In this study, four types of fall detection systems for seniors living alone using x-y scatter and Doppler range images measured from frequency-modulated continuous wave (FMCW) millimeter-wave (mmWave) sensors were introduced. Despite advancements in fall detection, existing long short-term memory (LSTM)-based approaches often struggle with effectively distinguishing falls from similar activities of daily living (ADLs) due to their uniform treatment of all time steps, potentially overlooking critical motion cues. To address this limitation, an attention mechanism has been integrated. Data was collected from seven participants, resulting in a dataset of 669 samples, including 285 falls and 384 ADLs with walking, lying, inactivity, and sitting. Four LSTM-based architectures for fall detection were proposed and evaluated: Raw-LSTM, Raw-LSTM-Attention, HOG-LSTM, and HOG-LSTM-Attention. The histogram of oriented gradient (HOG) method was used for feature extraction, while LSTM networks captured temporal dependencies. The attention mechanism further enhanced model performance by focusing on relevant input features. The Raw-LSTM model processed raw mmWave radar images through LSTM layers and dense layers for classification. The Raw-LSTM-Attention model extended Raw-LSTM with an added self-attention mechanism within the traditional attention framework. The HOG-LSTM model included an additional preprocessing step upon the RAW-LSTM model where HOG features were extracted and classified using an SVM. The HOG-LSTM-Attention model built upon the HOG-LSTM model by incorporating a self-attention mechanism to enhance the model’s ability to accurately classify activities. Evaluation metrics such as Sensitivity, Precision, Accuracy, and F1-Score were used to compare four architectural models. The results showed that the HOG-LSTM-Attention model achieved the highest performance, with an Accuracy of 95.3% and an F1-Score of 95.5%. Optimal self-attention configuration was found at a 2:64 ratio of number of attention heads to channels for keys and queries. Full article

Traditional 3D millimeter-wave radars lack target height information, leading to identification failures in complex scenarios. Upgrading to 4D millimeter-wave radars enables four-dimensional information perception, enhancing obstacle detection and improving the safety of autonomous driving. Given the high cost-sensitivity of in-vehicle radar systems, single-chip 4D millimeter-wave radar solutions, despite technical challenges in imaging, are of great research value. This study focuses on developing single-chip 4D automotive millimeter-wave radar, covering system architecture design, antenna optimization, signal processing algorithm creation, and performance validation. The maximum measurement error is approximately ±0.2° for azimuth angles within the range of ±30° and around ±0.4° for elevation angles within the range of ±13°. Extensive road testing has demonstrated that the designed radar is capable of reliably measuring dynamic targets such as vehicles, pedestrians, and bicycles, while also accurately detecting static infrastructure like overpasses and traffic signs. Full article

The field of metal additive manufacturing has witnessed significant growth in recent years, with technology offering the ability to produce complex geometries that are challenging to manufacture using the traditional methods. In situ monitoring and control of the manufacturing process are crucial for increasing the production capacity and improving the quality of manufactured parts. This article provides a comparative analysis of computational, indirect, and direct methods for in situ temperature monitoring during additive manufacturing of metal alloy components. Furthermore, it discusses the current status, recent improvements, and perspectives for in situ temperature measurements. The basic principles of thermal imaging, two-color pyrometry, and millimeter-wave radiometry are explored, highlighting their limitations for addressing challenges related to material emissivity and rapid changes in building material composition. Overcoming the challenges related to the inaccessibility of the chamber where the parts are formed, direct temperature measurements would allow for the integration of collected information into big data systems. Within the framework of Industry 4.0, this approach offers a viable alternative to the conventional metal shaping processes, improving the production capacity and part quality. This research aims to contribute to ongoing advancements in metal additive manufacturing and its potential to completely replace traditional metal casting practices in the Industry 4.0 era. Full article

A metasurface capable of flexibly manipulating electromagnetic waves to realize holograms presents significant potential in millimeter-wave imaging systems and data storage domains. In this study, full-space three-dimensional holograms are realized from a reflection–transmission integrated reconfigurable metasurface, which can achieve nearly 360° phase coverage in reflection space and 180° phase coverage in transmission space. By adjusting the voltage applied to the constituting electronically tunable meta-atoms of the metasurface, an octahedron hologram constituted by three hologram images in different focal planes is generated in the reflection space at 6.25 GHz. Moreover, a diamond hologram, also composed of three hologram images in different focal planes, is achieved in the transmission space at 6.75 GHz. Both the numerical simulation and experimental measurement are performed to validate the full-space holograms implemented by the modified weighted Gerchberg–Saxton (WGS) algorithm with specific phase distribution in different imaging planes. The obtained results pave the way for a wide range of new applications, such as next-generation three-dimensional displays for immersive viewing experiences, high-capacity optical communication systems with enhanced data encoding capabilities, and ultra-secure anti-counterfeiting solutions that are extremely difficult to replicate. Full article

