An innovative and efficient hybrid technique, which combines the Method of Moments (MoM) with Volume Meshed Shooting and Bouncing Ray (VSBR), is presented to analyze the scattering of metallic–dielectric mixed multi-scale structures in urban scenes. Additionally, the technique can rapidly generate radar images at different angles, which is useful for the video remote sensing community. By dividing the mixed multi-scale targets into sub-regions, different solvers are employed to compute the scattering contributions based on their varying electrical sizes. For large-scale sub-regions, the VSBR method is employed on both the medium and metal parts, leading to a multilevel electromagnetic field including both the direct induced field and the multi-reflection field. This field contributes to the integral equation in the MoM sub-regions. Additionally, interactions from the MoM region are considered within the VSBR region, followed by a surface current integration to compute the scattered field. When addressing mixed multi-scale electromagnetic problems, this technique proves to be more efficient and easier to implement in general-purpose computer codes. Furthermore, this method is accelerated using the local coupling (LC) theory and fast multipole method (FMM). Using this fast computational method, efficient simulation results of radar images at different angles for the scenes can be obtained and the numerical results demonstrate the efficiency and accuracy of the proposed method. Full article

The growing demand for stealth technology in military and aerospace applications has driven the development of advanced radar-absorbing structures. In particular, honeycomb absorbing structures (HASs) have shown promise due to their unique properties. In order to enhance the absorption characteristics of HASs and evaluate its application effect on aircraft, firstly, the mechanism of enhancing the electromagnetic (EM) absorption capacity of honeycomb structures by using a gradient design for the impregnation material is studied. Secondly, a multi-layer gradient honeycomb absorbing structure (MGHAS) with top skin and intermediate bonding layers is proposed. The influence of the type and arrangement of impregnation materials on reflectivity is analyzed to obtain design strategies that can enhance the absorption performance of the MGHAS. An improved particle swarm optimization (PSO) algorithm is proposed to optimize the EM absorption performance of the MGHAS. The optimized MGHAS achieves broadband absorption below −10 dB in a 2–18 GHz range, and the reflectivity even reaches −30 dB near 10 GHz. Finally, to solve the problem of electromagnetic scattering characteristics of periodic structures, such as HASs applied to electrically large targets, reflectivity is introduced into a shooting and bouncing ray method, which is a high-frequency algorithm used to analyze the electromagnetic scattering characteristics of the aircraft inlet. Based on this method, the reduction effect of the MGHAS on the radar cross section (RCS) of the aircraft inlet is explored. The results indicate that at the detection angle at 0° and detection frequency at 10 GHz, an aircraft inlet equipped with the MGHAS achieves a 26 dB reduction in the RCS compared with an aircraft inlet without stealth technologies and an 18 dB reduction compared with an inlet with coating-type absorbing material in TM mode. This study demonstrates that the proposed MGHAS effectively reduces the electromagnetic scattering intensity of the aircraft inlet and enhances the radar stealth performance of the aircraft. Full article

Automatic classification of buildings within port areas from synthetic aperture radar (SAR) images is crucial for effective port monitoring and planning. Yet, the unique challenges of SAR imaging, such as side-looking geometry, multi-bouncing scattering, and the compact arrangement of structures, often lead to incomplete building structures and blurred boundaries in classification results. To address these issues, this paper introduces SPformer, an efficient and lightweight pyramid transformer model tailored for semantic segmentation. The SPformer utilizes a pyramid transformer encoder with spatially separable self-attention (SSSA) to refine both local and global spatial information and to process multi-scale features, enhancing the accuracy of building structure delineation. It also integrates a lightweight all multi-layer perceptron (ALL-MLP) decoder to consolidate multi-scale information across various depths and attention scopes, refining detail processing. Experimental results on the Gaofen-3 (GF-3) 1 m port building classification dataset demonstrate the effectiveness of SPformer, achieving competitive performance compared to state-of-the-art models, with mean intersection over union (mIoU) and mean F1-score (mF1) reaching 77.14% and 87.04%, respectively, while maintaining a compact model size and lower computational requirements. Experiments conducted on the entire scene of SAR images covering port area also show the good capabilities of the proposed method. Full article

