Search Results (67)

The research is motivated by the search for materials with negative viscosity to exploit the effect of negative mass. We introduce media (gaseous and liquid) that demonstrate negative viscosity. Consider the vibrated plate, which is vertically pulled through the ideal gas and built from the core–shell “meta-molecules”. Vibrating the vertical plate supplies an excess vertical momentum to the core–shell meta-molecules. If the frequency of vibrations is larger than the resonant frequency, the excess moment is oriented against the direction of the vertical motion; thus, the effect of negative viscosity becomes possible. The effective viscosity becomes negative when the frequency of the plate vibrations approaches the resonant frequency from above. Thus, a novel physical mechanism resulting in negative viscosity is introduced. No violation of energy conservation is observed; the energy is supplied to the system by the external source vibrating the plate. The effect of the negative viscosity is also possible in liquids. Frequency dependence of the viscosity is addressed. Asymptotic expressions are derived for the frequency-dependent viscosity. Introduced meta-materials may be exploited for the development of media with prescribed rheological properties. Possible realizations of the negative-viscosity media are discussed. Full article

This research proposes an all-metal metamaterial-based absorber with a novel geometry capable of refractive index sensing in the terahertz (THz) range. The structure consists of four concentric diamond-shaped gold resonators on the top of a gold metal plate; the resonators increase in height by 2 µm moving from the outer to the inner resonators, making the design distinctive. This novel configuration has played a very significant role in achieving multiple ultra-narrow resonant absorption peaks that produce very high sensitivity when employed as a refractive index sensor. Numerical simulations demonstrate that it can achieve six significant ultra-narrow absorption peaks within the frequency range of 5 to 8 THz. The sensor has a maximum absorptivity of 99.98% at 6.97 THz. The proposed absorber also produces very high-quality factors at each resonance. The average sensitivity is 7.57/Refractive Index Unit (THz/RIU), which is significantly high when compared to the current state of the art. This high sensitivity is instrumental in detecting smaller traces of samples that have very correlated refractive indices, like several harmful gases. Hence, the proposed metamaterial-based sensor can be used as a potential gas detector at terahertz frequency. Furthermore, the structure proves to be polarization-insensitive and produces a stable absorption response when the angle of incidence is increased up to 60°. At terahertz wavelength, the proposed design can be used for any value of the aforementioned angles, targeting THz spectroscopy-based biomolecular fingerprint detection and energy harvesting applications. Full article

To reduce the low-frequency noise inside automobiles, a lightweight plate-type locally resonant acoustic metamaterial (LRAM) is proposed. The design method for the low-frequency bending wave bandgap of the LRAM panel was derived. Prototype LRAM panels were fabricated and tested, and the effectiveness of the bandgap design was verified by measuring the vibration transmission characteristics of the steel panels with the installed LRAM. Based on the bandgap design method, the influence of geometric and material parameters on the bandgap of the LRAM panel was investigated. The LRAM panel was installed on the inner side of the tailgate of a traditional SUV, which effectively reduced the low-frequency noise (around 34 Hz) during acceleration and constant-speed driving, improving the subjective perception of the low-frequency noise from “very unsatisfactory” to “basically satisfactory”. Furthermore, the noise reduction performance of the LRAM panel was compared with that of traditional damping panels. It was found that, with a similar installation area and lighter weight than the traditional damping panels, the LRAM panel still achieved significantly better low-frequency noise reduction, exhibiting the advantages of lightweight, superior low-frequency performance, designable bandgap and shape, and high environmental reliability, which suggests its great potential for low-frequency noise reduction in vehicles. Full article

Three-dimensional metamaterials endowed with two-dimensional in-plane periodicity exhibit peculiar thermoelastic behaviour when heated or cooled. By proper design of the unit cell, the equivalent thermal expansion coefficient can be programmed and can also reach negative values. The heterogeneity in the third direction of such metamaterials also causes, in general, a thermal-induced deflection. The prediction of the equivalent thermal properties is important to design the metamaterial suitable for a specific application. Under the hypothesis of small thickness with respect to the global in-plane dimensions, we make use of asymptotic homogenization to describe the thermoelastic behaviour of these metamaterials as that of an equivalent homogenous plate. The method provides explicit expressions for the effective thermal properties, which allow for a cost-effective prediction of the thermoelastic response of these metaplates. Full article

