Search Results (68)

To address the poor thermal performance and low output efficiency of conventional solid-state microchip lasers, this study proposes and implements a bonded Nd:YAG/Cr⁴⁺:YAG laser based on fiber splitter pumping. Experimental results demonstrate that at a 4.02 mJ pump pulse energy and a 100 Hz repetition rate, the system achieves four linearly polarized output beams with an average pulse energy of 0.964 mJ, a repetition rate of 100 Hz, and an optical-to-optical conversion efficiency of 23.98%. The energy distribution ratios for the upper-left, lower-left, upper-right, and lower-right beams are 22.61%, 24.46%, 25.50%, and 27.43%, with pulse widths of 2.184 ns, 2.193 ns, 2.205 ns, and 2.211 ns, respectively. As the optical axis distance increases, the far-field spot pattern transitions from a single circular profile to four fully separated spots, where the lower-right beam exhibits beam quality factors of M_x² = 1.181 and M_y² = 1.289. Simulations at a 293.15 K coolant temperature and a 4.02 mJ pump energy reveal that split pumping reduces the volume-averaged temperature rise in Nd:YAG by 28.81% compared to single-beam pumping (2.57 K vs. 3.61 K), decreases the peak temperature rise by 66.15% (6.97 K vs. 20.59 K), and suppresses peak-to-peak temperature variation by 78.6% (1.34 K vs. 6.26 K). Compared with existing multi-beam generation methods, the fiber splitter approach offers integrated advantages—including compact size, low cost, high energy utilization, superior beam quality, and elevated damage thresholds—and thus shows promising potential for automotive multi-point ignition, multi-beam single-photon counting LiDAR, and laser-induced breakdown spectroscopy (LIBS) online analysis. Full article

We propose a hybrid-integrated III–V-silicon optical-phased-array (OPA) based on passive alignment flip–chip bonding technology and provide new solutions for LiDAR. To achieve a large range of vertical beam steering in a hybrid-integrated OPA, a multi-lines OPA in a single chip is introduced. The system allows parallel hybrid integration of multiple dies onto a single wafer, achieving a multi-fold improvement in tuning efficiency. In order to increase the range of horizontal beam steering, we propose a half-wavelength pitch waveguide emitter with non-uniform width to reduce the crosstalk, which can remove the higher-order grating lobes in free space. In this work, we simulate OPA individually for four-lines and eight-lines. As a result, we simultaneously achieved a beam steering with nearly ±90° (horizontal) × 17.2° (vertical, when four-line OPA) or 39.6° (vertical, when eight-line OPA) field of view (FOV) and a high tuning efficiency with 1.13°/nm (when eight-line OPA). Full article

LiDAR-based simultaneous localization and mapping (SLAM) techniques are commonly applied in high-precision mapping and positioning for mobile platforms. However, the vertical resolution limitations of multi-beam spinning LiDAR sensors can significantly impair vertical estimation accuracy. This challenge is accentuated in scenarios involving fewer-line or cost-effective spinning LiDARs, where vertical features are sparse. To address this issue, we introduce LIO-GC, which effectively extracts ground features and integrates them into a factor graph to rectify vertical accuracy. Unlike conventional methods relying on geometric features for ground plane segmentation, our approach leverages a self-adaptive strategy that considers the uneven point cloud distribution and inconsistency due to ground fluctuations. By optimizing laser range factors, ground feature constraints, and loop closure factors using graph optimization frameworks, our method surpasses current approaches, demonstrating superior performance through evaluation on open-source and newly collected datasets. Full article

