Search Results (33)

Search Parameters:
Keywords = millimeter-wave (MMW) antenna

Order results
Result details
Results per page
Select all
Export citation of selected articles as:
13 pages, 4379 KiB
Article
A Broadband Millimeter-Wave Circularly Polarized Folded Reflectarray Antenna Based on Transmissive Linear-to-Circular Polarization Converter
by Yue Cao, Zhuwei Wang, Qing Wang, Mingzhu Du and Miaojuan Zhang
Micromachines 2025, 16(6), 711; https://doi.org/10.3390/mi16060711 - 14 Jun 2025
Viewed by 475
Abstract
In this paper, a wideband circularly polarized folded reflectarray antenna (CPFRA) based on a transmissive linear-to-circular polarization converter is proposed. The CPFRA consists of a primary reflector and a sub-reflector. To achieve broadband performance, a metasurface-based RA element on the primary reflector surface [...] Read more.
In this paper, a wideband circularly polarized folded reflectarray antenna (CPFRA) based on a transmissive linear-to-circular polarization converter is proposed. The CPFRA consists of a primary reflector and a sub-reflector. To achieve broadband performance, a metasurface-based RA element on the primary reflector surface and a transmissive linear-to-circular polarization converter on the sub-reflector surface are applied. Moreover, the transmissive linear-to-circular polarization converter on the sub-reflector surface helps convert linear polarization to circular polarization. To verify the proposed CPFRA, a prototype is designed, fabricated, and tested. The measured results exhibit that the proposed CPFRA presents a 3 dB gain bandwidth of 27.4% and a 3 dB axial ratio bandwidth of 23%. The CPFRA achieves a peak gain of 21.2 dBi with an aperture efficiency of 27.2%. The proposed CPFRA is a promising candidate for millimeter-wave (mm-W) satellite communication applications because of its advantages of high gain, low cost, low profile, and broad bandwidth. Full article
(This article belongs to the Special Issue Microwave Passive Components, 3rd Edition)
Show Figures

Figure 1

14 pages, 20644 KiB
Article
A High-Gain Circularly Polarized Magnetoelectric Dipole Antenna Array for Millimeter-Wave Applications
by Jun Xiao, Jing Wu, Zihang Ye, Tongyu Ding, Chongzhi Han and Qiubo Ye
Sensors 2025, 25(10), 3046; https://doi.org/10.3390/s25103046 - 12 May 2025
Viewed by 513
Abstract
A high-gain circularly polarized (CP) magnetoelectric dipole (ME-dipole) radiating element is demonstrated at a millimeter-wave (MMW) 5G band of 37–43.5 GHz. Each ME-dipole radiating element, consisting of two pairs of ring-shaped and L-shaped metal posts is excited by a cross-shaped substrate-integrated waveguide (SIW) [...] Read more.
A high-gain circularly polarized (CP) magnetoelectric dipole (ME-dipole) radiating element is demonstrated at a millimeter-wave (MMW) 5G band of 37–43.5 GHz. Each ME-dipole radiating element, consisting of two pairs of ring-shaped and L-shaped metal posts is excited by a cross-shaped substrate-integrated waveguide (SIW) coupling slot to achieve CP radiation. Through the use of all-metal radiating structures with a height of 3.4 mm, high-gain and high-efficiency radiation performances are achieved. For proof of concept, a 4 × 4 antenna array with a SIW feeding network is designed, fabricated, and measured. The measured impedance bandwidth of the proposed 4 × 4 CP antenna array is 19.2% from 33.9 to 41.1 GHz for |S11| ≤ −10 dB. The measured 3 db AR bandwidth is 10.3% from 37 to 41 GHz. The measured peak gain is 20.3 dBic at 41 GHz. The measured and simulated results are in good agreement. Full article
(This article belongs to the Special Issue Design and Measurement of Millimeter-Wave Antennas)
Show Figures

