This study addresses the dynamic response control of deep-water jacket offshore platforms under typhoon and misaligned wave loads by proposing a Tuned Mass Damper (TMD)-based vibration suppression strategy. Typhoon loading is predicted using the Weather Research and Forecasting (WRF) model to simulate maximum wind speed and direction, a customized exponential wind profile fitted to WRF results, and a spectral model calibrated with field-measured data. Correspondingly, typhoon wave loading is calculated using stochastic wave theory with the Joint North Sea Wave Project (JONSWAP) spectrum. A rigorous Finite Element Model (FEM) incorporating soil–structure interaction (SSI) and water-pile interaction is implemented in the Opensees platform. The SSI is modeled using nonlinear Beam on Nonlinear Winkler Foundation (BNWF) elements (PySimple1, TzSimple1, QzSimple1). Numerical simulations demonstrate that the TMD effectively mitigates dynamic platform responses under aligned typhoon and wave conditions. Specifically, the maximum deck acceleration in the X-direction is reduced by 26.19% and 31.58% under these aligned loads, with a 17.7% peak attenuation in base shear. For misaligned conditions, the TMD exhibits pronounced control over displacements in both X- and Y-directions, achieving reductions of up to 29.4%. Sensitivity studies indicated that the TMD’s effectiveness is more significantly impacted by stiffness detuning than mass detuning. It should be emphasized that the effectiveness verification of linear TMD is limited to the load levels within the design limits; for the load conditions that trigger extreme structural nonlinearity, its performance remains to be studied. This research provides theoretical and practical references for multi-directional coupled vibration control of deep-water jacket platforms in extreme marine environments. Full article

This study investigates the use of viscous dampers (VDs) to reduce the vibration of a deepwater offshore platform under joint wind, wave, and earthquake action. A finite element model was established based on the Opensees software (version 3.7.1), incorporating soil–structure interaction simulated by the nonlinear Winkler springs and simulating hydrodynamic loads via the Morison equation. Turbulent wind fields were generated using the von Kármán spectrum, and irregular wave profiles were synthesized from the JONSWAP spectrum. The 1995 Kobe earthquake record served as seismic input. The time-history dynamic response for the deepwater offshore platform was evaluated under two critical scenarios: isolated seismic excitation and the joint action of wind, wave, and seismic loading. The results demonstrate that VDs configured diagonally at each structural level effectively suppress platform vibrations under both isolated seismic and wind–wave–earthquake conditions. Under seismic excitation, the VD system reduced maximum deck acceleration, velocity, displacement, and base shear force by 9.95%, 22.33%, 14%, and 31.08%, respectively. For combined environmental loads, the configuration achieved 15.87%, 21.48%, 13.51%, and 34.31% reductions in peak deck acceleration, velocity, displacement, and base shear force, respectively. Moreover, VD parameter analysis confirms that increased damping coefficients enhance control effectiveness. Full article

To solve the problem of the boundary condition of the electrochemical field for a cathodic protection system of a steel offshore platform jacket, a new concept for the real electrochemical boundary condition was first proposed. The new idea considers that different points on the steel surface have different surface states and different polarization processes. The new method involved using sixteen sets of measurement equipment and a small test jacket to obtain different polarization processes at different points. A new test device was designed to obtain the relationship curves of potential/current density at different points. The polarization processes at different points were obtained. We first found that all polarization processes had four stages: rapid polarization, data jumping, polarization with middle speed, and slow polarization. At the end of the measurement, the current density interval exhibited a convergence phenomenon. The fitting curve based on the endpoint of the fourth stage of each relationship curve was regarded as the real boundary condition. The boundary condition was verified by the small test jacket and the real jacket. The comparison between the calculation and the measurement proved that the boundary condition was correct. The real boundary condition based on the new method reflected the real state and polarization process of the jacket and provided the correct incoming data for electrochemical field. Full article