The circular synthetic aperture radar (CSAR) has the ability of all-round continuous observation and high-resolution imaging detection, and can obtain all-round scattering information and higher-resolution images of the observation scene, so as to realize the target information extraction and three-dimensional (3D) contour reconstruction of the observation targets. However, the existing methods are not accurate enough to extract the information of vehicle targets. Through the analysis of the vehicle target scattering model and CSAR image characteristics, this paper proposes a vehicle target information extraction and 3D contour reconstruction method based on multiple different pitch-angle observation CSAR data. The proposed method creatively utilizes the projection relationship of the vehicle in 2D CSAR imaging to reconstruct the 3D contour of the vehicle, without prior information. Firstly, the CSAR data obtained from multiple different pitch-angle observations are fully utilized, and the scattering points of odd-bounce reflection and even-bounce reflection echoes are extracted from the two-dimensional (2D) coherent CSAR images of the vehicle target. Secondly, the basic contour of the vehicle body is extracted from the scattering points of the even-bounce reflected echoes. Then, the geometric projection relationship of the “top–bottom shifting” effect of odd-bounce reflection is used to calculate the height and position information of the scattering points of odd-bounce reflection, so as to extract the multi-layer 3D contour of the vehicle target. Finally, the basic contour and the multi-layer 3D contour of the vehicle are fused to realize high-precision 3D contour reconstruction of the vehicle target. The correctness and effectiveness of the proposed method are verified by using the CVDomes simulation dataset of the American Air Force Research Laboratory (AFRL), and the experimental results show that the proposed method can achieve high-precision information extraction and realize distinct 3D contour reconstruction of the vehicle target. Full article

To study the electromagnetic scattering of tilt-rotor aircraft during multi-mode continuous flight, a dynamic simulation approach is presented. A time-varying mesh method is established to characterize the dynamic rotation and tilting of tilt-rotor aircraft. Shooting and bouncing rays and the uniform theory of diffraction are used to calculate the multi-mode radar cross-section (RCS). And the scattering mechanisms of tilt-rotor aircraft are investigated by extracting the micro-Doppler and inverse synthetic aperture radar images. The results show that the dynamic RCS of tilt-rotor aircraft in helicopter and airplane mode exhibits obvious periodicity, and the transition mode leads to a strong specular reflection on the rotor’s upper surface, which increases the RCS with a maximum increase of about 36 dB. The maximum micro-Doppler shift has functional relationships with flight time, tilt speed, and wave incident direction. By analyzing the change patterns of maximum shift, the real-time flight state and mode can be identified. There are some significant scattering sources on the body of tilt-rotor aircraft that are distributed in a planar or point-like manner, and the importance of different scattering sources varies in different flight modes. The pre-studies on the key scattering areas can provide effective help for the stealth design of the target. Full article

In this study, a modified non-stationary geometry-based scattering model for tunnel vehicle-to-vehicle (V2V) multiple-input multiple-output Ricean fading channels is presented. The proposed channel introduces non-line-of-sight three-dimensional multi-bounced scattering propagation paths under an assumption of equivalent scattering points to depict the tunnel environments, in which the scatterers are randomly distributed on the semi-cylindrical tunnel wall (i.e., cable racks, jetfans, road signs, lighting facilities). Furthermore, the time-varying channel statistics (i.e., the space and frequency correlation functions) resulting from the relative movement between the mobile transmitter and mobile receiver are analyzed. Finally, numerical results show that the space correlations of the proposed model significantly decrease when the multi-bounced scattering rays are taken into account; moreover, when the velocity and the antenna angle ${\gamma }_R$ increase, the correlations decrease therewith, which exhibits good agreement with the existing V2V scattering channel models and measured data in a real tunnel environment, demonstrating the rationality of the underlying channel model. Full article