Figure 1

11 pages, 9562 KiB
Article
Enhanced Radiation in a Millimeter-Wave Circularly Polarized On-Chip Bowtie Antenna Using a Low-Cost PCB Package
by Yanjun Wang, Jiasheng Liang, Aguan Hong, Xiang Yi, Pei Qin, Haoshen Zhu, Wenquan Che and Quan Xue
Electronics 2025, 14(4), 642; https://doi.org/10.3390/electronics14040642 - 7 Feb 2025
Viewed by 871
Abstract
This paper presents a circularly polarized on-chip antenna (OCA) operating in the D-band for a fully integrated bidirectional transceiver in TSMC 40 nm bulk CMOS process. Circular polarization is achieved by arranging two pairs of antennas in an orthogonal configuration. The target [...] Read more.
This paper presents a circularly polarized on-chip antenna (OCA) operating in the D-band for a fully integrated bidirectional transceiver in TSMC 40 nm bulk CMOS process. Circular polarization is achieved by arranging two pairs of antennas in an orthogonal configuration. The target design at 145 GHz features a compact hybrid structure that integrates a bowtie antenna with a PCB package. This configuration not only shields the antenna from environmental interference but also improves its radiation efficiency. The proposed OCA demonstrates a simulated gain of −1.4 dBi and a radiation efficiency of 32% at 145 GHz, along with a compact footprint of 0.4 × 0.4 mm2. To further enhance radiation efficiency and gain, the antenna elements are integrated into chip arrays. The OCA design presented in this work addresses key objectives in system design, including compactness, cost-effectiveness, and compatibility with existing technologies. Full article
Show Figures

Figure 1

13 pages, 3634 KiB
Article
A 60 GHz Slotted Array Horn Antenna for Radar Sensing Applications in Future Global Industrial Scenarios
by Binyi Ma, Jing Li, Yu Chen, Yuheng Si, Hongyan Gao, Qiannan Wu and Mengwei Li
Micromachines 2024, 15(6), 728; https://doi.org/10.3390/mi15060728 - 30 May 2024
Cited by 2 | Viewed by 1608
Abstract
This paper presents the design of a 60 GHz millimeter-wave (MMW) slot array horn antenna based on the substrate-integrated waveguide (SIW) structure. The novelty of this device resides in the achievement of a broad impedance bandwidth and high gain performance by meticulously engineering [...] Read more.
This paper presents the design of a 60 GHz millimeter-wave (MMW) slot array horn antenna based on the substrate-integrated waveguide (SIW) structure. The novelty of this device resides in the achievement of a broad impedance bandwidth and high gain performance by meticulously engineering the radiation band structure and slot array. The antenna demonstrates an impressive impedance bandwidth of 14.96 GHz (24.93%), accompanied by a remarkable maximum reflection coefficient of −39.47 dB. Furthermore, the antenna boasts a gain of 10.01 dBi, showcasing its outstanding performance as a high-frequency antenna with a wide bandwidth and high gain. To validate its capabilities, we fabricated and experimentally characterized a prototype of the antenna using a probe test structure. The measurement results closely align with the simulation results, affirming the suitability of the designed antenna for radar sensing applications in future global industrial scenarios. Full article
(This article belongs to the Special Issue Recent Advances in Electromagnetic Devices)
Show Figures

Figure 1

13 pages, 2732 KiB
Article
High-Resolution Millimeter-Wave Radar for Real-Time Detection and Characterization of High-Speed Objects with Rapid Acceleration Capabilities
by Yair Richter and Nezah Balal
Electronics 2024, 13(10), 1961; https://doi.org/10.3390/electronics13101961 - 16 May 2024
Cited by 1 | Viewed by 2682
Abstract
In this study, we present a novel approach for the real-time detection of high-speed moving objects with rapidly changing velocities using a high-resolution millimeter-wave (MMW) radar operating at 94 GHz in the W-band. Our detection methodology leverages continuous wave transmission and heterodyning of [...] Read more.
In this study, we present a novel approach for the real-time detection of high-speed moving objects with rapidly changing velocities using a high-resolution millimeter-wave (MMW) radar operating at 94 GHz in the W-band. Our detection methodology leverages continuous wave transmission and heterodyning of the reflected signal from the moving target, enabling the extraction of motion-related attributes such as velocity, position, and physical characteristics of the object. The use of a 94 GHz carrier frequency allows for high-resolution velocity detection with a velocity resolution of 6.38 m/s, achieved using a short integration time of 0.25 ms. This high-frequency operation also results in minimal atmospheric absorption, further enhancing the efficiency and effectiveness of the detection process. The proposed system utilizes cost-effective and less complex equipment, including compact antennas, made possible by the low sampling rate required for processing the intermediate frequency signal. The experimental results demonstrate the successful detection and characterization of high-speed moving objects with high acceleration rates, highlighting the potential of this approach for various scientific, industrial, and safety applications, particularly those involving targets with rapidly changing velocities. The detailed analysis of the micro-Doppler signatures associated with these objects provides valuable insights into their unique motion dynamics, paving the way for improved tracking and classification algorithms in fields such as aerospace research, meteorology, and collision avoidance systems. Full article
(This article belongs to the Special Issue Advances in Terahertz Radiation Sources and Their Applications)
Show Figures

