Search Results (344)

In laser wireless power transmission systems, the powersphere serves as a spherical enclosed receiver that performs photoelectric conversion, achieving uniform light distribution within the cavity through infinite internal light reflection. However, in practical applications, the high level of light absorption displayed by photovoltaic cells leads to significant disparities in light intensity between directly irradiated regions and reflected regions on the inner surface of the powersphere, resulting in poor light uniformity. One approach aimed at addressing this issue uses a spectroscope to split the incident beam into multiple paths, allowing the direct illumination of all inner surfaces of the powersphere and reducing the light intensity difference between direct and reflected regions. However, experimental results indicate that light transmission through lenses introduces power losses, leading to improved uniformity but reduced output power. To address this limitation, this study proposes a method that utilizes multiple incident laser beams combined with a centrally positioned spherical reflector within the powersphere. A wireless power transmission system model was developed using optical simulation software, and the uniformity of the intracavity light field in the system was analyzed through simulation. To validate the design and simulation accuracy, an experimental system incorporating semiconductor lasers, spherical mirrors, and a powersphere was constructed. The data from the experiments aligned with the simulation results, jointly confirming that integrating a spherical reflector and distributed incident lasers enhances the uniformity of the internal light field within the powersphere and improves the system’s efficiency. Full article

A bias-free antenna tuning technique that eliminates conventional DC biasing networks is presented. The tuning mechanism is based on a Light-Dependent Resistor (LDR) embedded within the antenna structure. Optical illumination is used to modulate the LDR’s resistance, thereby altering the antenna’s effective electrical length and enabling tuning of its resonant frequency and operating bands. By removing the need for bias lines, RF chokes, blocking capacitors, and control circuitry, the proposed approach minimizes parasitic effects, losses, biasing energy, and routing complexity. This makes it particularly suitable for compact and energy-constrained platforms, such as Internet of Things (IoT) devices. As proof of concept, an LDR is integrated into a ring monopole antenna, achieving tri-band operation in both high and low resistance states. In the high-resistance (OFF) state, the fabricated prototype operates across 2.1–3.1 GHz, 3.5–4 GHz, and 5–7 GHz. In the low-resistance (ON) state, the LDR bridges the two arcs of the monopole, extending the current path and shifting the lowest band to 1.36–2.35 GHz, with only minor changes to the mid and upper bands. The antenna maintains linear polarization across all bands and switching states, with measured gains reaching up to 5.3 dBi. Owing to its compact, bias-free, and low-cost architecture, the proposed design is well-suited for integration into portable wireless devices, low-power IoT nodes, and rapidly deployable communications systems where electrical biasing is impractical. Full article

In recent years, with the continuous advancement of technology and the expansion of application scenarios, AR has become a highly regarded field. However, AR still faces several challenges in practical usage. Notable shortcomings include inadequate image uniformity, low diffraction efficiency. Among these, the insufficient image uniformity stands out as a significant issue directly affecting user experience. The analysis of uniformity improvement in this study is limited to the simulated scenario of monochromatic blue light (LED light source), aiming to optimize the insufficient uniformity of the image output of the diffractive optical waveguide-based AR technology scheme. We improve the details of the input grating in the waveguide, such as the morphological characteristics of the grating, the detail parameter, etc. In addition, we propose to incorporate a photonic crystal film in the waveguide as an innovative study and find that the incorporation of the photonic crystal thin film significantly improves the uniformity of the output image in the diffractive optical waveguide scheme. In order to further verify the effect of the photonic crystal film on the uniformity of its image output, we also compare different types of coupled gratings and find that they all have a positive effect. Thus, the photonic crystal film demonstrated effective control over the diffraction optical waveguide scheme. This research offers new insights and design approaches for enhancing the output image uniformity based on diffraction optical waveguide technology, providing a new path for improving image uniformity in AR displays. Full article