This paper presents a comprehensive on-site decision-making framework for assessing the structural integrity of a jacket-type offshore platform in the Gulf of Mexico, installed at a water depth of 50 m. Six critical analyses—(i) static operation and storm, (ii) dynamic storm, (iii) strength-level seismic, (iv) seismic ductility (pushover), (v) maximum wave resistance (pushover), and (vi) spectral fatigue—are performed using SACS V16 software to capture both linear and nonlinear interactions among the soil, piles, and superstructure. The environmental conditions include multi-directional wind, waves, currents, and seismic loads. In the static linear analyses (i, ii, and iii), the overall results confirm that the unity checks (UCs) for structural members, tubular joints, and piles remain below allowable thresholds (UC < 1.0), thus meeting API RP 2A-WSD, AISC, IMCA, and Pemex P.2.0130.01-2015 standards for different load demands. However, these three analyses also show hydrostatic collapse due to water pressure on submerged elements, which is mitigated by installing stiffening rings in the tubular components. The dynamic analyses (ii and iii) reveal how generalized mass and mass participation factors influence structural behavior by generating various vibration modes with different periods. They also include a load comparison under different damping values, selecting the most unfavorable scenario. The nonlinear analyses (iv and v) provide collapse factors (Cr = 8.53 and RSR = 2.68) that exceed the minimum requirements; these analyses pinpoint the onset of plasticization in specific elements, identify their collapse mechanism, and illustrate corresponding load–displacement curves. Finally, spectral fatigue assessments indicate that most tubular joints meet or exceed their design life, except for one joint (node 370). This joint’s service life extends from 9.3 years to 27.0 years by applying a burr grinding weld-profiling technique, making it compliant with the fatigue criteria. By systematically combining linear, nonlinear, and fatigue-based analyses, the proposed framework enables robust multi-hazard verification of marine platforms. It provides operators and engineers with clear strategies for reinforcing existing structures and guiding future developments to ensure safe long-term performance. Full article

The offshore jacket structure has the advantages of suitable stiffness, convenient construction, anti-collision, and strong fatigue resistance, and it is the main structural form of offshore converter station. By constructing a numerical wave tank for the hydrodynamic response analysis of the offshore jacket structure, the wave field distribution around and the wave slamming load on the offshore jacket structure for the converter station under the action of waves are analyzed based on the Star CCM+ software 2206. In addition, the effects of wave height and wave period on its hydrodynamic loads are discussed. The results indicated that: (1) A thin jet layer can be formed on the wave-facing side of the square box when the waves attack the box, and the height of the jet is not the maximum when the horizontal load generated by the jet at the front of the box reaches the maximum value. (2) The pressure distribution on the wave-facing side of the square box for the converter station is relatively discrete, with the pressure in the middle part being slightly larger than that on both sides. At the bottom of the box, the pressure in the middle and back part is significantly larger than that in the front part. (3) When the waves attack the box for the converter station, it caused significant energy dissipation, and the horizontal load on the offshore jacket is less than that when no wave slamming occurs. Full article

Currently, divers face significant safety risks when cleaning marine organisms from the steel structures of offshore underwater platform jackets. Consequently, utilizing robots instead of divers to carry out underwater biofouling removal operations will be an important development direction for the underwater maintenance of offshore platforms in the future. In this study, a wall-climbing robot was designed to clean marine organisms from the underwater surface of a platform jacket leg. The overall structure of the underwater cleaning wall-climbing robot is introduced, including the cleaning actuator and the variable curvature-adapted connecting rod mechanism. The corresponding relationship between the variable curvature-adapted connecting rod mechanism and the jacket leg is analyzed in detail. The variable curvature-adapted connecting rod mechanism was optimized using a genetic algorithm to ensure that the underwater cleaning wall-climbing robot can adapt to a minimum diameter of 1 m for the jacket leg. By drawing on Airy wave theory and random wave theory, the Airy wave parameters for waves were analyzed under different sea conditions, considering practical application scenarios. By using Fluent software 2022, a 2D numerical wave tank was constructed to simulate waves under various sea conditions, and the wave surface shapes for different sea states were determined. By building on the Morison equation, a method for calculating the horizontal wave forces on the underwater cleaning wall-climbing robot using the equivalent area and equivalent volume is proposed. By using the two aforementioned methods, the horizontal wave forces on the underwater cleaning wall-climbing robot under specific sea states were determined. The horizontal wave forces of the underwater cleaning wall-climbing robot under different sea conditions were analyzed and simulated in a 3D numerical wave tank. By comparing the theoretical analysis results with the numerical simulation results, where the maximum difference at the extreme points is approximately 11%, the feasibility of the proposed horizontal wave force estimation method was verified. Full article

This study conducted ice-induced vibration analysis on offshore platform structures using the cohesive element method (CEM). The efficacy of this method in simulating the interaction between sea ice and the platform structure is verified by comparing it with the Hamburg Ship Modeling Pool (HSVA) ice-breaking experiment. Subsequently, the vibration response of a sea-ice-jacket platform model is investigated under both unprotected conditions and with the presence of ice-breaking cones. The findings reveal that the motion response of offshore platforms exhibits a positive correlation with the impact velocity of the ice, while the sensitivity of this impact is found to be minimal. Furthermore, the influence of different ice directions on the vibration response of offshore platforms is significant, and the shielding effect has an important impact on the platform’s response. Notably, offshore platforms equipped with 52.5-degree cones demonstrate the most effective vibration reduction, reducing the maximum acceleration by 63% compared to unprotected configurations. It is worth mentioning that as the cone angle increases, the corresponding ice-breaking cone undergoes higher load-bearing. Full article

