Article
Fast Parameter Identification of the Fractional-Order Creep Model
by Shabnam Tashakori, Andres San-Millan, Vahid Vaziri and Sumeet S. Aphale
Actuators 2024, 13(12), 534; https://doi.org/10.3390/act13120534 - 23 Dec 2024
Viewed by 733
Abstract
In this study, a parameter identification approach for the fractional-order piezoelectric creep model is proposed. Indeed, creep is a wide-impacting phenomenon leading to time-dependent deformation in spite of constant persistent input. The creep behavior results in performance debasement, especially in applications with low-frequency [...] Read more.
In this study, a parameter identification approach for the fractional-order piezoelectric creep model is proposed. Indeed, creep is a wide-impacting phenomenon leading to time-dependent deformation in spite of constant persistent input. The creep behavior results in performance debasement, especially in applications with low-frequency responses. Fractional-Order (FO) modeling for creep dynamics has been proposed in recent years, which has demonstrated improved modeling precision compared to integer-order models. Still, parameter uncertainty in creep models is a challenge for real-time control. Aiming at a faster identification process, the proposed approach in this paper identifies the model parameters in two layers, i.e., one layer for the fractional-order exponent, corresponding to creep, and the other for the integer-order polynomial coefficients, corresponding to mechanical resonance. The proposed identification strategy is validated by utilizing experimental data from a piezoelectric actuator used in a nanopositioner and a piezoelectric sensor. Full article
(This article belongs to the Special Issue Recent Developments in Precision Actuation Technologies)
Show Figures

Figure 1

14 pages, 10865 KiB
Article
A Novel Thermal Deformation Self-Stabilization Flexible Connection Mechanism
by Fahui Feng, Zhihang Lin and Hui Tang
Actuators 2024, 13(4), 146; https://doi.org/10.3390/act13040146 - 15 Apr 2024
Viewed by 1759
Abstract
In micro-LED chip repair, a nanopositioner is commonly used to adjust the positioning of the LED chip. However, during the bonding process, the heat generated can cause the positioning system to deform, leading to inaccurate alignment and poor-quality chip repair. To solve this [...] Read more.
In micro-LED chip repair, a nanopositioner is commonly used to adjust the positioning of the LED chip. However, during the bonding process, the heat generated can cause the positioning system to deform, leading to inaccurate alignment and poor-quality chip repair. To solve this issue, a novel flexible connection structure has been proposed that can eliminate thermal deformation. The principle of this novel flexible connection structure is that the thermal distortion self-elimination performance is achieved via three flexible connection modules (FCM) so that the thermal stress is automatically eliminated. First, the paper introduces the principle of thermal deformation elimination, and then the design and modeling process of the proposed structure are described. A heat transfer model is then developed to determine how temperature is distributed within the structure. A thermal deformation model is established, and the size of the FCM is optimized using a genetic algorithm (GA) to minimize the thermal deformation. Finite element analysis (FEA) is used to simulate and evaluate the thermal distortion self-elimination performance of the optimized mechanism. Finally, experiments are conducted to verify the reliability and accuracy of the simulation results. The simulations and experiments show that the proposed structure can eliminate more than 38% of the thermal deformation, indicating an excellent thermal deformation self-eliminating capability. Full article
(This article belongs to the Section Actuators for Manufacturing Systems)
Show Figures

