Search Results (54)

Chirped radio-frequency signals are essential waveforms in radar systems. To enhance resolution and improve the signal-to-noise ratio through higher energy transmission, chirps with high time–bandwidth products are highly desirable. Photonic technologies, with their ability to handle broad electrical bandwidths, have been widely employed in the generation, filtering, processing, and detection of broadband electrical waveforms. In this work, we propose a photonics-based large-TBWP RF chirp generator utilizing dual optical frequency combs with a small difference in the repetition rate. By employing dispersion modules for frequency-to-time mapping, we convert the spectral interferometric patterns into a temporal RF sinusoidal carrier signal whose frequency is swept through the optical shot-to-shot delay. We derive analytical expressions to quantify the system’s performance under various design parameters, including the comb repetition rate and its offset, the second-order dispersion, the transform-limited optical pulse width, and the photodetector’s bandwidth limitations. We benchmark the expected system performance in terms of RF bandwidth, chirp duration, chirp rate, frequency step size, and TBWP. Using realistic dual-comb source parameters, we demonstrate the feasibility of generating RF chirps with a duration of 284.44 $\mathsf{\mu }$s and a bandwidth of 234.05 GHz, corresponding to a TBWP of $3.3\times {10}^7$. Full article

A novel photonics-assisted technique for generating reconfigurable frequency hopping (FH) signals is proposed and demonstrated through optical comb filtering (OCF). The arithmetic progression of frequency difference between OCF passbands and optical frequency comb lines is exploited to enable wavelength selection controlled by an intermediate frequency signal, with ultra-wideband FH signals subsequently being generated through optical heterodyning. Comprehensive theoretical and numerical investigations are conducted, demonstrating the successful generation of diverse FH waveforms including 5-, 10-, and 25-level stepped frequency signals, Costas-coded patterns, as well as complex wideband signals such as 30 GHz linear frequency modulated and 24 GHz sinusoidal chirped waveforms. Critical system considerations including laser frequency stability, FH speed, and parameter optimization are examined. Wide tunable bandwidth exceeding 30 GHz, good stability, and inherent compatibility with photonic integration is achieved, showing significant potential for advanced applications in cognitive radio and modern radar systems where high-performance frequency-agile signal generation is required. Full article

This work proposes a precise temperature measurement method based on wavelength modulation heterodyne phase-sensitive dispersion spectroscopy (WM-HPSDS). Before the light intensity of the laser was modulated by an electro-optic modulator to generate a three-tone beam, the laser produced additional wavelength modulation by superimposing a high-frequency sinusoidal waveform on a slow sawtooth wave. The second harmonic peak value of the H₂O dispersion phase at 7185.59 cm⁻¹ and 7182.94 cm⁻¹ was used to extract temperature through two-line thermometry. The experiment was carried out on a water-based thermostat and an acoustically excited Bunsen burner. The extracted temperatures of the thermostat agreed well with the reference temperature, and the deviation was within 1.5 °C. The measurement stability of the Bunsen burner flame was approximately 10.4 dB higher than that of direct HPSDS. Furthermore, measuring the peak values under varying laser powers demonstrated that WM-HPSDS was immune to optical power fluctuations. Therefore, this method has potential for measuring temperature in harsh environments. Full article

Coherent anti-Stokes Raman scattering (CARS) is a powerful nonlinear spectroscopic technique widely used in biological imaging, chemical analysis, and combustion and flame diagnostics. The adoption of pulse shapers in CARS has emerged as a useful approach, offering precise control of optical waveforms. By tailoring the phase, amplitude, and polarization of laser pulses, the pulse shaping approach enables selective excitation, spectral resolution improvement, and non-resonant background suppression in CARS. This paper presents a comprehensive review of applying pulse shaping techniques in CARS spectroscopy for biophotonics. There are two different pulse shaping strategies: passive pulse shaping and active pulse shaping. Two passive pulse shaping techniques, hybrid CARS and spectral focusing CARS, are reviewed. Active pulse shaping using a programmable pulse shaper such as spatial light modulator (SLM) is discussed for CARS spectroscopy. Combining active pulse shaping and passive shaping, optimizing CARS with acousto-optic programmable dispersive filters (AOPDFs) is discussed and illustrated with experimental examples conducted in the authors’ laboratory. These results underscore pulse shapers in advancing CARS technology, enabling improved sensitivity, specificity, and broader applications across diverse scientific fields. Full article

