This paper presents the development and analysis of a planar microfluidic microwave sensor featuring three circular complementary split-ring resonators (CSRRs) fabricated on an RO3035 substrate. The sensor demonstrates enhanced sensitivity in characterizing liquids contained in a fine glass capillary tube by leveraging a novel configuration: a central 5-split-ring CSRR with a drilled hole to suspend the capillary, flanked by two 2-split-ring CSRRs to improve the band-stop filtering effect. The sensor’s performance is benchmarked against another CSRR-based microwave sensor with a similar configuration. High linearity is observed (R² > 0.99), confirming its capability for precise ethanol concentration prediction. Compared to the replicated square CSRR design from the literature, the proposed sensor achieves a 35.22% improvement in sensitivity, with a frequency shift sensitivity of 567.41 kHz/% ethanol concentration versus 419.62 kHz/% for the reference sensor. The enhanced sensitivity is attributed to several key design strategies: increasing the intrinsic capacitance by enlarging the effective area and radial slot width to amplify edge capacitive effects, adding more split rings to intensify the resonance dip, placing additional CSRRs to improve energy extraction at resonance, and adopting circular CSRRs for superior electric field confinement. Additionally, the proposed design operates at a lower resonant frequency (2.234 GHz), which not only reduces dielectric and radiation losses but also enables the use of more cost-effective and power-efficient RF components. This advantage makes the sensor highly suitable for integration into portable and standalone sensing platforms. Full article

This paper presents a carbon monoxide (CO) detection mechanism achieved through further improvement of the sensing antenna based on hybrid spoof localized surface plasmons (SLSPs) and cavity resonance. Unlike conventional approaches relying on chemical reactions or photoelectric effects, the all-metal configuration detects dielectric variations through microwave-regime resonance frequency shifts, enabling CO/air differentiation with theoretically enhanced robustness and environmental adaptability. The designed system achieves measured figures of merit (FoMs) of 183.2 RIU⁻¹, resolving gases with dielectric contrast below 0.1%. Experimental validation successfully discriminated CO (ε_r = 1.00262) from air (ε_r = 1.00054) under standard atmospheric pressure at 18 °C. Full article

Hydrogen is gaining prominence as a clean energy vector, yet its extreme flammability demands robust detection solutions for industrial safety. In this study, we present the development and experimental validation of a microwave hydrogen gas sensor based on a patch-type microstrip antenna with a silver sensing element. The device operates at 5.99 GHz and was tested under controlled environmental conditions (humidity: 20 ± 0.4%, temperature: 27 ± 0.2 °C). Hydrogen exposure induces measurable shifts in the antenna’s resonant frequency due to dielectric modulation of the silver layer. The sensor exhibited a linear sensitivity of 3 kHz/ppm in the 310–600 ppm concentration range, with a residual standard deviation of 31.1 kHz and a calculated limit of detection (LOD) of approximately 31 ppm. The reflection coefficient remained below −10 dB throughout, confirming that the antenna maintains functional RF performance during sensing. These results demonstrate the sensor’s dual functionality for gas detection and communication, offering a compact and scalable platform for hydrogen safety monitoring. Full article

This article introduces a microwave sensor tailored for skin hydration monitoring. The design enables wireless operation by separating the sensing component from the reader, making it ideal for wearable devices like wristbands. The sensor consists of a semi-lumped $LC$ resonator coupled to an inductive coil reader, where the capacitive part of the sensing tag is in contact with the skin. The variations in the skin hydration level alter the dielectric properties of the skin, which, in turn, modify the resonances of the $LC$ resonator. Experimental in vivo measurements confirmed the sensor’s ability to distinguish between four hydration conditions: wet skin, skin treated with moisturizer, untreated dry skin, and skin treated with Vaseline, by measuring the resonance frequencies of the sensor. Measurement of the input reflection coefficient ($S_{11}$) using a vector network analyzer (VNA) revealed distinct reflection poles and zeros for each condition, demonstrating the sensor’s effectiveness in detecting skin hydration levels. The sensing principle was analyzed using an equivalent circuit model and validated through measurements of a fabricated sensor prototype. The results confirm in vivo skin hydration monitoring by detecting frequency shifts in the reflection response within the 50–200 MHz range. The measurements and data analysis show less than $0.037\%$ error in transmission zero ($f_z$) together with less than $1.5\%$ error in transmission pole ($f_p$) while being used to detect skin hydration status on individual human subjects. The simplicity of the detection method, focusing on key frequency shifts, underscores the sensor’s potential as a practical and cost-effective solution for non-invasive skin hydration monitoring. This advancement holds significant potential for skincare and biomedical applications, enabling detection without complex signal processing. Full article

