With the increasing integration of renewable energy into power grids, voltage source converter-based high-voltage direct current (VSC-HVDC) stations often adopt hybrid grid-following (GFL) and grid-forming (GFM) control strategies to improve adaptability to varying grid strengths. In many existing schemes, the hybrid coefficient changes abruptly, which may produce large transient current overshoots and compromise the safe and stable operation of converters. An adaptive hybrid GFL-GFM control framework equipped with a hybrid coefficient transition regulation is proposed. Small-signal state–space models are established and eigenvalue analysis confirms stability over the considered short-circuit ratio (SCR) range. The regulating method is activated only during coefficient transitions and is inactive in steady-state, thereby preserving the operating-point eigenvalue properties. Dynamic equations of the converter current change rate are derived to reveal the key role of the hybrid-coefficient change rate in driving transient current overshoots, based on which a real-time hybrid coefficient regulating method is developed to shape coefficient transitions. Simulations on a 500 kV/2100 MW VSC-HVDC project demonstrate reduced transient current overshoot and power oscillations during SCR variations, with robustness under moderate parameter deviations as well as representative SCR assessment error and update delay. Full article

The non-thermal plasma-driven cascade process for CO₂-to-methanol conversion shows significant potential in the field of green methanol synthesis. This process innovatively couples a plasma activation module with a catalytic synthesis module via a multi-stage pressurization device, establishing an efficient two-step pathway that converts CO₂ into methanol via a CO intermediate. Such an arrangement establishes an energy conversion system characterized by both low carbon emissions and high efficiency. This work involved an initial technical evaluation employing a custom-built, lab-scale apparatus. The optimum parameters determined through this assessment were a plasma input voltage of 40 V combined with a subsequent reaction temperature of 240 °C. Operation at these specified parameters yielded a CO₂ conversion of 48%, with the methanol selectivity and production rate reaching 40% and 502 g_MeOH·kg−1 cat·h⁻¹, respectively. Furthermore, industrial-scale process design and scale-up were performed, accompanied by process simulation using Aspen Plus and a subsequent techno-economic evaluation. The results indicate that, compared to the conventional direct CO₂ hydrogenation process, the proposed cascade route can reduce the capital investment by approximately 17%. Full article

Aerospace power systems, including satellites in low earth orbit (LEO) and geostationary earth orbit (GEO), face stringent thermal constraints to minimize size, weight, and power (SWaP). Gallium nitride (GaN) devices offer superior radiation hardness—critical for the harsh space environment—and MHz-level switching capabilities. This high-frequency operation minimizes passive components, particularly magnetics, thereby reducing the overall volume. However, above 10 MHz, magnetic cores become impractical due to material limitations. To address these issues, this article proposes a design methodology for a GaN-based quasi-square-wave (QSW) buck converter integrated with a PCB air-core inductor. First, the impact of the switching frequency and dead time on the zero-voltage switching (ZVS) condition is elaborated. Then, a power loss model accounting for various loss mechanisms is presented. To overcome high GaN body diode reverse conduction loss, an auxiliary diode is employed. Based on the model, a design procedure is developed to optimize the inductor for 10 MHz operation while maximizing efficiency. To validate the design, a 28 V/12 V, 18 W prototype was built and tested. Experimental results demonstrate a peak efficiency of 86.5% at 10 MHz. The auxiliary diode improves efficiency by 4%, verifying reverse conduction loss mitigation. Thermal analysis confirms a full-load case temperature of 62.2 ${}^{\circ }$C, providing a 47.8 ${}^{\circ }$C safety margin compliant with aerospace derating standards. These findings validate the solution for high-frequency, space-constrained aerospace applications. Full article