Figure 1

12 pages, 3549 KiB
Article
Wireless Piezoelectric Motor Drive
by Burhanettin Koc, Sebastian Kist and Ammar Hamada
Actuators 2023, 12(4), 136; https://doi.org/10.3390/act12040136 - 23 Mar 2023
Cited by 4 | Viewed by 2265
Abstract
Nanopositioners with embedded piezoelectric motors are used in a variety of industries, from microscopy to laser processing or measurement systems. A concrete example would be fine-tuning of multiple mirror or lens units in a system. After fine adjustment of a mirror or lens, [...] Read more.
Nanopositioners with embedded piezoelectric motors are used in a variety of industries, from microscopy to laser processing or measurement systems. A concrete example would be fine-tuning of multiple mirror or lens units in a system. After fine adjustment of a mirror or lens, its position is expected to be maintained when the system is not energized. Features such as small size, direct drive, and maintaining position with high rigidity at power off make inertia-type piezoelectric motors suitable for such “set and go”-type applications. However, wiring with dedicated control electronics for each positioner can increase system complexity. In this study, a wireless driving method for piezoelectric inertia-type motors is introduced for the first time, to the best of our knowledge. In our approach, sawtooth signals for driving a two-phase piezoelectric inertia motor are converted into two complementary pulse-width-modulated (PWM) signals at 1.0 MHz and amplified by class-D amplifier topology, in which GaN transistors are implemented. The amplified complementary PWM signals are applied to a transmitter coil. A receiver coil, which forms an LC network with the capacitances of the piezoelectric multilayer actuators, picks up the driving signals. The filtered voltage waveform by the receiver coil is converted into a modified sawtooth signal, which can operate the piezoelectric inertia-type motor wirelessly. Initial measurements revealed that even a single driving pulse can be transmitted to the receiver coil and precise movements of the slider can be obtained. Mean step sizes for single pulse drive are 140 nm in one direction and 125 nm in the reverse direction. Full article
(This article belongs to the Special Issue Actuators in 2022)
Show Figures

Figure 1

8 pages, 3387 KiB
Article
Design and Test of a Spatial Nanopositioner for Evaluating the Out-of-Focus-Plane Performance of Micro-Vision
by Ruizhou Wang and Heng Wu
Micromachines 2023, 14(3), 513; https://doi.org/10.3390/mi14030513 - 22 Feb 2023
Cited by 2 | Viewed by 1431
Abstract
Micro-vision possesses high in-focus-plane motion tracking accuracy. Unfortunately, out-of-focus-plane displacements cannot be avoided, decreasing the in-focus-plane tracking accuracy of micro-vision. In this paper, a spatial nanopositioner is proposed to evaluate the out-of-focus-plane performance of a micro-vision system. A piezoelectric-actuated spatial multi-degree-of-freedom (multi-DOF) nanopositioner [...] Read more.
Micro-vision possesses high in-focus-plane motion tracking accuracy. Unfortunately, out-of-focus-plane displacements cannot be avoided, decreasing the in-focus-plane tracking accuracy of micro-vision. In this paper, a spatial nanopositioner is proposed to evaluate the out-of-focus-plane performance of a micro-vision system. A piezoelectric-actuated spatial multi-degree-of-freedom (multi-DOF) nanopositioner is introduced. Three in-plane Revolute-Revolute-Revolute-Revolute (RRRR) compliant parallel branched chains produce in-focus-plane motions. Three out-of-plane RRRR chains generate out-of-focus-plane motions. A typical micro-vision motion tracking algorithm is presented. A general grayscale template matching (GTM) approach is combined with the region of interest (ROI) method. The in-focus-plane motion tracking accuracy of the micro-vision system is tested. Different out-of-focus-plane displacements are generated using the proposed nanopositioner. The accuracy degradation of the in-focus-plane motion tracking is evaluated. The experimental results verify the evaluation ability of the proposed nanopositioner. Full article
Show Figures

Figure 1

14 pages, 758 KiB
Article
Linear Matrix Inequality Approach to Designing Damping and Tracking Control for Nanopositioning Application
by Adedayo K. Babarinde and Sumeet S. Aphale
Vibration 2022, 5(4), 846-859; https://doi.org/10.3390/vibration5040050 - 29 Nov 2022
Viewed by 1975
Abstract
This paper presents a method to extend the eigenstructure assignment based design of the Positive Position Feedback (PPF) damping controller to the family of well-known second-order Positive Feedback Controllers (PFC) namely: (i) the Positive Velocity and Position Feedback (PVPF) and (ii) the Positive [...] Read more.
This paper presents a method to extend the eigenstructure assignment based design of the Positive Position Feedback (PPF) damping controller to the family of well-known second-order Positive Feedback Controllers (PFC) namely: (i) the Positive Velocity and Position Feedback (PVPF) and (ii) the Positive Acceleration Velocity and Position Feedback (PAVPF) using appropriate eigenstructure assignment. This design problem entails solving a set of linear equations in the controller parameters using Linear Matrix Inequalities (LMI) to specify a convex design constraint. These damping controllers are popularly used in tandem with a tracking controller (typically an integrator) to deliver high-bandwidth nanopositioning performance. Consequently, the closed-loop performance of all three controllers (PPF, PVPF and PAVPF) employed in tandem with suitably gained integral tracking loops is thoroughly quantified via relevant performance metrics, using measured frequency response data from one axis of a piezo-stack actuated x-y nanopositioner. Full article
Show Figures

