Metal bellows feature a simple structure, high-temperature resistance, corrosion resistance, and strong flexibility for compensation, making them widely used in the aerospace, machinery, and petrochemical industries. Compared to multilayer bellows, single-layer bellows are simpler in structure and forming process, making the performance easier to achieve. The structural parameters of multilayer metal bellows, particularly the number of layers, significantly impact the performance. This study focuses on multilayer U-shaped metal bellows made of 304 stainless steel. Using ABAQUS finite element software, a full simulation of the hydroforming and performance analysis of multilayer U-shaped metal bellows is conducted. This study examines the effects of wall thickness thinning and residual stress distribution caused by hydroforming and explores how structural parameters (including outer diameter, corrugation height, corrugation spacing, and wall thickness) influence axial stiffness and bending performance. The findings provide valuable insights for the design and selection of metal bellows. Full article

Firmly, the bearing capacity test of 1:1 equal ratio pillar under different constraint forms and different filling medium conditions was carried out. The results show that the binding pillar-forming effect is relatively good. The constraint ability of unconstrained, metal mesh, polyester mesh, hooked iron flat-hoop bushing, bellows, and spiral iron pipe is enhanced, in turn, and the carrying capacity is improved successfully. The homogeneity of high-water materials is better than concrete, and they have better compressibility, but their carrying capacity is relatively weak. The carrying capacity of concrete pillars is generously higher than that of high-water materials, but the compressibility is poor. Second, the migration characteristics of the surrounding rock structure of the gob-side entry retaining and the rule of side support are analyzed, the requirements of the side support are pointed out, and the side-support technology of the binding pillar is proposed. Taking Hijiata Mine’s 50108 working face gob-side entry retaining as an example, the bellows pump-filled concrete pillar is used as the side support body, supplemented by handling steel mesh and air-duct cloth, and toughness material is sprayed between the pillars to seal the goaf, meeting the requirements of side support and road stability. The pillar has the characteristics of high early strength, strong final consolidation carrying capacity, good crimping effect, high mechanism degree, fast construction speed, less concrete consumption, low comprehensive cost, etc., and it has a good application prospect in the gob-side entry retaining or rapid advanced working face. Full article

Several chemicals, such as pesticides and heavy metals, are frequently encountered together in environment matrices, becoming a priority concerning the prevention of their emissions, as well as their removal from the environment. In this sense, this work aimed to evaluate the effectiveness of a permeable biosorbent bio-barrier reactor (PBR) on the removal of atrazine and heavy metals (copper and zinc) from aqueous solutions. The permeable bio-barrier was built with a bacterial biofilm of R. viscosum supported on 13X zeolite. One of the aims of this work is the investigation of the toxic effects of atrazine, copper and zinc on the bacterial growth, as well as the assessment of their ability to adapt to repeated exposure to contaminants and to degrade atrazine. The growth of R. viscosum was not affected by concentrations of atrazine bellow 7 mg/L. However, copper and zinc in binary solutions were able to inhibit the growth of bacteria for all the concentrations tested (5 to 40 mg/L). The pre-acclimation of the bacteria to the contaminants allowed for an increase of 50% of the bacterial growth. Biodegradation tests showed that 35% of atrazine was removed/degraded, revealing that this herbicide is a recalcitrant compound that is hard to degrade by pure cultures. The development of a PBR with R. viscosum supported on zeolite was successfully performed and the removal rates were 85% for copper, 95% for zinc and 25% for atrazine, showing the potential of the sustainable and low-cost technology herein proposed. Full article

Silicon-ethanol is a relatively new smart composite in the category of phase-change materials (PCM). It consists of liquid ethanol entrapped in bubbles spread into a silicone rubber matrix, i.e., during cooling. The composite is able to expand significantly when heat is applied and shrink when it is removed. The properties of this material can be used in a new type of actuator. In this paper, the basic equations that describe the properties of actuators with a silicon-ethanol composite are given. Using them, two solutions of unidirectional actuators with a composite inserted into polycarbonate tubes and metal bellows are designed and investigated. In the study, actuators with different geometric dimensions and applied composite volumes are investigated. The elongations of the actuators and the blocking forces are measured. The theoretical relationships given at the beginning of the paper that describe the properties of the composite are validated using the performed experimental results of the built actuators. The tube actuators achieved elongation between 32% and 35% at a temperature of 75 degrees Celsius, that is, less than that predicted according to equations from earlier publications. Due to this, a modified equation that includes the influence of friction was proposed and compared with experimental results. The performance of the tube actuator deteriorates rapidly. In the case of bellow actuators, they stabilize after a few cycles of heating and cooling. Full article