Figure 1

22 pages, 2688 KiB
Review
Advanced Dielectric Resonator Antenna Technology for 5G and 6G Applications
by Yingqi Zhang, Stanislav Ogurtsov, Vasilii Vasilev, Ahmed A. Kishk and Diego Caratelli
Sensors 2024, 24(5), 1413; https://doi.org/10.3390/s24051413 - 22 Feb 2024
Cited by 18 | Viewed by 5106
Abstract
We review dielectric resonator antenna (DRA) designs. This review examines recent advancements across several categories, specifically focusing on their applicability in array configurations for millimeter-wave (mmW) bands, particularly in the context of 5G and beyond 5G applications. Notably, the off-chip DRA designs, including [...] Read more.
We review dielectric resonator antenna (DRA) designs. This review examines recent advancements across several categories, specifically focusing on their applicability in array configurations for millimeter-wave (mmW) bands, particularly in the context of 5G and beyond 5G applications. Notably, the off-chip DRA designs, including in-substrate and compact DRAs, have gained prominence in recent years. This surge in popularity can be attributed to the rapid development of cost-effective multilayer laminate manufacturing techniques, such as printed circuit boards (PCBs) and low-temperature co-fired ceramic (LTCC). Furthermore, there is a growing demand for DRAs with beam-steering, dual-band functions, and on-chip alignment availability, as they offer versatile alternatives to traditional lossy printed antennas. DRAs exhibit distinct advantages of lower conductive losses and greater flexibility in shapes and materials. We discuss and compare the performances of different DRA designs, considering their material usage, manufacturing feasibility, overall performance, and applications. By exploring the pros and cons of these diverse DRA designs, this review provides valuable insights for researchers in the field. Full article
(This article belongs to the Special Issue Antenna Array Design for Wireless Communications and Remote Sensing)
Show Figures

Figure 1

15 pages, 9951 KiB
Article
A Dual-Polarized CTS Array Antenna with Four Reconfigurable Beams for mm-Wave Wind Profile Radar
by Lei Yan, Wenbin Zou, Kaihong Zheng, Guangli Yang and Yong Luo
Electronics 2024, 13(1), 238; https://doi.org/10.3390/electronics13010238 - 4 Jan 2024
Cited by 3 | Viewed by 2378
Abstract
The wind profiler radar (WPR) system requires a dual-polarized antenna with multiple low-sidelobe and high-gain beams to facilitate the detection of weak signals reflected by atmospheric turbulence. This paper proposes a dual-polarized continuous transverse stub (CTS) K-band antenna with four reconfigurable beams, which [...] Read more.
The wind profiler radar (WPR) system requires a dual-polarized antenna with multiple low-sidelobe and high-gain beams to facilitate the detection of weak signals reflected by atmospheric turbulence. This paper proposes a dual-polarized continuous transverse stub (CTS) K-band antenna with four reconfigurable beams, which comprises a series-fed CTS array and four 1-to-14 power dividers as line source generators (LSGs) to generate a high-quality quasi-TEM wave. The CTS element incorporates a stepped transition radiation stub design and employs a short cutoff stub on the upper surface of the series-fed parallel plate waveguide (PPW) to achieve optimal impedance matching. The entire antenna is an all-metal structure with remarkably low loss, and low-cost standard fabrication processes are employed for the prototype, which achieves fast reconfigurable four-beam scanning to 15°, with a gain of 31.09 dBi and sidelobe levels below −17.6 dB. Measurement results in an anechoic chamber agree well with simulations, demonstrating the antenna’s ease of manufacture, stability, and suitability for wind profile radar applications. Full article
(This article belongs to the Special Issue Feature Papers in Microwave and Wireless Communications Section)
Show Figures

