The electron transport layer (ETL) plays a crucial role in solar cell technology, particularly in perovskite solar cells (PSCs), where nanostructured TiO₂ films have been investigated as superior ETLs compared to compact TiO₂. In this study, we explored the nanocolumnar growth of TiO₂ in the anatase phase for bilayer thin films by DC reactive magnetron sputtering (MS) technique and glancing-angle deposition (GLAD). For the growth of the compact TiO₂ layer, it was found that the crystalline quality of the films is strongly dependent on the sputtering power, and the samples deposited at 120 and 140 W are those with the best crystalline quality. However, for the nanocolumnar layer, the reactive atmosphere composition determined the best crystalline properties. By optimizing the growth parameters, the formation of TiO₂ nanocolumns with a cross-sectional diameter ranging from 50 to 75 nm was achieved. The average thickness of the films exceeded 12.71 ± 0.5 µm. All nanostructured films were grown at a constant GLAD angle of 70°, and after deposition, the measured inclination angle of the nanocolumns is very close to this, having values between 68 and 80°. Furthermore, a correlation was observed between the quality of the initial layer and the enhanced growth of the TiO₂ nanocolumns. All bilayer films are highly transparent, allowing light to pass through up to 90%, and present a band gap with values between 3.7 and 3.8 eV. This article offers the experimental parameters for the fabrication of a nanocolumnar TiO₂ using the magnetron sputtering technique and the glancing-angle deposition configuration. Full article

Microbial colonization on various surfaces is a serious problem. Biofilms from these microbes pose serious health and economic threats. In addition, the recent global pandemic has also attracted great interest in the latest techniques and technology for antimicrobial surface coatings. Incorporating antimicrobial nanocompounds into materials to prevent microbial adhesion or kill microorganisms has become an increasingly challenging strategy. Recently, many studies have been conducted on the preparation of nanomaterials with antimicrobial properties against diseases caused by pathogens. Despite tremendous efforts to produce antibacterial materials, there is little systematic research on antimicrobial coatings. In this article, we set out to provide a comprehensive overview of nanomaterials-based antimicrobial coatings that can be used to stop the spread of contamination to surfaces. Typically, surfaces can be simple deposits of nanomaterials, embedded nanomaterials, as well as nanotubes, nanowires, nanocolumns, nanofibers, nanoneedles, and bio-inspired structures. Full article

GaN/AlN heterostructures with thicknesses of one monolayer (ML) are currently considered to be the most promising material for creating UVC light-emitting devices. A unique functional property of these atomically thin quantum wells (QWs) is their ability to maintain stable excitons, resulting in a particularly high radiation yield at room temperature. However, the intrinsic properties of these excitons are substantially masked by the inhomogeneous broadening caused, in particular, by fluctuations in the QWs’ thicknesses. In this work, to reduce this effect, we fabricated cylindrical nanocolumns of 50 to 5000 nm in diameter using GaN/AlN single QW heterostructures grown via molecular beam epitaxy while using photolithography with a combination of wet and reactive ion etching. Photoluminescence measurements in an ultrasmall QW region enclosed in a nanocolumn revealed that narrow lines of individual excitons were localized on potential fluctuations attributed to 2-3-monolayer-high GaN clusters, which appear in QWs with an average thickness of 1 ML. The kinetics of luminescence with increasing temperature is determined via the change in the population of localized exciton states. At low temperatures, spin-forbidden dark excitons with lifetimes of ~40 ns predominate, while at temperatures elevated above 120 K, the overlying bright exciton states with much faster recombination dynamics determine the emission. Full article

The adjustable bandgap, single crystal structure, and strong chemical inertness of GaN materials make them excellent candidates for water splitting applications. The fabrication of GaN nanostructures can enhance their water splitting performance by increasing their surface area, improving photon absorption, and accelerating photocatalytic reactions. Developing cost-effective methods to fabricate GaN nanostructures is crucial to promote the development of GaN-based materials in water splitting applications. In this review, we introduce the main cost-effective techniques for the fabrication of GaN nanostructures and highlight future development directions. Full article

The morphology and void connectivity of thin films grown by a magnetron sputtering deposition technique at oblique geometries were studied in this paper. A well-tested thin film growth model was employed to assess the features of these layers along with experimental data taken from the literature. A strong variation in the film morphology and pore topology was found as a function of the growth conditions, which have been linked to the different collisional transport of sputtered species in the plasma gas. Four different characteristic film morphologies were identified, such as (i) highly dense and compact, (ii) compact with large, tilted mesopores, (iii) nanocolumns separated by large mesopores, and (iv) vertically aligned sponge-like coalescent nanostructures. Attending to the topology and connectivity of the voids in the film, the nanocolumnar morphology was shown to present a high pore volume and area connected with the outside by means of mesopores, with a diameter above 2 nm, while the sponge-like nanostructure presented a high pore volume and area, as well as a dense network connectivity by means of micropores, with a diameter below 2 nm. The obtained results describe the different features of the porous network in these films and explain the different performances as gas or liquid sensors in electrochromic applications or for infiltration with nanoparticles or large molecules. Full article