A sparse coded mask modeling technique is proposed to increase the transmission capacity of an optical wireless link based on Li-Fi. The learning model for the discrete multitone (DMT) signal waveform is implemented using the proposed technique, which is designed based on a masked auto-encoder. The entire length of the DMT signal waveform, encoded using quadrature phase shift keying (QPSK) or 16-quadrature amplitude modulation (16-QAM) symbols, is divided into equal intervals to generate DMT patches, which are subsequently compressed based on the specified masking ratio. After 1-m optical wireless transmission, the DMT signal waveform is reconstructed from the received DMT patch through a decoding process and then QPSK or 16-QAM symbols are recovered. Using the proposed technique, we demonstrate that we can increase the transmission capacity by up to 1.85 times for a 10 MHz physical bandwidth. Additionally, we verify that the proposed technique is feasible in Li-Fi networks with illumination environments above 240 lux. Full article

This research presents a novel approach to 28 $\mathrm{GHz}$ impulse radio ultra-wideband (IR-UWB) transmission using pulse position modulation (PPM) over an analog radio-over-fiber (ARoF) link, investigating the impact of fiber-based fronthaul on the overall performance of the communication system. In this setup, an arbitrary waveform generator (AWG) is employed for PPM signal generation, while demodulation is performed with a commercial time-to-digital converter (TDC) based on an event timer. To enhance the reliability of transmitted reference PPM (TR-PPM) signals, the transmission system integrates Gray coding and Consultative Committee for Space Data Systems (CCSDS)-standard-compliant Reed-Solomon (RS) error correcting code (ECC). System performance was evaluated by transmitting pseudorandom binary sequences (PRBSs) and measuring the bit error ratio (BER) across a 5-m wireless link between two 20 $\mathrm{d}\mathrm{B}\mathrm{i}$ gain horn (Ka-band) antennas, with and without a 20 $\mathrm{k}\mathrm{m}$ single-mode optical fiber (SMF) link in transmitter side and ECC at the receiver side. The system achieved a BER of less than 8.17 × 10⁻⁷, using a time bin duration of 200 $\mathrm{p}\mathrm{s}$ and a pulse duration of 100 $\mathrm{p}\mathrm{s}$, demonstrating robust performance and significant potential for space-to-ground telecommunication applications. Full article

The measurement system proposed in this paper, based on double intensity modulation, can achieve the detection and recovery of vibration signals. The system uses a Mach–Zehnder modulator to modulate the intensity of the laser light before and after it is reflected from the target, and the modulated optical signal carries the vibration signal information. After photoelectric conversion and data processing, the system measures and recovers the amplitude and frequency of the vibration signal. For sinusoidal signals, amplitudes of $15\mathsf{\mu }$m, $25\mathsf{\mu }$m and $40\mathsf{\mu }$m and frequencies of 100 Hz, 500 Hz and 1000 Hz were measured, and the experimental results demonstrate that the rapid measurement and waveform recovery of such signals can be achieved using our proposed system. Specifically, the absolute deviation in amplitude measurement is less than $0.13\mathsf{\mu }$m, and the relative error does not exceed 0.35%; the absolute deviation in frequency measurement is less than 0.35 Hz, with a relative error below 0.01%; and a refresh rate of up to 4 kHz can be reached. Moreover, an aluminum plate is selected as the target object instead of the reflector in the system, providing a new method for vibration signal detection and expanding the scope of dynamic detection in industrial applications. Full article

Photonic millimeter-wave communication systems are promising for high-capacity, high-speed wireless networks, and their production is driven by the growing demand from data-intensive applications. However, challenges such as inter-symbol interferences (ISIs), inter-band interferences (IBIs), symbol timing offsets (STOs), and nonlinearity impairments exist, especially in non-orthogonal multiband configurations. This paper proposes and demonstrates the neural network-based waveform-to-symbol converter (NNWSC) for a coordinated multi-input and single-output (MISO) photonic millimeter-wave system with multiband multiplexing. The NNWSC replaces conventional matched filtering, down-sampling, and equalization, simplifying the receiver and enhancing interference resilience. Additionally, it reduces computational complexity, improving operational feasibility. As a proof of concept, experiments are conducted in a 16QAM non-orthogonal multiband carrierless amplitude and phase (NM-CAP) modulation system with coordinated MISO configurations in a scenario where two base stations have 5 km and 10 km fiber links, respectively. Data were collected across various roll-off factors, sub-band spacings, and received optical power (ROP) levels. Based on the proposed method, a coordinated MISO photonic millimeter-wave (mmWave) communication system at 91.9 GHz is demonstrated at a transmission speed of 30 Gbps. The results show that the NNWSC-based receiver achieves significant bit error rate (BER) reductions compared to conventional receivers across all configurations. The tolerances to the STO of NNWSC are also studied. These findings highlight NNWSC integration as a promising solution for high-frequency, interference-prone environments, with potential improvements for low-SNR and dynamic STO scenarios. Full article