Figure 1

18 pages, 1971 KiB
Article
How Far Should Poles Be Placed? Selecting Positive Feedback Controllers for Damping and Tracking Applications: A Complete Characterisation
by James MacLean, Majid Aleyaasin and Sumeet S. Aphale
Vibration 2022, 5(4), 641-658; https://doi.org/10.3390/vibration5040038 - 20 Sep 2022
Cited by 1 | Viewed by 2103
Abstract
Designers of Positive Feedback Controllers (PFCs) arbitrarily place poles into the left-hand half-plane of the complex plane without any detailed understanding of where to stop. This works aims to clearly demonstrate, via rigorous mathematical derivation, the conditions for which pole–placement becomes possible. It [...] Read more.
Designers of Positive Feedback Controllers (PFCs) arbitrarily place poles into the left-hand half-plane of the complex plane without any detailed understanding of where to stop. This works aims to clearly demonstrate, via rigorous mathematical derivation, the conditions for which pole–placement becomes possible. It also highlights the design limits for the family of second–order PFCs—the most popular PFC group. To this end, the complete family of PFCs, namely, Positive Acceleration Velocity Position Feedback and its derivatives, are analysed in great depth with respect to pure damping and also with respect to combined damping and tracking applications. To showcase the practical value and validity of this work, experimental results on a piezoelectric nanopositioner are also presented and discussed. Full article
Show Figures

Figure 1

14 pages, 4255 KiB
Article
Pursuing the Diffraction Limit with Nano-LED Scanning Transmission Optical Microscopy
by Sergio Moreno, Joan Canals, Victor Moro, Nil Franch, Anna Vilà, Albert Romano-Rodriguez, Joan Daniel Prades, Daria D. Bezshlyakh, Andreas Waag, Katarzyna Kluczyk-Korch, Matthias Auf der Maur, Aldo Di Carlo, Sigurd Krieger, Silvana Geleff and Angel Diéguez
Sensors 2021, 21(10), 3305; https://doi.org/10.3390/s21103305 - 11 May 2021
Cited by 7 | Viewed by 4037
Abstract
Recent research into miniaturized illumination sources has prompted the development of alternative microscopy techniques. Although they are still being explored, emerging nano-light-emitting-diode (nano-LED) technologies show promise in approaching the optical resolution limit in a more feasible manner. This work presents the exploration of [...] Read more.
Recent research into miniaturized illumination sources has prompted the development of alternative microscopy techniques. Although they are still being explored, emerging nano-light-emitting-diode (nano-LED) technologies show promise in approaching the optical resolution limit in a more feasible manner. This work presents the exploration of their capabilities with two different prototypes. In the first version, a resolution of less than 1 µm was shown thanks to a prototype based on an optically downscaled LED using an LED scanning transmission optical microscopy (STOM) technique. This research demonstrates how this technique can be used to improve STOM images by oversampling the acquisition. The second STOM-based microscope was fabricated with a 200 nm GaN LED. This demonstrates the possibilities for the miniaturization of on-chip-based microscopes. Full article
(This article belongs to the Section Sensing and Imaging)
Show Figures

