This work presents a novel approach to investigating epitaxial GaAsN layers and GaAsN-based p-i-n solar cell structures using light-assisted scanning capacitance microscopy (SCM) and spectroscopy. Due to the technological challenges in growing high-quality GaAsN with controlled nitrogen incorporation, the epitaxial layers often exhibit inhomogeneity in their opto-electrical properties. By combining localized cross-section SCM measurements with wavelength-tunable optical excitation (800–1600 nm), we resolved carrier concentration profiles, internal electric fields, and deep-level transitions across the device structure at a nanoscale resolution. A comparative analysis between electrochemical capacitance–voltage (EC-V) profiling and photoluminescence spectroscopy confirmed multiple localized transitions, attributed to compositional fluctuations and nitrogen-induced defects within GaAsN. The SCM method revealed spatial variations in energy states, including discrete nitrogen-rich regions and gradual variations in the nitrogen content throughout the layer depth, which are not recognizable using standard characterization methods. Our results demonstrate the unique capability of the photo-scanning capacitance microscopy and spectroscopy technique to provide spatially resolved insights into complex dilute nitride structures, offering a universal and accessible tool for semiconductor structures and optoelectronic devices evaluation. Full article

Bio-nanocomposite films were prepared using chitosan, gelatin, and varying concentrations (0, 0.5, 1.0, 2.0, and 5.0 wt%) of titanium dioxide (TiO₂) nanoparticles in acetic acid via a casting method. The incorporation of TiO₂ nanoparticles into the bio-chitosan matrix enhanced ultraviolet (UV) absorption and improved the films’ physical, mechanical, and electrical properties. Additionally, the TiO₂-loaded films exhibited antimicrobial activity, contributing to the extended preservation of packaged products by inhibiting microbial growth. Notably, the bio-nanocomposite films containing 1.0 wt% TiO₂ exhibited an electroactive response, bending under relatively low electric field strength (250 V/mm), whereas the control film without TiO₂ required higher field strength (550 V/mm) to achieve bending. This indicates potential applications in electroactive actuators requiring precise movement control. Among the tested concentrations, films containing 0.5 wt% and 1.0 wt% TiO₂ (Formulas 7 and 8) demonstrated optimal performance. These films presented a visually appealing appearance with no tear marks, low bulk density (0.91 ± 0.04 and 0.85 ± 0.18 g/cm³), a satisfactory electromechanical response at 250 V/m (17.85 ± 2.58 and 61.48 ± 6.97), low shrinkage percentages (59.95 ± 3.59 and 54.17 ± 9.28), high dielectric constant (1.80 ± 0.07 and 8.10 ± 0.73), and superior UV absorption compared with pure bio-chitosan films, without and with gelatin (Formulas 1 and 6). Full article

Two-dimensional (2D) materials are regarded as key foundational materials for next-generation optoelectronic devices. As a promising new type of 2D layered semiconductor, Bi₂O₂Se has emerged as a strong candidate for high-performance opto-electronic devices due to its high carrier mobility, tunable bandgap, and excellent environmental stability. However, achieving precise control over Bi₂O₂Se growth to obtain high-quality Bi₂O₂Se remains a challenge in the field. In this study, we employed chemical vapor deposition (CVD) to grow thin-layer 2D Bi₂O₂Se flakes. We further used a transport model and thermodynamic Arrhenius fitting to analyze the relationship between vapor flux and the properties of the flakes. Density functional theory was used to study the electronic structure of the as-grown samples. The electrical and optoelectronic results demonstrate that Bi₂O₂Se-based FETs exhibit good performance in terms of mobility (129 cm²V⁻¹s⁻¹), on/off ratio (4.51 × 10⁵), and photoresponsivity (94.98 AW⁻¹). This work provides a new way to study the influence of vapor flux on the sizes and shapes of Bi₂O₂Se flakes for photodetectors. Full article