Oil storage tank detection and classification in synthetic aperture radar (SAR) images play a vital role in monitoring energy distribution and consumption. Due to the SAR side-looking imaging geometry and multibouncing scattering mechanism, dense oil tank detection and classification tasks have faced more challenges, such as overlapping, blurred contours, and geometric distortion, especially for small-sized tanks. To address the above issues, this paper proposes YOLOX-TR, an improved YOLOX based on the Transformer encoder and structural reparameterized VGG-like (RepVGG) blocks, to achieve end-to-end oil tank detection and classification in densely arranged areas of large-scale SAR images. Based on YOLOX, the Transformer encoder, a self-attention-based architecture, is integrated to enhance the representation of feature maps and capture the region of interest of oil tanks in densely distributed scenarios. Furthermore, RepVGG blocks are employed to reparameterize the backbone with multibranch typologies to strengthen the distinguishable feature extraction of multi-scale oil tanks without increasing computation in inference time. Eventually, comprehensive experiments based on a Gaofen-3 1 m oil tank dataset (OTD) demonstrated the effectiveness of the Transformer encoder and RepVGG blocks, as well as the performance superiority of YOLOX-TR with a mAP and mAP_0.5 of 60.8% and 94.8%, respectively. Full article

It is difficult to detect ports in polarimetric SAR images due to the complicated components, morphology, and coastal environment. This paper proposes an unsupervised port detection method by extracting the water of the port based on three-component decomposition and multi-scale thresholding segmentation. Firstly, the polarimetric characteristics of the port water are analyzed using modified three-component decomposition. Secondly, the volume scattering power and the power ratio of the double-bounce scattering power to the volume scattering power (PRDV) are used to extract the port water. Water and land are first separated by a global thresholding segmentation of the volume scattering power, in which the sampling region used for the threshold calculation is automatically selected by a proposed homogeneity measure. The interference water regions in the ports are then separated from the water by segmenting the PRDV using the multi-scale thresholding segmentation method. The regions of interest (ROIs) of the ports are then extracted by determining the connected interference water regions with a large area. Finally, ports are recognized by examining the area ratio of strong scattering pixels to the land in the extracted ROIs. Seven single quad-polarization SAR images acquired by RADARSAT-2 covering the coasts of Dalian, Zhanjiang, Fujian, Tianjin, Lingshui, and Boao in China and Berkeley in America are used to test the proposed method. The experimental results show that all ports are correctly and quickly detected. The false alarm rates are zero, the intersection of union section (IoU) indexes between the detected port and the ground truth can reach 75%, and the average processing time can be less than 100 s. Full article

We present a GPU-based computation for simulating the synthetic aperture radar (SAR) image of the complex target. To be more realistic, we included the multiple scattering field and antenna pattern tracking in producing the SAR echo signal for both Stripmap and Spotlight modes. Of the signal chains, the computation of the backscattering field is the most computationally intensive. To resolve the issue, we implement a computation parallelization for SAR echo signal generation. By profiling, the overall processing was identified to find which is the heavy loading stage. To further accommodate the hardware structure, we made extensive modifications in the CUDA kernel function. As a result, the computation efficiency is much improved, with over 224 times the speed up. The computation complexity by comparing the CPU and GPU computations was provided. We validated the proposed simulation algorithm using canonical targets, including a perfectly electric conductor (PEC), dielectric spheres, and rotated/unrotated dihedral corner reflectors. Additionally, the targets can be a multi-layered dielectric coating or a layered medium. The latter case aimed to evaluate the polarimetric response quantitively. Then, we simulated a complex target with various poses relative to the SAR imaging geometry. We show that the simulated images have high fidelity in geometric and radiometric specifications. The decomposition of images from individual scattering bounce offers valuable exploitation of the scattering mechanisms responsible for imaging certain target features. Full article