Socket connection need a groove reserved in the cap to accommodate a bridge pier, which greatly weaken the vertical bearing capacity of the cap. The conventional treatment measure is to increase the thickness of the cap, and the corresponding cost will increase. The measures to enhance the vertical bearing capacity of socket caps without increasing the thickness of the cap were discussed in this paper, including a rough interface at the bottom of the pier, additional hanging bars, high-strength grouting material in the seam, and large-diameter metal corrugated pipes, etc. Based on a previous test, the finite element analysis of the vertical bearing capacity of pile caps with new socket connections was carried out. The analysis parameters included the construction method, steel bar diameter in the bottom of the cap, socket depth, thickness of the bottom plate, pile length, and friction coefficient, etc. The bearing capacity M–N relation of the full-scale model was also analyzed. Research indicated the vertical bearing capacity of the cap is mainly provided by rough interfaces, the bottom plate, and the additional hanging bars, and the contribution of the three parts was about 40%, 34%, and 26%; the vertical bearing capacity was proportional to the areas of steel bars on the cap and the thickness of the bottom plate, and was inversely proportional to the length of the pile. To obtain the vertical bearing capacity of the overall cast-in-place plan for the socket cap, the thickness of the cap needs to be increased by 27%. At last, a design formula for the calculation of the vertical bearing capacity was proposed. Full article

Piping systems are a representative social infrastructure to provide oil, gas, and water. Damage to piping systems may cause serious consequences, such as fire, water outage, and environmental pollution. Therefore, piping systems need to be protected from natural disasters, such as earthquakes. Earthquakes may cause deformation that exceeds piping design criteria. For example, large relative displacements and liquefaction of the ground resulting in loss of strength and ground subsidence, and the side-sway of primary structures subjected to a strong ground motion may cause critical damage to piping systems. Therefore, expansion joints to maintain flexibility can be applied to locations where excessive deformation is expected to improve the seismic performance of piping systems. Metal bellows, a type of expansion joints, are flexible, so they are highly durable against deformation and fatigue loads. This indicates that metal bellows can be used as seismic separation joints for piping. In this study, experimental research was conducted to analyze the seismic performance of multi-ply bellows type expansion joints, a type of metal bellows. Monotonic loading tests and cyclic loading tests were conducted on 2-ply bellows and 3-ply bellows, and the results were compared. In the cyclic loading tests, multi-step increasing amplitude cyclic loading, which used the displacement history amplified in stages, and constant amplitude cycling loading with various magnitudes were considered. The test results showed no significant difference in bending performance for monotonic loading between the two types of multi-ply bellows. The 3-ply bellows, however, showed higher performance for low-cycle fatigue than 2-ply bellows. Full article

Floating liquefied natural gas (FLNG) cryogenic hoses can be employed for the transmission of liquefied natural gas (LNG). Usually, U-shaped metal bellows can be applied as the inner lining of FLNG cryogenic hoses. In installation, positioning and other working conditions, torsion is one of the main loads, and torsional buckling instability is a major failure mode of U-shaped metal bellows of FLNG cryogenic hoses. In the current research, the buckling instability of bellows under torsional loads has been investigated in detail, the mechanical mechanism of deformation in torsional buckling mode of bellows has been analyzed and the influence of the structural design parameters on the stability performance has been summarized. It was seen that the axis of the bellows was presented as a spiral line shape during the torsional buckling stage. At the same time, the torsional buckling properties of toroid and spiral bellows were analyzed. The obtained results showed that the torsional buckling stability of the spiral bellows was weaker than that of the toroid bellows and increase of the spiral angle of the spiral bellows intensified this trend. In addition, the post-buckling analysis of U-shaped bellows under torsional loads was carried out by means of experiments and finite element simulation. It was shown that the results obtained from finite element (FE) analysis in this research presented a relatively accurate critical torque value and a consistent buckling instability mode, compared with the experimental results. On this basis, the effects of common defects such as thickness thinning on the torsional stability of bellows were investigated. Considering the geometric defect of thickness thinning, the error of FE analysis was reduced further, and it was found that the defect could significantly decrease the stability of the bellows. The above analysis results could provide a reference for structural design and post-buckling analysis of bellows. Full article