In many noise scenarios, it is necessary to ensure ventilation and noise suppression. In this paper, a ventilated acoustic metamaterial labyrinth plate (VAMLP), formed by an array of labyrinth cells (LCs), is presented. Each labyrinth cell contains four labyrinth waveguide units (WUs). Based on the impedance series principle, an analytical model of the WU was developed and validated by a numerical model and impedance-tube experiments to determine the sound transmission loss of the WU and the LC. The mechanism of the influence of thermo-viscous loss was quantitatively analyzed, and it was clarified that the VAMLP produced sound absorption due to thermo-viscous loss. The change law of impedance at the entrance of the waveguide was analyzed, revealing the noise-reduction mechanism of the labyrinth unit. Combining a BP network and an improved sparrow search algorithm (ISSA), a BP–ISSA optimization model is proposed to optimize the ventilation capacity of the labyrinth cells. The BP-network model can accurately predict the resonance frequency from the structural parameters to form the fitness function. The ISSA optimization model was constructed using the fitness function as the constraint of an equation. Finally, the combination of structural parameters with optimal ventilation capacity was obtained for a given noise frequency. Full article

Phononic crystals based on lattice structures provide important wave dispersion characteristics as band structures, showing excellent compatibility with additive manufacturing. Although the lattice structures have shown the potential for vibration suppression, a design guideline to control the frequency range of the bandgap has not been well established. This paper studies the dispersion characteristics of plane wave propagation in lattice-based mechanical metamaterials to realize effective vibration suppression for potential aerospace applications. Triangular and hexagonal periodic lattice structures are mainly studied in this paper. The influence of different geometric parameters on the bandgap characteristics is investigated. A finite element approach with Floquet–Bloch’s principles is implemented to effectively evaluate the dispersion characteristics of waves in lattice structures, which is validated numerically and experimentally with a 3D-printed lattice plate. Based on numerical studies with the developed analysis framework, the influences of the geometric parameters of lattice plate structures on dispersion characteristics can mainly be categorized into three patterns: change in specific branches related to in-plane or out-of-plane vibrations, upward/downward shift in frequency range, and drastic change in dispersion characteristics. The results obtained from the study provide insight into the design of band structures to realize vibration suppression at specific frequencies for engineering applications. Full article

This article proposes a novel fixed-frequency beam scanning leakage antenna based on a liquid crystal metamaterial (LCM) and adopting a metal column embedded microstrip line (MCML) transmission structure. Based on the microstrip line (ML) transmission structure, it was observed that by adding two rows of metal columns in the dielectric substrate, electromagnetic waves can be more effectively transmitted to reduce dissipation, and attenuation loss can be lowered to improve energy radiation efficiency. This antenna couples TEM mode electromagnetic waves into free space by periodically arranging 72 complementary split ring resonators (CSRRs). The LC layer is encapsulated in the transmission medium between the ML and the metal grounding plate. The simulation results show that the antenna can achieve a 106° continuous beam turning from reverse −52° to forward 54° at a frequency of 38 GHz with the holographic principle. In practical applications, beam scanning is achieved by applying a DC bias voltage to the LC layer to adjust the LC dielectric constant. We designed a sector-blocking bias feeder structure to minimize the impact of RF signals on the DC source and avoid the effect of DC bias on antenna radiation. Further comparative experiments revealed that the bias feeder can significantly diminish the influence between the two sources, thereby reducing the impact of bias voltage introduced by LC layer feeding on antenna performance. Compared with existing approaches, the antenna array simultaneously combines the advantages of high frequency band, high gain, wide beam scanning range, and low loss. Full article

