The dispersion behavior of ceramic particles in aluminum alloys during rapid solidification critically affects the resulting microstructure and mechanical performance. In this study, we investigated the nucleation and growth of Al₃(Sc,Zr) on TiB₂ surfaces in a 2TiB₂/Al–8Ni–0.6Sc–0.1Zr alloy, fabricated via wedge-shaped copper mold casting and laser surface remelting. Thermodynamic calculations were employed to optimize alloy composition, ensuring sufficient nucleation driving force under rapid solidification conditions. The results show that the formation of Al₃(Sc,Zr)/TiB₂ composite interfaces is highly dependent on cooling rate and plays a pivotal role in promoting uniform TiB₂ dispersion. At an optimal cooling rate (~1200 °C/s), Al₃(Sc,Zr) nucleates heterogeneously on TiB₂, forming core–shell structures and enhancing particle engulfment into the α-Al matrix. Orientation relationship analysis reveals a preferred (111)α-Al//(0001)TiB₂ alignment in Sc/Zr-containing samples. A classical nucleation model quantitatively explains the observed trends and reveals the critical cooling-rate window for composite interface formation. This work provides a mechanistic foundation for designing high-performance aluminum-based composites with uniformly dispersed reinforcements for additive manufacturing applications. Full article

The polytetrafluoroethylene/aluminum (PTFE/Al) granular composite, a common formulation in impact-initiated energetic materials, undergoes mechanochemical coupling reactions under sufficiently strong dynamic loading. This investigation discusses the dynamic properties and the constitutive relationship of the PTFE/Al granular composite to provide a preliminary guide for the research on mechanical properties of a series of composite materials based on PTFE/Al as the matrix. Firstly, the 26.5Al-73.5PTFE (wt.%) composite specimens are prepared by preprocessing, mixing, molding, high-temperature sintering, and cooling. Then, the quasi-static compression and Hopkinson bar tests are performed to explore the mechanical properties of the PTFE/Al composite. Influences of the strain rate of loading on the yield stress, the ultimate strength, and the limited strain are also analyzed. Lastly, based on the experimental results, the material parameters in the Johnson–Cook constitutive model are obtained by the method of piecewise fitting to describe the stress–strain relation of the PTFE/Al composite. Combining the experimental details and the obtained material parameters, the numerical simulation of the dynamic compression of the PTFE/Al composite specimen is carried out by using the ANSYS/LS-DYNA platform. The results show that the computed stress–strain curves present a reasonable agreement with the experimental data. It should be declared that this research does not involve the energy release behavior of the 26.5Al-73.5PTFE (wt.%) reactive material because the material is not initiated within the strain rate range of the dynamic test in this paper. Full article

We have improved the efficiency of the protection of occupants of cars by effectively reducing the injury and mortality rate caused by accidents when using safety belts. To ensure the protection efficiency of the safety belt outlet cover, we tested and adjusted the following parameters: the filling time, flow-front temperature and switching pressure, injection position pressure, locking force, shear rate, shear force, air hole, melting mark, material flow freezing-layer factor, volume shrinkage rate during jacking out, coolant temperature and flow rate in the cooling stage, part temperature, mold temperature difference, deflection stage, warping deformation analysis, differential cooling, differential shrinkage, and directional effect. Full article

This study investigates a hybrid manufacturing approach that combines 3D printing and injection molding to extend the limitations of each individual technique. Injection molding is often limited by high initial tooling costs, long lead times, and restricted geometric flexibility, whereas 3D-printed molds tend to suffer from material degradation, extended cooling times, and lower surface quality. By integrating 3D-printed molds into the injection-molding process, this hybrid method enables the production of complex geometries with improved cost-efficiency. The approach is demonstrated using a range of polymeric materials, including ABS, nylon, and polyurethane foam—each selected to enhance the mechanical and thermal performance of the final products. Finite element method (FEM) analysis was conducted to assess thermal distribution, deformation, and stress during manufacturing. Results indicated that both temperature and stress remained within safe operational limits for 3D-printed materials. An economic analysis revealed substantial cost savings compared to fully 3D-printed components, establishing hybrid manufacturing as a viable and scalable alternative. This method offers broad industrial applicability, delivering enhanced mechanical properties, design flexibility, and reduced production costs. Full article