Non-invasive glucose monitoring has become a critical area of research for diabetes management, offering a less intrusive and more patient-friendly alternative to traditional methods such as finger-prick tests. This study presents a novel approach using a semi-solid tissue-mimicking phantom designed to replicate the dielectric properties of human skin and blood vessels. The phantom was simplified to focus solely on the skin layer, with embedded channels representing veins to achieve realistic glucose monitoring conditions. These channels were filled with D-(+)-Glucose solutions at varying concentrations (60 mg/dL to 200 mg/dL) to simulate physiological changes in blood glucose levels. A miniature patch antenna optimized to operate at 14 GHz with a penetration depth of approximately 1.5 mm was designed and fabricated. The antenna was tested in direct contact with the skin phantom, allowing for precise measurements of the changes in glucose concentration without interference from deeper tissue layers. Simulations and experiments demonstrated the antenna’s sensitivity to variations in glucose concentration, as evidenced by measurable shifts in the dielectric properties of the phantom. Importantly, the system enabled stationary measurements by injecting glucose solutions into the same blood vessels, eliminating the need to reposition the sensor while ensuring reliable and repeatable results. This work highlights the importance of shallow penetration depth in targeting close vessels for noninvasive glucose monitoring, and emphasizes the potential of microwave-based sensing systems as a practical solution for continuous glucose management. Full article

The early diagnosis of Alzheimer’s disease remains an unmet medical need due to the cost and invasiveness of current methods. Early detection would ensure a higher quality of life for patients, enabling timely and suitable treatment. We investigate microwave sensing for low-cost, non-intrusive early detection and assessment of Alzheimer’s disease. This study is based on the emerging evidence that the electromagnetic properties of cerebrospinal fluid are affected by abnormal concentrations of proteins recognized as early-stage biomarkers. We design a conformal six-element antenna array placed on the upper portion of the head, operating in the 500 MHz to 6.5 GHz band. It measures scattering response due to changes in the dielectric properties of intracranial cerebrospinal fluid. A multi-layer perceptron network extracts the diagnostic information. Data classification consists of two steps: binary classification to identify the disease presence and multi-class classification to evaluate its stage. The algorithm is trained and validated through controlled experiments mimicking various pathological severities with an anthropomorphic multi-tissue head phantom. Results support the feasibility of the proposed method using only amplitude data and lay the foundation for more extensive studies on microwave sensing for early Alzheimer’s detection. Full article

This paper introduces a flexible loop antenna-based sensor optimized for real-time monitoring of meat quality by detecting changes in dielectric properties over a six-day storage period. Operating within the 2.4 GHz ISM band, the sensor is designed using CST Microwave Studio 2024 to deliver high sensitivity and accuracy. The sensing mechanism leverages resonance frequency shifts caused by variations in permittivity as the meat degrades. Experimental validation across five samples showed a consistent frequency shift from 2.14 GHz (Day 0) to 1.29 GHz (Day 5), with an average sensitivity of $0.173\mathrm{GHz}/\mathrm{day}$. A strong correlation was observed between measured and simulated results, as evidenced by linear regression ($R^2=0.984$ and $R^2=0.974$ for measured and simulated data, respectively). The sensor demonstrated high precision and repeatability, validated by low standard deviations and minimal frequency deviations. Compact, printable, and cost-effective, the proposed sensor offers a scalable solution for food quality monitoring. Its robust performance highlights its potential for integration into IoT platforms and extension to other perishable food products, advancing real-time, non-invasive, RF-based food safety technologies. Full article

Rapid and accurate leaf area index (LAI) determination is important for monitoring daylily growth, yield estimation, and field management. Because of low estimation accuracy of empirical models based on single-source data, we proposed a machine-learning algorithm combining optical and microwave remote-sensing data as well as the random forest regression (RFR) importance score to select features. A high-precision LAI estimation model for daylilies was constructed by optimizing feature combinations. The RFR importance score screened the top five important features, including vegetation indices land surface water index (LSWI), generalized difference vegetation index (GDVI), normalized difference yellowness index (NDYI), and backscatter coefficients VV and VH. Vegetation index features characterized canopy moisture and the color of daylilies, and the backscatter coefficient reflected dielectric properties and geometric structure. The selected features were sensitive to daylily LAI. The RFR algorithm had good anti-noise performance and strong fitting ability; thus, its accuracy was better than the partial least squares regression and artificial neural network models. Synergistic optical and microwave data more comprehensively reflected the physical and chemical properties of daylilies, making the RFR-VI-BC05 model after feature selection better than the others ( r = 0.711, RMSE = 0.498, and NRMSE = 9.10%). This study expanded methods for estimating daylily LAI by combining optical and radar data, providing technical support for daylily management. Full article

