In recent years, the non-invasive load monitoring (NILM) method based on sparse coding has shown promising research prospects. This type of method learns a sparse dictionary for each monitoring target device, and it expresses load decomposition as a problem of signal reconstruction using dictionaries and sparse vectors. The existing NILM methods based on sparse coding have problems such as inability to be applied to multi-state and time-varying devices, single-load characteristics, and poor recognition ability for similar devices in distributed manners. Using the analysis above, this paper focuses on devices with similar features in households and proposes a distributed non-invasive load monitoring method using Karhunen–Loeve (KL) feature extraction and an improved deep dictionary. Firstly, Karhunen–Loeve expansion (KLE) is used to perform subspace expansion on the power waveform of the target device, and a new load feature is extracted by combining singular value decomposition (SVD) dimensionality reduction. Afterwards, the states of all the target devices are modeled as super states, and an improved deep dictionary based on the distance separability measure function (DSM-DDL) is learned for each super state. Among them, the state transition probability matrix and observation probability matrix in the hidden Markov model (HMM) are introduced as the basis for selecting the dictionary order during load decomposition. The KL feature matrix of power observation values and improved depth dictionary are used to discriminate the current super state based on the minimum reconstruction error criterion. The test results based on the UK-DALE dataset show that the KL feature matrix can effectively reduce the load similarity of devices. Combined with DSM-DDL, KL has a certain information acquisition ability and acceptable computational complexity, which can effectively improve the load decomposition accuracy of similar devices, quickly and accurately estimating the working status and power demand of household appliances. Full article

Energy disaggregation algorithms disintegrate aggregate demand into appliance-level demands. Among various energy disaggregation approaches, non-intrusive load monitoring (NILM) algorithms requiring a single sensor have gained much attention in recent years. Various machine learning and optimization-based NILM approaches are available in the literature, but bulk training data and high computational time are their respective drawbacks. Considering these drawbacks, we devised an event matching energy disaggregation algorithm (EMEDA) for NILM of multistate household appliances using smart meter data. Having limited training data, K-means clustering was employed to estimate appliance power states. These power states were accumulated to generate an event database (EVD) containing all combinations of appliance operations in their various states. Prior to matching, the test samples of aggregate demand events were decreased by event-driven data compression for computational effectiveness. The compressed test events were matched in the sorted EVD to assess the contribution of each appliance in the aggregate demand. To counter the effects of transient spikes and/or dips that occurred during the state transition of appliances, a post-processing algorithm was also developed. The proposed approach was validated using the low-rate data of the Reference Energy Disaggregation Dataset (REDD). With better energy disaggregation performance, the proposed EMEDA exhibited reductions of 97.5 and 61.7% in computational time compared with the recent smart event-based optimization and optimization-based load disaggregation approaches, respectively. Full article

In this paper, a time-lapse image method is proposed to improve the classification accuracy for multistate appliances with complex patterns based on nonintrusive load monitoring (NILM). A log-likelihood ratio detector with a maxima algorithm was applied to construct a real-time event detection of home appliances. Moreover, a novel image-combining method was employed to extract information from the data based on the Gramian angular field (GAF) and recurrence plot (RP) transformations. From the simulation results, it was confirmed that the classification accuracy can be increased by up to 30% with the proposed method compared with the conventional approaches in classifying multistate appliances. Full article

Non-intrusive load monitoring, a convenient way to discern the energy consumption of a house, has been studied extensively. However, most research works have been carried out based on a hypothetical condition that each electric appliance has only one running state. This leads to low identification accuracy for multi-state electric appliances. To deal with this problem, a method for identifying the type and state of electric appliances based on a power time series is proposed in this paper. First, to identify the type of appliance, a convolutional neural network model was constructed that incorporated residual modules. Then, a k-means clustering algorithm was applied to calculate the number of states of the appliance. Finally, in order to identify the states of the appliances, different k-means clustering models were established for different multi-state electric appliances. Experimental results show effectiveness of the proposed method in identifying both the type and the running state of electric appliances. Full article

This paper presents a comparison of the reliability of various configurations of electronic navigation appliances, from a single system not duplicated (without back-up) to complex systems built of a master system and different numbers of reserve (back-up) systems. For reliability analysis, we created a model of an electronic navigation system reflecting the influence of the number of reserve systems on the entire system reliability. Navigation systems were analyzed as multistate systems. Assuming that they degrade from the state of full reliability to entire failure, their basic reliability characteristics were determined. We also conducted a comparison of system lifetimes in certain reliability state subsets, for different system configurations depending on the number of back-up systems. Additionally, the relationship between the costs associated with setting up a system with a certain configuration and its mean lifetime in reliability state subsets is shown. We also propose procedures for determining the moment of exceeding the allowed limit of system safety, with the use of reliability functions determined for different configurations of the system. One of the major conclusions arising from the reliability analysis is that setting a navigation system with a certain number of back-up solutions is of key importance to improve the system’s reliability in the initial period of operation, while the number of back-up systems has a minor influence on the overall system lifetime. Full article

With the large-scale deployment of smart meters worldwide, research in non-intrusive load monitoring (NILM) has seen a significant rise due to its dual use of real-time monitoring of end-user appliances and user-centric feedback of power consumption usage. NILM is a technique for estimating the state and the power consumption of an individual appliance in a consumer’s premise using a single point of measurement device such as a smart meter. Although there are several existing NILM techniques, there is no meaningful and accurate metric to evaluate these NILM techniques for multi-state devices such as the fridge, heat pump, etc. In this paper, we demonstrate the inadequacy of the existing metrics and propose a new metric that combines both event classification and energy estimation of an operational state to give a more realistic and accurate evaluation of the performance of the existing NILM techniques. In particular, we use unsupervised clustering techniques to identify the operational states of the device from a labeled dataset to compute a penalty threshold for predictions that are too far away from the ground truth. Our work includes experimental evaluation of the state-of-the-art NILM techniques on widely used datasets of power consumption data measured in a real-world environment. Full article

In a real interactive service system, a smart meter can only read the total amount of energy consumption rather than analyze the internal load components for users. Nonintrusive load monitoring (NILM), as a vital part of smart power utilization techniques, can provide load disaggregation information, which can be further used for optimal energy use. In our paper, we introduce a new method called linear-chain conditional random fields (CRFs) for NILM and combine two promising features: current signals and real power measurements. The proposed method relaxes the independent assumption and avoids the label bias problem. Case studies on two open datasets showed that the proposed method can efficiently identify multistate appliances and detect appliances that are not easily identified by other models. Full article