The addition of beryllium (Be) to Al–Cu alloys enhances their mechanical properties and corrosion resistance. This study aims to investigate the effects of solidification cooling rates and the addition of Be on the microstructural refinement and corrosion behavior of an Al–5wt.%Cu–1wt.%Si–0.5wt.%Be alloy. Radial solidification under unsteady-state conditions was performed using a stepped brass mold, producing four distinct cooling rates. An experimental growth law, λ₂ = 26${\dot{\mathrm{T}}}^{-1/3}$, was established, confirming the influence of Be and the cooling rate on dendritic size reduction. The final microstructure was characterized by an α-Al dendritic matrix with eutectic compounds (α-Al + θ-Al₂Cu + Si + Fe-rich phase) confined to the interdendritic regions. No Be-containing intermetallic phases were detected, and beryllium remained homogeneously distributed within the eutectic. Notably, Be addition promoted a morphological transformation of the Fe-rich phases from angular or acicular forms into a Chinese-script-like structure, which is associated with reduced local stress concentrations. Tensile tests revealed an ultimate tensile strength of 248.8 ± 11.2 MPa and elongation of approximately 6.4 ± 0.5%, indicating a favorable balance between strength and ductility. Corrosion resistance assessment by EIS and polarization tests in a 0.06 M NaCl solution showed a corrosion rate of 28.9 µm·year⁻¹ and an Epit of −645 mV for the Be-containing alloy, which are lower than those measured for the reference Al–Cu and Al–Cu–Si alloys. Full article

Based on a novel ternesite sulphoaluminate cement (NTSAC), the effects of various influencing factors on the calcination of clinker were studied, including mineral composition of clinker, grinding fineness of raw materials, molding technology of samples, and cooling methods of clinker. The research was carried out by taking the calcination system and mineral content of clinker as evaluation indexes, and using RSM and QXRD as analytical means. The results indicate that the optimal calcination temperature of clinker varies with the design mineral composition, while the holding time remains basically unchanged. Clinker with high CaSO₄ content has a relatively lower calcination temperature. The use of a calcination system of 1175 °C-49 min can control the mineral content error of the cement below 15%. Moreover, the molding pressure, molding methods, grinding fineness of raw materials, and cooling methods of clinker have significant effects on the clinker preparation to varying degrees, with the order of influence from high to low being molding methods, grinding fineness of raw materials, molding pressure, and cooling methods of clinker. Within the range of experimental parameters, the better preparation conditions are compression molding (molding method), 15 MPa (molding pressure), and 20 μm (grinding fineness). The above research conclusions provide reference data for cement preparation in the laboratory, offering useful guidance for developing novel types of cement. Full article

In recent years, plastic decorative materials have been used in the automotive industry due to their advantages such as being environmentally friendly, aesthetic, light and economically affordable. Plastic decorative materials can exhibit high strength and metallic reflection with metal coatings. Chrome plating is generally preferred in the production of decorative plastic parts in the automotive industry. In this study, the effect of injection molding processing parameters on the metal–polymer adhesion of chrome-plated acrylonitrile butadiene styrene (ABS) was investigated. The ABS-based front grille frames are fabricated by means of using an industrial-scale injection molding machine. Then, the fabricated ABS-based front grille frame was plated with chrome by means of the electroplating method. The metal–polymer adhesion was investigated as a function of the injection molding processing parameters by means of a cross-cut test and scanning electron microscope (SEM). As a result, it was determined that the optimal injection process parameters, a cooling time of 18 s, a mold temperature of 70 °C, injection rates of 45-22-22-20-15-10 mm/s, and packing pressures of 110-100-100 bar, were effective in enhancing polymer–metal adhesion for the ABS-based front grille frame. Full article

This study explores the thermophysical properties and crystallization behavior of two industrial Mold Fluxes (MF1 and MF2) used in continuous steel casting. Viscosity, density, and surface tension were measured using the Rotating Bob Viscometry (RBV) and the Maximum Bubble Pressure (MBP) method, while crystallization dynamics were assessed via the Single Hot Thermocouple Technique (SHTT). Both fluxes showed temperature-dependent viscosity with distinct break temperatures influenced by chemical composition. MF1 had higher viscosity and activation energy (127.72 kJ mol⁻¹) than MF2 (112.11 kJ mol⁻¹) due to its higher Al₂O₃ content. Density and surface tension decreased linearly from 1523 to 1623 K, with values of 2642–2618 kg m⁻³ and 299–291 mN m⁻¹ for MF1, and 2708–2656 kg m⁻³ and 348–305 mN m⁻¹ for MF2. Crystallization analysis showed that MF1 required higher cooling rates (critical cooling rates: 21 K s⁻¹ vs. 18 K s⁻¹ for MF2) for glass formation, highlighting its greater glass-former content. Full article