A solar-pumped Ce:Nd:YAG laser amplifier design is proposed to address the challenge of scaling output power in solar-pumped laser oscillators while maintaining high beam quality. The design employs a 1.33 m² flat Fresnel lens with a 2 m focal length as a primary concentrator, which is combined with a secondary homogenizing concentrator, featuring 40 mm × 40 mm input aperture, 200 mm length, and 11.3 mm × 26 mm output aperture, to provide efficient coupling and uniform distribution of solar radiation onto a 2.9 mm thick Ce:Nd:YAG slab with 11.3 mm × 26 mm surface area and two beveled corners. This geometry enables multiple total internal reflections of a 1064 nm TEM₀₀ mode seed laser beam inside the slab, ensuring efficient interaction with the active Ce³⁺ and Nd³⁺ ions in the gain medium. Performed numerical analysis shows that the present approach can deliver a uniform solar pump power density of 2.5 W/mm² to the slab amplifier. This value is 2.05-times higher than the numerically calculated power density incident on the Nd:YAG slab of the previous solar-pumped amplifier that achieved the highest continuous-wave laser gain of 1.64. Furthermore, the optimized slab geometry with 0.44 width-to-height ratio allows the seed laser to undergo 32 internal reflections, extending its optical path length by a factor of 1.45 compared to the earlier design. These numerical achievements, combined with the Ce:Nd:YAG medium’s capacity to deliver nearly 1.57-times more laser power than Nd:YAG, reveal the potential of proposed design to yield a gain enhancement factor of 4.16, making the first solar-pumped Ce:Nd:YAG amplifier a promising solution toward energy-efficient, sustainable solutions for terrestrial and space applications. Full article

Multimode VCSELs coupled into waveguides can be a practical path toward realizing commercially viable photonic interposer chips. The experimental coupling of multimode VCSEL light to a non-silicon waveguide fabricated using a CMOS-compatible process is demonstrated. The GaP prism was tested and adopted as a coupling method. Both conventional and cavity-type optical waveguides, fabricated from CMOS-compatible PECVD SiO₂, Si₃N₄, and SiO_xN_y materials, were evaluated. The average propagation loss transmitted through the cavity-type waveguide was measured as 0.444 dB/cm. A polyimide micro-lens, cavity-type waveguide, and a GaP prism coupler are developed to inject the multimode VCSEL light into the waveguide measuring the net coupling loss of 0.762 dB. The packaged size of VCSEL has an area of 0.4 mm² and a height of 0.64 mm. MUX/DeMUX was designed on the bottom of the prism. A light source, a modulator, and MUX/DeMUX are all located in the same area of the prism bottom in VCSEL-based interconnections. Full article

Optical phase modulation is essential for a wide range of silicon photonic integrated circuits used in communication applications. In this study, an optical phase shifter utilizing photo-elastic effects is proposed, where mechanical stress is induced by electrostatic micro-electro-mechanical systems (MEMS) with actuators arranged in a comb drive configuration. The design incorporates suspended serpentine silicon nitride (SiN) optical waveguides. Through extensive numerical simulations, it is shown that the change in the effective refractive index (n_eff) of the optical waveguide is a function of the voltage applied to the electrostatic actuators and that such n_eff tuning can be achieved for a broad range of wavelengths. Implemented within one arm of an unbalanced Mach–Zehnder interferometer (MZI), the phase shifter achieves a phase change of π when the stressed optical path measures 4.7 mm, and the actuators are supplied with 80 V DC and consume almost no power. This results in a half-wave voltage-length product (V_πL) of 37.6 V·cm. Comparative analysis with contemporary optical phase shifters highlights the proposed design’s superior power efficiency, compact footprint, and simplified fabrication process, making it a highly efficient component for reconfigurable MEMS-based silicon nitride photonic integrated circuits. Full article