This study details the manufacture of vanadium-doped ZnS thin films via a cost-effective spray pyrolysis technique at varying concentrations of vanadium (4, 8, and 12 wt.%). The XRD data demonstrate the hexagonal structure of the vanadium-doped ZnS layers. The analysis of their structural properties indicates that the crystallite size (D) of the vanadium-doped ZnS films decreased as the vanadium concentration rose. The strain and dislocation density of the analyzed films were enhanced by increasing the vanadium content from 4 to 12 wt.%. The linear optical results of the vanadium-doped ZnS films revealed that the refractive index values were improved from 2.31 to 3.49 by increasing the vanadium concentration in the analyzed samples. Further, the rise in vanadium content enhanced the absorption coefficient. The energy gap (Eg) study indicates that the vanadium-doped ZnS films exhibited direct optical transitions, with the Eg values diminishing from 3.74 to 3.15 eV as the vanadium concentration increased. The optoelectrical analysis shows that the rise in vanadium concentration increases the dispersion energy from 9.48 to 12.76 eV and reduces the oscillator energy from 3.69 to 2.17 eV. The optical carrier concentration of these layers was improved from 1.49 × 1053 to 2.15 × 1053, while the plasma frequency was decreased from 4.34 × 1013 to 3.67 × 1013 by boosting the vanadium concentration from 4 to 12 wt.%. Simultaneously, the increase in vanadium content improves the nonlinear optical parameters of the vanadium-doped ZnS films. The hot probe method identifies these samples as n-type semiconductors. The findings suggest that these samples serve as an innovative window layer. Full article

Carbon-based nanomaterials with excellent electrical and optical properties are highly sought after for a plethora of hybrid applications, ranging from advanced sustainable energy storage devices to opto-electronic components. In this contribution, we examine in detail the dependence of electrical conductivity and the ultrafast optical nonlinearity of graphene oxide (GO) films on their degrees of reduction, as well as the link between the two properties. The GO films were first synthesized through the vacuum filtration method and then reduced partially and controllably by way of femtosecond laser direct writing with varying power doses. Subsequently, the four-point probe measurements of the reduced-GO (r-GO) films were demonstrated to exhibit superior resistivity and electrical conductivity compared with the pristine-GO counterpart. It was found that the conductivity of the film increases and then decreases with increasing ablation laser power (P), and GO was completely reduced at P = 100 mW, with a resistivity and electrical conductivity of 1.09 × 10⁻³ Ω·m and 9.19 × 10² S/m, respectively. GO was over-reduced at P = 120 mW, with its resistivity and electrical conductivity being 3.72 × 10⁻³ Ω·m and 2.69 × 10² S/m, respectively. We further tested the ultrafast optical nonlinearity (ONL) of the as-prepared pristine and reduced GO with the femtosecond Z-scan technique. The results show that the behavior of ONL is reversed whenever GO is reduced in a controlled manner. More interestingly, the higher the ablation laser power is, the stronger the optical nonlinearity of r-GO is. In particular, the nonlinear absorption and refraction coefficients of the r-GO films reach up to 3.26 × 10⁻⁸ m/W and −1.12 × 10⁻¹³ m²/W when P = 120 mW. The nonlinear absorption and refraction coefficients reach 1.9 × 10⁻⁸ m/W and −3 × 10⁻¹³ m²/W, respectively, for P = 70 mW. GO/r-GO thin films with tunable photovoltaic response properties have potential for a wide range of applications in microelectronic circuits, energy, and environmental sustainability. Full article