Generating aerial shoreline segmentation masks can be a daunting task, often requiring manual labeling or correction. This is further problematic because neural segmentation models require decent and abundant data for training, requiring even more manpower to automate the process. In this paper, we propose utilizing Unmanned Surface Vehicles (USVs) in an automated shoreline segmentation system on satellite imagery. The remotely controlled vessel first collects above- and underwater shoreline information using light detection and ranging (LiDAR) and multibeam echosounder (MBES) measuring instruments, resulting in a geo-referenced 3D point cloud. After cleaning and processing these data, the system integrates the projected map with an aerial image of the region. Based on the height values of the mapped points, the image is segmented. Finally, post-processing methods and the k-NN algorithm are introduced, resulting in a complete binary shoreline segmentation mask. The obtained data were used for training U-Net-type segmentation models with pre-trained backbones. The InceptionV3-based model achieved an accuracy of 96% and a dice coefficient score of 93%, demonstrating the effectiveness of the proposed system as a source of data acquisition for training deep neural networks. Full article

Lidar technology plays a pivotal role in lunar exploration, particularly in terrain mapping, 3D topographic surveying, and velocity measurement, which are crucial for guidance, navigation, and control. This paper reviews the current global research and applications of lidar technology in lunar missions, noting that existing efforts are primarily focused on 3D terrain mapping and velocity measurement. The paper also discusses the detailed system design and key results of the laser altimeter, laser ranging sensor, laser 3D imaging sensor, and laser velocity sensor used in the Chang’E lunar missions. By comparing and analyzing similar foreign technologies, this paper identifies future development directions for lunar laser payloads. The evolution towards multi-beam single-photon detection technology aims to enhance the point cloud density and detection efficiency. This manuscript advocates that China actively advance new technologies and conduct space application research in areas such as multi-beam single-photon 3D terrain mapping, lunar surface water ice measurement, and material composition analysis, to elevate the use of laser pay-loads in lunar and space exploration. Full article

Ultra-compact passive phase shifters are inversely designed by the multi-objective particle swarm optimization algorithm. The wavelength-dependent phase difference between two output beams originates from the different distances of the input light passing through the 4 μm × 3.2 μm rectangular waveguide with random-distributed air-hole arrays. As the wavelength changes from 1535 to 1565 nm, a phase difference tuning range of 6.26 rad and 6.95 rad is obtained for TE and TM modes, respectively. Compared with the array waveguide grating counterpart, the phase shifters exhibit higher transmission with a much smaller footprint. By combining the inverse-designed phase shifter and random-grating emitter together, integrated beam-steering structures are built, which show a large scanning range of ±25.47° and ±27.85° in the lateral direction for TE and TM mode, respectively. This work may pave the way for the development of ultra-compact high-performance optical phased array LiDARs. Full article

Photodetectors play a critical role in space lidars designed for scientific investigations from orbit around planetary bodies. The detectors must be highly sensitive due to the long range of measurements and tight constraints on the size, weight, and power of the instrument. The detectors must also be space radiation tolerant over multi-year mission lifetimes with no significant performance degradation. Early space lidars used diode-pumped Nd:YAG lasers with a single beam for range and atmospheric backscattering measurements at 1064 nm or its frequency harmonics. The photodetectors used were single-element photomultiplier tubes and infrared performance-enhanced silicon avalanche photodiodes. Space lidars have advanced to multiple beams for surface topographic mapping and active infrared spectroscopic measurements of atmospheric species and surface composition, which demand increased performance and new capabilities for lidar detectors. Higher sensitivity detectors are required so that multi-beam and multi-wavelength measurements can be performed without increasing the laser and instrument power. Pixelated photodetectors are needed so that a single detector assembly can be used for simultaneous multi-channel measurements. Photon-counting photodetectors are needed for active spectroscopy measurements from short-wave infrared to mid-wave infrared. HgCdTe avalanche photodiode arrays have emerged recently as a promising technology to fill these needs. This paper gives a review of the photodetectors used in past and present lidars and the development and outlook of HgCdTe APD arrays for future space lidars. Full article