The three-component accelerometer array has garnered significant attention in seismic wave detection. In this paper, we designed a three-dimensional optical fiber accelerometer based on a circular cross-section cantilever beam and distributed optical fiber strain interrogator. An externally modulated optical frequency domian reflectometry (OFDR) system with centimeter-level spatial resolution is developed to demodulate the dynamic strain on fiber. An algorithm to reconstruct the three-component acceleration from the strain of the optical fiber was derived, and the factors affecting the errors in reconstruction were also investigated. The developed accelerometer exhibits comparable performance to an electrical accelerometer in the experiment. The correlation coefficient between the reconstructed signal waveforms from the two accelerometers exceeded 0.9, and the angular error was less than 8°. The proposed accelerometer is highly compatible with distributed optical fiber sensing technology, presenting significant potential for long-distance array deployment of three-component seismic wave monitoring. Full article

We present a 520 μJ microsecond burst-mode pulse fiber amplifier with a GHz-tunable intra-burst repetition rate and a nearly flat-top pulse envelope. The amplifier architecture comprises a microsecond pulse seed, a high-bandwidth electro-optic modulator (EOM), two pre-amplifier stages, a waveform-compensated acoustic-optic modulator (AOM), and two main amplifier stages. To address amplified spontaneous emission (ASE) and nonlinear effects, a multistage synchronous pumping scheme that achieved a maximum energy output of 520 μJ and has a peak power of 160 W was used. To produce a flat-topped burst pulse envelope, the AOM generates an editable waveform with a leading edge and a high trailing edge to compensate for waveform distortion, resulting in a 5 μs nearly flat-top pulse envelope at maximum energy. The laser provides an adjustable intra-burst pulse repetition rate range of 1–5 GHz through the high-bandwidth EOM modulation. The intra-burst pulse jitter time of the laser remains below 4.31 ps at different frequencies. Moreover, the beam quality of the amplifier is M²x = 1.04 and M²y = 1.1. This amplifier exhibits promising potential and can be further amplified as an optical drive source for high-power, large-bandwidth microwave photon (MWP) radar applications. Meanwhile, it is also potentially applicable as a pulse source for high-speed optical communications, the high-precision processing of special materials, and LIDAR ranging. Full article

To mitigate inter-symbol interference (ISI) caused by Faster-than-Nyquist (FTN) technology in a multiple input multiple output (MIMO) optical wireless communication (OWC) system, we propose an ISI cancellation algorithm that combines multi-head self-attention (MHSA), a one-dimensional convolutional neural network (1D CNN), and bi-directional long short-term memory (Bi-LSTM). This hybrid network extracts data features using 1D CNN and captures sequential information with Bi-LSTM, while incorporating MHSA to comprehensively reduce ISI. We analyze the impact of antenna numbers, acceleration factors, wavelength, and turbulence intensity on the system’s bit error rate (BER) performance. Additionally, we compare the waveform graphs and amplitude–frequency characteristics of FTN signals before and after processing, specifically comparing sampled values of four-pulse-amplitude modulation (4PAM) signals with those obtained after ISI cancellation. The simulation results demonstrate that within the Mazo limit for selecting acceleration factors, our proposal achieves a 7 dB improvement in BER compared to the conventional systems without deep learning (DL)-based ISI cancellation algorithms. Furthermore, compared to systems employing a point-by-point elimination adaptive pre-equalization algorithm, our proposal exhibits comparable BER performance to orthogonal transmission systems while reducing computational complexity by 31.15%. Full article