Figure 1

15 pages, 6069 KiB
Article
Metamaterial-Based Series-Fed Antenna with a High Gain and Wideband Performance for Millimeter-Wave Spectrum Applications
by Bashar A. F. Esmail, Slawomir Koziel and Dustin Isleifson
Electronics 2023, 12(23), 4836; https://doi.org/10.3390/electronics12234836 - 30 Nov 2023
Cited by 1 | Viewed by 2352
Abstract
This paper presents a high-gain, wideband series-fed antenna designed for 5G millimeter-wave (MMW) applications. The structure employs a substrate-integrated-waveguide (SIW)-based power splitter and metamaterials (MMs). The power divider functions effectively at 27.5 GHz, exhibiting an impedance bandwidth from 26.9 to 28.6 GHz. The [...] Read more.
This paper presents a high-gain, wideband series-fed antenna designed for 5G millimeter-wave (MMW) applications. The structure employs a substrate-integrated-waveguide (SIW)-based power splitter and metamaterials (MMs). The power divider functions effectively at 27.5 GHz, exhibiting an impedance bandwidth from 26.9 to 28.6 GHz. The series-fed dipole is assembled on the SIW-based power splitter, incorporating four dipoles with varying lengths and spacing. The dipoles are connected in series on both sides, running in parallel through a microstrip line. Effectively combining the resonances of the series-fed dipoles and the SIW results in a broad impedance bandwidth, ranging from 26.9 GHz to 34.75 GHz. The design has a gain extending from 9 to 10.5 dBi within the operating bandwidth. To improve gain performance without a substantial increase in antenna size, 11 × 6 MM unit cells were positioned in front of the antenna. As a result, the proposed antenna achieves a maximum gain of 14.1 dBi at 30.5 GHz while maintaining an operational bandwidth of 7.85 GHz. Additionally, due to the arrangement of the two MM-based series-fed dipoles, the antenna exhibits symmetrical dual-beam E-plane radiation at ±20° and 28 GHz in the end-fire direction. The developed system was experimentally validated and an excellent agreement between the simulated and measured data was demonstrated. Full article
(This article belongs to the Section Microwave and Wireless Communications)
Show Figures

Figure 1

31 pages, 1021 KiB
Review
Overview of Tensor-Based Cooperative MIMO Communication Systems—Part 1: Tensor Modeling
by Gérard Favier and Danilo Sousa Rocha
Entropy 2023, 25(8), 1181; https://doi.org/10.3390/e25081181 - 8 Aug 2023
Cited by 3 | Viewed by 2029
Abstract
Due to increasingly strong and varied performance requirements, cooperative wireless communication systems today occupy a prominent place in both academic research and industrial development. The technological and economic challenges for future sixth-generation (6G) wireless systems are considerable, with the objectives of improving coverage, [...] Read more.
Due to increasingly strong and varied performance requirements, cooperative wireless communication systems today occupy a prominent place in both academic research and industrial development. The technological and economic challenges for future sixth-generation (6G) wireless systems are considerable, with the objectives of improving coverage, data rate, latency, reliability, mobile connectivity and energy efficiency. Over the past decade, new technologies have emerged, such as massive multiple-input multiple-output (MIMO) relay systems, intelligent reflecting surfaces (IRS), unmanned aerial vehicular (UAV)-assisted communications, dual-polarized (DP) antenna arrays, three dimensional (3D) polarized channel modeling, and millimeter-wave (mmW) communication. The objective of this paper is to provide an overview of tensor-based MIMO cooperative communication systems. Indeed, during the last two decades, tensors have been the subject of many applications in signal processing, especially for digital communications, and more broadly for big data processing. After a brief reminder of basic tensor operations and decompositions, we present the main characteristics allowing to classify cooperative systems, illustrated by means of different architectures. A review of main codings used for cooperative systems is provided before a didactic and comprehensive presentation of two-hop systems, highlighting different tensor models. In a companion paper currently in preparation, we will show how these tensor models can be exploited to develop semi-blind receivers to jointly estimate transmitted information symbols and communication channels. Full article
(This article belongs to the Special Issue Wireless Networks: Information Theoretic Perspectives III)
Show Figures