During the last decade jacket-frames have emerged as the main kind of substructure for bottom-mounted offshore wind farms in intermediate water depths. With the offshore wind industry moving towards deeper waters, the predominance of jacket-frames is expected to increase in future years. Multipurpose platforms combining wind and wave energy are proposed as an innovative solution to enhance the sustainability of offshore wind energy. In this research, a multipurpose platform is investigated with a novel feature in its oscillating water column (OWC) wave energy converter—a variable geometry skirt. A comprehensive physical modelling campaign was carried out using a 1:50 scale model. The performance of the OWC and its interaction with the wave field were investigated under four different skirt aperture angles. It was found that the skirt aperture angle plays a significant role in the capture-width ratio and the pneumatic mean power of the OWC. The best performance was obtained with a skirt aperture angle of 140 deg. More generally, these results prove that the variable-geometry skirt is a promising innovation for hybrid wave-wind systems mounted on jacket-frame substructures. Full article

The oil and natural gas resources of the Bohai Sea are mainly marginal oil fields, and there are currently a large number of structures that are approaching or have reached the end of their service life called aging structures. The interactions between ice and offshore structures could lead to significant ice-induced vibration. Ice-induced vibrations may evoke fatigue damage in tubular joints, which results in severe dangers for offshore platforms in the Bohai Sea. Dynamic ice force models and sea ice fatigue environmental parameters have not been well developed in the current design codes. It is not accurate to evaluate the fatigue damage of structures only with numerical simulation. In this paper, a faster method for evaluating fatigue damage on aging structures is proposed. Firstly, the approximate linear relationship between the fatigue hot spot stress and the vibration response of the deck structure has been discovered using dynamic analysis for jacket platform of Bohai Sea. Then, the procedure of the fatigue damage evaluation of the aging structures in the Bohai Sea is established. Finally, the numerical simulation of the structure is carried out considering ice thickness, ice velocity, ice direction, and action height of sea ice. Fatigue damage is calculated by the fatigue hot spot stress and the Palmgren–Miner rule. The measured data on the platform in the Bohai Sea are selected to obtain the fatigue hot spot stress using a mathematical model. The fatigue damage results considering the actual ice conditions of a jacket structure in the Bohai Sea are compared using the proposed method and finite element analysis. The comparison of the results verifies the rationality of the method proposed in this work. Full article

Accurate estimation of offshore wind turbine (OWT) modal parameters has a prominent effect on the design loads, lifetime prediction, and dynamic response of the system. Modal parameters can vary during the operation of OWTs. This paper studies the variation and sensitivity analysis of an OWT’s modal parameters with respect to operational and environmental conditions. Three finite element models of a jacket-supported OWT at the Block Island Wind Farm are created within the OpenSees, SAP2000, and OpenFAST platforms and validated using experimental measurements. The OpenFAST model is used to simulate the modal parameters of the turbine under various wind speed, rotor speed, power, yaw angle, mean sea level, blade pitch angle, and soil spring values. The model-predicted modal parameters of the first fore–aft (FA) and side–side (SS) modes are compared to those identified from experimental measurements. Results from the simulations show that the first FA natural frequency and damping ratio mostly depend on the rotor speed and wind speed, respectively, while yaw angle and mean sea level do not have a visible effect. It is observed that there is about 8% stiffening in the first FA frequency and an aerodynamic damping of 7.5% during the operation of the OWT. Full article

This paper addresses a detailed analysis of the ice–structure interaction process of the phase-locked ice crushing (PLC) against offshore structures. Directly measured ice load, structure response data, and in situ observation from the field measurements on the Molikpaq lighthouse and jacket platform were used in the study. This paper summarizes a new ductile damage-collapse (DDC) failure mechanism for the PLC process. The DDC mechanism shows that the ice failure is a discrete ductile crushing process rather than a ductile–brittle transition process. The analysis identifies that the ice has a failure length in PLC and this failure length plays an important role in understanding the interaction. It reveals that PLC can occur on most vertical-sided offshore structures when the velocity of the ice sheet falls within the range of the failure length divided by the natural period of the structure. This paper proposes that this relationship between ice failure length and the natural period of the structure can be used as one of the PLC occurrence conditions. The DDC failure mechanism provides a basis for another technical route to solve the PLC problem. Full article