This work investigates the time-dependent changes in temperature, flow, and solidification microstructure under various cooling conditions. The mechanism of the effects of different pouring temperatures on the morphology and evolution of the solidification microstructure is explored. During gradual cooling, the temperature distribution remained consistent and the solid–liquid interface extended to its furthest extent. In contrast, water cooling generated the most pronounced temperature gradient at the solidification front, which was conducive to the development of columnar grains. Specifically, the maximum solidification rates at the center of the casting under the water-cooled copper mold, copper mold, and ceramic mold conditions were 2.71 mm/s, 1.45 mm/s, and 0.95 mm/s, respectively, with water cooling achieving the fastest rate. In the early stages of solidification, the flow velocity at the casting center was relatively high, and during slow cooling, the molten material tended to flow toward the surface. When air cooling was applied, the molten material at the center migrated outward, while under water cooling, the fluid moved in an upward direction. At a heat transfer coefficient of 100 W/(m²·K), the alloy primarily formed equiaxed grains; however, at 5000 W/(m²·K), the proportion of columnar grains increased significantly, and the average grain area expanded from 3.664 × 10⁻⁶ m² to 4.441 × 10⁻⁶ m². Additionally, as the pouring temperature increased from 1100 °C to 1200 °C, the number of grains decreased, while the average radius grew from 1.665 × 10⁻³ m to 1.820 × 10⁻³ m, resulting in a reduced fraction of equiaxed grains. This study provides valuable theoretical insights for optimizing the solidification process of this particular alloy. Full article

This study developed a multi-objective optimization procedure aimed at minimizing surface roughness and volumetric shrinkage in injection-molded products. Surrogate models for both outputs were constructed using the Kriging technique, based on experimental data and seven input parameters: packing pressure, mold temperature, cooling time, injection speed, injection pressure, melt temperature, and packing time. A multi-objective optimization problem was formulated and solved using the pattern search algorithm, generating a Pareto front that highlights the trade-off between the two objectives. This Pareto front was further analyzed to determine three optimal parameter sets. The first point minimizes volumetric shrinkage at 1.9314 mm³ but results in the highest surface roughness of 0.55956 µm. In contrast, the second point yields the lowest surface roughness of 0.20557 µm but the highest volumetric shrinkage of 3.9286 mm³. The third point offers the best compromise between the two objectives, with a volumetric shrinkage of 2.2348 mm³ and surface roughness of 0.28246 µm. The proposed approach provides an experimentally validated tool for plastic engineers, enabling informed parameter adjustments to achieve optimal trade-offs in surface quality and dimensional stability within practical manufacturing constraints. Full article

The material in the mold of the injection-molding machine releases significant latent heat of solidification during the cooling process. The efficient recovery and utilization of this waste heat is crucial for improving energy efficiency. A novel integrated energy management system for mold cooling/heat pump/material preheating is proposed in this paper. Taking the symmetrical thermodynamic performance of the heat pump components as the basis and optimizing the system configurations, four system configurations were investigated: MC/BHP/MPCC, MC/RHP/MPCC, MC/HP/MP-IEMS, and MC/DCHP/MP-IEMS, utilizing EBSILON software. The performance of the systems was evaluated through the coefficient of performance (COP) and whole cycle energy efficiency (η). The T-q, T-s, and P-h diagrams were analyzed. It was found that, under comparative operating conditions, both the MC/HP/MP-IEMS and MC/DCHP/MP-IEMS systems exhibited significantly higher COP and η than the MC/BHP/MPCC and MC/RHP/MPCC systems. MC/HP/MP-IEMS achieves a COP of 13.66 and η of 22.09. Similarly, MC/DCHP/MP-IEMS achieves a COP of 14.00 and η of 22.53. The paper optimizes the other three systems using MC/BHP/MPCC as the comparison condition. Optimal cycle performances are achieved with COP and η values of 9, 16, 16, and 9, 26, 25, respectively. A comparison of the thermodynamic performance of five different refrigerants revealed that R123 and R245fa have superior overall performance. This study provides theoretical support for the engineering implementation of integrated energy management systems for injection-molding machines. Full article