Figure 1

20 pages, 8958 KiB
Article
A Quad-Band Shared-Aperture Antenna Based on Dual-Mode Composite Quarter-Mode SIW Cavity for 5G and 6G with MIMO Capability
by Amjaad T. Altakhaineh, Saqer S. Alja’afreh, Aser M. Almatarneh, Eqab Almajali, Luae Al-Tarawneh and Jawad Yousaf
Electronics 2023, 12(11), 2480; https://doi.org/10.3390/electronics12112480 - 31 May 2023
Cited by 18 | Viewed by 2854
Abstract
This study introduces a new design for an ultra-compact shared-aperture antenna utilizing a quarter-mode substrate integrated waveguide (QMSIW) cavity. The proposed antenna operates as a 4 × 4 multi-input multi-output (MIMO) system in three 5G/6G millimeter-wave (MMw) bands, while functioning as a single [...] Read more.
This study introduces a new design for an ultra-compact shared-aperture antenna utilizing a quarter-mode substrate integrated waveguide (QMSIW) cavity. The proposed antenna operates as a 4 × 4 multi-input multi-output (MIMO) system in three 5G/6G millimeter-wave (MMw) bands, while functioning as a single element antenna for a 5.5 GHz wireless fidelity Microwave (Mw) band. The antenna comprises four QMSIW cavity resonators; each QMSIW is loaded with dual slots to produce tri-band MMw operation at 28 GHz, 38 GHz, and 0.13 THz. The four cavities are arranged to reuse the entire aperture by creating a conventional open-loop antenna that operates at a frequency of 5.5 GHz. Simulation, measurement, and co-simulation results show that the proposed antenna has a quad-band operation and exhibits favorable characteristics. The measured scattering parameters validate the simulated ones over the four bands under consideration. The lowest values of the measured total radiation efficiencies are 80%, 73%, 62%, and 72% (co-simulation) within the four covered bands, respectively. The antenna peak gains are 1.8 to 1.85 dBi, 4.0 to 4.5 dBi, 4.3 to 4.5 dBi, and 6.5 to 6.6 dBi within the covered bands. Furthermore, the design satisfies MIMO and diversity conditions (envelope correlation coefficient and branch power ratio) over frequency bands of operation. All excellent results are achieved from an ultra-compact size in terms of footprint area (0.018λ02), where λ0 represents the free space wavelength at 5.5 GHz. The antenna boasts an excellent reuse aperture utilization efficiency (RAU) of 92% and a large ratio frequency of 23, making it an ideal candidate for compact devices. With its superior performance, the proposed design is well-suited for a range ofs wireless communication systems, including mobile devices and the Internet of Things. Full article
(This article belongs to the Special Issue Advanced Antenna Design for 5G and beyond Communications)
Show Figures

Figure 1

11 pages, 3422 KiB
Article
Multiple-Beam Steering Using Graphene-Based Coding Metasurfaces
by Bin Zheng, Xin Rao, Yuyu Shan, Chuandong Yu, Jingke Zhang and Na Li
Micromachines 2023, 14(5), 1018; https://doi.org/10.3390/mi14051018 - 9 May 2023
Cited by 9 | Viewed by 2780
Abstract
Recently, the coding metasurface has gained significant attention due to its exceptional potential in controlling electromagnetic (EM) waves with the rapid development of wireless communication systems. Meanwhile, graphene shows tremendous promise for the implementation of reconfigurable antennas due to its high tunable conductivity [...] Read more.
Recently, the coding metasurface has gained significant attention due to its exceptional potential in controlling electromagnetic (EM) waves with the rapid development of wireless communication systems. Meanwhile, graphene shows tremendous promise for the implementation of reconfigurable antennas due to its high tunable conductivity and its unique property that makes it a very suitable material for realizing steerable coded states. In this paper, we first propose a simple structured beam reconfigurable millimeter wave (MMW) antenna using a novel graphene-based coding metasurface (GBCM). Different from the previous method, its coding state can be manipulated by altering the sheet impedance of graphene instead of bias voltage. Then, we design and simulate several most popular coding sequences, including dual-, quad-and single-beam-generated implement, 30° beam deflection, as well as a random coding sequence for radar cross-section (RCS) reduction. The theoretical and simulation results show that graphene has great potential for MMW manipulation applications, which lay a foundation for the subsequent development and fabrication of GBCM. Full article
(This article belongs to the Special Issue Beam Steering via Arrayed Micromachines, 2nd Edition)
Show Figures