Figure 1

13 pages, 4441 KiB
Article
Design and Analysis of a Novel Flexure-Based Dynamically Tunable Nanopositioner
by Zeying Li, Pengbo Liu and Peng Yan
Micromachines 2021, 12(2), 212; https://doi.org/10.3390/mi12020212 - 19 Feb 2021
Cited by 11 | Viewed by 2989
Abstract
Various tools, such as biomedical manipulators, optical aligners, and ultraprecision manufacturing tools, implement nanopositioners that must be dynamically tunable to satisfy the requirements of different working conditions. In this paper, we present the design and analysis of a flexure-based nanopositioner with dynamically tunable [...] Read more.
Various tools, such as biomedical manipulators, optical aligners, and ultraprecision manufacturing tools, implement nanopositioners that must be dynamically tunable to satisfy the requirements of different working conditions. In this paper, we present the design and analysis of a flexure-based nanopositioner with dynamically tunable characteristics for the implementation of a high-performance servomechanism. The nanopositioner is composed of four flexure beams that are positioned in parallel and symmetric configurations sandwiched between magnetorheological elastomers (MREs). The properties of MREs impart dynamicity to the nanopositioner, allowing the workspace, stiffness, and damping characteristics in particular to be tuned under the action of an external magnetic field. By utilizing elastic beam theory and electromagnetic field coupling analysis, kinetostatic and dynamic models of the proposed nanopositioner were established to predict the variable stiffness property and dynamically tunable characteristics. The models were validated by performing a finite element analysis. Herein, it is shown that the proposed nanopositioner model can actively adjust the trade-offs between the working range, speed, and sustained load capability by changing the magnetic field. The proposed dynamic tuning method offers new insight into the design of flexure-based nanopositioners for real applications. Full article
(This article belongs to the Section E:Engineering and Technology)
Show Figures

Figure 1

14 pages, 1653 KiB
Article
A Myosin II-Based Nanomachine Devised for the Study of Ca2+-Dependent Mechanisms of Muscle Regulation
by Irene Pertici, Giulio Bianchi, Lorenzo Bongini, Vincenzo Lombardi and Pasquale Bianco
Int. J. Mol. Sci. 2020, 21(19), 7372; https://doi.org/10.3390/ijms21197372 - 6 Oct 2020
Cited by 12 | Viewed by 3123
Abstract
The emergent properties of the array arrangement of the molecular motor myosin II in the sarcomere of the striated muscle, the generation of steady force and shortening, can be studied in vitro with a synthetic nanomachine made of an ensemble of eight heavy-meromyosin [...] Read more.
The emergent properties of the array arrangement of the molecular motor myosin II in the sarcomere of the striated muscle, the generation of steady force and shortening, can be studied in vitro with a synthetic nanomachine made of an ensemble of eight heavy-meromyosin (HMM) fragments of myosin from rabbit psoas muscle, carried on a piezoelectric nanopositioner and brought to interact with a properly oriented actin filament attached via gelsolin (a Ca2+-regulated actin binding protein) to a bead trapped by dual laser optical tweezers. However, the application of the original version of the nanomachine to investigate the Ca2+-dependent regulation mechanisms of the other sarcomeric (regulatory or cytoskeleton) proteins, adding them one at a time, was prevented by the impossibility to preserve [Ca2+] as a free parameter. Here, the nanomachine is implemented by assembling the bead-attached actin filament with the Ca2+-insensitive gelsolin fragment TL40. The performance of the nanomachine is determined both in the absence and in the presence of Ca2+ (0.1 mM, the concentration required for actin attachment to the bead with gelsolin). The nanomachine exhibits a maximum power output of 5.4 aW, independently of [Ca2+], opening the possibility for future studies of the Ca2+-dependent function/dysfunction of regulatory and cytoskeletal proteins. Full article
Show Figures