In the continuous casting of special steel blooms, low casting speeds result in slow renewal of the molten steel surface in the mold, adversely affecting mold flux melting and liquid slag layer supply, which may lead to surface cracks, slag entrapment, and breakout incidents. To optimize the flow and heat transfer behavior in the mold, a three-dimensional numerical model was developed based on the VOF multiphase flow model, $k-ϵ$ RNG turbulence model, and DPM discrete phase model, employing the finite volume method with SIMPLEC algorithm for solution. The effects of casting speed, argon injection rate, and mold flux properties were systematically investigated. Simulation results demonstrate that when casting speed increases from 0.35 m·min⁻¹ to 0.75 m·min⁻¹, the jet penetration depth increases by 200 mm and meniscus velocity rises by 0.014 m·s⁻¹. Increasing argon flow rate from 0.50 L·min⁻¹ to 1.00 L·min⁻¹ leads to 350 mm deeper bubble penetration, 10 mm reduction in jet penetration depth, 0.002 m·s⁻¹ increase in meniscus velocity, and decreased meniscus temperature due to bubble cooling. When mold flux viscosity increases from 0.2 Pa·s to 0.6 Pa·s, the average liquid slag velocity decreases by 0.006 m·s⁻¹ with a maximum temperature drop of 10 K. Increasing density from 2484 kg·m⁻³ to 2884 kg·m⁻³ results in 0.005 m·s⁻¹ higher slag velocity and average 8 K temperature reduction. Comprehensive analysis indicates that optimal operational parameters are casting speed 0.35–0.45 m·min⁻¹, argon flow ≤ 0.50 L·min⁻¹, mold flux viscosity 0.2–0.4 Pa·s, and density 2484–2684 kg·m⁻³. These conditions ensure more stable flow and heat transfer characteristics, effectively reducing slab defects and improving casting process stability. Full article

A gauge plate is a typical thick-walled injection-molded component featuring a complex construction used in high-speed railways, and it is prone to sink voids during the injection process. It is difficult to obtain a void-free injection molded part due to uneven cooling-induced localized thermal gradients, crystallization shrinkage of semicrystalline thermoplastics, fiber orientation-induced anisotropic shrinkage, injection parameter-dependent fountain flow, and inconsistent core compensation. This work employed design of experiment (DOE) and computer-aided engineering (CAE) simulations to analyze the influence of injection parameters on the volumetric shrinkage of the gauge plate and to identify the optimal injection process. A Taguchi orthogonal array L9 was applied, in which four injection molding process parameters were varied at three different levels. The fundamental causes of sink void defects in the gauge plate were then examined via MoldFlow analysis on the basis of the optimized injection parameters. The MoldFlow study indicates a high probability of the presence of sink void defects in the injection-molded gauge plate. To minimize sink void defects, a structural optimization design of the gauge plate was implemented to achieve a more uniform wall thickness, and the advantages of this optimization were demonstrated via comparative analysis. The small batch production of the injection-molded gauge plates demonstrates that the optimized gauge plate shows no sink voids, ensuring consistent quality that adheres to the engineering process and technical specifications. Full article

This study elucidates the underlying formation mechanisms and mitigation strategies for the W-shaped solidification profile in slab continuous casting. Through the development of a multiphysics coupling numerical model, integrated with measured nozzle cooling characteristics in the secondary cooling zone, the effect of steel flow patterns in mold and non-uniform cooling conditions in the secondary cooling zone on solidifying shell evolution is systematically studied. A principal finding is that wide-face shell erosion, induced by both the radial expansion jet and the lower recirculation, constitutes the primary determinant of uneven shell thickness. An increase in the immersion depth and inclination angle of the nozzle side-hole exacerbates the non-uniformity of the solidified shell. Non-uniform cooling in the secondary cooling zone further amplifies the shell thickness differences, culminating in characteristic dumbbell-shaped solidified shell geometry. Strategic implementation of localized enhanced cooling on the wide face in the secondary cooling zone demonstrates significant improvement in shell uniformity, with implementation efficacy contingent upon a critical process window (Segments 1–6). These findings establish mechanistic foundations and deliver practical guidance for minimizing centerline segregation through optimized continuous casting parameter configuration. Full article

The use of conformal cooling channels (CCC) in the injection molding process has revolutionized the polymer industry by enhancing part cooling uniformity and improving cooling efficiency, minimizing undesired defects such as warpage and shrinkage inherent to the process. This review paper provides a detailed investigation of the literature on CCC, with special focus on how computational fluid dynamics (CFD) has been employed to analyze and optimize the thermal performance of the cooling system. Additionally, key aspects of CCC design, including geometry optimization, surface roughness, and flow dynamics, are evaluated to improve cooling efficiency, reduce cycle time, and enhance product quality. Several CFD-based studies are reviewed to highlight commonly used simulation methods and CCC optimization approaches for heat transfer enhancement. Particular attention is given to how simulation tools contribute to design improvement and decision-making, addressing practical constraints related to thermal behavior and manufacturability. Key performance parameters such as pressure drop, temperature uniformity, cooling time, and manufacturing limitations are examined and compared, offering a foundation for future directions to advance CCC design and CFD analysis to optimize injection molding. Aiming at contributing to the academia and the industry, the novelty of this review paper lies in its integrative perspective, providing a comprehensive analysis of coupling designing tasks with CFD simulations. As a result, this paper serves as a valuable resource for researchers and industry professionals aiming to leverage CFD for the development of high-performance, energy-efficient CCC. Full article