Additive manufacturing enables the production of lattice structures, which have been proven to be a superior class of lightweight mechanical metamaterials whose specific stiffness can reach the theoretical limit of the upper Hashin–Shtrikman bound for isotropic cellular materials. To achieve isotropy, complex structures are required, which can be challenging in powder bed additive manufacturing, especially with regard to subsequent powder removal. The present study focuses on the Finite Element Method simulation of 2.5D anisotropic plate lattice metamaterials and the investigation of their lightweight potential. The intentional use of anisotropic structures allows the production of a cell architecture that is easily manufacturable via Laser Powder Bed Fusion (LPBF) while also enabling straightforward optimization for specific load cases. The work demonstrates that the considered anisotropic plate lattices exhibit high weight-specific stiffnesses, superior to those of honeycomb structures, and, simultaneously, a good de-powdering capability. A significant increase in stiffness and the associated surpassing of the upper Hashin–Shtrikman bound due to anisotropy is achievable by optimizing wall thicknesses depending on specific load cases. A stability analysis reveals that, in all lattice structures, plastic deformation is initiated before linear buckling occurs. An analysis of stress concentrations indicates that the introduction of radii at the plate intersections reduces stress peaks and simultaneously increases the weight-specific stiffnesses and thus the lightweight potential. Exemplary samples illustrate the feasibility of manufacturing the analyzed metamaterials within the LPBF process. Full article

Acoustic metamaterials (AMs) composed of periodic artificial structures have extraordinary sound wave manipulation capabilities compared with traditional acoustic materials, and they have attracted widespread research attention. The sound insulation performance of thin-walled structures commonly used in engineering applications with restricted space, for example, vehicles’ body structures, and the latest studies on the sound insulation of thin-walled metamaterial structures, are comprehensively discussed in this paper. First, the definition and math law of sound insulation are introduced, alongside the primary methods of sound insulation testing of specimens. Secondly, the main sound insulation acoustic metamaterial structures are summarized and classified, including membrane-type, plate-type, and smart-material-type sound insulation metamaterials, boundaries, and temperature effects, as well as the sound insulation research on composite structures combined with metamaterial structures. Finally, the research status, challenges, and trends of sound insulation metamaterial structures are summarized. It was found that combining the advantages of metamaterial and various composite panel structures with optimization methods considering lightweight and proper wide frequency band single evaluator has the potential to improve the sound insulation performance of composite metamaterials in the full frequency range. Relative review results provide a comprehensive reference for the sound insulation metamaterial design and application. Full article

Actuators play a crucial role in microelectromechanical systems (MEMS) and hold substantial potential for applications in various domains, including reconfigurable metamaterials. This research aims to design, fabricate, and characterize structures for the actuation of the EMA. The electromagnetic actuator overcomes the lack of high drive voltage required by other actuators. The proposed actuator configuration comprises supporting cantilever beams with fixed ends, an integrated coil positioned above the cantilever’s movable plate, and a permanent magnet located beneath the cantilever’s movable plate to generate a static magnetic field. Utilizing flexible polyimide, the fabrication process of the EMA is simplified, overcoming limitations associated with silicon-based micromachining techniques. Furthermore, this approach potentially enables large-scale production of EMA, with displacement reaching up to 250 μm under a 100 mA current, thereby expanding their scope of applications in manufacturing. To demonstrate the function of the EMA, we integrated it with a metamaterial structure to form a compact, tunable terahertz absorber, demonstrating a potential for reconfigurable electromagnetic space. Full article

It is known that the dielectric layer (resonator) located behind the conducting plate of the bolometer system can significantly increase its sensitivity near the resonance frequencies. In this paper, the possibility of receiving broadband electromagnetic signals in a multilayer bolometric meta-material made of alternating conducting (e.g., silicon semiconductor) and dielectric layers is demonstrated both experimentally and numerically. It is shown that such a multilayer structure acts as a lattice of resonators and can significantly increase the width of the frequency band of efficient electromagnetic energy absorption. The parameters of the dielectric and semiconductor layers determine the frequency bands. Numerical modeling of the effect has been carried out under the conditions of our experiment. The numerical results show acceptable qualitative agreement with the experimental data. This study develops the previously proposed technique of resonant absorption of electromagnetic signals in bolometric structures. Full article

