Search Results (46)

Recent technological advancements have resulted in the emergence of portable electronic devices (PEDs), including mobile phones equipped with satellite communication capabilities. These devices generally emit higher power, which can potentially cause electromagnetic interference to GPS antennas. This study uses both simulation and experimental methods to evaluate the interference path loss (IPL) between PEDs located inside an A320 aircraft and an external GPS antenna. The effects of PED location, antenna polarization, and frequency bands on IPL were simulated and analyzed. Additionally, measurement experiments were conducted on an A320 aircraft, and statistical methods were used to compare the experimental data with the simulation results. Considering the front-door coupling of both spurious and intentional radiated emissions, the measured IPL is up to 15 ± 3 dB lower than the $IP{L}_{target}$. This result should be interpreted with caution. This issue offers new insights into the potential risks of electromagnetic interference in aviation environments. The findings help quantify the probability of interference with GPS antennas. Furthermore, the modeling simplification method used in this study may be applicable to the analysis of other large and complex structures. Full article

This article focuses on the assessment of point clouds obtained by various laser scanning methods as a tool for 3D mapping and Digital Twin concepts. The presented research employed terrestrial and mobile laser scanning methods to obtain high-precision spatial data, enabling efficient spatial documentation of urban structures and infrastructure. As a reference method, static terrestrial laser scanning (TLS) was chosen. Mobile laser scanning (MLS) data obtained by devices such as Lidaretto, the Stonex X120GO laser scanning device, and an iPhone 13 Pro with an Emlid scanning kit and GNSS antenna Reach RX were evaluated. Analyses based on comparing methods of classification, differences in individual objects, detail/density, and noise were performed. The results confirm the high accuracy of the methods and their ability to support the development of digital twins and smart solutions that enhance the efficiency of infrastructure management and planning. Full article

This article introduces a novel biodegradable metasurface-loaded mobile phone back cover designed to reduce electromagnetic exposure and enhance antenna performance. The cover operates across the low GHz band (2–8 GHz) and the millimeter-wave band (22–25.6 GHz), utilizing polylactic acid as an eco-friendly substrate. Integrated with a six-port multiple-input multiple-output (MIMO) antenna system, the cover achieves port isolation above 20 dB in both bands. Specific absorption rate (SAR) analysis, performed using a human head model, shows significant reductions in electromagnetic exposure—61.1% in the low GHz band (from 1.06 W/kg to 0.412 W/kg) and 55% in the millimeter wave band (from 2.061 W/kg to 0.917 W/kg). Additionally, the metasurface cover enhances antenna gain and increases impedance bandwidth by 20% in the low GHz band and 8.3% in the millimeter-wave band. A comparative study highlights superior SAR reduction and bandwidth improvement of a metasurface on a biodegradable substrate over one on a silicone substrate. Prototypes of the MIMO antenna and the proposed cover were fabricated and tested, revealing strong alignment between simulated and measured results. These findings highlight the potential of biodegradable metasurface-based covers to deliver high-performance, sustainable solutions for mobile communication devices. Full article

This article introduces a broadband sub-6 GHz 8 × 8 MIMO (multi-input multi-output) antenna array for 5G (fifth-generation) metal-frame mobile phone applications. The unique advantage of this compact antenna design is its placement in the corners of the mobile phone, allowing for significant PCB board space reduction. The proposed antenna’s 6 dB impedance bandwidth ranged from 3.3 to 6 GHz, covering the n77/78/79 and WiFi-5GHz bands. The main radiating element was an open-slot antenna coupled by a T-shaped structure connected to a 50-Ω transmission line. The size of the single-antenna element was 12.25 mm × 2.5 mm × 7 mm, and these antennas were symmetrical at four corners of the smartphone. A wide slot and neutral line were incorporated to reduce mutual coupling between adjacent antennas. The MIMO antenna array achieved isolation above 12 dB. The peak realized gain ranged from 2 to 5.28 dBi, and the total efficiency spanned 37% to 71%. The ECC (envelope correlation coefficient) was less than 0.34, and the CC (channel capacity) ranged from 33 and 41 bps/Hz. Full article