Mueller matrix polarimetry is recently attracting more and more attention for its diagnostic potentials. However, for prevalently used division of time Mueller matrix polarimeter based on dual-rotating retarder scheme, beam drift induced by rotating polarizers and waveplates introduces spatial misalignment and pseudo-edge artifacts in imaging results, hindering following accurate microstructural features characterization. In this paper, we quantitatively analyze the beam drift phenomenon in dual-rotating retarder Mueller matrix microscopy and its impact on linear retardance measurement, which is frequently used to reflect tissue fiber arrangement. It is demonstrated that polarizer rotation induces larger beam drift than waveplate rotation due to surface non-uniformity and stress deformation. Furthermore, for waveplates rotated constantly in dual-rotating retarder scheme, their tilt within polarization state analyzer can result in more drift and throughput loss than those within polarization state generator. Finally, phantom and tissue experiments confirm that beam drift, rather than inherent optical path changes, dominates the systematic overestimation of linear retardance in boundary image regions. The findings highlight beam drift as a dominant error source for quantifying linear retardance, necessitating careful optical design alignment and a reliable registration algorithm to obtain highly accurate polarization data for training machine learning models of pathological diagnosis using Mueller matrix microscopy. Full article

As an important traffic and transportation roadway, tunnel engineering is widely used in important fields such as highways, railways, water conservancy, subways and mining. It is limited by complex geological conditions, harsh construction environments and poor robustness of the monitoring system. If the construction process and monitoring method are not properly designed, it will often directly induce disasters such as tunnel deformation, collapse, leakage and rockburst. This seriously threatens the safety of tunnel construction and operation and the protection of the regional ecological environment. Therefore, based on distributed fiber optic sensing technology, the full–cycle spatiotemporally continuous sensing information of the tunnel structure is obtained in real time. Accordingly, the health status of the tunnel is dynamically grasped, which is of great significance to ensure the intrinsic safety of the whole life cycle for the tunnel project. Firstly, this manuscript systematically sorts out the development and evolution process of the theory and technology of structural health monitoring in tunnel engineering. The scope of application, advantages and disadvantages of mainstream tunnel engineering monitoring equipment and main optical fiber technology are compared and analyzed from the two dimensions of equipment and technology. This provides a new path for clarifying the key points and difficulties of tunnel engineering monitoring. Secondly, the mechanism of action of four typical optical fiber sensing technologies and their application in tunnel engineering are introduced in detail. On this basis, a spatiotemporal continuous perception method for tunnel engineering based on DFOS is proposed. It provides new ideas for safety monitoring and early warning of tunnel engineering structures throughout the life cycle. Finally, a high–speed rail tunnel in northern China is used as the research object to carry out tunnel structure health monitoring. The dynamic changes in the average strain of the tunnel section measurement points during the pouring and curing period and the backfilling period are compared. The force deformation characteristics of different positions of tunnels in different periods have been mastered. Accordingly, scientific guidance is provided for the dynamic adjustment of tunnel engineering construction plans and disaster emergency prevention and control. At the same time, in view of the development and upgrading of new sensors, large models and support processes, an innovative tunnel engineering monitoring method integrating “acoustic, optical and electromagnetic” model is proposed, combining with various machine learning algorithms to train the long–term monitoring data of tunnel engineering. Based on this, a risk assessment model for potential hazards in tunnel engineering is developed. Thus, the potential and disaster effects of future disasters in tunnel engineering are predicted, and the level of disaster prevention, mitigation and relief of tunnel engineering is continuously improved. Full article

This paper is a result of the search for design assumptions for a sensor to detect oil dispersed in the sea waters (oil-in-water emulsions). Our approach is based on analyzing changes in the underwater solar radiance (L) field caused by the presence of oil droplets in the water column. This method would enable the sensor to respond to the presence of oil contaminants dispersed in the surrounding environment, even if they are not located directly at the measurement point. This study draws on both literature sources and the results of current numerical modeling of the spread of solar light in the water column to account for both downward and upward irradiance (Es). The core principle of the analysis involves simulating the paths of a large number of virtual solar photons in a seawater model defined by spatially distributed Inherent Optical Properties (IOPs). The IOPs data were taken from the literature and pertain to the waters of the southern Baltic Sea. The optical properties of the oil used in the model correspond to crude oil extracted from the Baltic shelf. The obtained results were compared with previously published spectral analyses of an analogous polluted sea model, considering vertical downward radiance, vertical upward radiance, and downward and upward irradiance. It was found that the optimal wavelength ratio of 555/412, identified for these quantities, is also applicable to scalar irradiance. The findings indicate that the most effective way to determine this index is by measuring it using a sensor with its window oriented in the direction of upward-traveling light. Full article

