Search Results (54)

In this study, we discuss a series of eight energy scales, some of which are our own speculations, and fit the logarithms of these energies as a straight line versus a quantity related to the dimensionalities of action terms in a way to be defined in the article. These terms in the action are related to the energy scales in question. So, for example, the dimensionality of the Einstein–Hilbert action coefficient is one related to the Planck scale. In fact, we suppose that, in the cases described with quantum field theory, there is, for each of our energy scales, a pair of associated terms in the Lagrangian density, one “kinetic” and one “mass or current” term. To plot the energy scales, we use the ratio of the dimensionality of, say, the “non-kinetic” term to the dimensionality of the “kinetic” one. For an explanation of our phenomenological finding that the logarithm of the energies depends, as a straight line, on the dimensionality defined integer q, we give an ontological—i.e., it really exists in nature in our model—“fluctuating lattice” with a very broad distribution of, say, the link size a. We take the Gaussian in the logarithm, $ln\left(a\right)$. A fluctuating lattice is very natural in a theory with general relativity, since it corresponds to fluctuations in the gauge depth of the field of general relativity. The lowest on our energy scales are intriguing, as they are not described by quantum field theory like the others but by actions for a single particle or single string, respectively. The string scale fits well with hadronic strings, and the particle scale is presumably the mass scale of Standard Model group monopoles, the bound state of a couple of which might be the dimuon resonance (or statistical fluctuation) found in LHC with a mass of 28 GeV. Full article

This study investigates the electromagnetic performance of two carbon fiber monopole antennas integrated into a UAV copter frame, with emphasis on design adaptation, impedance matching, and propagation behavior. A comprehensive experimental campaign was conducted to characterize key parameters such as center frequency, bandwidth, gain, VSWR, and S₁₁. Both antennas exhibited dual-band resonance at approximately 381 MHz and 1.19 GHz, each achieving a 500 MHz bandwidth where VSWR ≤ 2. The modified antenna achieved a minimum reflection coefficient of –14.6 dB and a VSWR of 1.95 at 381.45 MHz, closely aligning with theoretical predictions. Gain deviations between measured (0.15–0.19 dBi) and calculated (0.19 dBi) values remained within 0.04 dB, while received power fluctuations did not exceed 1.3 dB under standard test conditions despite the composite material’s finite conductivity. Free-space link-budget tests at 0.5 m and 2 m of separation revealed received-power deviations of 0.9 dB and 1.3 dB, respectively, corroborating the Friis model. Radiation pattern measurements in both azimuth and elevation planes confirmed good directional behavior, with minor side lobe variations, where Antenna A displayed variations between 270° and 330° in azimuth, while Antenna B remained more uniform. A 90° polarization mismatch led to a 15 dBm signal drop, and environmental obstructions caused losses of 9.4 dB, 12.6 dB, and 18.3 dB, respectively, demonstrating the system’s sensitivity to alignment and surroundings. Additionally, signal strength changes observed in a Two-Ray propagation setup validated the importance of ground reflection effects. Small-scale fading analysis at 5 m LOS indicated a Rician-distributed envelope with mean attenuation of 53.96 dB, σ_dB = 5.57 dB, and a two-sigma interval spanning 42.82 dB to 65.11 dB; the fitted K-factor confirmed the dominance of the LOS component. The findings confirm that carbon fiber UAV frames can serve as effective directional antenna supports, providing proper alignment and tuning. These results support the future integration of lightweight, structure-embedded antennas in UAV systems, with potential benefits in communication efficiency, stealth, and design simplification. Full article