Silver nanowire transparent conductive films (AgNW TCFs), as the novel transparent electrode materials replacing ITO, are anticipated to be applied in numerous optoelectronic devices, and slot-die coating is currently acknowledged as the most suitable method for the mass production of large-sized AgNW TCFs. In this study, sodium carboxymethyl cellulose (CMC) and polyvinyl alcohol (PVA), as film-forming aids, and AgNWs, as conductive materials, were utilized to prepare a specialized AgNW ink, and a slot-die coating is employed to print and prepare AgNW TCFs. The optoelectrical properties of AgNW TCFs are optimized by adjusting the compositions of AgNW ink and the process parameters of slot-die coating. The suitable compositions of AgNW ink and the optimal parameters of slot-die coating are a CMC type of V, a PVA volume of 1 mL, a AgNW volume of 1.5 mL, a volume ratio of 30 and 45 nm AgNWs (2:1), and a coating height of 400 μm. The resultant AgNW TCFs achieve excellent comprehensive optoelectronic performance, with a sheet resistance of less than 50 Ω/sq, a visible light transmittance exceeding 92%, and a haze below 1.8%. This research provides a valuable approach to producing AgNW TCFs on a large scale via the slot-die coating. Full article

Thermal camouflage is a highly coveted technology aimed at enhancing the survivability of military equipment against infrared (IR) detectors. Recently, two-dimensional (2D) nanomaterials have shown low IR emissivity, widely tunable opto-electronic properties, and compatibility with stealth applications. Among these, graphene and graphene-like materials are the most appealing 2D materials for thermal camouflage applications. In multilayer graphene (MLG), charge density can be effectively tuned through sufficiently intense electric fields or through electrolytic gating. Therefore, MLG’s optical properties, like infrared emissivity and absorbance, can be controlled in a wide range by voltage bias. The large emissivity modulation achievable with this material makes it suitable in the design of thermal dynamic camouflage devices. Generally, the emissivity modulation in the multilayered graphene medium is governed by an intercalation process of non-volatile ionic liquids under a voltage bias. The electrically driven reduction of emissivity lowers the apparent temperature of a surface, aligning it with the background temperature to achieve thermal camouflage. This characteristic is shared by other graphene-based materials. In this review, we focus on recent advancements in the thermal camouflage properties of graphene in composite films and aerogel structures. We provide a summary of the current understanding of how thermal camouflage materials work, their present limitations, and future opportunities for development. Full article

In this work, we report on the fabrication of ZnO thin films doped with Ge via the ALD method. With an optimized amount of Ge doping, there was an improvement in the conductivity of the films owing to an increase in the carrier concentration. The optical properties of the films doped with Ge show improved transmittance and reduced reflectance, making them more attractive for opto-electronic applications. The band gap of the films exhibits a blue shift with Ge doping due to the Burstein–Moss effect. The variations in the band gap and the work function of ZnO depend strongly on the carrier density of the films. From the surface studies carried out using XPS, we could confirm that Ge replaces some of the Zn in the wurtzite structure. In the films containing Ge, the concentration of oxygen vacancies is also high, which is somehow related to the poor electrical properties of the films at higher Ge concentrations. Full article

High-performance photovoltaic devices require active photoanodes with superior optoelectric properties. In this study, we synthesized neodymium ruthenate, Nd₂Ru₂O₇ (NRO), and gadolinium ruthenate pyrochlore oxides, Gd₂Ru₂O₇ (GRO), via the solid-state reaction technique, showcasing their potential as promising candidates for photoanode absorbers to enhance the efficiency of dye-sensitized solar cells. A structural analysis revealed predominantly cubic symmetry phases for both materials within the Fd-3m space group, along with residual orthorhombic symmetry phases (Nd₃RuO₇ and Gd₃RuO₇, respectively) refined in the Pnma space group. Raman spectroscopy further confirmed these phases, identifying distinct active modes of vibration in the predominant pyrochlore oxides. Additionally, a scanning electron microscopy (SEM) analysis coupled with energy-dispersive X-ray spectroscopy (EDX) elucidated the morphology and chemical composition of the compounds. The average grain size was determined to be approximately 0.5 µm for GRO and 1 µm for NRO. Electrical characterization via I-V measurements revealed that these pyrochlore oxides exhibit n-type semiconductor behavior, with conductivity estimated at 1.5 (Ohm·cm)⁻¹ for GRO and 4.5 (Ohm·cm)⁻¹ for NRO. Collectively, these findings position these metallic oxides as promising absorber materials for solar panels. Full article