Most existing cloud base height (CBH) retrieval algorithms are only applicable for daytime satellite observations due to their dependence on visible observations. This study presents a novel algorithm to retrieve day and night CBH using infrared observations of the geostationary Advanced Himawari Imager (AHI). The algorithm is featured by integrating deep learning techniques with a physical model. The algorithm first utilizes a convolutional neural network-based model to extract cloud top height (CTH) and cloud water path (CWP) from the AHI infrared observations. Then, a physical model is introduced to relate cloud geometric thickness (CGT) to CWP by constructing a look-up table of effective cloud water content (ECWC). Thus, the CBH can be obtained by subtracting CGT from CTH. The results demonstrate good agreement between our AHI CBH retrievals and the spaceborne active remote sensing measurements, with a mean bias of −0.14 ± 1.26 km for CloudSat-CALIPSO observations at daytime and −0.35 ± 1.84 km for EarthCARE measurements at nighttime. Additional validation against ground-based millimeter wave cloud radar (MMCR) measurements further confirms the effectiveness and reliability of the proposed algorithm across varying atmospheric conditions and temporal scales. Full article

Millimeter-wave (mmWave) antennas and antenna arrays have gained significant attention due to their pivotal role in emerging wireless communication, sensing, and imaging technologies. With the rapid deployment of 5G and the transition toward 6G networks, the demand for compact, high-gain, and reconfigurable mmWave antennas has intensified. This article highlights recent advancements in mmWave antenna technologies, including hybrid beamforming using phased arrays, dynamic beam-steering enabled by liquid crystal and MEMS-based structures, and high-capacity MIMO architectures. We also examine the integration of metamaterials and metasurfaces for miniaturization and gain enhancement. Applications covered include wearable antennas with low-SAR textile substrates, conformal antennas for UAV-based mmWave relays, and high-resolution radar arrays for autonomous vehicles. The study further analyzes innovative fabrication methods such as inkjet and aerosol jet printing, micromachining, and laser direct structuring, along with advanced materials like Kapton, PDMS, and graphene. Numerical modeling techniques such as full-wave EM simulation and machine learning-based optimization are discussed alongside experimental validation approaches. Beyond communications, we assess mmWave systems for biomedical imaging, security screening, and industrial sensing. Key challenges addressed include efficiency degradation at high frequencies, interference mitigation in dense environments, and system-level integration. Finally, future directions, including AI-driven design automation, intelligent reconfigurable surfaces, and integration with quantum and terahertz technologies, are outlined. This comprehensive synthesis aims to serve as a valuable reference for advancing next-generation mmWave antenna systems. Full article

Fine-mesh netting, with mesh dimensions of the order of a few millimeters, is widely used in sampling nets for the collection of larval and juvenile fishes. The wave force characteristics of fine-mesh netting significantly affect the operational performance of these nets. This study employed both wave tank experiments and numerical simulations to analyze the hydrodynamic performance of fine-mesh netting under varying wave conditions. A series of numerical simulations and particle image velocimetry (PIV) experiments were conducted to investigate the damping effects of fine-mesh netting on wave propagation. The results revealed that horizontal wave forces increased with both the wave period and wave height. When the wave period was held constant, the drag and inertial coefficients of the netting generally decreased as the Reynolds number and the Keulegan–Carpenter (KC) number increased. The wave transmission coefficients of the netting decreased as the wave height increased for the same wave period. However, at a constant wave height, the transmission coefficients initially increased and then decreased with the increasing wave period. The water particle velocity was significantly affected by the netting, with a notable reduction in velocity downstream of the netting at both the wave crest and trough phases. The simulation results and PIV measurements of the water particle velocity field distribution were in good agreement. This study provides important insights for the design and optimization of sampling nets. Full article