There is growing international interest in assessing population exposure to radiofrequency electromagnetic fields, especially those generated by mobile-phone base stations. The work presented here is an experimental study in which we assess exposure to radiofrequency electromagnetic fields in a university environment, where there is a site with mobile-phone antennas and where a large number of people live on a daily basis. The data were collected with a personal exposure meter in two samplings, one walking at ground level and the other using an aerial vehicle at a height higher than the buildings. The geo-referenced electric-field data were subjected to a process in which a theoretical model was adjusted to the experimental variograms, and heat maps were obtained using kriging interpolation. The research carried out is of great relevance, since it provides detailed measurements of the electromagnetic radiation levels both at ground level and at significant heights, using innovative methodologies such as the use of drones. Furthermore, the results obtained allow for contextualizing the exposures in relation to international safety limits, highlighting the importance of rigorous monitoring in everyday environments. Full article

With the rapid consumer adoption of mobile devices such as tablets and smart phones, tele-traffic has experienced a tremendous growth, making low-power technologies highly desirable for future communication networks. In this paper, we consider an ambient backscatter (AB)-based user cooperation (UC) scheme for mmWave wireless-powered communication networks (WPCNs) with lens antenna arrays. Firstly, we formulate an optimization problem to maximize the minimum rate of two users by jointly designing power and time allocation. Then, we introduce auxiliary variables and transform the original problem into a convex form. Finally, we propose an efficient algorithm to solve the transformed problem. Simulation results demonstrate that the proposed AB-based UC scheme outperforms the competing schemes, thus improving the fairness performance of throughput in WPCNs. Full article

This study introduces RTEEMF (Real-Time Evaluation Electromagnetic Field)-PhoneAnts, a novel Deep Learning (DL) framework for the efficient evaluation of mobile phone antenna performance, addressing the time-consuming nature of traditional full-wave numerical simulations. The DL model, built on convolutional neural networks, uses the Near-field Electromagnetic Field (NEMF) distribution of a mobile phone antenna in free space to predict the Effective Isotropic Radiated Power (EIRP), Total Radiated Power (TRP), and Specific Absorption Rate (SAR) across various configurations. By converting antenna features and internal mobile phone components into near-field EMF distributions within a Huygens’ box, the model simplifies its input. A dataset of 7000 mobile phone models was used for training and evaluation. The model’s accuracy is validated using the Wilcoxon Signed Rank Test (WSR) for SAR and TRP, and the Feature Selection Validation Method (FSV) for EIRP. The proposed model achieves remarkable computational efficiency, approximately 2000-fold faster than full-wave simulations, and demonstrates generalization capabilities for different antenna types, various frequencies, and antenna positions. This makes it a valuable tool for practical research and development (R&D), offering a promising alternative to traditional electromagnetic field simulations. The study is publicly available on GitHub for further development and customization. Engineers can customize the model using their own datasets. Full article

Polymer materials with a low dielectric constant and low dielectric loss have the potential to be applied to high-frequency signal transmissions, such as mobile phone antennas and millimeter wave radars. Two types of diamines, 4,4′-diamino-p-tetraphenyl (DPT) and crown ether diamine (CED), were prepared for ternary copolymerization with BPDA in this study. Cross-links with molecular chains were formed, increasing molecular chain distance by utilizing rings of CED. The MPI films exhibit a good thermal performance with the increase in CED addition, with Tg > 380 °C and CTE from −4 × 10⁻⁶ K⁻¹ to 5 × 10⁻⁶ K⁻¹. The Young’s modulus can reach 8.6 GPa, and the tensile strength is above 200 MPa when 5% and 7% CED are introduced. These MPI films exhibit good mechanical performances. The dielectric constant of PI−10% film can go as low as 3.17. Meanwhile, the relationship between dielectric properties and molecular structure has been demonstrated by Molecular Simulation (MS). PI molecules are separated by low dielectric groups, resulting in a decrease in the dielectric constant. Full article