Oxygen vacancies (V_o) can significantly degrade the electrical properties of indium oxide (In₂O₃) thin films, thus limiting their application in the field of ultraviolet detection. In this work, the V_o is effectively suppressed by adjusting the Trimethylindium (TMIn) flow rate (f_TMIn). In addition, with the reduction of the f_TMIn, the background carrier concentration and the roughness of the film decrease gradually. And a smooth In₂O₃ thin film with roughness of 0.44 nm is obtained when the f_TMIn is 5 sccm. The MSM photodetectors (PDs) are constructed based on In₂O₃ thin films with different f_TMIn to investigate the opto-electric characteristics of the films. The dark current of the PDs is significantly reduced by five orders from 100 mA to 0.28 μA with the reduction of the f_TMIn from 50 sccm to 5 sccm. In addition, the photo response capacity of PDs is dramatically enhanced. The photo-to-dark current ratio (PDCR) increases from 0 to 2589. Finally, the PD with the f_TMIn of 5 sccm possesses a record-high responsivity of 2.53 × 10³ AW⁻¹, a high detectivity of 5.43 × 10⁷ Jones and a high EQE of 9383 × 100%. Our work provides an important reference for the fabrication of high-sensitivity UV PDs. Full article

The present work is on the synthesis and investigation of the structural, optical, and optoelectrical properties of NbSe₂ as an efficient material for energy conversion applications. The liquid phase exfoliation method was employed for the synthesis of 2D nanosheets from the bulk NbSe₂ at different exfoliation levels. SEM was used to confirm the physical dimensions of the nanosheets, while XRD was used to verify the structural retention of hexagonal nanosheets. The results demonstrate that high-quality, single-crystalline NbSe₂ nanosheets with a size of ≈1 μm in the lateral dimension and ≈6–12 nm thick were obtained. The 2D nanosheets will be further explored for energy storage and conversion applications. Full article

In this work, a nanocomposite consisting of ternary chalcogenide CuInS₂ and TiO₂ was prepared and its optical and optoelectrical properties were investigated. The CuInS₂/TiO₂ nanocomposite was produced via one-step mechanochemical synthesis and characterized from the crystal structure, microstructural, morphology, surface, optical, and optoelectrical properties viewpoints. X-ray diffraction confirmed the presence of both components, CuInS₂ and TiO₂, in the nanocomposite and revealed a partial transformation of anatase to rutile. The presence of both components in the samples was also proven by Raman spectroscopy. HRTEM confirmed the nanocrystalline character of the samples as crystallites ranging from around 10 nm and up to a few tens of nanometers were found. The presence of the agglomerated nanoparticles into larger grains was proven by SEM. The measured optical properties of CuInS₂, TiO₂, and CuInS₂/TiO₂ nanocomposites demonstrate optical bandgaps of ~1.62 eV for CuInS₂ and 3.26 eV for TiO₂. The measurement of the optoelectrical properties showed that the presence of TiO₂ in the CuInS₂/TiO₂ nanocomposite increased its conductivity and modified the photosensitivity depending on the ratio of the components. This study has demonstrated the possibility of preparing a CuInS₂/TiO₂ nanocomposite material with promising applications in optoelectronics in the visible region in an eco-friendly manner. Full article