The growing demand for high-speed and high-capacity wireless communication has intensified the need for compact, wideband, and efficient MIMO antenna systems, particularly for 5G mid-band and UWB applications. This article presents a miniaturized dual and quad port MIMO antenna design optimized for 5G mid-band (n77/n78/n79/n96/n102) and Ultra-Wideband (UWB) applications without employing any decoupling structures between the radiating elements. The 2-port configuration features two closely spaced symmetric monopole elements (spacing < λ_max/2), promoting efficient use of space without degrading performance. An FR4 substrate (εr = 4.4) is used for fabrication with a compact size of 30 × 41 × 1.6 mm³. This layout is extended orthogonally and symmetrically to form a compact quad-port variant with dimensions of 60 × 41 × 1.6 mm³. Both designs offer a broad operational bandwidth from 2.6 GHz to 10.8 GHz (8.2 GHz), retaining return loss (S_XX) below −10 dB and strong isolation (S_XY < −20 dB at high frequencies, <−15 dB at low frequencies). The proposed MIMO antennas demonstrate strong performance and excellent diversity characteristics. The two-port antenna achieves an average envelope correlation coefficient (ECC) of 0.00204, diversity gain (DG) of 9.98 dB, and a mean effective gain difference (MEG_ij) of 0.3 dB, with a total active reflection coefficient (TARC) below −10 dB and signal delay variation under 0.25 ns, ensuring minimal pulse distortion. Similarly, the four-port design reports an average ECC of 0.01432, DG of 9.65 dB, MEG_ij difference below 0.3 dB, and TARC below −10 dB, confirming robust diversity and MIMO performance across both configurations. Full article

To achieve multi-band coverage within limited space, reduce antenna types, and enhance communication capabilities, an eight-unit dual-band 5G MIMO antenna array is proposed based on a monopole structure. The antenna operates in two frequency bands (3.23–4.14 GHz and 4.31–5.3 GHz), covering the n78 and n79 bands for 5G applications. The dual-band and miniaturized design of the antenna elements is achieved through the slotting and branch-loading techniques. The orthogonal placement of corner antenna elements is implemented to reduce coupling and optimize spatial utilization, achieving isolation of over 16 dB between elements. The introduction of a metasurface structure further improved isolation by 2 dB and increased the peak gain of the antenna array to 11.95 dBi. A prototype is fabricated and tested, demonstrating the following performance metrics: isolation exceeding 18 dB, gain ranging from 6 to 12 dBi, envelope correlation coefficient below 0.05, channel capacity greater than 41 bps/Hz, diversity gain of approximately 10 dB, total active reflection coefficient below −24 dB, and radiation efficiency exceeding 72%. These results confirm the superior performance of the proposed antenna design. Full article

This paper introduces a novel-shaped, compact, multiband monopole antenna sensor incorporating an irregular curved split-ring resonator (SRR) design for non-invasive, continuous monitoring of human blood glucose levels (BGL). The sensor operates at multiple resonance frequencies: 0.94, 1.5, 3, 4.6, and 6.3 GHz, achieving coefficient reflection impedance bandwidths ≤ −10 dB of 4%, 1%, 3.5%, 65%, and 50%, respectively. Additionally, novel shapes of two SRR metamaterial cells create notches at 1.7 GHz and 4.4 GHz. The antenna is fabricated on an economical FR4 substrate with compact dimensions of 35 × 50 × 1.6 mm³. The sensor’s performance is evaluated using 3D electromagnetic software, incorporating a human finger phantom model and applying the Cole–Cole model to mimic the blood layer’s sensitivity to blood glucose variations. The phantom model is positioned at different angles relative to the biosensor to detect frequency shifts corresponding to different glucose levels. Experimental validation involves placing a real human finger around the sensor to measure resonant frequency, magnitude, and phase changes. The fabricated sensor demonstrates a superior sensitivity of 24 MHz/mg/dL effectiveness compared to existing methods. This emphasizes its potential for practical, non-invasive glucose monitoring applications. Full article

This article presents a symmetrical reduced-size eight-element MIMO antenna array with high electromagnetic isolation among radiators. The array utilizes easy-to-build techniques to cover the n77 and n78 new radio (NR) bands. It is based on an octagonal double-negative metamaterial split-ring resonator (SRR), which enables a size reduction of over 50% for the radiators compared to a conventional disc monopole antenna by increasing the slow-wave factor. Additionally, due to the extreme proximity between the radiating elements in the array, the modal significance (MS) method was employed to identify which propagation modes had the most impact on the electromagnetic coupling among elements. This approach aimed to mitigate their effect by using an electromagnetic barrier, thereby enhancing electromagnetic isolation. The electromagnetic barriers, implemented with strip lines, achieved isolation values exceeding 20 dB for adjacent elements (<0.023 λ) and approaching 40 dB for opposite ones (<0.23 λ) after analyzing the surface current distribution by the MS method. The elements are arranged in axial symmetry, forming an octagon with each antenna port located on a side. The array occupies an area of 0.32 λ² at 3.5 GHz, significantly smaller than previously published works. It exhibits excellent performance for MIMO applications, demonstrating an envelope correlation coefficient (ECC) below 0.0001, a total active reflection coefficient (TARC) lower than −10 dB for various incoming signals with random phases, and a diversity gain (DG) close to 20 dB. Full article