Figure 1

12 pages, 19873 KiB
Communication
A Compact Aperture-Sharing Sub-6 GHz/Millimeter-Wave Dual-Band Antenna
by Qinghu Zhang, Bitian Chai, Jianxin Chen and Wenwen Yang
Sensors 2023, 23(9), 4400; https://doi.org/10.3390/s23094400 - 30 Apr 2023
Cited by 6 | Viewed by 2646
Abstract
In this article, a microwave (MW)/millimeter wave (MMW) aperture-sharing antenna is proposed. The antenna is constructed using two orthogonal columns of grounded vias from a 3.5 GHz slot-loaded half-mode substrate-integrated waveguide (HMSIW) antenna. These vias are reused to create two sets of 1 [...] Read more.
In this article, a microwave (MW)/millimeter wave (MMW) aperture-sharing antenna is proposed. The antenna is constructed using two orthogonal columns of grounded vias from a 3.5 GHz slot-loaded half-mode substrate-integrated waveguide (HMSIW) antenna. These vias are reused to create two sets of 1 × 4 MMW substrate-integrated dielectric resonator antenna (SIDRA) arrays. With this proposed partial structure reuse strategy, the MW antenna and MMW arrays can be integrated in a shared-aperture manner, improving space utilization and enabling dual-polarized beam steering capability in the MMW band, which is highly desirable for multiple-input multipleoutput (MIMO) applications. The integrated antenna prototype was manufactured and measured for verification. The 3.5 GHz antenna has a relative bandwidth of 3.4% (3.44–3.56 GHz) with a peak antenna gain of 5.34 dBi, and the 28 GHz antenna arrays cover the frequency range of 26.5–29.8 GHz (11.8%) and attain a measured peak antenna gain of 11.0 dBi. Specifically, the 28 GHz antenna arrays can realize dual-polarization and ±45° beam steering capability. The dual-band antenna has a very compact structure, and it is applicable for 5G mobile communication terminals. Full article
(This article belongs to the Special Issue MIMO Technologies in Sensors and Wireless Communication Applications)
Show Figures

Figure 1

10 pages, 4511 KiB
Communication
Single-Layer Interconnected Magneto-Electric Dipole Antenna Array for 5G Communication Applications
by Zihao Chen, Wenxu Zhang and Kaixu Wang
Electronics 2023, 12(4), 922; https://doi.org/10.3390/electronics12040922 - 12 Feb 2023
Cited by 3 | Viewed by 2530
Abstract
A high-gain and wideband interconnected magneto-electric (ME) dipole on a single-layer PCB substrate is designed for 5G communication applications. Microstrip lines and coplanar striplines (CPSs) serve as transmission lines to connect the ME dipole elements along the E-plane and the H-plane directions, respectively. [...] Read more.
A high-gain and wideband interconnected magneto-electric (ME) dipole on a single-layer PCB substrate is designed for 5G communication applications. Microstrip lines and coplanar striplines (CPSs) serve as transmission lines to connect the ME dipole elements along the E-plane and the H-plane directions, respectively. Impedance matching and sidelobe-level suppression are the key challenges to design a large-scale interconnected ME dipole antenna array. It is shown that impedance matching can be improved by introducing slots and adjusting the width of microstrip lines. Sidelobe level can be enhanced by properly choosing the length of the microstrip lines. A 5 × 5 interconnected ME dipole array is fabricated on a single layer of the RT/duroid 5880 substrate. The proposed antenna exhibits a measured −10 dB impedance bandwidth of 14.5 GHz (52% at 28 GHz) and a maximal peak realized gain of 20.44 dBi at 27.5 GHz with a 3 dB gain bandwidth of 3.5 GHz (12.5% at 28 GHz). The proposed antenna array is a good candidate for 5G communication applications due to its advantages of simple feeding structure, wide bandwidth, high gain, and low profile. Full article
Show Figures