The potential collision between the ship and the pipe piles of the jacket structure brings huge risks to the safety of an offshore platform. Due to their high energy-absorbing capacity, honeycomb structures have been widely used as impact protectors in various engineering applications. This paper proposes a data-driven intelligent approach for the prediction of the collision response of honeycomb-reinforced structures under ship collision. In the proposed model, the artificial neural network (ANN) is combined with the dynamic particle swarm optimization (DPSO) algorithm to predict the collision responses of honeycomb reinforced pipe piles, including the maximum collision depth (δ_max) and maximum absorption energy (E_max). Furthermore, a data-driven evaluation method, known as grey relational analysis (GRA), is proposed to evaluate the collision responses of the honeycomb-reinforced pipe piles of offshore platforms. Results of the case study demonstrate the accuracy of the DPSO-BP-ANN model, with measured mean-square-error (MSE) of 5.06 × 10⁻⁴ and 4.35 × 10⁻³ and R² of 0.9906 and 0.9963 for δ_max and E_max, respectively. It is shown that the GRA method can provide a comprehensive evaluation of the performance of a honeycomb structure under impact loads. The proposed model provides a robust and efficient assessment tool for the safe design of offshore platforms under ship collisions. Full article

Offshore platform plays an important role in ocean strategy, and the construction of structural health monitoring (SHM) system could significantly improve the safety of the platform. In this paper, complete SHM system architecture design for offshore platform is presented, including the sensor subsystem, data reading and transferring subsystem, data administration subsystem, and assessment subsystem. First, the sensor subsystem is determined to include the structure information, component information, and vibration information monitoring of the offshore platform. Based on the monitoring target, three sensor types including incline sensor, acceleration sensor, and strain sensor are initially selected. Second, the assessment subsystem is determined to include safety monitoring and early warning evaluation using static measurements, overall performance evaluation based on frequency variation, and damage identification based on strain modal using strain monitoring. Overall performance evaluation based on frequency variation and damage identification based on Strain modal are illustrated. Finally, an offshore platform in the East China Sea is selected to establish a finite-element model to discuss the application and feasibility of the SHM system, the frequency variation due to scouring, corrosion, the growth of marine organisms, and temperature variation was investigated, and the overall performance of the platform was also evaluated. This work can provide a reference for installation and implementation of SHM system for offshore platform. Full article

The existence of soft soil in offshore areas may lead to the amplification of vibration received from offshore facilities, especially from the existing fixed-jacket platforms, which were designed without provision to seismicity, as in Malaysian water. Therefore, this study was designed to develop a seismic microzonation map and a soil amplification factor map according to soil type; we propose horizontal response spectra and site coefficient values (Ca and Cv) for the Malay Basin. A one-dimensional nonlinear analysis of layered soil (NERA) was used in the ground response analysis for six selected seismic events under five return periods of 100, 200, 500, 1000, and 2500 years. Soil amplification factors for soil types D and E showed a decreasing trend from 100 years to 2500 years. Two designed horizontal response spectra are proposed (for soil type D and E) under average and envelope conditions; a comparison with ISO showed that the proposed spectra were higher, especially for soil type E. To summarize, the seismicity effect should be included in the development of offshore industries as findings indicated that soil amplification occurred in soil types D and E at the Malay Basin. Full article

The collision between the pipe legs of jacket platforms and bypassing ships is of great concern for the safety assessment of platforms. Honeycomb structures have been widely used owing to their unique deformation and mechanical properties under dynamic impact loads. In this paper, two typical honeycomb structures, namely hexagonal honeycomb and arrow honeycomb, were constructed for the impact protection of inclined pipe legs in jacket platforms, and the present study aimed to assess the dynamical performance and crushing resistance of the designed honeycomb reinforced structure under ship collision by using the numerical simulation software ANSYS/LS-DYNA. The dynamical performance of the honeycomb reinforced pipe leg was investigated considering various influential parameters, including the impact velocity and impact direction. The crashworthiness of the two types of honeycomb was evaluated and compared by different criteria, namely the maximum impact depth (δ_max), specific energy absorption (SEA) and the proposed index offset sliding (OS). The results demonstrated that both the hexagonal honeycomb structure and the arrow honeycomb structure can reduce the damage of inclined pipe legs caused by ship collision, while the hexagonal honeycomb can provide the better anti-collision capacity, which can well reduce the offset sliding and better protect the pipe leg from ship collision. Full article