This paper investigates the reliability of welded metal bellows used in mechanical seals under specified working conditions. Firstly, considering the working environment of mechanical seals and the structural characteristics of welded metal bellows, a stress relaxation test bench was developed to obtain projectile loss data of welded metal bellows under different compression loads at elevated temperatures. The creep constants for a stress relaxation simulation were derived from the experimental data, and a stress relaxation finite element analysis (FEA) of the bellows was conducted using Workbench under different compression loads. We found that the stress relaxation simulation of welded metal bellows can accurately simulate the relaxation characteristics of welded metal bellows. The reliability of the welded metal bellows was calculated using Six Sigma response surface reliability by taking the material properties and compression load as variable parameters and the residual elasticity of the bellows as the objective function. We concluded that the reliability calculation method of welded metal bellows promotes reliability research into welded metal bellows for mechanical seals. Full article

To reduce the transmission of vibration energy from the ship’s pipeline to the bulkhead, a novel all-metal pipe element passing through the bulkhead with symmetrical elastic installation was proposed in this paper. A metal bellow, a multi-layer thin-walled symmetrical structure, was used as an elastic element and entangled metallic wire materials (EMWM) were used as a damping element. The insertion loss was adopted to evaluate the vibration damping performance. The results show that compared with the pipe element passing through the bulkhead with rigid installation, the vibration damping performance of the pipe element passing through bulkhead with symmetrical elastic installation can significantly isolate the vibration transition, and the maximum average insertion loss in each direction can reach 25.4 dB. A thermal-vibration joint test system of the pipe element passing through the bulkhead was built. A series of comparison experiments were carried out to investigate the influence of temperature, symmetrical measure points, and exciting directions on the vibration response transmitted to the bulkhead. Therefore, the vibration damping performance was verified. Full article

Welded metal bellows are an elastic element widely used in the field of mechanical seals. The main objective of the present study was to investigate the reliability of welded metal bellows in mechanical seals under specified working conditions. To this end, a stress relaxation test bench was built to obtain the residual elastic force data of welded metal bellows under different compression loads in high-temperature environments. Then, the elastic force loss equation of the bellows was fitted. Moreover, a failure judgment form of welded metal bellows in the mechanical seal is proposed. According to the calculation relationship between the seal face pressure and the welded metal bellows’ elastic force, the elasticity force loss range of the bellows was 556–708 N. Finally, according to the elastic force loss equation, elastic force loss was determined. The maintenance time of the welded metal bellows, and the bellow’s failure limit state equation were determined, and the limit state equation was substituted into the center point method. The reliability of the welded metal bellows was 0.9958. The results show that the new failure criterion and the center point reliability calculation method proposed in this paper have certain practical value for the rapid reliability prediction of welded metal bellows. Full article

The U-shaped metal bellows expansion joint compensates for the pipeline displacement by its own deformation. The compensation performance of the metal bellows in the initial stage of tension and compression deformation is unstable. In this paper, the symmetrical cyclic tension and compression (SCTC) process of metal bellows was simulated by ABAQUS software. Then, the SCTC process experiment of metal bellows was completed on the universal material testing machine. The distribution law of axial load with displacement and that of axial stiffness and yield load with cycles of metal bellows were obtained. Finally, the X-ray diffraction peak confirmed the deformation-induced martensite in the wave trough and proved that the plastic strain and hardness values of metal bellows increased with the displacement amplitude. The microstructure in the wave trough area was observed by a Zeiss microscope, and the stability characteristics mechanism of the metal bellows was revealed. The martensite in the wave trough increases the grain boundary area under SCTC loading. The forward movement of the slip band in the grain caused by large deformation reached an equilibrium state with the resistance at the grain boundary, which promotes the macroscopic mechanical properties of the metal bellows to be stable characteristics under SCTC loading. Full article