Flood detection and monitoring is increasingly important, especially on remote areas such as African tropical river basins, where ground investigations are difficult. We present an experiment aimed at integrating multi-temporal and multi-source data from the Sentinel-1 and ALOS 2 synthetic aperture radar (SAR) sensors, operating in C band, VV polarization, and L band, HH and HV polarizations, respectively. Information from the globally available CORINE land cover dataset, derived over Africa from the Proba V satellite, and available publicly at the resolution of 100 m, is also exploited. Integrated multi-frequency, multi-temporal, and multi-polarizations analysis allows highlighting different drying dynamics for floodwater over various land cover classes, such as herbaceous vegetation, wetlands, and forests. They also enable detection of different scattering mechanisms, such as double bounce interaction of vegetation stems and trunks with underlying floodwater, giving precious information about the distribution of flooded areas among the different ground cover types present on the site. The approach is validated through visual analysis from Google Earth^TM imagery. This kind of integrated analysis, exploiting multi-source remote sensing to partially make up for the unavailability of reliable ground truth, is expected to assume increasing importance as constellations of satellites, observing the Earth in different electromagnetic radiation bands, will be available. Full article

Imaging of scenes using light or other wave phenomena is subject to the diffraction limit. The spatial profile of a wave propagating between a scene and the imaging system is distorted by diffraction resulting in a loss of resolution that is proportional with traveled distance. We show here that it is possible to reconstruct sparse scenes from the temporal profile of the wave-front using only one spatial pixel or a spatial average. The temporal profile of the wave is not affected by diffraction yielding an imaging method that can in theory achieve wavelength scale resolution independent of distance from the scene. Full article

Icebergs are ocean hazards which require extensive monitoring. Synthetic Aperture Radar (SAR) satellites can help with this, however, SAR backscattering is strongly influenced by the properties of icebergs, together with meteorological and environmental conditions. In this work, we used five images of quad-pol ALOS-2/PALSAR-2 SAR data to analyse 1332 icebergs in five locations in west and east Greenland. We investigate the backscatter and polarimetric behaviour, by using several observables and decompositions such as the Cloude–Pottier eigenvalue/eigenvector and Yamaguchi model-based decompositions. Our results show that those icebergs can contain a variety of scattering mechanisms at L-band. However, the most common scattering mechanism for icebergs is surface scattering, with the second most dominant volume scattering (or more generally, clouds of dipoles). In some cases, we observed a double bounce dominance, but this is not as common. Interestingly, we identified that different locations (e.g., glaciers) produce icebergs with different polarimetric characteristics. We also performed a multi-scale analysis using boxcar 5 × 5 and 11 × 11 window sizes and this revealed that depending on locations (and therefore, characteristics) icebergs can be a collection of strong scatterers that are packed in a denser or less dense way. This gives hope for using quad-pol polarimetry to provide some iceberg classifications in the future. Full article

Color enhancement of decomposed fully polarimetric synthetic aperture radar (PolSAR) image is vital for visual understanding and interpretation of the polarimetric information about the target. It is common practice to use RGB or HIS color space to display the chromatic information for polarization-encoded, Pauli-basis images, or model-based target decomposition of PolSAR images. However, to represent the chroma for multi-polarization SAR data, the region of basic RGB color space does not fully cover the human perceptual system, leading to information loss. In this paper, we propose a color-encoding framework based on the CIE-Lab, a perceptually uniform color space, aiming at a better visual perception and information exploration. The effective interpretability in increasing chromatic, and thus visual enhancement, is presented using extensive datasets. In particular, the four decomposed components—volume scattering, surface scattering, double bounce, and helix scattering—along with total return power, are simultaneously mapped into the color space to improve the discernibility among the scattering components. The five channels derived from the four-component decomposition method can be simultaneously mapped to CIE-Lab color space intuitively. Results show that the proposed color enhancement not only preserves the color tone of the polarization signatures, but also magnifies the target information embedded in the total returned power. Full article