Limited depth of field in modern optical imaging systems often results in partially focused images. Multi-focus image fusion (MFF) addresses this by synthesizing an all-in-focus image from multiple source images captured at different focal planes. While deep learning-based MFF methods have shown promising results, existing approaches face significant challenges. Convolutional Neural Networks (CNNs) often struggle to capture long-range dependencies effectively, while Transformer and Mamba-based architectures, despite their strengths, suffer from high computational costs and rigid input size constraints, frequently necessitating patch-wise fusion during inference—a compromise that undermines the realization of a true global receptive field. To overcome these limitations, we propose MLP-MFF, a novel lightweight, end-to-end MFF network built upon the Pyramid Fusion Multi-Layer Perceptron (PFMLP) architecture. MLP-MFF is specifically designed to handle flexible input scales, efficiently learn multi-scale feature representations, and capture critical long-range dependencies. Furthermore, we introduce a Dual-Path Adaptive Multi-scale Feature-Fusion Module based on Hybrid Attention (DAMFFM-HA), which adaptively integrates hybrid attention mechanisms and allocates weights to optimally fuse multi-scale features, thereby significantly enhancing fusion performance. Extensive experiments on public multi-focus image datasets demonstrate that our proposed MLP-MFF achieves competitive, and often superior, fusion quality compared to current state-of-the-art MFF methods, all while maintaining a lightweight and efficient architecture. Full article

Curved prisms can serve as core components of dispersive spectroscopy and converge light paths, making them widely used in spectral imaging technology. Their positional stability, surface shape errors, and temperature stability in optical systems directly affect the performance of spectral imaging systems. On the basis of the analysis of design indicators and optimization of the support structure for curved prisms, a multipoint flexible adhesive support structure (MPPASS) of large rectangular curved prisms for space-based application is proposed. The novelty of the MPPASS lies in its ability to achieve micro-stress and high stability support for large-aperture rectangular optical elements through the bonding of peripheral small points and the introduction of flexible bonding rings. The design principles of the adhesive support structure were deeply studied, and on this basis, the engineering design, finite element analysis, adhesive testing, and mechanical testing of large curved prisms were completed. The designed curved prism assembly has a maximum deformation displacement of 0.0085 mm and a maximum tilt angle of 0.65” under gravity loading, a first-order frequency of 1003.5 Hz, and a maximum acceleration amplification factor of 3.12 in the X, Y, and Z directions. The root mean square (RMS) variation value of the mirror shape errors for the curved prism assembly was 5.26 nm under a uniform temperature load of 20 ± 1 °C, and the RMS value of the mirror shape errors was 0.019 λ after mechanical testing. The installation surface flatness of 0.02 mm did not significantly affect its mirror shape errors. The experimental results verified the rationality of the design, temperature stability, and mechanical stability of the MPPASS. Full article

Recently, diffractive optics systems have garnered increasing attention due to their myriad benefits in various applications, such as creating vortex beams, Bessel beams, or optical traps, while refractive optics systems still exhibit some disadvantages related to materials, substrates, and intensity shapes. The manufacturing of diffractive optical elements has become easier due to the development of lithography techniques such as direct laser writing, photo lithography, and electron beam lithography. In this paper, we improve the results from previous research and propose a new methodology to design and fabricate advanced binary diffractive optical elements that achieve a square focal spot independently, reducing reliance on additional components. By integrating a binary square zone plate with an axicon zone plate of the same scale, we employ machine learning for laser path optimization and direct laser lithography for manufacturing. This streamlined approach enhances simplicity, accuracy, efficiency, and cost effectiveness. Our upgraded binary diffractive optical elements are ready for real-world applications, marking a significant improvement in optical capabilities. Full article