This paper presents a controller-hardware-in-the-loop simulation (C-HILS) framework for validating models, evaluating control performance, and assessing the thermal lifetime of a tens-of-kilowatt inverter. The real inverter and the C-HILS platform were operated in parallel, and accuracy was quantified using phase-current root mean square error, voltage spectral analysis, and total harmonic distortion (THD). Across a wide range of SVPWM and DPWM cases, deviations remained within 2–5%, confirming close agreement between experiment and simulation. Using the validated C-HILS system, sampling frequency and output power were swept while comparing current tracking, THD, average switching frequency, semiconductor losses, and efficiency. SVPWM achieved lower THD, whereas DPWM reduced average switching frequency and switching losses, improving efficiency. C-HILS waveforms were then applied to a Foster thermal network to reconstruct the junction–temperature trajectory; T_j(t), and ΔT_j and T_j,min were mapped to lifetime using the Bayerer model. For a representative cyclic mission, ΔT_j decreased from approximately 25.6 °C with SVPWM to about 17.5 °C with DPWM, increasing the estimated lifetime from approximately 1.36 years to 9.14 years. These results demonstrate that the proposed C-HILS framework provides a unified pre-prototype tool for model verification, control strategy comparison, and quantitative thermal reliability assessment of shipboard propulsion inverters. Full article

Voltage control is problematic in an islanded microgrid, as small and mismatched feeder impedances lead to inaccurate reactive power sharing among grid-forming inverters and potential instability under conventional droop control. Existing adaptive virtual impedance solutions often depend on communication links, creating a system vulnerability. This study introduces an autonomous control strategy to enhance reactive power sharing without requiring communication. The proposed method utilizes an artificial neural network (ANN) consisting of an offline and online phase to determine the optimal virtual impedance locally at each grid-forming inverter. During an offline phase, a physics-aware recursive least-squares (RLS) algorithm is used to generate a training data set. In online operation, the trained ANN is a lightweight model that uses only local measurements to calculate the required voltage compensation. This ANN-based virtual impedance is a practical and adaptable solution for autonomous voltage and reactive power control. By eliminating communication dependency, this strategy enhances microgrid stability, reliability, and scalability, offering a significant improvement over communication-based methods in terms of cybersecurity. MATLAB/SIMULINK simulations validate the approach, showing that the controller achieves precise reactive power sharing under varying loads and eliminates steady-state errors. Significantly, it maintains robust performance during communication failures and seamlessly adapts to the grid changes. Full article

Battery energy storage systems (BESSs) are increasingly required to provide grid-support services under weak-grid conditions, where the stability of virtual synchronous generator (VSG) control largely depends on the health status and dynamic characteristics of the battery unit. However, existing VSG strategies typically assume fixed parameters and neglect the intrinsic coupling between battery aging, DC-link energy variations, and converter dynamic performance, resulting in reduced damping, degraded transient regulation, and accelerated lifetime degradation. This paper proposes a health-responsive VSG control strategy enabled by real-time energy-dynamics sensing. By reconstructing the DC-link energy state from voltage and current measurements, an intrinsic indicator of battery health and instantaneous power capability is established. This energy-dynamics indicator is then embedded into the VSG inertia and damping loops, allowing the control parameters to adapt to battery health evolution and operating conditions. The proposed method achieves coordinated enhancement of transient stability, weak-grid robustness, and lifetime management. Simulation studies on a multi-unit BESS demonstrate that the proposed strategy effectively suppresses low-frequency oscillations, accelerates transient convergence, and maintains stability across different aging stages. Full article

This article presents a hybrid optimization model designed to determine the optimal location and operation of capacitor banks in medium-voltage distribution networks, aiming to reduce energy losses and enhance the system’s economic efficiency. The use of reactive power compensation through fixed-step capacitor banks is highlighted as an effective and cost-efficient solution; however, their optimal placement and sizing pose a mixed-integer nonlinear programming optimization challenge of a combinatorial nature. To address this issue, a multi-objective optimization methodology based on the Sine Cosine Algorithm (SCA) is proposed to identify the ideal location and capacity of capacitor banks within distribution networks. This model simultaneously focuses on minimizing technical losses while reducing both investment and operational costs, thereby producing a Pareto front that facilitates the analysis of trade-offs between technical performance and economic viability. The methodology is validated through comprehensive testing on the 33- and 69-bus reference systems. The results demonstrate that the proposed SCA-based approach is computationally efficient, easy to implement, and capable of effectively exploring the search space to identify high-quality Pareto-optimal solutions. These characteristics render the approach a valuable tool for the planning and operation of efficient and resilient distribution networks. Full article