In August 2022, China successfully launched the Terrestrial Ecosystem Carbon Inventory Satellite (TECIS). The primary payload of this satellite is an onboard multi-beam lidar system, which is capable of observing aerosol optical parameters on a global scale. This pioneering study used the Fernald forward integration method to retrieve aerosol optical parameters based on the Level 2 data of the TECIS, including the aerosol depolarization ratio, aerosol backscatter coefficient, aerosol extinction coefficient, and aerosol optical depth (AOD). The validation of the TECIS-retrieved aerosol optical parameters was conducted using CALIPSO Level 1 and Level 2 data, with relative errors within 30%. A comparison of the AOD retrieved from the TECIS with the AERONET and MODIS AOD products yielded correlation coefficients greater than 0.7 and 0.6, respectively. The relative error of aerosol optical parameter profiles compared with ground-based measurements for CALIPSO was within 40%. Additionally, the correlation coefficients R² with MODIS and AERONET AOD were approximately between 0.5 and 0.7, indicating the high accuracy of TECIS retrievals. Utilizing the TECIS retrieval results, combined with ground air quality monitoring data and HYSPLIT outcomes, a typical dust transport event was analyzed from 2 to 7 April 2023. The results indicate that dust was transported from the Taklamakan Desert in Xinjiang, China, to Henan and Anhui provinces, with a gradual decrease in the aerosol depolarization ratio and backscatter coefficient during the transport process, causing varying degrees of pollution in the downstream regions. This research verifies the accuracy of the retrieval algorithm through multi-source data comparison and demonstrates the potential application of the TECIS in the field of aerosol science for the first time. It enables the fine-scale regional monitoring of atmospheric aerosols and provides reliable data support for the three-dimensional distribution of global aerosols and related scientific applications. Full article

The digital representation of seafloor, a challenge in UNESCO’s Ocean Decade initiative, is essential for sustainable development support and marine environment protection, aligning with the United Nations’ 2030 program goals. Accuracy in seafloor representation can be achieved through remote sensing measurements, including acoustic and laser sources. Ground truth information integration facilitates comprehensive seafloor assessment. The current seafloor mapping paradigm benefits from the object-based image analysis (OBIA) approach, managing high-resolution remote sensing measurements effectively. A critical OBIA step is the segmentation process, with various algorithms available. Recent artificial intelligence advancements have led to AI-powered segmentation algorithms development, like the Segment Anything Model (SAM) by META AI. This paper presents the SAM approach’s first evaluation for seafloor mapping. The benchmark remote sensing dataset refers to Puck Lagoon, Poland and includes measurements from various sources, primarily multibeam echosounders, bathymetric lidar, airborne photogrammetry, and satellite imagery. The SAM algorithm’s performance was evaluated on an affordable workstation equipped with an NVIDIA GPU, enabling CUDA architecture utilization. The growing popularity and demand for AI-based services predict their widespread application in future underwater remote sensing studies, regardless of the measurement technology used (acoustic, laser, or imagery). Applying SAM in Puck Lagoon seafloor mapping may benefit other seafloor mapping studies intending to employ AI technology. Full article

The mechanical LiDAR sensor is crucial in autonomous vehicles. After projecting a 3D point cloud onto a 2D plane and employing a deep learning model for computation, accurate environmental perception information can be supplied to autonomous vehicles. Nevertheless, the vertical angular resolution of inexpensive multi-beam LiDAR is limited, constraining the perceptual and mobility range of mobile entities. To address this problem, we propose a point cloud super-resolution model in this paper. This model enhances the density of sparse point clouds acquired by LiDAR, consequently offering more precise environmental information for autonomous vehicles. Firstly, we collect two datasets for point cloud super-resolution, encompassing CARLA32-128in simulated environments and Ruby32-128 in real-world scenarios. Secondly, we propose a novel temporal and spatial feature-enhanced point cloud super-resolution model. This model leverages temporal feature attention aggregation modules and spatial feature enhancement modules to fully exploit point cloud features from adjacent timestamps, enhancing super-resolution accuracy. Ultimately, we validate the effectiveness of the proposed method through comparison experiments, ablation studies, and qualitative visualization experiments conducted on the CARLA32-128 and Ruby32-128 datasets. Notably, our method achieves a PSNR of 27.52 on CARLA32-128 and a PSNR of 24.82 on Ruby32-128, both of which are better than previous methods. Full article