This paper introduces a novel method for measuring the dielectric permittivity of materials within the microwave and millimeter wave frequency ranges. The proposed approach, classified as a guided wave transmission system, employs a periodic transmission line structure characterized by mirror/glide symmetry. The dielectric permittivity is deduced by measuring the transmission properties of such structure when presence of the dielectric material breaks the inherent symmetry of the structure and consequently introduce a stopband in propagation characteristic. To explore the influence of symmetry breaking on propagation properties, an analytical dispersion equation, for both symmetries, is formulated using the Rigorous Coupled Wave Analysis (RCWA) combined with the matrix transverse resonance condition. Based on the analytical equation, an optimization procedure and linearized model for a sensing structure is obtained, specifically for X-band characterization of FR4 substrates. The theoretical results of the model are validated with full wave simulations and experimentally. Full article

This study investigates the use of spoof surface plasmon polaritons (SSPPs) as an effective feeding mechanism for antennas functioning within the extremely high-frequency (EHF) range. A novel method is proposed for feeding a dielectric rod antenna with SSPPs, featuring a simple design made from FR-4 material with a relative permittivity of 4.3. In contrast to traditional tapered dielectric rod antennas and their feeding configurations, this design shows promise for achieving a gain of up to 16.85 dBi with an antenna length of 7.6 λ₀. By carefully optimizing the design, impedance matching and directional radiation characteristics were obtained at 7.3 GHz. Simulations were conducted using CST Microwave Studio to validate and evaluate the design’s performance. The enhanced gain, improved impedance bandwidth, and use of cost-effective materials such as FR-4 present a compelling case for adopting this design in future wireless communication technologies. Additionally, the remote sensing properties of the feeder can be utilized for concealed object detection, material characterization, and the analysis of the spectral properties of materials. Full article

In this article, the authors developed a novel method for the moisture mapping of the soil surface of agrophytocenosis using a neural network based on synchronized radar and multispectral optoelectronic data from Sentinel-1,2. The significance of this research lies in its potential to enhance precision farming practices, which are increasingly vital in addressing global agricultural challenges such as water scarcity and the need for sustainable resource management. To verify the developed method, data from two experimental plots were utilized. These plots were located on irrigated soybean crops, with the first plot situated on the right bank (plot No. 1) and the second on the left bank (plot No. 2) of the lower Volga River. Two experimental soil moisture geodatasets were created through measurements and geo-referencing points using the gravimetric method (for plot No. 1) and the proximal sensing method (for plot No. 2) employing the Soil Moisture Sensor ML3-KIT (THETAKIT, Delta). The soil moisture retrieval algorithm was based on the use of a neural network to predict the reflection coefficient of an electro-magnetic wave from the soil surface, followed by inversion into soil moisture using a dielectric model that takes into account the soil texture. The input parameter of the neural network was the ratio of the microwave radar vegetation index (calculated based on Sentinel-1 data) to the index (calculated based on the data of multispectral optoelectronic channels 8 and 11 of Sentinel-2). The retrieved soil moisture values were compared with in situ measurements, showing a determination coefficient of 0.44–0.65 and a standard deviation of 2.4–4.2% for plot No. 1 and similar metrics for plot No. 2. The conducted research laid the groundwork for developing a new technology for remote sensing of soil moisture content in agrophytocenosis, serving as a crucial component of precision farming systems and agroecology. The integration of this technology promotes sustainable agricultural practices by minimizing water consumption while maximizing crop productivity. This aligns with broader environmental goals of conserving natural resources and reducing agricultural runoff. On a larger scale, data derived from such studies can inform policy decisions related to water resource management, guiding regulations that promote efficient water use in agriculture. Full article