Figure 1

11 pages, 5078 KiB
Article
Visual Servo Control System of a Piezoelectric2-Degree-of-Freedom Nano-Stepping Motor
by Cheng-Lung Chen and Shao-Kang Hung
Micromachines 2019, 10(12), 811; https://doi.org/10.3390/mi10120811 - 25 Nov 2019
Cited by 5 | Viewed by 3309
Abstract
A nano-stepping motor can translate or rotate when its piezoelectric element pair is electrically driven in-phase or anti-phase. It offers millimeter-level stroke, sub-micron-level stepping size, and sub-nanometer-level scanning resolution. This article proposes a visual servo system to control the nano-stepping motor, since its [...] Read more.
A nano-stepping motor can translate or rotate when its piezoelectric element pair is electrically driven in-phase or anti-phase. It offers millimeter-level stroke, sub-micron-level stepping size, and sub-nanometer-level scanning resolution. This article proposes a visual servo system to control the nano-stepping motor, since its stepping size is not consistent due to changing contact friction, using a custom built microscopic instrument and image recognition software. Three kinds of trajectories—straight lines, circles, and pentagrams—are performed successfully. The smallest straightness and roundness ever tested are 0.291 µm and 2.380 µm. Experimental results show that the proposed controller can effectively compensate for the error and precisely navigate the rotor along a desired trajectory. Full article
(This article belongs to the Special Issue Piezoelectric Transducers: Materials, Devices and Applications)
Show Figures

Figure 1

12 pages, 1214 KiB
Article
Lights Out! Nano-Scale Topography Imaging of Sample Surface in Opaque Liquid Environments with Coated Active Cantilever Probes
by Fangzhou Xia, Chen Yang, Yi Wang, Kamal Youcef-Toumi, Christoph Reuter, Tzvetan Ivanov, Mathias Holz and Ivo W. Rangelow
Nanomaterials 2019, 9(7), 1013; https://doi.org/10.3390/nano9071013 - 14 Jul 2019
Cited by 9 | Viewed by 4009
Abstract
Atomic force microscopy is a powerful topography imaging method used widely in nanoscale metrology and manipulation. A conventional Atomic Force Microscope (AFM) utilizes an optical lever system typically composed of a laser source, lenses and a four quadrant photodetector to amplify and measure [...] Read more.
Atomic force microscopy is a powerful topography imaging method used widely in nanoscale metrology and manipulation. A conventional Atomic Force Microscope (AFM) utilizes an optical lever system typically composed of a laser source, lenses and a four quadrant photodetector to amplify and measure the deflection of the cantilever probe. This optical method for deflection sensing limits the capability of AFM to obtaining images in transparent environments only. In addition, tapping mode imaging in liquid environments with transparent sample chamber can be difficult for laser-probe alignment due to multiple different refraction indices of materials. Spurious structure resonance can be excited from piezo actuator excitation. Photothermal actuation resolves the resonance confusion but makes optical setup more complicated. In this paper, we present the design and fabrication method of coated active scanning probes with piezoresistive deflection sensing, thermomechanical actuation and thin photoresist polymer surface coating. The newly developed probes are capable of conducting topography imaging in opaque liquids without the need of an optical system. The selected coating can withstand harsh chemical environments with high acidity (e.g., 35% sulfuric acid). The probes are operated in various opaque liquid environments with a custom designed AFM system to demonstrate the imaging performance. The development of coated active probes opens up possibilities for observing samples in their native environments. Full article
Show Figures

Figure 1

15 pages, 1317 KiB
Article
Enhanced Positioning Bandwidth in Nanopositioners via Strategic Pole Placement of the Tracking Controller
by Mohammed Altaher and Sumeet Aphale
Vibration 2019, 2(1), 49-63; https://doi.org/10.3390/vibration2010004 - 11 Jan 2019
Cited by 7 | Viewed by 4102
Abstract
Tracking triangular or staircase trajectories is a challenge for a piezo-driven nanopositioner due to vibration problems. The piezo-driven nanopositioner is a lightly-damped system because of its mechanical construction. These reference trajectories are high-frequency components that tend to excite the mechanical resonance of the [...] Read more.
Tracking triangular or staircase trajectories is a challenge for a piezo-driven nanopositioner due to vibration problems. The piezo-driven nanopositioner is a lightly-damped system because of its mechanical construction. These reference trajectories are high-frequency components that tend to excite the mechanical resonance of the nanopositioner, causing vibration and thus affecting the accuracy. The Integral Resonant Controller (IRC) is employed to damp the resonance and thereby furnish a larger gain margin for a high-gain tracking controller to be implemented. The IRC, however, introduces a low-frequency pole. Due to other control issues, such as hysteresis nonlinearity, Integral (I) or Proportional Integral (PI) tracking control is used as a tracking loop to address uncertainties (hysteresis). The traditional method using a PI controller has a limited positioning bandwidth. This paper presents the strategic zero placement of the PI controller to enhance the positioning bandwidth, thereby overcoming the limitations of tracking error. Using experimental validations to confirm the feasibility of the proposed method, it is shown that significant improvement regarding bandwidth and disturbance rejection are reported. Full article
Show Figures

