A novel dual-band multi-linear polarization reconfigurable (MLPR) antenna for body-centric wireless communication systems (BWCS) is presented in this paper. The design comprises five symmetrically arranged multi-branch radiating units, each integrating an elliptical patch and curved spring branch for the Medical Implant Communication Service (MICS) band (403–405 MHz), and a pair of orthogonal strip patches for the Industrial, Scientific and Medical (ISM) $2.45$ GHz band (2.40–2.48 GHz). By selectively biasing PIN diodes between each unit and a central pentagonal feed, five distinct LP states with polarization directions of $0^{\circ }$, ${72}^{\circ }$, ${144}^{\circ }$, ${216}^{\circ }$, and ${288}^{\circ }$ are achieved. A dual-line isolation structure is introduced to suppress mutual coupling between radiating units, ensuring cross-polarization levels (XPLs) better than $-15.0$ dB across the operation bands. Prototypes fabricated on a $160\times 160\times 1.5$ mm³ substrate demonstrate measured $|S_{11}|<-10$ dB across 401–409 MHz and 2.34–2.53 GHz and stable omnidirectional patterns despite biasing circuitry perturbations. The compact form and robust dual-band, multi-polarization performance make the proposed antenna a promising candidate for implantable device wake-up signals and on-body data links in dense indoor environments. Full article

Specialized antennas called wearable antennas for biotelemetry wireless communication are made to be built into or worn on the body to allow wireless communication between devices like heart monitors, medical implants, and other bio-telemetry equipment. These kinds of antennas are usually incredibly small and need to be able to function properly while near a human body. Wearable antennas for wireless biotelemetry communication can be constructed from a range of materials, such as textiles, polymers, and metals. The UHF, ISM, and Medical Implant Communication Service (MICS) bands are among the several wireless communication frequencies in which they are intended to function. These antennas are essential for the wireless transmission of medical data, including vital signs, that are gathered by biotelemetry devices. Full article

This paper proposes a wideband ultra-compact implantable antenna for a wireless body area network (WBAN). The proposed patch antenna works in the industrial, scientific, and medical (ISM) bands. The proposed patch antenna with an ultra-compact size (5 × 5 × 0.26 mm³) was designed with 29% wide bandwidth (about 670 MHz). This wide bandwidth makes the antenna unaffected by implantation in different human body parts. The miniaturization process passed many steps by adding many slots with different shapes in the radiating element as well as in the ground plane. A 50 Ω coaxial feeding excites the antenna to maintain matching and low power loss. The specific absorption rate (SAR) was calculated for health considerations. The result was within the standard limits of IEEE organizations and the International Commission on Non-Ionizing Radiation Protection (ICNRP). The antenna was tested in tissues with multiple layers (up to seven layers) and at various depths (up to 29 mm). The link margin was calculated, and the proposed antenna enables 100 Kbps of data to be transferred over a distance of 20 m and approximately 1 Mbps over a distance of 7 m. The proposed antenna was fabricated and tested. The measured S₁₁ parameters and the simulated results using the Computer Simulation Technology (CST Studio) simulator were in good agreement. Full article

An implantable stacked planar inverted-F antenna (PIFA) for biotelemetric communication in the 402–405 MHz Medical Implant Communications Service (MICS) frequency band is designed and fabricated. With the proposed PIFA structure, a slot on each radiating patch was embedded, resulting in a size reduction of 0.013 $\lambda$ and a compact size of 10 × 10 × 1.905 mm${}^3$. Both in vitro and in vivo experiments verified the simulation performance with characteristics of −10 dB bandwidth of 29 MHz, radiation efficiency of 0.9%, and a maximum far-field gain of −18.8 dB. We calculated the safety power delivered to the antenna using the specific absorption rate (SAR) limitation standard. Compared to other implantable antennas for biotelemetry, this antenna performs comparably and has a smaller size. This design would further develop implantable medical devices that communicate in the MICS band. Full article

A flexible antenna of compact size with a dual band elliptical-shape implantable is designed for biomedical purposes. The suggested antenna has an elliptical shape to be more comfortable for being implanted in human tissue. The implantable antenna is printed on RO3010 substrate with 2 mm as a thickness and 10.2 as a dielectric constant. It consists of an active planar C-shaped element and a parasitic planar inverted C-shaped element. The proposed antenna is designed with a major axis radius of 12 mm and a minor axis radius of 8 mm. It operates in dual bands: The Industrial Scientific and Medical band (ISM) [2.4 GHz–3.5 GHz] and Medical Implant Communications Service band (MICS) [394 MHz–407.61 MHz]. A short-circuited pin is used to minimize the antenna’s overall size and for further size reduction a capacitive load is used between the radiator and the ground plane. For biocompatibility, a thin-thickness layer of Alumina is used as a superstrate. The suggested antenna is tested in a multi-layer tissue model and the Specific Absorption Rate (SAR) value is computed. The proposed antenna was fabricated, and the reflection coefficient is measured and compared with simulated results. Full article