The impact of radomization on the radiation pattern of a millimeter-wave antenna for an ETA system utilizing synthetic aperture radar (SAR) is examined with special emphasis placed on the phase shift across both the beamwidth and the bandwidth, rather than the amplitude. Three different radomization approaches, including one based on metasurfaces, are evaluated for a radar antenna operating within the 24.05–24.25 GHz frequency range. Fabricated prototypes, both of the standalone antenna and the radomized version, are tested and compared in terms of electromagnetic image quality. The metasurface-based radome provides the best results among the radomization options analyzed. Full article

Arc scanning synthetic aperture radar (ArcSAR) can achieve high-resolution panoramic imaging and retrieve submillimeter-level deformation information. To monitor buildings in a city scenario, ArcSAR must be lightweight; have a high resolution, a mid-range (around a hundred meters), and low power consumption; and be cost-effective. In this study, a novel high-resolution wide-beam single-chip millimeter-wave (mmwave) ArcSAR system, together with an imaging algorithm, is presented. First, to handle the non-uniform azimuth sampling caused by motor motion, a high-accuracy angular coder is used in the system design. The coder can send the radar a hardware trigger signal when rotated to a specific angle so that uniform angular sampling can be achieved under the unstable rotation of the motor. Second, the ArcSAR’s maximum azimuth sampling angle that can avoid aliasing is deducted based on the Nyquist theorem. The mathematical relation supports the proposed ArcSAR system in acquiring data by setting the sampling angle interval. Third, the range cell migration (RCM) phenomenon is severe because mmwave radar has a wide azimuth beamwidth and a high frequency, and ArcSAR has a curved synthetic aperture. Therefore, the fourth-order RCM model based on the range-Doppler (RD) algorithm is interpreted with a uniform azimuth angle to suit the system and implemented. The proposed system uses the TI 6843 module as the radar sensor, and its azimuth beamwidth is 64°. The performance of the system and the corresponding imaging algorithm are thoroughly analyzed and validated via simulations and real data experiments. The output image covers a 360° and 180 m area at an azimuth resolution of 0.2°. The results show that the proposed system has good application prospects, and the design principles can support the improvement of current ArcSARs. Full article

This article presents a low-noise amplifier (LNA) with high image rejection ratio (IRR) operating in the 5G millimeter-wave band using a 65 nm CMOS process. The circuit adopts an inter-stage notch filtering structure composed of a transformer and a switched capacitor array to achieve image suppression and impedance matching with no die area overhead. By adjusting the values of the switch capacitor array, the transmission zeros are positioned in the stopband while the poles are placed in the passband, thereby realizing image rejection. Furthermore, the number and distribution of poles under the both real and complex impedance conditions are analyzed. Moreover, the quality factor (Q) of the zero is derived to establish the relationship between Q and the image rejection ratio, guiding the optimization of both gain and IRR of the circuit design. Measurement results demonstrate that the LNA exhibits a gain of 18 dB and a noise figure (NF) of 4.4 dB at 40 GHz, with a corresponding IRR of 53.4 dB when the intermediate frequency (IF) is 6 GHz. The circuit demonstrates a 3 dB bandwidth from 36.3 to 40.7 GHz, with an IRR greater than 42 dB across this frequency range. The power consumption is 25.4 mW from a 1 V supply, and the pad-excluded core area of the entire chip is 0.13 mm². Full article

A methodology utilizing low-resolution camera data is proposed to mitigate clutter effects on radar sensors in smart indoor environments. The proposed technique suppresses clutter in distance–velocity (range–Doppler) images obtained from millimeter-wave radar by estimating clutter locations using approximate spatial information derived from low-resolution camera images. Notably, the inherent blur present in low-resolution images closely corresponds to the distortion patterns induced by clutter in radar signals, making such data particularly suitable for effective sensor fusion. Experimental validation was conducted in indoor path-tracking scenarios involving a moving subject within a 10 m range. Performance was quantitatively evaluated against baseline range–Doppler maps obtained using radar data alone, without clutter mitigation. The results show that our approach improves the signal-to-noise ratio by 2 dB and increases the target detection rate by 8.6% within the critical 4–6 m range, with additional gains observed under constrained velocity conditions. Full article