To improve the efficiency and stability of the system, this paper proposes a monolithic integrated optical path design for a cavity optomechanical accelerometer based on a 250 nm top silicon thickness silicon-on-insulator (SOI) wafer instead of readout through U-shape fiber coupling. Finite Element Analysis (FEA) and Finite-Difference Time-Domain (FDTD) methods are employed to systematically investigate the performance of key optical structures, including the resonant modes and bandgap characteristics of photonic crystal (PhC) microcavities, transmission loss of strip waveguides, coupling efficiency of tapered-lensed fiber-to-waveguide end-faces, coupling characteristics between strip waveguides and PhC waveguides, and the coupling mechanism between PhC waveguides and microcavities. Simulation results demonstrate that the designed PhC microcavity achieves a quality factor (Q-factor) of 2.26 × 10⁵ at a 1550 nm wavelength while the optimized strip waveguide exhibits a low loss of merely 0.2 dB over a 5000 μm transmission length. The strip waveguide to PhC waveguide coupling achieves 92% transmittance at the resonant frequency, corresponding to a loss below 0.4 dB. The optimized edge coupling structure exhibits a transmittance of 75.8% (loss < 1.2 dB), with a 30 μm coupling length scheme (60% transmittance, ~2.2 dB loss) ultimately selected based on process feasibility trade-offs. The total optical path system loss (input to output) is 5.4 dB. The paper confirms that the PhC waveguide–microcavity evanescent coupling method can effectively excite the target cavity mode, ensuring optomechanical coupling efficiency for the accelerometer. This research provides theoretical foundations and design guidelines for the fabrication of high-precision monolithic integrated cavity optomechanical accelerometers. Full article

Driven by the rapid development of e-commerce and intelligent logistics, the volume of express delivery services has surged, making the efficient and accurate identification of shipping information a core requirement for automatic sorting systems. However, traditional Optical Character Recognition (OCR) technology struggles to meet the accuracy and real-time demands of complex logistics scenarios due to challenges such as image distortion, uneven illumination, and field overlap. This paper proposes a three-level collaborative recognition method based on deep learning that facilitates structured information extraction through regional normalization, dual-path parallel extraction, and a dynamic matching mechanism. First, the geometric distortion associated with contour detection and the lightweight direction classification model has been improved. Second, by integrating the enhanced YOLOv5s for key area localization with the upgraded PaddleOCR for full-text character extraction, a dual-path parallel architecture for positioning and recognition has been constructed. Finally, a dynamic space–semantic joint matching module has been designed that incorporates anti-offset IoU metrics and hierarchical semantic regularization constraints, thereby enhancing matching robustness through density-adaptive weight adjustment. Experimental results indicate that the accuracy of this method on a self-constructed dataset is 89.5%, with an F1 score of 90.1%, representing a 24.2% improvement over traditional OCR methods. The dynamic matching mechanism elevates the average accuracy of YOLOv5s from 78.5% to 89.7%, surpassing the Faster R-CNN benchmark model while maintaining a real-time processing efficiency of 76 FPS. This study offers a lightweight and highly robust solution for the efficient extraction of order information in complex logistics scenarios, significantly advancing the intelligent upgrading of sorting systems. Full article

To enable accurate evaluation of satellite laser communication terminals under solar outage interference, this paper presents the design and implementation of a solar radiation simulation system targeting the 1540–1560 nm communication band. The system reconstructs co-propagating interference conditions through standardized and continuously tunable output, based on high irradiance and spectral uniformity. A compound beam homogenization structure—combining a multimode fiber and an apodizator—achieves 85.8% far-field uniformity over a 200 mm aperture. A power–spectrum co-optimization strategy is introduced for filter design, achieving a spectral matching degree of 78%. The system supports a tunable output from 2.5 to 130 mW with a 50× dynamic range and maintains power control accuracy within ±0.9%. To suppress internal background interference, a BRDF-based optical scattering model is established to trace primary and secondary stray light paths. Simulation results show that by maintaining the surface roughness of key mirrors below 2 nm and incorporating a U-shaped reflective light trap, stray light levels can be reduced to 5.13 × 10⁻¹² W, ensuring stable detection of a 10⁻¹⁰ W signal at a 10:1 signal-to-background ratio. Experimental validation confirms that the system can faithfully reproduce solar outage conditions within a ±3° field of view, achieving consistent performance in spectrum shaping, irradiance uniformity, and background suppression. The proposed platform provides a standardized and practical testbed for ground-based anti-interference assessment of optical communication terminals. Full article