In this paper, a prediction model of the coupling coefficient based on a multi-module neural network (MMNN) is developed to quickly optimize the installation position of the roof antenna of the 5G-Railway (5G-R) communication system, so as to improve the anti-interference performance of the roof antenna. Firstly, a simulation model of the coupling coefficient between the pantograph arcing and the roof antenna (a monopole antenna operating frequency of 2 GHz) was established to construct the dataset. It is also verified that the influence of the electromagnetic interference (EMI) of pantograph arcing can be significantly reduced by predicting the new installation position (minimum coupling coefficient), and the installation position optimization of roof antenna can be realized. Then, the mind evolutionary algorithm of the back propagation neural network (MEA-BP) algorithm and particle swarm optimization—extreme learning machine (PSO-ELM) algorithm were adopted, respectively. The extreme learning machine algorithm constructed a different prediction model. And, by setting the integrated strategy of piecewise prediction, the prediction results are optimized and the accuracy of the prediction model based on the MMNN is further improved. Finally, the prediction model is proven to be able to replace the complicated electromagnetic simulation work accurately and efficiently by a variety of prediction performance indices, which provides an effective prediction method for the rapid optimization of the installation position of the roof antenna. Full article

In this paper, a multi-frequency MIMO antenna for 5G and Wi-Fi 6E is presented. The antenna uses a cosine-shape monopole and split-ring resonator (SRR) structure for tri-band radiation, and frequency band expansion is achieved through SRR, folded split-ring resonators (FSRR) and Archimedean spiral metasurfaces for decoupling, with which a combination of surface wave and space wave decoupling is achieved. The Archimedean spiral metasurface unit can achieve space wave decoupling in the tri-band. By adopting the method of combining space wave decoupling and surface wave decoupling, the miniature antenna is achieved. The measured results closely align with the simulated results. Specifically, maintaining a reflection coefficient of −10 dB, the measured results indicate an increase in isolation of 3.5 dB, 36.47 dB, and 6.42 dB for the frequency bands of 3.45–3.55 GHz, 5.7–5.9 GHz, and 6.75–7 GHz, respectively. Additionally, the MIMO antenna demonstrates an average efficiency of approximately 89%, with an average envelope correlation coefficient (ECC) of 0.0025. Furthermore, the antenna’s peak gain increases by 4.3 dB at 3.5 GHz, 3.8 dB at 5.8 GHz, and 1.9 dB at 6.9 GHz upon integrating the metasurface. The proposed method and structure are anticipated to contribute significantly to decoupling in multi-frequency MIMO antennas. Full article

In this paper, a novel input impedance analysis methodology based on Babinet’s principle to broaden bandwidth is proposed, and a broadband multiple-input and multiple-output (MIMO) antenna system is designed, fabricated, and measured for fifth-generation (5G) and Wireless Fidelity (Wi-Fi) 6E/7 mobile applications. By analyzing the input impedance of open-slot antennas and planar monopole antennas using numerical calculations, the characteristics of the input impedance can be obtained. We find that combining the two antenna types in parallel can significantly enhance the bandwidth. Then, the four-dimensional image calculated by MATLAB based on the parallel impedance formula is processed to validate the methodology. Thus, a broad antenna element based on the impedance property analysis methodology is achieved, which operates ranging from 2.6 GHz to 7.46 GHz. Moreover, the equivalent circuit of the antenna element is established to further verify the validity of the methodology. Finally, a broadband MIMO antenna system consisting of eight antenna elements is designed, fabricated, and measured, and the isolation performance is better than 12 dB. Acceptable total efficiency higher than 45% is also obtained with envelope correlation coefficients (ECCs) lower than 0.05. The proposed impedance property analysis methodology innovatively proposes a new way to increase bandwidth, which can be widely applied in various antenna designs. Also, reasonable results show that the proposed MIMO antenna system is a good candidate for 5G and Wi-Fi 6E/7 mobile applications. Full article