Shallow water bathymetry is a topic of significant interest in various fields, including civil construction, port monitoring, and military operations. This study presents several methods for assessing shallow water bathymetry using maritime uncrewed systems (MUSs) integrated with advanced and innovative sensors such as Light Detection and Ranging (LiDAR) and multibeam echosounder (MBES). Furthermore, this study comprehensively describes satellite-derived bathymetry (SDB) techniques within the same geographical area. Each technique is thoroughly outlined with respect to its implementation and resultant data, followed by an analytical comparison encompassing their accuracy, precision, rapidness, and operational efficiency. The accuracy and precision of the methods were evaluated using a bathymetric reference survey conducted with traditional means, prior to the MUS survey and with cross-comparisons between all the approaches. In each assessment of the survey methodologies, a comprehensive evaluation is conducted, explaining both the advantages and limitations for each approach, thereby enabling an inclusive understanding for the reader regarding the efficacy and applicability of these methods. The experiments were conducted as part of the Robotic Experimentation and Prototyping using Maritime Unmanned Systems 23 (REPMUS23) multinational exercise, which was part of the Rapid Environmental Assessment (REA) experimentations. Full article

The reduction in the usable capacity of reservoirs, which is linked to the ongoing silting phenomenon, has led to the need to remove sediments to allow the storage of greater quantities of water resources. At the same time, however, the removal of sediment from the bottom results in the need to manage a large quantity of materials, for which the current prospect of discharge is both economically and environmentally unsustainable. This research work concerns the assessment of the silting volume increment of the Camastra reservoir and the phenomenon of progressing speed based on topographic and bathymetric surveys carried out in September 2022 through the use of a DJI Matrice 300 RTK drone with ZENMUSE L1 LiDAR technology, multibeam surveys, and geophysical prospecting using a sub-bottom profiler. It was possible to estimate the increase in dead volume and compare this value with that obtained from the surveys through a literature calculation model and previous silting data. The used model, which slightly underestimates the silting phenomenon, estimates the volume of accumulated sediment from the original capacity of the reservoir, which is understood as the volume that can be filled with sediment in an infinite time, from which an amount is removed depending on the characteristic time scale of reservoir filling and the level of complexity of the silting phenomenon for a specific reservoir. Furthermore, there is evidence of an increase in the speed of sediment accumulation, which is linked to the more frequent occurrence of high-intensity and short-duration meteoric events caused by climate change, which can lead to an increase in erosion and transport phenomena. Further evidence is provided by the occupation of approximately 50% of the Camastra’s reservoir capacity, which makes sediment dredging policies and interventions a priority, contributing to the practical significance of the present study. In this regard, the main recovery and reuse alternatives are identified and analyzed to make the removal of accumulated material environmentally and economically sustainable, such as through environmental and material recovery applications, with a preference for applications for which sediment pretreatment is not necessary. Full article

The leaf area index (LAI) serves as a crucial metric in quantifying the structure and density of vegetation canopies, playing an instrumental role in determining vegetation productivity, nutrient and water utilization, and carbon balance dynamics. In subtropical montane forests, the pronounced spatial heterogeneity combined with undulating terrain introduces significant challenges for the optical remote sensing inversion accuracy of LAI, thereby complicating the process of ground validation data collection. The emergence of UAV LiDAR offers an innovative monitoring methodology for canopy LAI inversion in these terrains. This study assesses the implications of altitudinal variations on the attributes of UAV LiDAR point clouds, such as point density, beam footprint, and off-nadir scan angle, and their subsequent ramifications for LAI estimation accuracy. Our findings underscore that with increased altitude, both the average off-nadir scan angle and point density exhibit an ascending trend, while the beam footprint showcases a distinct negative correlation, with a correlation coefficient (R) reaching 0.7. In contrast to parallel flight paths, LAI estimates derived from intersecting flight paths demonstrate superior precision, denoted by R² = 0.70, RMSE = 0.75, and bias = 0.42. Notably, LAI estimation discrepancies intensify from upper slope positions to middle positions and further to lower ones, amplifying with the steepness of the gradient. Alterations in point cloud attributes induced by the terrain, particularly the off-nadir scan angle and beam footprint, emerge as critical influencers on the precision of LAI estimations. Strategies encompassing refined flight path intervals or multi-directional point cloud data acquisition are proposed to bolster the accuracy of canopy structural parameter estimations in montane landscapes. Full article