The impact of N₂ purging in the CdS deposition bath and subsequent N₂ annealing is examined and contrasted with conventional CdS films, which were deposited without purging and annealed in ambient air. All films were fabricated using the chemical bath deposition method at a temperature of 80 °C on fluorine-doped tin oxide glass slides (FTO). N₂ purged films were deposited by introducing nitrogen gas into the deposition bath throughout the CdS deposition process. Subsequently, both N₂ purged and un-purged films underwent annealing at temperatures ranging from 100 to 500 °C for one hour, either in a nitrogen or ambient air environment. Photoelectrochemical (PEC) cell studies reveal that films subjected to both N₂ purging and N₂ annealing exhibit a notable enhancement of 37.5% and 27% in I_SC (short-circuit current) and V_OC (open-circuit voltage) values, accompanied by a 5% improvement in optical transmittance compared to conventional CdS thin films. The films annealed at 300 °C demonstrate the highest I_SC, V_OC, and V_FB values, 55 μA, 0.475 V, and −675 mV, respectively. The improved optoelectrical properties in both N₂-purged and N₂-annealed films are attributed to their well-packed structure, enhanced interconnectivity, and a higher sulfur to cadmium ratio of 0.76 in the films. Full article

In recent years, transparent conducting oxide semiconductor materials have found applications in both science and technology, especially in the areas of semiconductors, optoelectronics, and a wide range of energy efficiency devices. These TCO materials are the building blocks of various optoelectronic devices, such as transparent thin-film transistors, solar cells, and light-emitting diodes. This work concentrates on the structure, morphology, and optical properties of ZnO and Zn_0.95La_0.05O thin films at 673 K using a chemical spray technique. The polycrystalline nature and wurtzite structure of ZnO were confirmed by using XRD analysis with preferred growth along the (1 0 1) plane. The Zn_0.95La_0.05O deposits showed maximum crystallinity of 15.4 nm and a strain value of 2.4 × 10⁻³. The lattice constants increased for lanthanum-doped ZnO thin films due to the ionic radii mismatch of the doping material, which causes lattice expansion. Fibrous morphology was observed for ZnO, and a mixed structure of grains and fibers was observed for Zn_0.95La_0.05O films, which confirms the insertion of La³⁺ into the Zn²⁺ position. The Zn_0.95La_0.05O deposits showed transmittance above 80% due to the increased crystalline quality and a bandgap of 3.32 eV. The photoluminescence spectra showed peaks corresponding to e-h recombination, zinc defects (Zn_i and O_zn), and oxygen vacancy (O_i and V_o). The lanthanum-doped ZnO films showed increased band-edge emission and decreased defect-related peaks due to the increased crystalline quality. Hence, the doping of La³⁺ ions into a ZnO lattice enhances the crystalline quality and increases the transparency of the host ZnO matrix, which is suitable for optoelectric device applications. Full article

Hafnia-based nanostructures and other high-k dielectrics are promising wide-gap materials for developing new opto- and nanoelectronic devices. They possess a unique combination of physical and chemical properties, such as insensitivity to electrical and optical degradation, radiation damage stability, a high specific surface area, and an increased concentration of the appropriate active electron-hole centers. The present paper aims to investigate the structural, optical, and luminescent properties of anodized non-stoichiometric HfO₂ nanotubes. As-grown amorphous hafnia nanotubes and nanotubes annealed at 700 °C with a monoclinic crystal lattice served as samples. It has been shown that the bandgap E_g for direct allowed transitions amounts to 5.65 ± 0.05 eV for amorphous and 5.51 ± 0.05 eV for monoclinic nanotubes. For the first time, we have studied the features of intrinsic cathodoluminescence and photoluminescence in the obtained nanotubular HfO₂ structures with an atomic deficiency in the anion sublattice at temperatures of 10 and 300 K. A broad emission band with a maximum of 2.3–2.4 eV has been revealed. We have also conducted an analysis of the kinetic dependencies of the observed photoluminescence for synthesized HfO₂ samples in the millisecond range at room temperature. It showed that there are several types of optically active capture and emission centers based on vacancy states in the O_3f and O_4f positions with different coordination numbers and a varied number of localized charge carriers (V⁰, V⁻, and V²⁻). The uncovered regularities can be used to optimize the functional characteristics of developed-surface luminescent media based on nanotubular and nanoporous modifications of hafnia. Full article