In this paper, a new tuning strategy is proposed by incorporating a pneumatically actuated metamaterial to achieve on-demand polarization manipulation at THz frequencies. Through controlling the actuation pressure, the device function can be flexibly switched among three types of polarization conversion capabilities within the same operation frequency band, from 1.3 THz to 1.5 THz, in which the mutual conversion between linear polarization and circular polarization, such as a quarter-wave plate, and handedness inversion between circular polarizations as a helicity inverter as well as a helicity keeper, have been successfully achieved between the incidence and reflection. Moreover, the intrinsic tuning mechanism for the polarization manipulation is also discussed. Full article

Metamaterial-based quarter-wave plates (QWPs) have emerged as promising candidates for advanced polarization control in a variety of optical applications, owing to their unique properties, such as ultra-thin profiles and tailored spectral responses. We design an ultra-thin, high-efficiency, and broadband QWP in transmission mode based on a TiO${}_2$/Au grating structure. We show that multiple reflections and the near-field effects associated with the integration of these devices pose challenges that must be considered when combining multiple metamaterials. We present insights that facilitate improved design methodology and the optimization of integrated metamaterial QWPs and other metadevices. Our results contribute to the development of miniaturized and high-density advanced lightwave and polarization control devices in optical systems. Full article

The lattice metamaterial has attracted extensive attention due to its excellent specific strength, energy absorption capacity, and strong designability of the cell structure. This paper aims to explore the functional nickel plating on the basis of biomimetic-designed lattice structures, in order to achieve higher stiffness, strength, and energy absorption characteristics. Two typical structures, the body-centered cubic (BCC) lattice and the bioinspired hierarchical circular lattice (HCirC), were considered. The BCC and HCirC lattice templates were prepared based on DLP (digital light processing) 3D printing. Based on this, chemical plating, as well as the composite plating of chemical plating followed by electroplating, was carried out to prepare the corresponding nickel-plated lattice structures. The mechanical properties and deformation failure mechanisms of the resin-based lattice, chemically plated lattice, and composite electroplated lattice structures were studied by using compression experiments. The results show that the metal coating can significantly improve the mechanical properties and energy absorption capacity of microlattices. For example, for the HCirC structure with the loading direction along the x-axis, the specific strength, specific stiffness, and specific energy absorption after composite electroplating increased by 546.9%, 120.7%, and 2113.8%, respectively. The shell–core structure formed through composite electroplating is the main factor for improving the mechanical properties of the lattice metamaterial. In addition, the functional nickel plating based on biomimetic structure design can further enhance the improvement space of mechanical performance. The research in this paper provides insights for exploring lighter and stronger lattice metamaterials and their multifunctional applications. Full article

To reduce the noise generated by large mechanical equipment, a stackable and expandable acoustic metamaterial with multiple tortuous channels (SEAM–MTCs) was developed in this study. The proposed SEAM–MTCs consisted of odd panels, even panels, chambers, and a final closing plate, and these component parts could be fabricated separately and then assembled. The influencing factors, including the number of layers N, the thickness of panel t₀, the size of square aperture a, and the depth of chamber T₀ were investigated using acoustic finite element simulation. The sound absorption mechanism was exhibited by the distributions of the total acoustic energy density at the resonance frequencies. The number of resonance frequencies increased from 13 to 31 with the number of layers N increasing from 2 to 6, and the average sound absorption coefficients in [200 Hz, 6000 Hz] was improved from 0.5169 to 0.6160. The experimental validation of actual sound absorption coefficients in [200 Hz, 1600 Hz] showed excellent consistency with simulation data, which proved the accuracy of the finite element simulation model and the reliability of the analysis of influencing factors. The proposed SEAM–MTCs has great potential in the field of equipment noise reduction. Full article