Smart NFC tags are seeing many interesting applications and can benefit from further miniaturization. A passive temperature sensing tag with 5.1 mm diameter is demonstrated, comprising a thin-film microfabricated antenna and an NFC chip. The microantenna/coil comprises two 15 µm-thick electroplated copper layers embedded in SU-8, withstanding the soldering process of a BGA NFC IC. The µ-antenna design challenge is to miniaturize while minimizing performance impairment (inductive-coupling distance), while the micromachining process is very dependent on topography propagation. Fabricated coils were successfully characterized (2.32 µH inductance; 13.76 MHz self-resonance) and temperature was read (after assembly) with a mobile phone at distances of up to 7 mm. Full article

This paper proposes an eight-element dual-band multiple-input multiple-output (MIMO) antenna that operates in the fifth generation (5G), n78 (3400–3600 MHz), and WLAN (5275–5850 MHz) bands to accommodate the usage scenarios of 5G mobile phones. The eight antenna elements are printed on two long frames, which significantly reduce the usage of the internal space of the mobile phone. Each antenna element is printed on both surfaces of one frame, which consists of a radiator on the internal surface and a defected ground plane on the outer surface. The radiator is a rectangular ring fed by a 50 Ω microstrip line which is printed on the top surface of the system board. A parasitic unit is printed on the outer surface of each frame, which is composed of an inverted H-shaped and four L-shaped patches. Each parasitic unit is connected to the internal surface of the frames through a via, and then it is connected to a 1.5 mm wide microstrip line on the top surface of the system board, which is connected to the ground plane on the bottom surface of the system board by a via. Four L-shaped slots, four rectangular slots, and four U-shaped slots are etched onto the system board, which provides good isolation between the antenna elements. Two merged rectangular rings are printed on the center of each frame, which improves the isolation further. The return loss is better than 6 dB, and the isolation between the units is better than 15 dB in the required working frequency bands. In addition, the use of a defected ground structure not only makes the antenna element obtain better isolation but also improves the overall working efficiency. The measurement results show that the proposed MIMO antenna structure can be an ideal solution for 5G and WLAN applications. Full article

Deep Brain Stimulation (DBS), also known as the brain pacemaker, has gradually evolved from a scientific experiment into an effective clinical treatment for movement disorders as a method of improving movement disorders. At present, there are few studies on the effects of 5G mobile phone antenna radiation on the heads of adult patients implanted with DBS. In this study, COMSOL Multiphysics was used to establish a mobile phone model with a 5G/4G patch antenna, a real human head, and the DBS models. Then, we calculated the specific absorption rate (SAR) of various layers of the head tissues with the mobile phone at different distances from the human head, as well as the temperature change rule of the head and the DBS irradiated by the antenna for 30 min. The simulation results showed that when the frequency is 3500 MHz, the electromagnetic radiation of the phone to the patient’s head is generally greater than that of the 2400 MHz. When at 3500 MHz, the distance between the phone and the head is inversely proportional to the SAR value; thus, when the distance between the phone and the head is 1 cm, the maximum SAR value—which is 1.132 W/kg—appeared in the skin layer of the head with implanted DBS. But it is worth noting that the largest temperature rise appeared in the brain layer at 2400 MHz and at a distance of 1 cm, which is 0.2148 °C. Although the SAR values and temperature rise obtained from all simulations are below the limits of 2 W/kg and +1 °C specified by the International Commission on Non-Ionizing Radiation Protection (ICNIRP), we still recommend that patients with implanted DBS maintain a distance when using the phones. Full article

This paper presents a design and performance analysis of a 10-element 5G massive Multiple Input Multiple Output (m-MIMO) antenna array for sub-6 GHz mobile handsets, specifically for Long Term Evolution (LTE) bands 43 (3600–3800 MHz) and 48/49 (3550–3700 MHz) applications. The proposed antenna array consists of ten closely spaced inverted-F antennas with a compact size of 20 × 9 mm${}^2$ of a single element. The proposed antenna array provides high efficiency and low correlation between the antenna elements, which result in increased data rate and enhanced signal quality. The performance of the antenna array is evaluated in terms of the radiation pattern, diversity gain, efficiency, and correlation coefficient. The simulation and measured results show that the proposed antenna array achieves an approximate peak gain of 2.8 dBi and a total efficiency of 65% at the resonance frequency of 37 GHz and a low correlation coefficient of 0.07 between the adjacent antenna elements. Moreover, the single and two-hand modes are also given in order to highlight the potential of such a structure as a smart mobile terminal. The simulated results are discovered to be in excellent agreement with the measured values. We think this structure has a bright future in the next generation of smart mobile phones based on the performance and the measured findings. Full article