Figure 1

27 pages, 9295 KiB
Article
Modal Analysis, Metrology, and Error Budgeting of a Precision Motion Stage
by Ahmet Okyay, Kaan Erkorkmaz and Mir Behrad Khamesee
J. Manuf. Mater. Process. 2018, 2(1), 8; https://doi.org/10.3390/jmmp2010008 - 24 Jan 2018
Cited by 2 | Viewed by 7243
Abstract
In this study, a precision motion stage, whose design utilizes a single shaft supported from the bottom by an air bearing and voice coil actuators in complementary double configuration, is evaluated for its dynamic properties, motion accuracy, and potential machining force response, through [...] Read more.
In this study, a precision motion stage, whose design utilizes a single shaft supported from the bottom by an air bearing and voice coil actuators in complementary double configuration, is evaluated for its dynamic properties, motion accuracy, and potential machining force response, through modal testing, laser interferometric metrology, and spectral analysis, respectively. Modal testing is carried out using two independent methods, which are both based on impact hammer testing. Results are compared with each other and with the predicted natural frequencies based on design calculations. Laser interferometry has been used with varying optics to measure the geometric errors of motion. Laser interferometry results are merged with measured servo errors, estimated thermal errors, and the predicted dynamic response to machining forces, to compile the error budget. Overall accuracy of the stage is calculated as peak-to-valley 5.7 μm with a 2.3 μm non-repeatable part. The accuracy measured is in line with design calculations which incorporated the accuracy grade of the encoder scale and the dimensional tolerances of structural components. The source of the non-repeatable errors remains mostly equivocal, as they fall in the range of random errors of measurement in laser interferometry like alterations of the laser wavelength due to air turbulence. Full article
(This article belongs to the Special Issue Precision Manufacturing)
Show Figures

Figure 1

17 pages, 1351 KiB
Article
High-Precision Control of a Piezo-Driven Nanopositioner Using Fuzzy Logic Controllers
by Mohammed Altaher and Sumeet S. Aphale
Computers 2018, 7(1), 10; https://doi.org/10.3390/computers7010010 - 22 Jan 2018
Cited by 15 | Viewed by 7431
Abstract
This paper presents single- and dual-loop fuzzy control schemes to precisely control the piezo-driven nanopositioner in the x- and y-axis directions. Various issues are associated with this control problem, such as low stability margin due to the sharp resonant peak, nonlinear [...] Read more.
This paper presents single- and dual-loop fuzzy control schemes to precisely control the piezo-driven nanopositioner in the x- and y-axis directions. Various issues are associated with this control problem, such as low stability margin due to the sharp resonant peak, nonlinear dynamics, parameter uncertainty, etc. As such, damping controllers are often utilised to damp the mechanical resonance of the nanopositioners. The Integral Resonant Controller (IRC) is used in this paper as a damping controller to damp the mechanical resonance. A further inherent problem is the hysteresis phenomenon (disturbance), which leads to degrading the positioning performance (accuracy) of the piezo-driven stage. The common approach to treat this disturbance is to invoke tracking controllers in a closed-loop feedback scheme in conjunction with the damping controllers. The traditional approach uses the Integral Controller (I) or Proportional Integral (PI) as a tracking controller, whereas this paper introduces the Proportional and Integral (PI)-like Fuzzy Logic Controller (FLC) as a tracking controller. The effectiveness of the proposed control schemes over conventional schemes is confirmed through comparative simulation studies, and results are presented. The stability boundaries of the proposed control schemes are determined in the same way as with a conventional controller. Robustness against variations in the resonant frequency of the proposed control schemes is verified. Full article
Show Figures

Figure 1