The present work describes novel copper oxide thin film-modified indium tin oxide electrodes prepared by magnetron sputtering and their application for glucose sensing. Copper oxide-modified sensors were characterized by electrochemical techniques, X-ray photoelectron spectroscopy (XPS), and scanning electron microscopy (SEM). The deposited thin film (of about 400 nm of thickness) consisted of Cu₂O/CuO nanocolumns of ca. 80 nm in diameter. After optimizing the main experimental parameters, the electrodes showed noteworthy electrocatalytic properties for glucose detection (sensitivity ca. 2.89 A M⁻¹ cm⁻² and limit of detection ca. 0.29 μM (S/N = 3)). The sensor showed negligible response against common electroactive species and other sugars. Finally, recovery experiments in commercial soda drinks and the determination of glucose content in different commercial drinks, such as soda, tea, fruit juices, and sports drinks, are described. Full article

Emerging evidence from genomics, post-mortem, and preclinical studies point to a potential dysregulation of molecular signaling at postsynaptic density (PSD) in schizophrenia pathophysiology. The PSD that identifies the archetypal asymmetric synapse is a structure of approximately 300 nm in diameter, localized behind the neuronal membrane in the glutamatergic synapse, and constituted by more than 1000 proteins, including receptors, adaptors, kinases, and scaffold proteins. Furthermore, using FASS (fluorescence-activated synaptosome sorting) techniques, glutamatergic synaptosomes were isolated at around 70 nm, where the receptors anchored to the PSD proteins can diffuse laterally along the PSD and were stabilized by scaffold proteins in nanodomains of 50–80 nm at a distance of 20–40 nm creating “nanocolumns” within the synaptic button. In this context, PSD was envisioned as a multimodal hub integrating multiple signaling-related intracellular functions. Dysfunctions of glutamate signaling have been postulated in schizophrenia, starting from the glutamate receptor’s interaction with scaffolding proteins involved in the N-methyl-D-aspartate receptor (NMDAR). Despite the emerging role of PSD proteins in behavioral disorders, there is currently no systematic review that integrates preclinical and clinical findings addressing dysregulated PSD signaling and translational implications for antipsychotic treatment in the aberrant postsynaptic function context. Here we reviewed a critical appraisal of the role of dysregulated PSD proteins signaling in the pathophysiology of schizophrenia, discussing how antipsychotics may affect PSD structures and synaptic plasticity in brain regions relevant to psychosis. Full article

Herein, we investigate the chemical sensing by surface-enhanced Raman scattering regarding two templates of gold nanocolumns (vertical and tilted) manufactured by glancing angle deposition with magnetron sputtering. We selected this fabrication technique due to its advantages in terms of low-cost production and ease of implementation. These gold nanocolumnar structures allow producing a high density of strongly confined electric field spots within the nanogaps between the neighboring nanocolumns. Thiophenol molecules were used as model analytes since they have the principal property to adsorb well on gold surfaces. Regarding chemical sensing, the vertical (tilted) nanocolumnar templates showed a detection threshold limit of 10 nM (20 nM), an enhancement factor of 9.8 × 10${}^8$ (4.8 × 10${}^8$), and a high quality of adsorption with an adsorption constant $K_{ads}$ of 2.0 × 10${}^6$ M${}^{-1}$ (1.8 × 10${}^6$ M${}^{-1}$) for thiophenol molecules. Full article

In this paper, Cu nanocolumnar structure electrodes are synthetized using a clean and easy-to-scale-up direct-current magnetron sputtering (DC-MS) technique for non-enzymatic glucose sensing. The nanocolumnar structure increases the active surface area of the deposit, with the nanocolumns showing a mean size diameter of 121.0 nm ± 27.2 and a length of 2.52 µm ± 0.23. A scanning transmission electron (STEM) analysis shows the presence of Cu and a small amount of Cu₂O. The behavior of the electrodes in alkaline environments and the electrochemical affinity of the Cu nanocolumns (CuNCs) towards the electro-oxidation of glucose are investigated using cyclic voltammetry (CV). After performing CV in NaOH solution, the columnar structures present corrosion products containing Cu₂O, as revealed by STEM and X-ray diffraction (XRD) analyses. The amperometric responses of the CuNCs to the successive addition of glucose show a linear range up to 2 mM and a limit of detection of 5.2 µM. Furthermore, the electrodes are free from chloride poisoning, and they are insensitive to dopamine, uric acid, ascorbic acid, and acetaminophen at their physiological concentrations. Full article

Since the discovery of high-temperature superconductors (HTSs), significant progress in the fabrication of HTS films has been achieved. In this review, we intend to provide an overview of recent progress in how and why superconductivity can be enhanced by introducing nanoscale vortex pinning centers. The comprehensive control of morphology, dimension, orientation and concentration of artificial pinning centers (APCs) and the principle of vortex pinning are the focus of this review. According to the existing literature, HTSs with the best superconductivity can be obtained when one-dimensional (1D) and three-dimensional (3D) nanoscale APCs are combined for vortex pinning. Full article

