Slender structures such as minarets are highly susceptible to earthquake-induced damage in seismically active regions. Although various methods, including analytical and observational techniques, have been employed to study the seismic response of reinforced concrete (RC) minarets, the use of scaled physical models and shaking table testing remains limited. This research examines the numerical feasibility of employing scaled physical models for shaking table investigations of RC minarets under realistic laboratory constraints. A representative RC minaret with a height of 33.2 m was selected and a geometric scale ratio of 1:10 length was adopted. Established physical modeling approaches were evaluated through numerical implementation, with particular attention to similitude requirements, material properties, and laboratory limitations. Within this framework, the Artificial Mass Model (AMM) and the Neglected Gravity Model (NGM) were examined as candidate strategies for scaled modeling. Both approaches necessitate the use of a material with a reduced modulus of elasticity or an increased mass density relative to the prototype material. To satisfy these requirements, two micro-concrete mixes, designated as Mix-1 and Mix-2, incorporating partial replacement of the binder with lower-stiffness constituents such as plaster gypsum and fly ash, were developed and characterized. Numerical results indicate that both the AMM and NGM approaches are viable for modeling slender RC minaret structures. Although the AMM provides slightly higher accuracy in reproducing the prototype dynamic response, the NGM offers greater practical applicability by eliminating the need for additional artificial mass. Overall, this study presents a preliminary numerical feasibility assessment that supports the selection of appropriate physical modeling strategies and provides a rational basis for the subsequent execution of shaking table experiments. Full article

Traditional stone masonry walls are structural elements in most historic buildings. To preserve them and improve their ability to withstand extreme events, such as earthquakes, it is necessary to implement effective reinforcement solutions. This paper presents the modeling of traditional Portuguese rubble stone masonry walls, reinforced with external steel mesh, sprayed micro-concrete layers and transverse confinement by steel connectors, which were developed and tested experimentally in uniaxial compression. The modeling is carried out using micro-modeling through a 2D particle model (PM). The process of calibrating the properties of both micro-concrete and concrete is presented, the methodology for generating the numerical models is described and the numerical response is compared with the experimental results. The numerical results show that the PM can adequately reproduce the experimentally observed behavior of this type of reinforcement solution. Full article

This paper investigates the short-term behavior of microconcretes with recycled rubber (RmCs) for extensive use as structural and non-structural materials. The physical and mechanical properties of a typical microconcrete composition have been experimentally evaluated by replacing the fine aggregate with rubber granules in volumetric percentages of 10%, 20%, and 30%. The results obtained are compared with the data provided by other authors for crumb rubber concretes (CRCs). Material investment costs have also been estimated to determine the economic impact of using rubber as a fine aggregate in these products. It is observed that the use of small percentages of recycled rubber (up to 20%) produces significant increases in slump as well as important drops in compressive strength, although it substantially improves its post-critical behavior. These trends tend to stabilize with higher percentages of rubber (30%). It is also noted that the experimental results and predictive models developed for concretes are not applicable to microconcretes, so more specific research is desirable for this type of product. Regarding the economic profitability of the investment in RmCs, it is found that it is necessary to make recycled rubber cheaper and to ensure its technological performance in order to guarantee the quality of the final product. Full article

The structural rehabilitation of historic/traditional rubble masonry wall constructions requires consolidation and retrofitting solutions to be employed in order to withstand dynamic loads, high vertical loads, and differential settlements. One of these strengthening techniques is based on the use of steel bar connectors perpendicular to the wall, considered individually or integrated into more complex strengthening techniques. The aim of this study is to evaluate numerically the strengthening effect of transverse steel connectors on rubble masonry walls. With this purpose, a 2D particle-reinforced model (2D-PMR) was devised and applied to model uniaxial compression tests. The results presented show that predictions calculated using the proposed 2D-PMR model are very close to known experimental results, particularly in the corresponding failure modes, the increase of the maximum uniaxial compression value, and ductility. Parametric studies are also conducted by varying the diameter of the steel bars and the level of strengthening to assess the influence of the bar-bond effect and lateral plates. The presented parametric numerical studies show that (i) a two-level strengthening solution guarantees a similar response to the three-level strengthening solution adopted in the experiments; (ii) it is not relevant to apply a grout injection during the application process of the steel connectors if lateral plates are adopted; and (iii) the 2D-PMR model can be used in the definition of the steel bar diameter and properties; as shown, a smaller (8 mm) bar diameter predicts a similar strengthening effect to the (12 mm) bar size adopted in the experiments. Given the performance of the proposed 2D-PMR model, further work is underway that will allow the 2D-PMR model to numerically assess other reinforcement techniques, namely, reinforced micro-concrete layers and textile reinforced mortar. Full article