In flight tests, to meet the requirements of consistent acquisition and storage of multiple targets, multiple systems, and multiple data types, various data types are processed into Pulse Code Modulation (PCM) data streams using PCM encoding for storage. Aiming at the requirement of real-time storage of high-bit-rate PCM data streams, a large-capacity storage system based on Serial Advanced Technology Attachment 3.0 (SATA3.0) is designed. The system uses the Kintex 7 series Field-Programmable Gate Array (FPGA) as the control core, receives PCM data streams through the Low-Voltage Differential Signaling (LVDS) low-voltage differential interface, stores the received PCM data streams into the mSATA disk via the SATA3.0 transmission bus, and transmits the stored data back to the host computer through the USB3.0 interface for analysis. Meanwhile, to solve the problem of complex data export, the storage system constructs a FAT32 file system through the MicroBlaze soft core to optimize the management and operation of the large-capacity storage system. Test results show that the storage system can perform stable high-rate storage at −40 °C~80 °C. Full article

In electrical networks, the coordination and selectivity of protective devices are key to improving reliability and ensuring operational safety. Protections play a fundamental role in maintaining system stability and detecting faults within the power system. This study presents an optimized genetic algorithm (OGA) as a method to optimize the configurations of overcurrent protections in high voltage distribution systems. The OGA obtained the best results in all tested systems, demonstrating its effectiveness in coordinating protections according to IEC 60255-151:2009. In addition, simulations performed with the integration of Python and PowerFactory DigSILENT software validated the correct coordination of the protections, showing that the OGA not only optimizes response times, but also guarantees greater selectivity and reliability in the protection of the electrical system in an efficient way. Full article

The global shipping industry is surging ahead, and with it, a quiet revolution is taking place on the water: marine lithium-ion batteries have emerged as a crucial clean energy carrier, powering everything from ferries to container ships. When these vessels dock, they increasingly rely on shore power charging systems to refuel—essentially, plugging in instead of idling on diesel. But predicting how much power they will need is not straightforward. Think about it: different ships, varying battery sizes, mixed charging technologies, and unpredictable port stays all come into play, creating a load profile that is random, uneven, and often concentrated—a real headache for grid planners. So how do you forecast something so inherently variable? This study turned to the Monte Carlo method, a probabilistic technique that thrives on uncertainty. Instead of seeking a single fixed answer, the model embraces randomness, feeding in real-world data on supply modes, vessel types, battery capacity, and operational hours. Through repeated random sampling and load simulation, it builds up a realistic picture of potential charging demand. We ran the numbers for a simulated fleet of 400 vessels, and the results speak for themselves: load factors landed at 0.35 for conventional AC shore power, 0.39 for high-voltage DC, 0.33 for renewable-based systems, 0.64 for smart microgrids, and 0.76 when energy storage joined the mix. Notice how storage and microgrids really smooth things out? What does this mean in practice? Well, it turns out that Monte Carlo is not just academically elegant, it is practically useful. By quantifying uncertainty and delivering load factors within confidence intervals, the method offers port operators something precious: a data-backed foundation for decision-making. Whether it is sizing infrastructure, designing tariff incentives, or weighing the grid impact of different shore power setups, this approach adds clarity. In the bigger picture, that kind of insight matters. As ports worldwide strive to support cleaner shipping and align with climate goals—China’s “dual carbon” ambition being a case in point—achieving a reliable handle on charging demand is not just technical; it is strategic. Here, probabilistic modeling shifts from a simulation exercise to a tangible tool for greener, more resilient port energy management. Full article

This paper proposes a dynamic voltage restorer (DVR) based on a new three-phase multilevel inverter (MLI). An integral component of DVRs is the power electronic converter. At medium-to-high voltage levels, MLIs are the ideal converters for DVR applications because lower voltage-rated switches are used to generate high voltages, thus minimizing power losses. The proposed three-phase MLI generates 15 levels of load voltage per phase, using a reduced component count: eight lower-rated semiconductor power switches, four primary DC voltage sources, two auxiliary DC sources, and eight driver circuits per phase. Additionally, each phase features a low-frequency transformer with voltage-boosting and galvanic isolation capabilities. The switching sequence of the proposed MLI is simpler to execute using fundamental frequency control; this methodology provides reduced switching stress and reduced switching losses as merits. Structurally, the proposed MLI is less complex and thus scalable. The proposed DVR, based on three-phase MLI, efficiently offsets power quality problems such as voltage swell, voltage sags, and harmonics for balanced and unbalanced loads. The operational performance of the proposed DVR-MLI is verified by a simulation, using PSCAD software and an experimental prototype. Full article

