a lightweight model, RobotNet, with depthwise and pointwise convolutions and an attention module to recognize the point cloud. Second, we optimize RobotNet to accelerate its recognition speed on embedded devices using an existing compilation tool. Third, we design software to facilitate the visualization of point cloud data. Our software can not only display a large amount of point cloud data, but also visualize the details of OC components. Extensive experiments demonstrate that RobotNet recognizes OC components more accurately and efficiently than others. The inference speed of the optimized RobotNet increases by an order of magnitude. RobotNet has lower computational complexity than other studies. The visualization results also show that our recognition method is effective. Full article

High-speed railways have been one of the most popular means of transportation all over the world. As an important part of the high-speed railway power supply system, the overhead catenary system (OCS) directly influences the stable operation of the railway, so regular inspection and maintenance are essential. Now manual inspection is too inefficient and high-cost to fit the requirements for high-speed railway operation, and automatic inspection becomes a trend. The 3D information in the point cloud is useful for geometric parameter measurement in the catenary inspection. Thus it is significant to recognize the components of OCS from the point cloud data collected by the inspection equipment, which promotes the automation of parameter measurement. In this paper, we present a novel method based on deep learning to recognize point clouds of OCS components. The method identifies the context of each single frame point cloud by a convolutional neural network (CNN) and combines some single frame data based on classification results, then inputs them into a segmentation network to identify OCS components. To verify the method, we build a point cloud dataset of OCS components that contains eight categories. The experimental results demonstrate that the proposed method can detect OCS components with high accuracy. Our work can be applied to the real OCS components detection and has great practical significance for OCS automatic inspection. Full article

This paper presents a new method for detecting, locating and classifying overhead contact systems (catenary systems) in point clouds collected by mobile mapping systems (MMS) on rail roads. Contrary to many other application types, railway embankments are highly regulated and standardized. Railway infrastructure geometric relations remain roughly unchanged within established regions and have similarities between them. The newly-developed method exploits both these characteristics, as well as the survey process. There are several steps in this approach. Firstly, it restricts the search for catenaries relative to the distance to registered MMS trajectory, then finds possible support structures according to the density of points above the track. Subsequently, the method verifies the structures’ presence and classifies the points with the use of the RANSAC algorithm. It establishes the presence of cantilevers, as well as poles or structural beams, depending on the type of detected support structure. The method also determines the coordinates of the identified object on the ground. Finally, a classification is clarified with the use of a modified DBSCAN algorithm. The design method has been verified with data collected in four surveys where the cumulative length of the route was almost 90 km. Over 97% of support structures were correctly detected, and out of these, over 95% were completely classified. Full article