The high surface area and transfer-less growth of graphene on dielectric materials is still a challenge in the production of novel sensing devices. We demonstrate a novel approach to graphene synthesis on a C-plane sapphire substrate, involving the microwave plasma-enhanced chemical vapor deposition (MW-PECVD) technique. The decomposition of methane, which is used as a precursor gas, is achieved without the need for remote plasma. Raman spectroscopy, atomic force microscopy and resistance characteristic measurements were performed to investigate the potential of graphene for use in sensing applications. We show that the thickness and quality of graphene film greatly depend on the CH₄/H₂ flow ratio, as well as on chamber pressure during the synthesis. By varying these parameters, the intensity ratio of Raman D and G bands of graphene varied between ~1 and ~4, while the 2D to G band intensity ratio was found to be 0.05–0.5. Boundary defects are the most prominent defect type in PECVD graphene, giving it a grainy texture. Despite this, the samples exhibited sheet resistance values as low as 1.87 kΩ/□. This reveals great potential for PECVD methods and could contribute toward efficient and straightforward graphene growth on various substrates. Full article

Soil moisture is a critical factor that supports plant growth, improves crop yields, and reduces erosion. Therefore, obtaining accurate and timely information about soil moisture across large regions is crucial. Remote sensing techniques, such as microwave remote sensing, have emerged as powerful tools for monitoring and mapping soil moisture. Synthetic aperture radar (SAR) is beneficial for estimating soil moisture at both global and local levels. This study aimed to assess soil moisture and dielectric constant retrieval over agricultural land using machine learning (ML) algorithms and decomposition techniques. Three polarimetric decomposition models were used to extract features from simulated NASA-ISRO SAR (NISAR) L-Band radar images. Machine learning techniques such as random forest regression, decision tree regression, stochastic gradient descent (SGD), XGBoost, K-nearest neighbors (KNN) regression, neural network regression, and multilinear regression were used to retrieve soil moisture from three different crop fields: wheat, soybean, and corn. The study found that the random forest regression technique produced the most precise soil moisture estimations for soybean fields, with an R² of 0.89 and RMSE of 0.050 without considering vegetation effects and an R² of 0.92 and RMSE of 0.042 considering vegetation effects. The results for real dielectric constant retrieval for the soybean field were an R² of 0.89 and RMSE of 6.79 without considering vegetation effects and an R² of 0.89 and RMSE of 6.78 with considering vegetation effects. These findings suggest that machine learning algorithms and decomposition techniques, along with a semi-empirical technique like Water Cloud Model (WCM), can be effective tools for estimating soil moisture and dielectric constant values precisely. The methodology applied in the current research contributes essential insights that could benefit upcoming missions, such as the Radar Observing System for Europe in L-band (ROSE-L) and the collaborative NASA-ISRO SAR (NISAR) mission, for future data analysis in soil moisture applications. Full article

Microwaves can safely and non-destructively illuminate and penetrate dielectric materials, making them an attractive solution for various medical tasks, including detection, diagnosis, classification, and monitoring. Their inherent electromagnetic properties, portability, cost-effectiveness, and the growth in computing capabilities have encouraged the development of numerous microwave sensing and imaging systems in the medical field, with the potential to complement or even replace current gold-standard methods. This review aims to provide a comprehensive update on the latest advances in medical applications of microwaves, particularly focusing on the near-field ones working within the 1–15 GHz frequency range. It specifically examines significant strides in the development of clinical devices for brain stroke diagnosis and classification, breast cancer screening, and continuous blood glucose monitoring. The technical implementation and algorithmic aspects of prototypes and devices are discussed in detail, including the transceiver systems, radiating elements (such as antennas and sensors), and the imaging algorithms. Additionally, it provides an overview of other promising cutting-edge microwave medical applications, such as knee injuries and colon polyps detection, torso scanning and image-based monitoring of thermal therapy intervention. Finally, the review discusses the challenges of achieving clinical engagement with microwave-based technologies and explores future perspectives. Full article

Multi-beam microwave antennas have attracted enormous attention owing to their wide range of applications in communication systems. Here, we propose a broadband metamaterial-based multi-beam Luneburg lens-antenna with low polarization sensitivity. The lens is constructed from additively manufactured spherical layers, where the effective permittivity of the constituting elements is obtained by adjusting the ratio of dielectric material to air. Flexible microstrip patch antennas operating at different frequencies are used as primary feeds illuminating the lens to validate the radiation features of the lens-antenna system. The proposed Luneburg lens-antenna achieves ±72° beam scanning angle over a broad frequency range spanning from 2 GHz to 8 GHz and presents a gain between 15.3 dBi and 22 dBi, suggesting potential applications in microwave- and millimeter-wave mobile communications, radar detection and remote sensing. Full article