Strong electric fields are generated by radio frequency (RF) plasma sources, and though the RF portion is too high a frequency for ions to react, the direct current (DC) portion of these fields has been shown to cause the atomic migration of metals, which can influence film morphology even downstream of the plasma where ionized plasma species are absent. In particular, we have observed the growth of nanopillars due to metal atoms migrating toward the positive field of the remote plasma. A biased grid placed between the plasma and the substrate can shield the substrate from these fields so that, when grounded, smooth films can be grown to a root mean square roughness of less than 1 nm. Positively biasing the grid returns the growth of nanocolumns. Interestingly, negatively biasing the grid significantly reduced the carbon and hydrocarbon content of gallium nitride films grown at a low temperature (~660 °C) using a nitrogen plasma, as observed using secondary ion mass spectroscopy (SIMS) and optical absorption measurements. The films also showed a notable improvement in conductivity and visible appearance. Full article

SnO₂ thin films were prepared by conventional and Glancing Angle Deposition reactive sputtering, and their gas sensing properties were investigated. The porosity of the as-prepared films was widely assessed using optical methods, and the sensing performances of these active layers were correlated with the evolution of surface and film porosity as a function of deposition conditions and annealing treatment. The sensor made of inclined columns grown at high sputtering pressure (6 × 10⁻³ mbar) and annealed at 500 °C in air exhibited the best response to benzene, with a limit of detection of 30 ppb. In addition, successful BTEX (i.e., benzene, toluene, ethylbenzene, and xylenes) discrimination was achieved by combining the sensing signals of four nanostructured tin-oxide-based gas sensors. Full article

The use of Fe films as multi-element targets in space radiation experiments with high-intensity ultrashort laser pulses requires a surface structure that can enhance the laser energy absorption on target, as well as a low concentration and uniform distribution of light element contaminants within the films. In this paper, (110) preferred orientation nanocrystalline Fe thin films with controlled morphology and composition were grown on (100)-oriented Si substrates by oblique angle RF magnetron sputtering, at room temperature. The evolution of films key-parameters, crucial for space-like radiation experiments with organic material, such as nanostructure, morphology, topography, and elemental composition with varying RF source power, deposition pressure, and target to substrate distance is thoroughly discussed. A selection of complementary techniques was used in order to better understand this interdependence, namely X-ray Diffraction, Atomic Force Microscopy, Scanning and Transmission Electron Microscopy, Energy Dispersive X-ray Spectroscopy and Non-Rutherford Backscattering Spectroscopy. The films featured a nanocrystalline, tilted nanocolumn structure, with crystallite size in the (110)-growth direction in the 15–25 nm range, average island size in the 20–50 nm range, and the degree of polycrystallinity determined mainly by the shortest target-to-substrate distance (10 cm) and highest deposition pressure (10⁻² mbar Ar). Oxygen concentration (as impurity) into the bulk of the films as low as 1 at. %, with uniform depth distribution, was achieved for the lowest deposition pressures of (1–3) × 10⁻³ mbar Ar, combined with highest used values for the RF source power of 125–150 W. The results show that the growth process of the Fe thin film is strongly dependent mainly on the deposition pressure, with the film morphology influenced by nucleation and growth kinetics. Due to better control of film topography and uniform distribution of oxygen, such films can be successfully used as free-standing targets for high repetition rate experiments with high power lasers to produce Fe ion beams with a broad energy spectrum. Full article

We report on single-photon emitters for the telecommunication O-band (1260–1360 nm), which comprise an InAs/(In)GaAs quantum dot with asymmetric barriers, placed inside a semiconductor tapered nanocolumn acting as a photonic nanoantenna. The implemented design of the barriers provides a shift in the quantum dot radiation wavelength towards the O-band, while the nanoantenna collects the radiation and ensures its effective output. With non-resonant optical pumping, the average count rate of emitted single photons exceeds 10 MHz with the second-order correlation function $g^{\left(2\right)}$(0) = 0.18 at 8 K. Full article

In this study, we applied a mathematical model to explore the mechanism and factors leading to phase separation and the formation of branching structures with nanocolumns extending from larger clusters formed on the substrate of a grown film. The mathematical model simulated the growth of a thin film over time by using partial differential equations, including the processes of adsorption, phase separation, and diffusion due to the curvature of the thin film surface. The modeling results revealed the possible mechanism that could lead to the formation of the described branching structures. That mechanism can be divided into two main steps. The first step is the growth of a relatively large cluster (of a component that makes up the branching phase) on the substrate during the initial growth stages. The second step is the division process of that large cluster into smaller clusters in the later growth stages. The model parameters influencing the growth conditions that lead to the formation mechanism of the branching structures were determined, and their influences on the phase structure were analyzed. Full article