A high-resolution imaging radar is exceptionally well-suited for the detection and perception of extended targets (ETs), as it provides a comprehensive representation of the spatial distribution of target scattering characteristics. In this work, we propose an adaptive detection and tracking framework for non-cooperative ETs based on radar imaging. The framework leverages the statistical properties of ETs in radar imaging to construct a target distribution model and introduces an adaptive ET detection and tracking algorithm based on Scattering Point Shift (SPS). This algorithm is designed to track ETs with internal motion characterized by multiple scattering points. The initial target distribution is estimated using two-dimensional kernel density estimation (2D-KDE). Compared to existing ET tracking algorithms, the proposed SPS method demonstrates superior universality in accommodating diverse scattering point distributions and integrates detection and tracking into a unified process, thereby significantly improving information utilization efficiency. The effectiveness of the algorithm is validated through extensive simulations and real-world data collected using a millimeter-wave (mmWave) imaging radar operating in the Linear Frequency Modulated Continuous Wave (LFMCW) mode. Full article

This study investigates the application of terahertz frequency-modulated continuous-wave (FMCW) imaging for the non-destructive inspection of a historical enamel plate, using both reflection and transmission modes. A 300 GHz FMCW radar system was employed to capture high-resolution images of the plate’s internal and surface structures. Through optimized data acquisition and processing, the system successfully revealed subsurface features such as fractures, as well as surface-level textural variations linked to the decorative glazes. Although pigment differentiation remains a challenge, contrast variations observed in THz images suggest correlations with material composition. The results highlight the potential of FMCW terahertz imaging as a compact, rapid, and non-contact diagnostic tool for cultural heritage analysis. Its practicality and adaptability make it particularly suitable for in situ inspections in museums or restoration contexts. Full article

This article presents an innovative integration of Glow Discharge Detector Focal Plane Arrays (GDD FPA) with Chirped Frequency Modulated Continuous Wave (FMCW) Radar, enhancing millimeter-wave (MMW) imaging. The cost-effective FPA design using GDDs as pixel elements forms the foundation of the system. We investigate MMW effects on GDD discharge currents via basic data acquisition (DAQ) and implement a scanning mechanism with a step motor for sub-pixel imaging. The setup integrates an MMW source, optical components, a timer/counter, and an 8 × 8 FPA with 64 GDD, operating in electrical detection modes and processing signals using Fast Fourier Transform (FFT) algorithms. Recent advancements in millimeter-wave imaging have focused on improving image resolution and acquisition speed through various techniques, including lock-in amplifiers and electrical detection methods. However, these methods introduce complexity, cost, and extended acquisition times. Our approach mitigates these challenges by implementing a simplified FPA design that eliminates the need for external signal conditioning elements, providing faster and more efficient image acquisition. The primary contributions include significant improvements in the speed and automation of image acquisition achieved through a coordinated control mechanism for efficient row scanning. Compared to previous generations of GDD FPAs, this system achieves a notable reduction in image acquisition time by up to 75%, while maintaining high fidelity. These enhancements make the system particularly suitable for time-sensitive applications. Additionally, future research directions include the incorporation of 3D imaging using FMCW radar. Results from the FMCW measurements using the single GDD circuit demonstrate the system’s ability to accurately capture and process MMW radiation, even at low intensities. The combined strengths of GDD FPA and chirped FMCW radar underscore the system’s effectiveness in MMW detection, laying the groundwork for advanced MMW imaging capabilities across diverse applications. Full article

With the advancement in intelligent transportation systems, single-sensor perception solutions face inherent limitations. To address the constraints of monocular vision detection, this study presents a vehicle road detection system that integrates millimeter-wave radar and visual information. By generating mask maps from millimeter-wave radar point clouds, radar data transition from a global assistance role to localized guidance, identifying vehicle target positions within RGB images. These mask maps, along with RGB images, are processed by a Dual Cross-Attention Module (DCAM), where the fused features are fed into an enhanced YOLOv5 network, improving target localization accuracy. The proposed dual-input DCAM enables dynamic feature fusion, allowing the model to adjust its reliance on visual and radar data according to environmental conditions. To optimize the network architecture, ShuffleNetv2 replaces the YOLOv5 Backbone, while the Ghost Module is incorporated into the Neck, creating a lightweight design. Pruning techniques are applied to reduce model complexity, making it suitable for embedded applications and real-time detection scenarios. The experimental results demonstrate that this fusion scheme effectively improves vehicle detection accuracy and robustness compared to YOLOv5, with accuracy increasing from 59.4% to 67.2%. The number of parameters is reduced from 7.05 M to 2.52 M, providing a precise and reliable solution for intelligent transportation and roadside perception. Full article