This paper proposes the design of a compact sub-6 GHz four-port flexible antenna for utilization in 5G applications. A two-arm monopole with a coplanar waveguide feed line printed on a flexible substrate was proposed to shape the single-element antenna. The single element was designed, fabricated, and measured first; then, four copies of the single element were organized on a single flexible substrate to compose the four-port antenna. The MIMO antenna was simulated, fabricated, and experimentally measured. All the simulations and measurements of the flexible single element and MIMO antennas are presented. The presented MIMO antenna showed good impedance characteristics, with a deep level of −24 dB from 3 to 4.12 GHz. The antenna had omnidirectional and bi-directional patterns in the φ = 0° and φ = 90° planes. As an important parameter evaluation for MIMO, the mutual coupling between the different ports was investigated. The diversity gain (DG), the total active reflection coefficient (TARC), the mean effective gain (MEG), the envelop correlation coefficient (ECC), and the channel capacity loss (CCL) parameters were investigated and showed good performance. All the obtained simulation results were in a high degree of agreement with the measurement results, supporting the usage of the suggested antenna in 5G communications. Full article

Neurodegenerative diseases (NDs) can be life threatening and have chronic impacts on patients and society. Timely diagnosis and treatment are imperative to prevent deterioration. Conventional imaging modalities, such as Computed Tomography (CT), Magnetic Resonance Imaging (MRI), and Positron Emission Tomography (PET), are expensive and not readily accessible to patients. Microwave sensing and imaging (MSI) systems are promising tools for monitoring pathological changes, namely the lateral ventricle enlargement associated with ND, in a non-invasive and convenient way. This paper presents a dual-planar monopole antenna-based remote sensing system for ND monitoring. First, planar monopole antennas were designed using the simulation software CST Studio Suite. The antenna analysis was carried out regarding the reflection coefficient, gain, radiation pattern, time domain characterization, E-field distribution, and Specific Absorption Rate (SAR). The designed antennas were then integrated with a controlling circuit as a remote sensing system. The system was experimentally validated on brain phantoms using a vector network analyzer and a laptop. The collected reflection coefficient data were processed using a radar-based imaging algorithm to reconstruct images indicating brain abnormality in ND. The results suggest that the system could serve as a low-cost and efficient tool for long-term monitoring of ND, particularly in clinics and care home scenarios. Full article

In this article, a compact 4-port UWB (Ultra-Wide Band) MIMO (Multiple Input Multiple Output) antenna is proposed. A low profile FR-4 substrate is used as a dielectric material with the dimensions of 58 × 58 mm² (0.52λ × 0.52λ) at 2.8 GHz and a standard thickness of 1.6 mm. The proposed design characterizes an impedance bandwidth starting from 2.8 to 12.1 GHz (124.1%). Each of the four elements of the proposed MIMO antenna configuration consists of a monopole antenna with PG (partial ground) that has a slot at its center. The corner of each patch (radiator) and ground slot are rounded for impedance matching. Each unit cell is in an orthogonal orientation, forming a quad-port MIMO antenna system. For reference, the partial ground of each unit cell is connected meticulously with the others. The simulated results of the proposed quad-port MIMO antenna design were configured and validated by fabrication and testing. The proposed Quad-port MIMO design has a 6.57 dBi peak gain and 97% radiation efficiency. The proposed design has good isolation below 15 dB in the lower frequency range and below 20 dB in the higher frequency range. The design has a measured ECC (Envelop Correlation Co-efficient) of 0.03 and DG (Diversity Gain) of 10 dB. The value of TARC (Total Active Reflection Coefficient) over the entire operating band is less than 10 dB. Moreover, the design maintained CCL (Channel Capacity Loss) < 0.4 bits/sec/Hz and MEG (Mean Effective Gain) < 3 dB. Based on the obtained results, the proposed design is suitable for the intended high data rate UWB wireless communication portable devices. Full article