Aviation power systems require extremely high reliability. As a result, rectifiers must be capable of continuing operation during phase-lack faults, where the input voltage of one phase drops to zero. However, traditional fault-tolerant strategies often struggle to maintain effective control under these conditions. To address this issue, this paper proposes a single-phase control strategy specifically designed for the Vienna rectifier, a commonly used component in aerospace power systems. This strategy ensures a stable DC output during phase-lack faults while maintaining low total harmonic distortion and a near-unity power factor. Simulation results confirm the effectiveness of the proposed control method. Full article

Achieving high reliability remains the critical challenge for pulsed power supplies (PPS), whose core components are susceptible to severe degradation and catastrophic failure due to long-term operation under electrical, thermal and magnetic stresses, particularly those associated with high voltage and high current. This reliability challenge fundamentally limits the widespread deployment of PPSs in defense and industrial applications. This article provides a comprehensive and systematic review of the reliability challenges and recent technological progress concerning PPSs, focusing on three hierarchical levels: component, system integration, and extreme operating environments. The review investigates the underlying failure mechanisms, degradation characteristics, and structural optimization of key components, such as energy storage capacitors and power switches. Furthermore, it elaborates on advanced system-level techniques, including novel thermal management topologies, jitter control methods for multi-module synchronization, and electromagnetic interference (EMI) source suppression and coupling path optimization. The primary conclusion is that achieving long-term, high-frequency operation depends on multi-physics field modeling and robust, integrated design approaches at all three levels. In summary, this review outlines important research directions for future advancements and offers technical guidance to help speed up the development of next-generation PPS systems characterized by high power density, frequent repetition, and outstanding reliability. Full article

Conventional approaches for designing and integrating charging stations into the grid are time-consuming and computationally expensive. For the purpose of power quality enhancement of EVCS, more focus has been paid on charging station design infrastructure, hence neglecting the need for the technical design of grid topology. Therefore, this paper focuses on the design and development of multiple distribution grid topologies for topology-aware characterization of power quality in grid-tied solar-powered EV charging stations. The control and energy management strategy is implemented solely to enable consistent grid-PV-EV interaction. The models have been successfully developed and tested for four modes of operations, PV to EV, PV to Grid, V2G and G2V, in MATLAB/Simulink 2022b. From the results, it is clear that the grid voltage THD during V2G remains at 0.01%, 0.08% and 0.01% and the grid-connected current THD remains at 0.19%, 1.88% and 0.19% for three different grid topologies, GT1, GT2 and GT3, respectively, while, during G2V, the voltage THD are valued at 0.02%, 0.05% and 0.03% and the grid-connected current THD at 0.45%, 1.28% and 0.75% for grid topologies GT1, GT2 and GT3 respectively. The results demonstrate that grid topology-aware analysis is required for consistent harmonic characterization of PV-integrated EV charging stations under V2G, G2V and PV-assisted operating modes. Full article

In recent years, green hydrogen production via water electrolysis driven by renewable energy sources has garnered increasingly significant attention. Among the various water electrolysis technologies, proton-exchange membrane water electrolysis (PEMWE) distinguishes itself owing to the unique advantages, including the compact architecture, high efficiency, rapid dynamic response, and high purity of the generated hydrogen. The membrane electrode assembly (MEA) serves as the core component of a PEM electrolyzer. And only a high-performance and stable MEA can provide a reliable platform for investigating the mass transport behavior within the porous transport layer (PTL). In this study, the MEA fabrication method was optimized by varying the ionomer-to-carbon (I/C) ratio, coating strategy, and anode Ir mass loading. As a result, the cell voltage was reduced from 1.679 V to 1.645 V at 1.0 A cm⁻², with a small degradation of 1.3% over 70 h of operation. Based on the optimized MEA, the effects of the structure and porosity of PTL on the mass transport behavior were further analyzed. After the PTL parameter optimization, the cell voltage was further reduced to 1.630 V at 1.0 A cm⁻², while a high-speed camera captured bubble dynamics in real time, showing the fast detachment of small oxygen bubbles. The integrated electrochemical and visualization results provide a useful guideline to designing both MEA and PTL for efficient PEMWE. Full article