Braided corrugated hoses are widely used in displacement compensation and vibration absorption environments due to their excellent flexibility and energy dissipation properties; however, the axial stiffness has rarely been discussed before as an important physical property of braided corrugated hoses. In this paper, the theoretical axial stiffness model for braided corrugated hoses is established based on the energy method and the theory of the curved beam. The influences of the braiding parameters of the metallic braided tube and the structural parameters of the bellows on the axial stiffness are also discussed. Through finite element tensile testing, the axial stiffness curves of the braided corrugated hose under different braiding angles and different wire diameters are obtained. The theoretical axial stiffness model is in good agreement with the simulation experiment, which reflects the nonlinear effects of the braiding angle and wire diameter on the braided corrugated hose. This paper provides an accurate method and basis for the design of braided corrugated hoses in the future. Full article

This report describes the design of a new piezoelectric transducer for round window (RW)-driven middle ear implants. The transducer consists of a piezoelectric element, gold-coated copper bellows, silicone elastomer (polydimethylsiloxane, PDMS), metal cylinder (tungsten), and titanium housing. The piezoelectric element is fixed to the titanium housing and mechanical resonance is generated by the interaction of the bellows, PDMS, and tungsten cylinder. The dimensions of PDMS and the tungsten cylinder with output characteristics suitable for compensation of sensorineural hearing loss were derived by mechanical vibrational analysis (equivalent mechanical model and finite element analysis (FEA)). Based on the results of FEA, the RW piezoelectric transducer was implemented, and bench tests were performed under no-load conditions to confirm the output characteristics. The transducer generates an average displacement of 219.6 nm in the flat band (0.1–1 kHz); the resonance frequency is 2.3 kHz. To evaluate the output characteristics, the response was compared to that of an earlier transducer. When driven by the same voltage (6 V_p), the flat band displacement averaged 30 nm larger than that of the other transducer, and no anti-resonance was noted. Therefore, we expect that the new transducer can serve as an output device for hearing aids, and that it will improve speech recognition and treat high-frequency sensorineural hearing loss more effectively. Full article

Vibration control is important in maintaining the silence of the underwater vehicle. Among the many methods of vibration control, isolation is by far the most efficient approach. However, as one of the major vibration sources in underwater vehicle, the vibration isolation of the sea-water pump has not been well explored. The sea-water pipe is the primary vibration transmit path from the sea-water pump to the housing. In order to realize the vibration isolation of the sea-water pump, the sea-water pipe must have certain flexibility and damping. In this study, scaled model tests were carried out to investigate the isolation effectiveness of flexible pipes in isolated sea-water pump. Specifically, three types of flexible pipes, i.e., double layer metal bellows (DLMB), rubber pipes (RP) and bellows coated rubber (BCR) were designed and tested. Tests were carried out under the operation rotate speeds of the sea-water pump. Our results show that compared with single layer metal bellows (SLMB), the isolation effectiveness of DLMB and BCR were significant and stable in high frequency regions. The optimal pipe can be chosen for different vibration reduction requirements in practical engineering. Full article

A novel coated damping structure for metal rubber (MR) of bellows is designed based on large-size metal rubber sheets. This structure is dynamically tested in the bending direction at normal temperature. According to the test results, a model of the nonlinear elastic restoring force is set up, which describes the dynamic characteristics of the coated damping structure for metal rubber of bellows, and identifies the parameters of the model. The results show that the coated damping structure for metal rubber of bellows has a strong damping energy dissipation ability, its dynamic vibration characteristics are related to the vibration amplitude and frequency, and it is a complex nonlinear hysteretic system with multiple damping components. After identification of the parameters, the model of nonlinear elastic restoring force shows highly accurate results. Full article