Reinforced concrete (RC) frames are an integral part of modern construction as they resist both gravity and lateral loads in beams and columns. However, the construction methodologies of RC frames are vulnerable to non-engineering defects, particularly in developing countries. The most common non-engineering defect occurs due to improper lap splice, which can compromise the structural integrity. This research demonstrates an easy, low-cost, and verifiable experimental technique incorporating micro-concrete to evaluate the seismic performance of a completely engineered RC frame with the defect of improper lap splice. The micro-concrete was prepared by using the locally available material for a target compressive strength and then two scaled-down RC frames (1/16 scale) were prepared, including one proper frame and another with improper lap splice. Finally, these frames were tested on a shake table to study their behavior under various seismic loading conditions. This study quantifies the severity of high-risk structural systems due to non-engineering defects. The experimental results demonstrate that improper lap splice can alter the frame’s damage points, triggering the failure of the whole structure. Full article

As an important water conveying structure, the seismic safety of the hydraulic aqueduct has attracted considerable interest. Different from the general bridge structure, the seismic analysis of the aqueduct structure needs to consider its fluid–structure interaction. The existing numerical simulation methods cannot truly reflect the fluid–solid coupling mechanism. Therefore, scholars began to use shaking table tests to study the fluid–structure interaction mechanism. However, the research is immature, and it is mostly focused on the seismic response analysis, and there are few studies on the model test similarity ratio and model material properties. Based on this, in this paper, according to the requirements of the test similarity ratio, the orthogonal experiment was used to explore the influence of barite sand content, water–cement ratio, fine sand ratio, and lime ratio on the mechanical properties of microconcrete. The performance indicators of microconcrete under different mix ratios vary widely, with a minimum variation of 19% and a maximum of 102%. Barite sand has the most significant control effect on the density, and the water–cement ratio has the most significant control effect on the compressive strength and elastic modulus. The density variation range is 2.37–2.81 g/cm³, the cube compressive strength variation range is 18.37–36.94 MPa, and the elastic modulus variation range is 2.11 × 10⁴–3.28 × 10⁴ MPa. This study will provide certain evidence for the similarity ratio design and material selection of the scaled model test of the fluid–solid coupling structure. Full article

Concrete, the most common material in the building industry, involves the use of mineral aggregates that represent an exhaustible resource, despite their large availability. For a series of applications, these mineral aggregates can be replaced by vegetal ones, which represent an easy renewable natural resource. In this study, two types of vegetal raw materials, namely sunflower stalks and corn cobs, were used in developing 10 compositions of ecological microconcrete, with different percentages involved: 20%, 35%, 50%, 65% and 80%; they were analyzed from the perspectives of density, compressive strength, splitting tensile strength, resistance to repeated freeze-thaw cycles, modulus of elasticity and thermal conductivity. The results revealed that the microconcretes with sunflower stalks registered slightly higher densities and better results regarding the compressive strength, splitting tensile strength, modulus of elasticity, and freeze-thaw resistance than those with corn cobs. Lightweight concrete is obtained when more than 50% replacement rates of the mineral aggregates are used. Full article

This study aims to assess the production of cellular micro-concrete, consisting of quarry dust, calcareous fly ash, cement, and aluminum powder as aerating agent. The proposed mixture design methodology is based on a Box–Behnken fractional factorial experimental design. Testing of specimens included compressive and flexural strength, density, water absorption, and thermal conductivity measurements. Results indicate that density is a characteristic property which determines all the measured properties. Aerating agent to cement and fly ash ratio has the strongest effect on all the measured properties. The developed methodology is a valuable tool for the production of cellular micro-concrete with predetermined properties by utilizing large amounts of quarry dust. Full article

The morphology and mineralogical and geochemical compositions of the freshwater ferromanganese formations (FMF) of Lake Onego (NW Russia) and small lakes located in its catchment area were studied. The lake waters, bottom sediments and FMF were analyzed by a set of modern methods of geochemistry, mineralogy, and crystal chemistry (powder X-ray diffraction, IR spectroscopy, electron microscopy, ICP–MS analysis, atomic absorption, etc.). A detailed description of the microscopic structure in comparison with the geochemical characteristics of the FMF provides new information on the role of biota in the formation and behavior of individual elements at various stages in the nodule formation process. This study shows the homogeneous composition of microconcretions—only manganese or only ferruginous—in bottom sediments throughout the entire water area of Lake Onego and the rhythmic structures of the nodules, formed by macro- and microlayers with mineralized microbiota. The layers are composed of either crystalline Mn mineral phases (pyrolusite, rhodochrosite) or crystalline Fe mineral phases (siderite, goethite). The separation of Mn and Fe mineral phases in the nodules proceeded during their formation and diagenesis. The examined chemical and mineral compositions, textures, and structures of the nodules are a testament to the hydrogenic source of their ore substance and the formation of FMF is controlled primarily by redox environments at the water–sediment interface. Full article