In this paper, a compact and simplified geometry monopole antenna with high gain and wideband is introduced. The presented antenna incorporates a microstrip feedline and a circular patch with two circular rings of stubs, which are inserted into the reference circular patch antenna to enhance the bandwidth and return loss. Roger RT/Duroid 6002 is used as the material for the antenna, and has overall dimensions of W_S × L_S = 12 mm × 9 mm. Three designs of two-port MIMO configurations are derived from the reference unit element antenna. In the first design, the antenna element is placed parallel to the reference antenna, while in the second design, the element is placed orthogonal to the reference element of the antenna. In the third design, the antenna elements are adjusted to be opposite each other. In this study, we analyze the isolation between the MIMO elements with different arrangements of the elements. The MIMO configurations have dimensions of 15 mm × 26 mm for two of the cases and 15 mm × 28.75 mm for the third case. All three MIMO antennas are made using similar materials and have the same specifications as the single element antenna. Other significant MIMO parameters, including the envelope correlation coefficient (ECC), diversity gain (DG), channel capacity loss (CCL), and mean effective gain (MEG), are also researched. Additionally, the paper includes a table summarizing the assessment of this work in comparison to relevant literature. The results of this study indicate that the proposed antenna is well-suited for future millimeter wave applications operating at 28 GHz. Full article

The noise radiated by the flow around a cylinder in the subcritical regime at $R{e}_D=1\times {10}^4$ and at a subsonic Mach number of $M=0.5$ is here studied. The aerodynamic sound radiated by a cylinder has been studied with a wide range of Reynolds numbers, but there are no studies about how the Mach number affects the acoustic field in the subsonic regime. The flow field is resolved by means of large-eddy simulations of the compressible Navier–Stokes equations. For the study of the noise propagation, formulation 1C of the Ffowcs Williams–Hawkings analogy is used. The fluid flow results show good agreement when comparing the surface pressure coefficient, the recirculation length, the vortex shedding frequency and the force coefficients against other studies performed under similar conditions. The dynamic mode decomposition of the pressure fluctuations is used to relate them with the far-field noise. It is shown that, in contrast to what happens for low Mach numbers, quadrupoles have a significant impact mainly in the observers located in the streamwise direction. This effect leads to a global monopole directivity pattern as the shear fluctuations compensate for the lower value of the aeolian tone away from the cross-stream direction. Full article

Spectrum sensing is an important aspect in cognitive radio (CR) networks as it involves the identification of unused frequency spectra, which saves both bandwidth and energy. The design of a compact super-wideband (SWB) multi-input multi-output (MIMO)/diversity antenna with triple-band-notched features is presented for spectrum sensing in CR systems. The MIMO antenna comprises four identical semi-elliptical-shaped monopole resonators, which are orthogonally positioned and excited individually via tapered coplanar waveguide feed lines. Also, a mirror-slot analogous to the radiator is etched in the ground conductor of each antenna element to achieve SWB characteristics. In order to avoid interference with the SWB, the antenna radiator is loaded with a staircase-shaped slit and a pair of concentric slits, arranged like a complementary split-ring resonator. The antenna resonates from 1.2 to 43 GHz, exhibiting a bandwidth ratio of 36:1. In the MIMO antenna, the antenna elements are located orthogonally, and the isolation > 18 dB and envelope correlation coefficient < 0.01 are realized in the resonating band. The antenna offers a peak gain of 4 dBi, and a sharp reduction in gain at notch frequencies (3.5 GHz, 5.5 GHz, and 8.5 GHz) is achieved. The size of the MIMO antenna is 52 mm × 52 mm. The proposed compact-size antenna features a high bandwidth ratio and straightforward design procedure, and can be simply integrated into contemporary RF equipment. The presented SWB MIMO antenna outperforms SWB antenna designs reported in the open literature, which featured one or two notched bands, whereas it has three notched bands. Also, the three notches in the SWB are achieved without the use of any filters, which simplifies the antenna development process. Full article