Figure 1

10 pages, 3382 KiB
Article
Millimeter-Wave Image Deblurring via Cycle-Consistent Adversarial Network
by Huteng Liu, Shuoguang Wang, Handan Jing, Shiyong Li, Guoqiang Zhao and Houjun Sun
Electronics 2023, 12(3), 741; https://doi.org/10.3390/electronics12030741 - 1 Feb 2023
Cited by 2 | Viewed by 1926
Abstract
Millimeter-wave (MMW) imaging has a tangible prospect in concealed weapon detection for security checks. Typically, a one-dimensional (1D) linear antenna array with mechanical scanning along a perpendicular direction is employed for MMW imaging. To achieve high-resolution imaging, the target under test needs to [...] Read more.
Millimeter-wave (MMW) imaging has a tangible prospect in concealed weapon detection for security checks. Typically, a one-dimensional (1D) linear antenna array with mechanical scanning along a perpendicular direction is employed for MMW imaging. To achieve high-resolution imaging, the target under test needs to keep steady enough during the mechanical scanning process since slight movement can induce large phase variation for MMW systems, which will result in a blurred image. However, in the scenario of imaging of a human body, sometimes it is difficult to meet this requirement, especially for the elderly. Such blurred MMW images would reduce the detection accuracy of the concealed weapons. In this paper, we propose a deblurring method based on cycle-consistent adversarial network (Cycle GAN). Specifically, the Cycle GAN can learn the mapping between the blurred MMW images and the focused ones. To minimize the effect of the shaking blur, we introduce an identity loss. Moreover, a mean squared error loss (MSE loss) is utilized to stabilize the training, so as to obtain more refined deblurred results. The experimental results demonstrate that the proposed method can efficiently suppress the blurring effect in the MMW image. Full article
(This article belongs to the Special Issue Recent Advances in Microwave and Terahertz Engineering)
Show Figures

Figure 1

12 pages, 6699 KiB
Article
Multi-Beam Conformal Array Antenna Based on Highly Conductive Graphene Films for 5G Micro Base Station Applications
by Bin Zheng, Xiangyang Li, Xin Rao and Na Li
Sensors 2022, 22(24), 9681; https://doi.org/10.3390/s22249681 - 10 Dec 2022
Cited by 2 | Viewed by 2080
Abstract
Recently, micro base station antennas have begun to play a more important role in 5G wireless communication, with the rapid development of modern smart medical care, the Internet of things, and portable electronic devices. Meanwhile, in response to the global commitment to long-term [...] Read more.
Recently, micro base station antennas have begun to play a more important role in 5G wireless communication, with the rapid development of modern smart medical care, the Internet of things, and portable electronic devices. Meanwhile, in response to the global commitment to long-term carbon neutrality, graphene film has received significant attention in the field of antennas due to its low carbon environmental impact and high electrical conductivity properties. In this work, a conformal array antenna based on highly conductive graphene films (CGF) is proposed for 5G millimeter-wave (MMW) applications. The proposed antenna consists of three antenna arrays, with eight patch elements in each array, operating at 24 GHz, with linear polarization. Each antenna array’s current amplitude distribution coefficient is constructed by synthesizing a series-feeding linear array using the Chebyshev method. The measurement results demonstrated that the proposed CGF antenna exhibits a peak realized gain higher than 8 dBi in the bandwidth of 23.0–24.7 GHz. The proposed antenna achieves three independent beams from bore-sight to ±37° in conformal installations, with a cylinder radius of 30 mm, showing excellent beam-pointing performance. These characteristics indicate that the CGF can be used for the design of MMW micro base station antennas, fulfilling the requirements of the conformal carrier platform for a lightweight and compact antenna. Full article
(This article belongs to the Section Electronic Sensors)
Show Figures

Figure 1