Water is an essential natural resource, and information about surface water conditions can support a wide variety of applications, including urban planning, agronomy, hydrology, electrical power generation, disaster relief, ecology and preservation of natural areas. Synthetic Aperture Radar (SAR) is recognized as an important source of data for monitoring surface water, especially under inclement weather conditions, and is used operationally for flood mapping applications. The canopy penetration capability of the microwaves also allows for mapping of flooded vegetation as a result of enhanced backscatter from what is generally believed to be a double-bounce scattering mechanism between the water and emergent vegetation. Recent investigations have shown that, under certain conditions, the SAR response signal from flooded vegetation may remain coherent during repeat satellite over-passes, which can be exploited for interferometric SAR (InSAR) measurements to estimate changes in water levels and water topography. InSAR results also suggest that coherence change detection (CCD) might be applied to wetland monitoring applications. This study examines wetland vegetation characteristics that lead to coherence in RADARSAT-2 InSAR data of an area in eastern Canada with many small wetlands, and determines the annual variation in the coherence of these wetlands using multi-temporal radar data. The results for a three-year period demonstrate that most swamps and marshes maintain coherence throughout the ice-/snow-free time period for the 24-day repeat cycle of RADARSAT-2. However, open water areas without emergent aquatic vegetation generally do not have suitable coherence for CCD or InSAR water level estimation. We have found that wetlands with tree cover exhibit the highest coherence and the least variance; wetlands with herbaceous cover exhibit high coherence, but also high variability of coherence; and wetlands with shrub cover exhibit high coherence, but variability intermediate between treed and herbaceous wetlands. From this knowledge, we have developed a novel image product that combines information about the magnitude of coherence and its variability with radar brightness (backscatter intensity). This product clearly displays the multitude of small wetlands over a wide area. With an interpretation key we have also developed, it is possible to distinguish different wetland types and assess year-to-year changes. In the next few years, satellite SAR systems, such as the European Sentinel and the Canadian RADARSAT Constellation Mission (RCM), will provide rapid revisit capabilities and standard data collection modes, enhancing the operational application of SAR data for assessing wetland conditions and monitoring water levels using InSAR techniques. Full article

Synthetic aperture radar polarimetry (PolSAR) and polarimetric decomposition techniques have proven to be useful tools for wetland mapping. In this study we classify reed belts and monitor their phenological changes at a natural lake in northeastern Germany using dual-co-polarized (HH, VV) TerraSAR-X time series. The time series comprises 19 images, acquired between August 2014 and May 2015, in ascending and descending orbit. We calculated different polarimetric indices using the HH and VV intensities, the dual-polarimetric coherency matrix including dominant and mean alpha scattering angles, and entropy and anisotropy (normalized eigenvalue difference) as well as combinations of entropy and anisotropy for the analysis of the scattering scenarios. The image classifications were performed with the random forest classifier and validated with high-resolution digital orthophotos. The time series analysis of the reed belts revealed significant seasonal changes for the double-bounce–sensitive parameters (intensity ratio HH/VV and intensity difference HH-VV, the co-polarimetric coherence phase and the dominant and mean alpha scattering angles) and in the dual-polarimetric coherence (amplitude), anisotropy, entropy, and anisotropy-entropy combinations; whereas in summer dense leaves cause volume scattering, in winter, after leaves have fallen, the reed stems cause predominately double-bounce scattering. Our study showed that the five most important parameters for the classification of reed are the intensity difference HH-VV, the mean alpha scattering angle, intensity ratio HH/VV, and the coherence (phase). Due to the better separation of reed and other vegetation (deciduous forest, coniferous forest, meadow), winter acquisitions are preferred for the mapping of reed. Multi-temporal stacks of winter images performed better than summer ones. The combination of ascending and descending images also improved the result as it reduces the influence of the sensor look direction. However, in this study, only an accuracy of ~50% correct classified reed areas was reached. Whereas the shorelines with reed areas (>10 m broad) could be detected correctly, the actual reed areas were significantly overestimated. The main source of error is probably the challenging data geocoding causing geolocation inaccuracies, which need to be solved in future studies. Full article