This paper presents a method for low data rate transmission for devices implanted in the body using backscattered Long Range (LoRa) signals. The method uses an antenna loaded with a switch that changes between two load impedances at the rate of a modulating oscillator. Consequently, the LoRa signal transmitted by a LoRa node is reflected in the adjacent channels and can be detected with a LoRa gateway tuned to the shifted channels. A prototype developed to operate at Medical Implant Communication Service (MICS) and the Industrial Scientific and Medical (ISM) 433 MHz band is presented. The prototype uses a commercial ceramic antenna with a matched network tuned to the frequency band with high radiation efficiency. The effect of the coating material covering the antenna was studied. Simulated and experimental results using a phantom show that it is feasible to read data from deep implanted devices placed a few meters from the body because of the high sensitivity of commercial LoRa receivers. Full article

We derived a closed-form expression of the maximum power transfer efficiency (MPTE) between a transmitting antenna inside the brain and a receiving antenna outside the head using spherical wave expansion. The derived expression was validated using a FEKO simulation. The properties of the insulator and radiation mode were analyzed in each available medical implant communications service (MICS) and industrial, scientific and medical (ISM) band as a means of increasing the reliability of wireless biotelemetry implementation. Some interesting preceding results in the literature were revisited with the figure-of-merit MPTE. It was also newly found that the effect on MPTE by the physical size and material properties of the insulator in both transverse magnetic (TM) and transverse electric (TE) mode decreases for 2.4 GHz and 5.8 GHz and the loss of the insulator does not have a severe impact on MPTE once the dielectric constant is greater than a certain value. This work can be used as an implanted-antenna design guide for building reliable biotelemetry communication. Full article

Recently, implantable devices have become widely used in neural prostheses because they eliminate endemic drawbacks of conventional percutaneous neural interface systems. However, there are still several issues to be considered: low-efficiency wireless power transmission; wireless data communication over restricted operating distance with high power consumption; and limited functionality, working either as a neural signal recorder or as a stimulator. To overcome these issues, we suggest a novel implantable wireless neural interface system for simultaneous neural signal recording and stimulation using a single cuff electrode. By using widely available commercial off-the-shelf (COTS) components, an easily reconfigurable implantable wireless neural interface system was implemented into one compact module. The implantable device includes a wireless power consortium (WPC)-compliant power transmission circuit, a medical implant communication service (MICS)-band-based radio link and a cuff-electrode path controller for simultaneous neural signal recording and stimulation. During in vivo experiments with rabbit models, the implantable device successfully recorded and stimulated the tibial and peroneal nerves while communicating with the external device. The proposed system can be modified for various implantable medical devices, especially such as closed-loop control based implantable neural prostheses requiring neural signal recording and stimulation at the same time. Full article

A low-power, low-phase-noise quadrature oscillator for Medical Implantable Communications Service (MICS) transceivers is presented. The proposed quadrature oscillator generates 349~689 MHz I/Q (In-phase and Quadrature) signals covering the MICS band. The oscillator is based on a differential pair with positive feedback. Each delay cell consists of a few transistors enabling lower voltage operation. Since the oscillator is very sensitive to disturbances in the supply voltage and ground, a self-bias circuit for isolating the voltage disturbance is proposed to achieve bias voltages which can track the disturbances from the supply and ground. The oscillation frequency, which is controlled by the bias voltages, is less sensitive to the supply and ground noise, and a low phase noise is achieved. The chip is fabricated in the UMC (United Microelectronics Corporation) 0.18 μm CMOS (Complementary Metal Oxide Semiconductor) process; the core just occupies a 28.5 × 22 μm² area. The measured phase noise is −108.45 dBc/Hz at a 1 MHz offset with a center frequency of 540 MHz. The gain of the oscillator is 0.309 MHz/mV with a control voltage from 0 V to 1.1 V. The circuit can work with a supply voltage as low as 1.2 V and the power consumption is only 0.46 mW at a 1.8 V supply voltage. Full article

An integration concept for an implantable biosensor for the continuous monitoring of blood sugar levels is presented. The system architecture is based on technical modules used in cardiovascular implants in order to minimize legal certification efforts for its perspective usage in medical applications. The sensor chip operates via the principle of affinity viscometry, which is realized by a fully embedded biomedical microelectromechanical systems (BioMEMS) prepared in 0.25-µm complementary metal–oxide–semiconductor (CMOS)/BiCMOS technology. Communication with a base station is established in the 402–405 MHz band used for medical implant communication services (MICS). The implant shall operate within the interstitial tissue, and the hermetical sealing of the electronic system against interaction with the body fluid is established using titanium housing. Only the sensor chip and the antenna are encapsulated in an epoxy header closely connected to the metallic housing. The study demonstrates that biosensor implants for the sensing of low-molecular-weight metabolites in the interstitial may successfully rely on components already established in cardiovascular implantology. Full article