The digital elevation model (DEM) is a three-dimensional digital representation of the terrain or the Earth’s surface. For determining topography, DEMs are the most used and ideal method with (i.e., the digital surface model) or without the objects (i.e., the digital terrain model). Various techniques are used to create DEMs, including traditional surveying methods, photogrammetry, InSAR, lidar, clinometry, and radargrammetry. DEMs generated by LiDAR tend to be the most accurate except for the VHR datasets acquired from UAVs with spatial resolution of a few centimeters. In many parts of the region, LiDAR data are not available, which limits researchers’ access to high-resolution and accurate DEMs. With a beam footprint of 13 m and a pulse interval of 0.7 m, ICESat-2 promises high orbital precision and high accuracy. ICESat-2 can produce high-accuracy DEMs in complex topographies with an accuracy of a few centimeters. The Earth’s surface elevations are provided by discrete photon data from ICESat-2. It is difficult to justify the continuity of the topographical data using traditional interpolation techniques since they over-smooth the estimated space. Geospatial data can be analyzed with machine learning algorithms to extract patterns and spatial extents. To estimate a DEM from LiDAR point data from ICESat-2 using CartoDEM, machine learning regression algorithms are used in this study V3 R1. This study was conducted over a hilly terrain of the Dehradun region in the foothills of the Himalayas in India. The applicability and robustness of these algorithms has been tested for a plain region of Ghaziabad, India, in an earlier study. The interpolation of DEM from ICESat-2 data was analyzed using regression-based machine learning techniques. Interpolated DEMs were evaluated against the TANDEM-X DEM of the same region with RMSEs of 7.13 m, 7.01 m, 7.15 m, and 3.76 m respectively, using gradient boosting regressors, random forest regressors, decision tree regressors, and multi-layer perceptron (MLP) regressors. Based on the four algorithms tested, the MLP regressor shows the best performance in the previous study. The accuracy of the simulated ICESat-2 DEM using the MLP regressor was assessed in this study using the DGPS points over the Dehradun region. The RMSE was of the order of 6.58 m for the DGPS reference data. Full article

This publication is aimed at developing a concept of an innovative system for dimensioning and predicting changes in the coastal zone topography using Unmanned Aerial Vehicles (UAVs) and Unmanned Surface Vehicles (USVs). The 4DBatMap system will consist of four components: 1. Measurement data acquisition module. Bathymetric and photogrammetric measurements will be carried out with a specific frequency in the coastal zone using a UAV equipped with a Global Navigation Satellite System (GNSS)/Inertial Navigation System (INS), Light Detection And Ranging (LiDAR) and a photogrammetric camera, as well as a USV equipped with a GNSS Real Time Kinematic (RTK) receiver and a MultiBeam EchoSounder (MBES). 2. Multi-sensor geospatial data fusion module. Low-altitude aerial imagery, hydrographic and LiDAR data acquired using UAVs and USVs will be integrated into one. The result will be an accurate and fully covered with measurements terrain of the coastal zone. 3. Module for predicting changes in the coastal zone topography. As part of this module, a computer application will be created, which, based on the analysis of a time series, will determine the optimal method for describing the spatial and temporal variability (long-term trend and seasonal fluctuations) of the coastal zone terrain. 4. Module for imaging changes in the coastal zone topography. The final result of the 4DBatMap system will be a 4D bathymetric chart to illustrate how the coastal zone topography changes over time. Full article