The COVID-19 pandemic affected many aspects of human mobility and resulted in unprecedented changes in population dynamics, including lifestyle and mobility. Recognizing the effects of the pandemic is crucial to understand changes and mitigate negative impacts. Spatial data on human activity, including mobile phone data, has the potential to provide movement patterns and identify regularly visited locations. Moreover, crowdsourced geospatial information can explain and characterize the regularly visited locations. The analysis of both mobility and routine locations in the same study has seldom been carried out using mobile phone data and linked to the effects of the pandemic. Therefore, in this article we study human mobility patterns within Portugal, using mobile phone and crowdsourced data to compare the population’s mobility and routine locations after the pandemic’s peak. We use clustering algorithms to identify citizens’ stops and routine locations, at an antenna level, during the following months after the pandemic’s first wave and the same period of the following year. Results based on two mobile phone datasets showed a significant difference in mobility in the two periods. Nevertheless, routine locations slightly differ. Full article

Quantum Key Distribution (QKD) is popular for establishing a native secure quantum communication network. However, existing QKD networks are built via classical wired fiber channels; it is difficult to distribute quantum keys directly into mobile phones, and no effective candidate solution is available yet. This paper presents a novel Flexible Physical Layer Authentication (FPLA) mechanism that exploits the unique characteristic of wireless signals from mobile phones to securely distribute quantum keys via wireless 5G channels. In particular, a 5G Up-Link Sounding Reference Signal (SRS)-based transmission model is developed to capture and extract the unique characteristic, which is then used to distribute quantum keys. Moreover, the model could lose accuracy due to SRS variations introduced by 5G Multiuser Multiple-Input Multiple-Output (MU-MIMO), so a dimensional transformation residual network is designed to classify legitimate and malicious user equipment (UE). An average authentication accuracy of 96.8% is proved by FPLA in multiple experiments in a 3 dB Signal-to-Noise Ratio (SNR) test environment with a training dataset of 300 samples per malicious UE. Simulation results show that FPLA is able to adapt to antenna diversity in 5G MU-MIMO systems. Full article

This paper presents the design and realization of a simple and low-profile, four-port multiple-input-multiple-output (MIMO) antenna operating in a mm-wave band supporting 5G communication technologies. As part of the design methodology, the initial stage involved the development of a conventional monopole patch antenna optimized for operation at 26 GHz, which was matched to a 50 Ω stepped feed line. Afterward, a square-shaped defected ground structure (DGS) with semi-circle slots on the edges was placed on the ground to improve the isolation, and the circular and rectangular slots were incorporated as DGSs to optimize the antenna impedance bandwidth. Etching semi-circular-shaped slots on the ground plane achieved more than 34.2 dB isolation in the 26 GHz operating band. In addition, an arrangement of four symmetrical radiating elements was positioned orthogonally to minimize the antenna’s physical size and improve the isolation. The proposed MIMO antenna’s overall dimension was 25 × 25 mm${}^2$, which was printed on a Rogers 5880 substrate at a width of 0.787 mm and ${\epsilon }_r$ = 2.2. The proposed antenna covered the 5G mm-wave band with a 10 dB bandwidth ranging from 25.28–28.02 GHz, whereas the maximum gain attained for the proposed structure was 8.72 dBi. Additionally, the implementation of these slots effectively mitigated mutual coupling, resulting in reduced envelope correlation coefficient (ECC) values. Furthermore, other MIMO performance metrics, including channel capacity loss (CCL), mean effective gain (MEG), and diversity gain (DG), were analyzed for the proposed structure. The obtained results indicate its suitability for various usage areas, such as smart devices, mobile phones, and sensors in 5G applications. Full article