We propose and demonstrate a photonic-assisted approach for generating arbitrary microwave waveforms based on a dual-polarization dual-parallel Mach–Zehnder modulator, offering significant advantages in terms of tunability of repetition rates and anti-dispersion capability. In order to generate diverse microwave waveforms, two sinusoidal radio frequency signals with distinct frequency relationships are applied to the dual-polarization dual-parallel Mach–Zehnder modulator. By adjusting the power of the applied sinusoidal radio frequency signal, the power ratio between these orthogonal polarized optical sidebands can be changed, and thereby desired radio frequency waveforms can be obtained after photoelectric conversion. In our proof-of-concept experiment, we systematically varied the repetition rate of triangular, rectangular and sawtooth waveforms. Meanwhile, we calculated the Root Mean Square Error (RMSE) to assess the approximation error in each waveform. The RMSEs are 0.1089, 0.2182 and 0.1185 for the triangular, rectangular and sawtooth microwave waveforms with repetition rate of 8 GHz, respectively. Furthermore, after passing through 25 km single mode fiber, the optical power decreased by approximately 5.6 dB, which verifies the anti-dispersion transmission capability of our signal generator. Full article

Here, we report on a simplified laser frequency noise measurement technique employing an acousto-optic modulator, a delay line, and a real-time oscilloscope. The technique is a slight modification of the typical delayed heterodyne method. Instead of using a swept frequency spectrum to analyze the laser emission spectrum, the waveform captured on a real-time oscilloscope is used to directly calculate the laser frequency noise. The oscilloscope bandwidth and sampling requirements can be kept modest by choosing a modulator driven at a few hundred megahertz, making this technique attractive for a large number of laboratories. We show the frequency noise measurements of two different lasers with linewidths at 2.7 kHz and 2 MHz. We took the opportunity to investigate the noise floor of the frequency noise measurement system, and we found that the noise floor of the frequency noise measurement depends on the power level of the laser that is being characterized, with the kilohertz linewidths laser requiring more power to reduce the noise floor to acceptable levels. Full article

Due to the ability of optical modulators to achieve rapid modulation of optical signals, meeting the demands of high-speed data transmission, modulators based on different novel nanomaterials have become one of the research hotspots over the past dacade. Recently, TiN/Ti₃C₂ heterojunction exhibits highly efficient thermo-optic performance and extremely strong stability. Therefore, we have demonstrated an all-optical modulator based on the principle of Michelson interference and the thermo-optic effect in this paper. The modulator employs a TiN/Ti₃C₂ heterojunction-coated microfiber (THM) and further demonstrates its ability to generate phase shifts through an ASE light source. The modulator, with a phase shift slope of 0.025π/mW, can also convert the phase shifts of signal light into amplitude modulation through Michelson interference. The fixed signal light wavelength is 1552.09 nm, and the modulation depth is stable at about 26.4 dB within a wavelength detuning range of −10 to 6 nm; The waveforms of signal light at modulation rates of 500 Hz, 1000 Hz, 2000 Hz, and 3000 Hz were tested, and a 3 dB modulation bandwidth of 2 kHz was measured. The all-optical modulator based on THM has the advantages of high efficiency and stability and has broad application prospects in the fields of all-optical signal processing and high-speed optical communication. Full article

Rotational speed measurement is important for many applications. Here, a noncontact rotational speed test method based on the detection of the periodically perturbed near-field microwave of an open-ended waveguide is proposed. Both simulations and experiments were conducted to verify the near-field microwave rotational speed sensor. The constructed rotation speed sensing system was composed of a standard open-ended WR-42 waveguide (in our measurements, a waveguide-to-coaxial adapter was used to represent an open-ended waveguide) working at ~18 GHz, a radio frequency (RF) circulator, a signal generator, a, RF detector and an oscilloscope. A rotating fan to be measured was placed close to the waveguide’s mouth and, thus, the waveguide’s reflection coefficient was periodically modulated by the rotating fan blades. Then, the RF detector converted this varying reflection coefficient into a direct current (DC) voltage, namely, a periodical waveform. Finally, the rotational speed of the fan could be extracted from this waveform. Measurements using both the proposed near-field microwave method and conventional optical transmission/reflection methods were conducted for verification. The effect of the rotating fan’s location relative to the waveguide’s mouth was also studied. The results show the following: 1. The proposed method works well with a rotational speed of up to ~5000 RPM (rounds per minute), and an accuracy of 1.7% can be achieved. 2. Metallic or non-metallic fan blades are all suitable for this method. Compared with the existing radar method, the proposed method may be advantageous for rotation detection in a constrained space. Full article
